P610
60 cm Fan oven
4 Functions
Energy efficiency class: A
Oven capacity: 57 litres
LED full programmer
Double-glazed removable door
Removable inner door glass
P620
60 cm Multifunction oven
7 Functions
Energy efficiency class: A
Oven capacity: 57 litres
LED full programmer
Double-glazed removable door
Removable inner door glass
P630
60 cm Multifunction oven
9 Functions
Energy efficiency class: A
Oven capacity: 57 litres
LED full programmer with temperature display
Push-in/push-out knob control
Electronically controlled thermostat
Wipeclean enamel cavity
Triple-glazed removable door
Removable inner door glass
Mark resistant coating
Telescopic runners
P640
60 cm Single knob multifunction oven
9 Functions
Energy efficiency class: A
Oven capacity: 57 litres
LED full programmer with function
and temperature display
Push-in/push-out knob control
Electronically controlled thermostat
Triple-glazed removable door
Removable inner door glass
Mark resistant coating
P650
60 cm Multifunction self-cleaning
pyrolytic oven
9 Functions
Energy efficiency class: A
Oven capacity: 57 litres
LED full programmer
Electronically controlled thermostat
Triple-glazed removable door
Automatic safety door-lock when
in pyrolytic mode
Mark resistant coating

GEOMETRY AT WORK
P960
60 cm Built-in electric double oven
Energy efficiency class: A
LED full programmer
Top oven: Static oven and grill
4 Functions
Capacity: 36 litres
Main oven: Multifunction oven
9 Functions
Capacity: 60 litres
P760
60 cm Built-under electric double oven
Energy efficiency class: A
LED full programmer
Top oven: Static oven and grill
4 Functions
Capacity: 36 litres
Main Oven: Multifunction oven
9 Functions
Capacity: 53 litres
PD3
14 cm high Warming drawer
3 Functions
Adjustable temperature (up to 85° C)
Integrated hot air fan
Accommodates dinnerware for 6 people
Maximum load: 25 kg
Dimensions in mm (h x w x d):
143 x 595 x 530
P460
46 cm high Multifunction touch
control oven
10 Functions
Energy efficiency class: A
Oven capacity: 45 litres
Touch control operation with customisable recipes
Triple-glazed removable door
Mark resistant coating
Telescopic runners
PD4
29 cm high Warming drawer
6 Functions + MAX
Adjustable temperature (up to70° C)
Integrated hot air fan
Accommodates dinnerware for 12 people
Maximum load: 25 kg
Dimensions in mm (h x w x d):
290 x 595 x 525
P660
60 cm Multifunction touch
control oven
10 Functions
Energy efficiency class: A
Oven capacity: 57 litres
Touch control operation with customisable recipes
Triple-glazed removable door
Removable inner door glass
Mark resistant coating
Telescopic runners

GEOMETRY AT WORK
PF75
75 cm Flush mounted front control
5 burner gas hob
Flame failure safety device on each burner
Front control operation
Heavy duty cast iron pan stands
Underknob auto-ignition
Flush mounted installation
Hypergas extra powerful wok burner (4.50 kW)
Not suitable for installation above built under ovens
P61 / P62
60 cm Front control
4 burner gas hob
Flame failure safety device
on each burner (P62)
Front control operation
Heavy duty cast iron pan stands
Underknob auto-ignition
P67 / P68
70 cm Front control
5 burner gas hob
Flame failure safety device
on each burner (P68)
Front control operation
Heavy duty cast iron pan stands
Underknob auto-ignition
Fits into a standard 60 cm cut out
P75
75 cm Front control
5 burner gas hob
Flame failure safety device on each burner
Front control operation
Heavy duty cast iron pan stands
Underknob auto-ignition
Fits into a standard 60 cm cut out
Hypergas extra powerful wok burner (4.50 kW)
P76
75 cm Front control
5 burner gas hob
Flame failure safety device on each burner
Front control operation
Heavy duty cast iron pan stands
Underknob auto-ignition
Fits into a standard 60 cm cut out
Hypergas extra powerful wok burner (4.50 kW)

GEOMETRY AT WORK
P90
90 cm Front control
5 burner gas hob
Flame failure safety device on each burner
Front control operation
Heavy duty cast iron pan stands
Underknob auto-ignition
Hypergas extra powerful wok burner (4.50 kW)
PG2
Domino 30 cm
2 burner gas hob
Flame failure safety device
on each burner
Front control operation
Cast iron pan stand
Underknob auto-ignition
PWK1
Domino 30 cm
1 wok burner gas hob
Flame failure safety device
Front control operation
Cast iron pan stand
Underknob auto-ignition
Hypergas extra powerful
wok burner (4.50 kW)
PVC2
Domino 30 cm
2 hyperspeed zone
ceramic hob
Front control operation
1 individual residual heat indicator
PBQ
Domino 30 cm
barbeque hob
Maximum output 2.40 kW
Front control operation
Removable enamelled griddle
Lava stones
PF1
Domino 30 cm
deep fat fryer hob
Maximum output 2.30 kW
Capacity: 3 litres
Front control operation
Removable stainless steel
basket and bowl

