Baumatic BEC455TS User manual

1
BEC455TS
Fully automatic built in
coffee machine

User Manual for your Baumatic
BEC455TS
Fully automatic built-in coffee machine
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 11/07/12
2

3
Contents
Environmental note 4
IMPORTANT SAFETY INFORMATION 5 – 6
Specifications 7 – 11
Product and aperture dimensions 7
Product specifications 8
Standardaccessories 8
Technical specifications 8
Description of the coffee machine 9
Controlpanel 10-11
Beforefirstuse 12 - 14
Cleaning 12
Filling the water tank 12 – 13
Fillingwithcoffeebeans 14
Using your coffee machine 14 – 19
Turning the coffee machine on 14 – 15
Coffeegrindregulation 15
Makingcoffee 16
Dispensing hot water 17
Dispensing steam 18 - 19
Settings 19 – 20
Programming the quantity of ground coffee 19
Programming the grinding time 19
Programming the coffee cup quantity 19 – 20
Restoring the factory settings 20
Using the coffee machine light 20
Warnings 20 – 22
Fill water tank warning 20 – 21
Replace the filter warning 21
Empty coffee grounds warning 21
Coffee probe malfunction warning 21
Malfunction warning 21 – 22
Recipes 22 - 23
Cleaning and maintenance 24 – 26
Stainless steel sections 24
Steamnozzle 24
Driptray 25
Watertank 25
Emptying the used coffee grounds 25 – 26
Self-cleaning cycle 26
Installation 27 – 31
Installationcomponents 27
Electricalconnection 28
Installing the coffee machine into a kitchen cabinet 29
Positioning 29
Installation of the coffee machine 30 - 31
Troubleshooting 32
Coffee glossary 33
Baumatic consumables 35
Contact details 36

Environmental note
4
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
all packaging material with due regard for the
environment.
oPlease discard

IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained i
5
n this
ooklet, please contact the Baumatic Advice Line.
eneral Information
using
t of Baumatic Ltd.
Guarantee. The foregoing does not
affect your statutory rights.
atic service
engineers or their authorised service agent.
arning and safety instructions
ot during use and retain heat after
wed to cool before
they are removed from the appliance.
b
G
oThis appliance is designed for domestic household use only. It
can ONLY be built into a standard kitchen cabinet or ho
unit and should NOT be used as a freestanding appliance.
oThe use of this appliance for any other purpose or in any other
environment without the express agreemen
will invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of
oRepairs may only be carried out by Baum
W
oThis appliance complies with all current European
safety legislation. Baumatic do wish to emphasise
that this compliance does not remove the fact
that the appliance surfaces will become
extremely h
operation.
oExtreme care MUST be taken when removing any of the
filters or nozzles. They should be allo

6
Child Safety
oBaumatic strongly recommend that babies and young
children are prevented from being near to the appliance
and not allowed to touch the appliance at any time.
se ensure that they are kept under close supervision
at all times.
eneral Safety
ot leave the coffee machine unattended when in
use.
to come into contact
with areas on the appliance that get hot.
oDo not install the appliance next to curtains or soft furnishings.
fee machine should be carried out
on a regular basis.
using this appliance and when
following the cleaning procedure.
nected from the
mains before following the cleaning procedure.
nstallation
son, strictly in accordance with the
manufacturer’s instructions.
a result of
t be used by a trained person for
rposes only.
oIf it is necessary for younger family members to be in the
kitchen, plea
G
oDo n
oDo not allow electrical fittings or cables
Cleaning
oCleaning of the cof
oGreat care should be taken whilst
oIMPORTANT: The appliance must be discon
I
This appliance must be installed by a suitably
qualified per
oBaumatic Ltd. declines any responsibility for injury or
damage, to any person or property, as
improper use or installation of this appliance.
oThe manufacturer declares that the coffee machine is built
using certified materials and requires the appliance to be
installed in accordance with the standards currently in
force. This appliance mus
domestic pu

7
pecificationsS
Product Dimensions
Apertur ons
Height: 453 mm
Width: 598 mm
Depth: 533 mm
e Dimensi
Depth: 560 mm
chocolate, tea and instant
ndicator
offee waste
oSelf-cleaning cycle
Height: 458 mm
Width: 560 mm
Product specifications
oTouch control operation
oMark resistant coating
oChoice of 1 or 2 cups
Steamospout for cappuccino, hot
coffee
oCoffee quantity regulation
oDrawer for coffee beans (capacity 400g)
oRegulation knob for grinding coffee beans
Empty water tank indicatoro
oEmpty coffee grounds container i
oPull-out drawer for c

