BC Biomedical SPO-2000 User manual

PULSE
OXIMETRY
SIMULATOR
SPO-2000 SYSTEM
USER MANUAL

i
WARNINGS, CAUTIONS, NOTICES...............................................................................ii
DESCRIPTION............................................................................................................. 1
LAYOUT....................................................................................................................... 2
KEYS............................................................................................................................ 3
LED INDICATORS....................................................................................................... 4
OPERATIONS.............................................................................................................. 5
MANUAL REVISIONS.................................................................................................. 6
LIMITED WARRANTY ................................................................................................. 6
SPECIFICATIONS ....................................................................................................... 7
NOTES......................................................................................................................... 8
BC BIOMEDICAL
SPO-2000 SYSTEM
TABLE OF CONTENTS

ii
CAUTION - SERVICE
The SPO-2000 System is intended to be serviced
only by authorized service personnel.
Troubleshooting and service procedures should
only be performed by qualified technical
personnel.
CAUTION - CLEANING
Do not immerse. The SPO-2000 System should
be cleaned by wiping gently with a damp, lint-free
cloth. A mild detergent can be used if desired.
WARNING - USERS
The SPO-2000 System is for use by
skilled technical personnel only.
WARNING - USE
The SPO-2000 System is intended for testing only
and should never be used in diagnostics,
treatment or any other capacity where it would
come in contact with a patient.
WARNING –LIQUIDS
Do not submerge or spill liquids on the SPO-2000
System. Do not operate the SPO-2000 System if
internal components not intended for use with
fluids may have been exposed to fluid, as the
internal leakage may have caused corrosion and
be a potential hazard.
WARNING - MODIFICATIONS
The SPO-2000 System is intended for use within
the published specifications. Any application
beyond these specifications or any unauthorized
user modifications may result in hazards or
improper operation.

iii
NOTICE –SYMBOLS
Symbol
Description
Center Negative
NOTICE –ABBREVIATIONS
BPM
Beats Per Minute
C
Celsius
°
Degree(s)
DUT
Device Under Test
F
Fahrenheit
kg
kilogram(s)
LED
Light Emitting Diode
mA
milliampere(s)
mm
millimeter(s)
Lbs
pounds
USA
United States of America
VDC
Volts Direct Current
CAUTION - ENVIRONMENT
Exposure to environmental conditions outside
the specifications can adversely affect the
performance of the SPO-2000 System. If the
SPO-2000 System is outside of Operating
specifications, allow it to acclimate to specified
conditions for at least 30 minutes before
attempting to operate it.
CAUTION - INSPECTION
The SPO-2000 System should be inspected
before each use for wear and should be serviced
if any parts are in question.

iv
SPO-2000 System User Manual Copyright © 2012
www.bcgroupintl.com Made in the USA
04/12 Rev 04
NOTICE –DISCLAIMER
BC GROUP INTERNATIONAL, INC. RESERVES THE RIGHT TO
MAKE CHANGES TO ITS PRODUCTS OR SPECIFICATIONS AT
ANY TIME, WITHOUT NOTICE, IN ORDER TO IMPROVE THE
DESIGN OR PERFORMANCE AND TO SUPPLY THE BEST
POSSIBLE PRODUCT. THE INFORMATIONINTHIS MANUAL HAS
BEEN CAREFULLY CHECKED AND IS BELIEVED TO BE
ACCURATE. HOWEVER, NO RESPONSIBILITY
IS ASSUMED FOR INACCURACIES.
NOTICE –CONTACT INFORMATION
BC BIOMEDICAL
BC GROUP INTERNATIONAL, INC.
3081 ELM POINT INDUSTRIAL DRIVE
ST. CHARLES, MO 63301
USA
1-800-242-8428
1-314-638-3800
www.bcgroupintl.com
[e-mail]
NOTICE –DISCLAIMER
BC GROUP INTERNATIONAL, INC. WILL NOT BE RESPONSIBLE
FOR ANY INJURIES SUSTAINED DUE TO UNAUTHORIZED
EQUIPMENT MODIFICATIONSORAPPLICATION OFEQUIPMENT
OUTSIDE OF THE PUBLISHED INTENDED USE AND
SPECIFICATIONS.

1
The SPO-2000 System is used to verify the operation of Pulse Oximeters. The SPO-2000
System is comprised of the SPO-2000 Base Unit and a FingerSim™simulated finger,
available in three different SpO2 saturation levels. The FingerSim™is inserted into the
SPO-2000 Base Unit, which then adds calibrated pulse rates to the functionality of the
FingerSim™.
The following are highlights of some of the main features.
SPO-2000 SYSTEM (BASIC FEATURES):
SIX CALIBRATED SIMULATOR PULSE RATES: 30, 60, 90, 120, 150, and 180
BPM
LED INDICATION OF SELECTED PULSE RATE
STANDBY MODE
AVAILABLE MODELS:
The SPO-2000 Base Unit plus one or more FingerSims™arerequiredinordertoverifythe
operation of Pulse Oximeters.
SPO-2000 SIMULATOR BASE UNIT
FingerSim™ KIT COMPLETESTARTERKIT(INCLUDES80%,90%AND
97% FingerSims™, FingerSim™ HOLDER, AND
CARRYING CASE)
FingerSim™ SET REPLACEMENT KIT (80%, 90% AND 97%
FingerSims™ ONLY)
STANDARD ACCESSORIES:
BC20-00431 110V AC POWER ADAPTER (US)
(OR)
BC20-40614 220V AC POWER ADAPTER (EURO)
OPTIONAL ACCESSORIES:
BC20-40110 CARRYING CASE FOR SPO-2000 BASE UNIT,
FingerSims™& ACCESSORIES
BC BIOMEDICAL
SPO-2000 SYSTEM
PULSE OXIMETRY SIMULATOR SYSTEM