GEOMETRY AT WORK
P14
60 cm Chimney hood
High extraction tangential motor
Touch control operation
2 Stainless steel grease filters
2 Fluorescent lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
P15
90 cm Chimney hood
High extraction tangential motor
Touch control operation
3 Stainless steel grease filters
2 Fluorescent lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
P10
90 cm Chimney hood
High extraction tangential motor
Touch control operation
3 Stainless steel grease filters
2 Halogen lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
P25
90 cm Chimney hood
Tangential motor with perimetric extraction
Touch control operation
Mark resistant coating FASTEEL
2 Metallic grease filters
2 Halogen lights
4 Speeds
STRATOX structure of front panel
Extraction capacity: 800 m3/hr
Extraction or recirculation
P20 / PI3
90 cm Chimney hood (P20)
90 cm Island cooker hood (PI3)
High extraction tangential motor
Touch control operation
3 Stainless steel grease filters
2 Fluorescent lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation

GEOMETRY AT WORK
P30
90 cm Chimney hood
High extraction tangential motor
Touch control operation
Mark resistant coating FASTEEL
2 Stainless steel grease filters
2 Halogen lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
P31
90 cm Glass chimney hood
High extraction tangential motor
Touch control operation
Mark resistant coating FASTEEL
2 Stainless steel grease filters
2 Halogen lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
P35
90 cm Chimney hood
Tangential motor with perimetric extraction
Touch control operation
Mark resistant coating FASTEEL
2 Metallic grease filters
3 Halogen lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
PI1
40 cm Island cooker hood
High extraction tangential motor
Touch control operation
Stainless steel grease filter
4 Halogen lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation
PI2 / PI2GL
35 cm Island cooker hood (PI2)
90 cm Glass island cooker hood (PI2GL)
High extraction tangential motor
Touch control operation
Metallic grease filter
3 Halogen lights
4 Speeds
Extraction capacity: 800 m3/hr
Extraction or recirculation

GEOMETRY AT WORK
Studioverde
Baumatic Č R, spol. s r. o.
T: [phone]
E: [email protected]
www.baumatic.cz
Baumatic Slovakia, s.r.o.
T: [phone]
E: [email protected]
www.baumatic.sk
Baumatic Ltd
(United Kingdom)
T: [phone]
E: [email protected]
www.baumatic.co.uk
Baumatic GmbH
(Germany)
T: [phone]
E: [email protected]
www.baumatic.de
Baumatic Asia Ltd.
(Hong Kong)
T: [phone]
E: [email protected]
www.baumatic.com
Baumatic Benelux B.V.
(The Netherlands)
T: [phone]
E: [email protected]
www.baumatic.nl
Baumatic Italia SRL
T: [phone]
E: [email protected]
www.baumatic.it
Baumatic (China) Co., Ltd.
T: [phone]
E: [email protected]
www.baumatic.com
Baumatic International s.r.o.
(other countries worldwide)
T: [phone]
E: [email protected]
www.baumatic.com
All appliances carry the full 12 months parts & labour guarantee
and 5 years parts guarantee (valid for United Kingdom and
Northern Ireland only). If you register your Baumatic appliance
within 28 days of purchase, you will receive the second year’s
labour warranty absolutely FREE - register either on-line at
www.baumatic.co.uk or complete the form inside your appliance.
PT2800
90 cm Cooking theatre
5 burner gas hob
Heavy duty cast iron pan stands
Underknob auto-ignition
Oven capacity: 105 litres
Energy effciency class: C
LED full programmer
PT2810
90 cm Twin cavity cooking theatre
5 burner gas hob
Heavy duty cast iron pan stands
Underknob auto-ignition
Energy effciency class: C
LED full programmer
Main oven: Multifunction - 8 Functions
Capacity: 52 litres
Second oven: Static with grill - 5 functions
Capacity: 31 litres
Storage compartment capacity: 40 litres
PT2815
90 cm Twin cavity cooking theatre
5 hyperspeed zone ceramic hob
5 residual heat indicators
Energy effciency class: C
LED full programmer
Main oven: Multifunction - 8 Functions
Capacity: 52 litres
Second oven: Static with grill - 5 functions
Capacity: 31 litres
Storage compartment capacity: 40 litres
PT2820
100 cm Twin cavity cooking theatre
5 gas burner hob
Heavy duty cast iron pan stands
Underknob auto-ignition
Energy effciency class: B
LED full programmer
Main oven: Multifunction - 8 Functions
Capacity: 52 litres
Second oven: Static with grill - 5 functions
Capacity: 31 litres
Storage compartment capacity: 40 litres