8
tandard accessories
oTelescopic runners for appliance extraction
echnical specifications
ntact gap)
oMains supply lead 3 x 1.5mm²
by opening the pull out drawer at the bottom of the
ffee maker.
odel Number ……………………………….
erial Number ……………………………….
ate of Purchase ………………………………
S
T
oCoffee / steam pump pressure: 12 bar
oCoffee boiler output 500 W
oSteam boiler output 1200 W
oWater tank capacity: 2.5 litres
oMAX connected load: 2.00 kW
oPower supply 230 Vac 50 – 60 Hz
oSupply connection 13A (double pole switched
fused outlet with 3 mm co
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your coffee machine
can be located
co
M
S
D

9
escription of the coffee machineD
filter
eam dispensing nozzle
n knob
9) Door / tray for emptying the coffee grounds
1) Water tank
2) Decalcifying
3) Dispenser
4) Water / st
5) Drip tray
6) Coffee container
7) Grind regulatio
8) Control panel

10
ontrol panel
TART / STOP button
SPRESSO COFFEE button
EGULAR COFFEE button
ATER button
ill water tank indicator
mpty coffee grounds indicator
alfunction warning indicator
ELF-CLEANING cycle button
IGHT button
TWO ESPRESSO COFFEES button
C
ON/OFFbutton
S
E
R
W
F
E
M
S
L

11
TWO REGULAR COFFEES button
TEAM button
Replace filter indicator
offee probe malfunction indicator
OFFEE QUANTITY REGULATION button
ight coffee indicator
edium coffee indicator
trong coffee indicator
S
C
C
L
M
S

Before first use
1) Cleaning
oIt is strongly recommended to clean the appliance
prior to its first use. Particular attention should be
iance, please refer to
as per the installation instructions contained
utes. You should always
hown in the diagram
on the left.
nd pull
the machine towards you.
out of the furniture housing by
sliding it on its telescopic runners.
paid to the water tank.
oFor further information on cleaning the appl
the cleaning instructions on pages 24 - 26.
oInstall the appliance
within this booklet.
2) Filling the water tank
oBefore filling the water tank, ensure that the decalcifying filter is
soaked in cold water for at least 20 min
follow the manufacturer’s instructions.
oRemove the drip tray from the
machine as s
oPress the unlocking lever under the
drip tray, in the directions shown in
the diagram on the left, a
oCarefully pull the coffee machine
12

oRemove the water tank lid and
insert the decalcifying filter as
shown in the diagram on the left.
Press the filter into place until
you hear a click.
oThe water in the tank should be
changed regularly, especially if
the machine has not been used
in a long time.
oReplacement filters can be
purchased from many appliance
stores or supermarkets.
oRemove the water tank by pulling
it upwards out of the coffee
machine as shown in the diagram
on the left.
oFill the water tank with drinking
water. The tank can hold a
maximum of 2.5 litres of water.
oPlace the water tank back into
the coffee machine by sliding it
down carefully.
oYou should ensure that the two
connection points at the bottom
match up.
13

3) Filling with coffee beans
oIMPORTANT: Before pouring coffee beans into the
container, you should check that there are no foreign
bodies inside.
oOpen the coffee container lid
and pour approximately 200g of
coffee beans into the container
as shown in the diagram on the
left.
oCarefully push the machine
back into the furniture housing
until you hear a click. This
indicates that the machine is
locked into place.
Using your coffee machine
Turning the coffee machine on
oPull the machine out of the
furniture housing as described in
the previous section.
oTurn the main switch, located at
the back of the machine, to
position ‘1’ as shown in the
diagram on the left.
oPush the machine back into the
furniture housing. The appliance
will now be in stand-by mode.
14

oPress the ON / OFF button. The LED lights will flash
before turning on which indicates that the machine is
ready to use.
oIMPORTANT: If the coffee machine is not used
for 45 minutes, it will return to stand-by mode.
Coffee grind regulation
IMPORTANT: The fineness of the coffee grind is
initially set at the default factory setting. The
fineness can be adjusted to suit personal taste.
oA grind that is too coarse produces coffee that flows too quickly
without creaminess and body. On the other hand, a grind that is
too fine produces coffee that flows very slowly with an intense
taste and a burnt smell.
oThe average pouring time for a regular espresso coffee is
between 20 – 30 seconds.
oTo regulate the coffee grind you should pull the machine out of
the furniture housing as described in the “Before First Use”
section on page 12.
oLocate the grind
regulation knob on the
right hand side of the
machine and rotate the
knob accordingly.
oTurning the knob
clockwise produces a
finer grind and
stronger coffee.
Turning the knob
anticlockwise produces
a coarser grind and
lighter coffee.
oThe grinding fineness can be viewed on the lid of the coffee bean
container.
oPush the machine back into the furniture housing until it clicks
into place.
15

