BCN3D ignis User manual

ignis
Instruction Manual

Contents
Compliance Information
General
Product Components
Technical Specifications
General description
General dimensions
BCN3D IGNIS main systems
Technical characteristics sheet
Processable materials
Security
Team of allowed users
Safety components
Warnings
Safety pictograms
Transport - Storage - Installation
Transport
Storage conditions
Installation conditions
Assembly and installation
PC configuration
RDWorks installation
Using RDWorks
Interface
Configuring the laser’s parameters
Sending tasks to BCN3D-IGNIS
Function of the control panel
Control panel
Introduction to the general interface
Z/U Menu
File Key
Operation
Control panel
Initial adjustments
Stops and emergency stops
Maintenance
Maintenance plan
Maintenance operations
Frequent problems
4
5
6
7
7
7
8
10
12
13
13
13
14
18
19
19
19
19
20
21
21
24
24
25
27
28
28
29
31
34
36
36
37
39
42
42
43
52

4 Instruction Manual
Conformity Information
The compliance label including regulations can be found
on the back of the machine.

Instruction Manual 5
General
This instruction manual aims to:
• Inform users of the machine, its operating modes and operating limitations;
• Present the product’s technical specifications;
• Warn on the safety requirements of the machine and its components;
• Establish modes for installation and start-up;
• Indicate the necessary maintenance procedures.
Following the instructions for use contained in this manual:
• Will avoid situations involving hazards and risks;
• Will minimize repairs costs and downtimes of the machine;
• Will increase the machine’s reliability and useful life.

6 Instruction Manual
Product Components
BCN3D Ignis “Honeycomb” metal mesh
PC-USB cable
Machine connection key
Instruction manual
Network cable Power supply cable
Electronic panel access key
2 lens-cleaning cloths
Pen drive - Software

1575,50
1247,25
1882
997
Instruction Manual 7
General description
General dimensions
Technical Specifications
BCN3D IGNIS has been designed for cutting, marking and engraving specific materials listed in this document (Pro-
cessable materials, page14).
For more information: https://www.bcn3dtechnologies.com/es/ignis-downloads/
DESCRIPTION
Maximum width
Maximum depth
Height, cover closed
Height, cover open
Minimum weight, with packaging
DIMENSION
1576
997
1248
1882
300
UNIT
mm
mm
mm
mm
Kg

8 Instruction Manual
The optic system is created with the tube, its mirrors, the
lens and the beam combiner. The function
of this system is to direct the radiation originating in
the laser tube up to the head by means of the mirrors and
to concentrate the energy at the cutting point by means of
the 2 inclus lens. The beam combiner allows having a
visual reference of the exact position of the beam during
the path.
The laser beam moves in the work plane from the action
of the motors for the X, Y guides.
Primary Systems for the BCN3D IGNIS
To better understand this instructions manual, the following describes the three fundamental systems of the
BCN3D IGNIS:
1Tube laser
2Mirror grouping
3Head
4 Y axis motor
5Y axis guides
6X axis motor
7X axis guides
8Beam Combiner
4
1
5
3
2
7
Optic system and X-Y axis
8

Instruction Manual 9
Work platform and the Z axis
Ventilation and refrigeration
integrated system
The parts for cutting or scanning are placed on the
Honeycomb, which are extractable to clean the cube.
The Z axis moves vertically, is motorized and works to
position the part to the correct height for the task.
This positioning is completed automatically with
the “Autofocus” function. The length of the z axis is
290mm.
BCN3D Ignis comes with an integrated ventilation
system with a turbine. This system is located in the
interior of the machine and is controlled by the system
itself. BCN3D Ignis has air vents on the upper case, thus
creating a continuous flow for extracting air.
The ventilation system guarantees an efficient
extraction of dust and gases that are formed while
operating a cut, mark and scanning.
The water refrigeration system allows the laser tube
to work in ideal conditions, lengthening the maximum
lifespan.
Primary Systems for the BCN3D IGNIS

10 Instruction Manual
Technical characteristics sheet
Physical properties
Exterior dimensions
Packaging dimensions
Weight
Noise (weighted in A)
Maximum operating temp.
Machine properties
Maximum cutting area
Maximum piece size
Repeatability
Resolution
Minimum text font
Laser type
Power
Display
Operations
Fume extraction
Cooling
Lens
Mirrors
Table type
Safety
Certification
Red pointer
1576x997x1248mm
160x1160x11411 (+-10)mm
300kg
70-71dB (A)
70ºC
995x575mm
1000x600x290mm
+-0.01mm
0.0231mm (1100DPI)
1,7mm alphanumeric characters
CO2
100w
320x480 TFT 3.5” color, con visualizador de operaciones
Engraving
Marking
Cutting
P550W 220V (860m3/h)
Water Chiller CW3000
2” (ZnSe) 2’5”; 3”; 3’5”; 4” (opcional)
3xØ20mm
Honeycomb
Category I (with ongoing supervision)
CE
The red pointer allows us to have a visual
reference of the point where the laser will cut

