Balluff Micropulse BTL5 Series User manual

www.balluff.com
User's Guide
Sensors Worldwide
BTL5-xxx-Mxxx-ZM-xxx
BTL5-xxx-Mxxx-ZM-xxx
BTL5-xxx-Mxxx-ZM-xxx
Rapid Replacement Module
For Micropulse Linear Position Transducers
For Micropulse Linear Position Transducers
For Micropulse Linear Position Transducers
For Micropulse Linear Position Transducers
For Micropulse Linear Position Transducers
™
Untitled-1 6/17/2005, 2:30 PM1

2
Rapid Replacement Module
Micropulse Linear Position Transducers
Installation Guide for
Rapid Replacement Module
Rapid Replacement Module
Micropulse Linear Position Transducers
WWW.BALLUFF.COM
•
1-800-543-8390
Rapid Replacement Module
Micropulse Linear Position Transducers
Overview
The Rapid Replacement Module (RRM) allows the electronics module
and waveguide assembly to be quickly and easily replaced without
removing the pressure tube.
Ordering Information
The RRM can be ordered as a complete unit, or as a replacement
module only. The replacement module can only be used with Balluff
BTL5-series linear transducers.
The ordering codes are shown below:
Ordering Example 1
Complete transducer unit with RRM + pressure tube
BTL5-xxx-Mxxxx-ZM-xxx
Add "M" after "Z"
BTL5-xxx-Mxxxx-ZM-xxx/RU
Add "M" after "Z"
Add "/RU" at end of ordering code
Included with "RU" Replacement Unit:
- Electronics head/sensing element unit
- Replacement housing gasket
- (2) M4x60 housing retaining screws
Ordering Example 2
Rapid Replacement Module Only
Untitled-1 6/17/2005, 2:30 PM2

Rapid Replacement Module
Micropulse Linear Position Transducers
1-800-543-8390
WWW.BALLUFF.COM
•
1-800-543-8390
3
Rapid Replacement Module
Micropulse Linear Position Transducers
Installation Guide for
Rapid Replacement Module
Removal and Replacement Procedure
Step 1
: Using a 3 mm hex wrench, loosen
and remove the (2) M4x60
housing retaining screws.
Step 2
: Carefully slide the electronics
module/sensor element assembly
out until the sensor element is free
from the pressure tube. Remove
and discard the existing housing
gasket. Replace gasket with the
supplied new gasket.
Step 3
: Carefully slide the new electronics
module/sensor element into the
pressure tube. Align the raised keys
on the pressure tube with the slots in
the face of the electronics module.
Do not force! Components should
slide together easily.
Step 4
: Tighten housing retaining screws securely.
M4x60 housing
M4x60 housing
retaining screw
retaining screw
M4x60 housing
retaining screw (not
visible in photo)
Remove and replace
Remove and replace
Remove and replace
old gasket
Untitled-1 6/17/2005, 2:30 PM3