2
This section looks at the layout of the SPO-2000 Base Unit and gives descriptions of the
elements that are present.
LAYOUT
2 Light Touch Keys
•ACTIVE/STANDBY for
enabling/disabling Pulse Simulation
•SCROLL for selecting the
Pulse Simulation rate.
FingerSim™Receptacle
(NOTE –FingerSim™is
shown installed for reference).
Connector for Power
Adapter
ON/OFF Switch
6 LED indicators for
Indicating Pulse
Simulation rate (BPM)
• 180 BPM
• 150 BPM
• 120 BPM
• 90 BPM
• 60 BPM
• 30 BPM
2 LEDs for Indicating Status
• ACTIVE for showing when Pulse
Simulation is active.
• POWER for showing when the
SPO-2000 Base Unit is On.

3
2 soft touch keys are provided for Base Unit operation:
–This key is used to turn the SPO-2000 Base Unit Pulse Simulation ON and OFF.
–This key is used to select the desired Pulse Simulation rate.
KEYS

4
There are eight LEDs to indicate the status of the Base Unit. They are marked POWER,
ACTIVE, 30, 60, 90, 120, 150, AND 180.
POWER –This LED indicates that the Base Unit power switch is turned ON and the
onboard power supply is functioning properly.
ACTIVE–This LED indicates that the Base Unit is in the ACTIVE mode, meaning Pulse
Simulation is activated. STANDBY mode is indicated by an active POWER LED and
inactive ACTIVE LED.
30 –This LED indicates that the currently selected Pulse Simulation rate is 30 BPM.
NOTE: This is the default Pulse Simulation rate when the Base Unit is first powered.
60 –This LED indicates that the currently selected Pulse Simulation rate is 60 BPM.
90 –This LED indicates that the currently selected Pulse Simulation rate is 90 BPM.
120 –This LED indicates that the currently selected Pulse Simulation rate is 120 BPM.
150 –This LED indicates that the currently selected Pulse Simulation rate is 150 BPM.
180 –This LED indicates that the currently selected Pulse Simulation rate is 180 BPM.
LED INDICATORS

5
The SPO-2000 Base Unit will start up in the STANDBY mode with a selected Pulse
Simulation rate of 30 BPM by default.
Insert the desired FingerSim™into the rectangular SPO-2000 FingerSim™receptacle.
NOTE: It is recommended that the FingerSim™be inserted with the printed side down to
minimize wear on the printing by the mechanism inside the SPO-2000 Base Unit.
Use the key to select the desired Pulse Simulation rate. Pulse Simulation is
enabled by depressing the key. The ACTIVE LED will turn on and the FingerSim™
will pulse at the desired rate.
The Pulse Simulation rate can be changed by depressing the key, in either the
ACTIVE or STANDBY mode.
Connect the finger probe of the DUT being tested to the FingerSim™. For tidiness, route
the probe’s cable underneath the SPO-2000 Base Unit.
Pulse Simulation is disabled by depressing the key, which sets the Base Unit to
STANDBY mode.
NOTE: The accuracy of the simulated SpO2saturation is a function of the FingerSim™,
not the SPO-2000 Base Unit. The SPO-2000 Base Unit only affects the Pulse Simulation
rate. See the FingerSim™ Specifications for accuracy and related data.
OPERATIONS

6
Revision # Revisions Made
Rev 01 Origination
Rev 02 Format Updated
Rev 03 Misc. Edits
Rev 04 Misc. Edits, Format Updated, Specifications Updated
P:\MANUALS\BCGroup\…\SPO-2000\SPO-2000_UM_Rev04.doc
MANUAL REVISIONS
LIMITED WARRANTY
WARRANTY: BC GROUP INTERNATIONAL, INC. WARRANTS ITS NEW PRODUCTS TO BE FREE
FROM DEFECTS IN MATERIALS AND WORKMANSHIP UNDER THE SERVICE FOR WHICH THEY
ARE INTENDED. THIS WARRANTY IS EFFECTIVE FOR TWELVE MONTHS FROM THE DATE OF
SHIPMENT.
EXCLUSIONS: THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
BC GROUP INTERNATIONAL, INC. IS NOT LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
NO PERSON OTHER THAN AN OFFICER IS AUTHORIZED TO GIVE ANY OTHER WARRANTY OR
ASSUME ANY LIABILITY.
REMEDIES: THE PURCHASER'S SOLE AND EXCLUSIVE REMEDY SHALL BE: (1) THE REPAIR OR
REPLACEMENT OF DEFECTIVE PARTS OR PRODUCTS, WITHOUT CHARGE. (2)AT THEOPTION
OF BC GROUP INTERNATIONAL, INC., THE REFUND OF THE PURCHASE PRICE.

7
SPO-2000 BASE UNIT
PULSE SIMULATION
RATE
30, 60, 90, 120, 150, 180 BPM
ACCURACY
± 1%
PHYSICAL, ENVIRONMENTAL, AND ELECTRICAL
SIZE
5.20 x 5.20 x 2.50 Inches
(132.1 x 132.1 x 63.5 mm)
WEIGHT
≤1 Lbs (0.45 kg)
CONSTRUCTION
ENCLOSURE
ABS Plastic
FACE PLATE
Lexan, Back printed
OPERATING RANGE
15° to 40° C (59° to 104° F)
STORAGE RANGE
-20° to 65° C (-4° to 149° F)
POWER
12 VDC, 500 mA
SPECIFICATIONS