Making coffee
oThe dispensing time for an excellent espresso coffee is about 15
– 25 seconds. Factors that can influence the dispensing time are
the fineness of the coffee grind and the quantity of ground
coffee. You can adjust either of these settings by following the
relevant instructions in this manual.
oPlace one or two cups under the dispenser and adjust the height
of the dispenser nozzle. Turning the dial raises or lowers the
nozzle accordingly. oPress the relevant button
for the number of coffees
and type that you need.
oPress the START / STOP button within 10 seconds of
making your selection and the coffee making process
will begin.
oThe dispensing of the coffee will end automatically
when the quantity of coffee selected has been poured.
You can stop the dispensing of coffee at any time by
pressing the START / STOP button.
oIMPORTANT: If the START / STOP button is not pressed
within 10 seconds of making your coffee selection, the
machine will cancel the selection.
16

Dispensing hot water
IMPORTANT: Please note that the main boiler and
the steam boiler CANNOT be operated at the same
time.
oIMPORTANT: You should not dispense hot water
immediately after dispensing steam.
oBefore dispensing hot water, place the water / steam nozzle in a
suitable position and place a container beneath it.
oPress the WATER button.
oPress and hold the START / STOP button within 10
seconds of selecting the hot water function.
oThe water will be dispensed all the time the button is held down.
To stop the dispensing of hot water, release the button.
oIMPORTANT: If the START / STOP button is not pressed
within 10 seconds of making your selection, the machine
will cancel the selection.
17

Dispensing steam
IMPORTANT: Please note that the main boiler and
the steam boiler CANNOT be operated at the same
time.
oPress the STEAM button. The indicator light will flash
for about 15 seconds. When the indicator light stops
flashing and remains on this shows that the machine
is ready to produce steam.
oPlace the water / steam nozzle in a suitable position and place
the container of liquid to be heated below the nozzle.
oYou should ensure that the nozzle is fully immersed in the liquid.
oPress and hold the START / STOP button and the steam
will be dispensed. The steam will continue to flow until you
release the button.
oIf you are preparing milk for a cappuccino it is recommended
that you agitate the milk for best results.
oIMPORTANT: If the START / STOP button is not pressed
within 10 seconds of the steam being ready, the machine
will cancel the selection.
oWARNING: During this operation, extreme
caution should be exercised, as the dispensing
pipe will get hot.
oWhen releasing steam, avoid directing the
steam towards your person. There is a danger
of scalding.
oAlways use a container or a mug underneath
the dispensing pipe whilst dispensing steam.
18

Settings
Programming the quantity of ground coffee
oYou are able to choose from 3 strengths of coffee which
are light, medium and strong.
oTo change the strength of coffee, press the COFFEE
QUANTITY REGULATION button repeatedly. The LED for
the selected coffee strength will light.
oOne bean indicates a light strength,
two beans indicate a medium strength
and 3 beans indicate a strong coffee.
Programming the grinding time
oYou can program the grinding time for the strong coffee setting
and the medium and light coffee settings will adjust accordingly.
oTo enter the programming mode, press and hold the
START / STOP button for about 5 seconds when the
machine is in stand-by mode.
oThe LEDs on the upper left line light up to indicate the
grinding time. Press the COFFEE QUANTITY REGULATION
button to increase the time.
oPress the START / STOP button to decrease the time.
When you have set the correct grind time press the ON /
OFF button to confirm the changes and exit the
programming mode.
Programming the coffee cup quantity
oAll of the coffee making options have a preset quantity, except
for hot water and steam. The machine is initially set to the
default factory setting to dispense the ideal quantity of coffee for
an espresso or regular cup.
oWhen coffee is being dispensed you can stop
the flow before the preset time by pressing the
START / STOP button.
oYou can also lengthen the pouring time for a larger quantity of
coffee by holding down the START / STOP button within 3
seconds from the end of the preset time. The coffee will keep
pouring until the button is released for up to a maximum of 20
seconds.
19

Restoring the factory settings
oThe coffee machine is programmed at the factory for Italian-
style espresso coffee and German-style regular coffee.
oIf changes have been made to the settings and you wish
to revert to the default factory programming, you must
press and hold the COFFEE QUANTITY REGULATION
button for about 6 seconds when the machine is in stand-
by mode.
oAll of the LEDs, except the ON / OFF button will flash for 5
seconds and after this the factory settings will be restored.
oPress the ON / OFF button to begin making coffee using the
default programming.
Using the coffee machine light
oThe coffee machine has LEDs for illuminating the dispensing
compartment for easier usage and observation.
oTo turn the light on, press the LIGHT button once.
Press this button once again to turn the light back
off.
oThe light function is only available when the machine is turned
on and not when it is in stand-by mode.
Warnings
oThe coffee machine may display a warning which prompts you to
carry out an action or alerts you to a problem with the machine.
Fill water tank warning
oThe machine is equipped with a sensor which detects water in
the water tank.
oIf there is no water in the tank, the fill water tank
indicator will light. The coffee machine will not function
until the water tank is filled.
oBefore attempting to use the coffee machine, you
should fill the water tank by following the instructions
outlined on pages 12 – 13.
20