Instruction Manual 11
Technical characteristics sheet
Electronics
Controller
Drivers
Motorisation
Connection
Software
Operating Systems
Software
File input formats
Compatible drawing software
Propiedades eléctricas
Power supply
Output
Power consumption
Ruida RD6442G
3xleadshine M880A
3xNema 23
Ethernet (LAN) (máx. 200m)
USB (máx 5m)
Autónomo (Pen drive USB)
Windows 7, Windows 10
RDWORKS V8.01.18
*.ai; *.dxf; *.plt; *.dst; *.dsb; *.eps; *.nc; *.bmp;
*.gif; *.jpg; *.tiff; *.png; *.ico; *.raw
Inkscape, Illustrator, Coreldraw, Photoshop,
Autocad, Gimp, Solidworks, Rhino, etc
AC 230V, AC 3,6-1,3A, 50-60Hz
24V DC, 13A
1000W

12 Instruction Manual
Processable materials
MATERIAL
Wood
Acrylic
Glass
Coated metals
Ceramic
Delrin
Leather
Melamine
Methacrylate
Paper
Agglomerate
Rubber
Cardboard
Plywood
Painted metals
Tile
Cork
Anodised aluminium
PVC (or Vinyl chloride derivatives)
Vinyl
MARKING
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
NO
ENGRAVING
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
NO
CUTTING
YES
YES
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
NO
YES
NO
NO
NO
More information:
https://www.bcn3dtechnologies.com/es/ignis-downloads/
Manual d’Instruccions 12

Instruction Manual 13
1
2
3
4
Security components
Security
Before starting up the machine, you must read the present instructions manual and, in
particular, the portion on “WARNINGS”.
In addition to reading the present manual, you must obtain the basic information for the laser
security before handling the machinery.
Any use that has not considered the present manual will be inappropriate and may cause
dangerous situations and run the risk of bodily harm and/or material damages.
The machine should only be used by authorized per-
sonnel who have specific training, who can work in the
industrial or non-industrial environment, by persons of
an age equal to or greater than 18 years old and with
minimum height of 2 meters with raised hands.
Any presence of external people or those without
training should be considered if close to the danger area
around the machine. It is recommended that the opera-
tion area of the machine be perfectly marked out, thus
allowing access only to authorized personnel.
BCN3D IGNIS is equipped with a security anchoring
system, whose function is to prevent any radiation from
accessing the danger area during the entire process
when the laser is active and guarantee that the machine
does not cause any risk during the tasks of supplying
and handling pieces. Other security components are:
Equipment for approved users
1Interrupter key
2Control panel
3Security covering
4Air entrance for
ventilation
Tasks of assembly, calibrating, maintenance (electric
and mechanical) and disassembly, among the other
services related with any adjustment or calibration, will
be completed solely by official personnel from BCN3D
or by the authorized Technical Assistance Service from
BCN3D and autorized distributors
ACTIVITIES
Operation and control
Maintenance, calibration,
assembly disassembly
and adjustments
GROUP OF USERS
Personnel with
specific training
Official personnel from
BCN3D or SAT

14 Instruction Manual
Correct use of the machine
Calibration, repairs and adjustments
Laser radiation
Unsupervised operations
Unqualified personnel
Warnings
• Any use not contemplate in this manual will be
considered as misuse.
• Misuse of the machine can lead to risks of body
injuries and/or material damage.
• Special attention should be paid to the type of ma-
terial and positioning of the piece to be processed.
Do not exceed the maximum dimensions for the
piece and place the piece on the work surface as
flat as possible
• The use and calibration of the machine must be
performed by official BCN3D personnel.
• Allowing unauthorised personnel to perform these
tasks may lead to grave injuries and/or damage to
the machine.
• A lack of protection measures can lead to: burnt
cornea, skin burns and risk of igniting clothing.
• You are using a 100W power laser. A wrong job
configuration (excess power, slow speed..., etc.)
can cause a fire hazard.
• Special attention must be paid to low speeds and
other powers while using combustible materials
such as paper, cardboard, wood, etc.
• Unsupervised operations can cause a fire which
could lead to very serious personal injuries and/or
damage to the machine.
• It is advisable to have a fire extinguishing system
installed close to the machine.
• The use of the machine by people with insufficient
knowledge may cause danger and/or damager to
the machine.
• Personnel must be informed of the machine’s
functions and any potential risks.
Before starting up the machine, operators must
read and apply the instructions contained in the
user manual.
Misuse of the machine is prohibited.
The repair, calibration, revision and start-up
tasks must be performed by official BCN3D
personnel and autorized BCN3D distributors.
Never operate the machine without supervision.
Never cancel out the safety systems.
Never manipulate the laser unit.
Ensure that the optical mirror system is not
blocked, broken or in poor condition (see
Maintenance section, page 37).
Ensure that the protection cover is not broken,
cracked or in poor condition.
Follow the maintenance plan described in this
manual.
All personnel operating the machine must
receive specific training.
The company must provide said training to the
team of people responsible for performing the
operations to be carried out using the machine.

Instruction Manual 15
Unauthorised handling
Faulty, damaged or poorly adjusted
machine
Reckless actions
Poor maintenance
Integrity of the machine
Warnings
• There must be authorised personnel responsible
for controlling the correct operation and handling
of the equipment by the rest of the operators.
• The person in charge of supervising must ensure
that all personnel coming into contact with the
machine has received correct training.
• The person in charge of supervising must ensure
that the machine is always watched over during
the materials process.
• The personnel in charge of supervising must safe-
guard to main switch key.
• Deviations in the machine’s normal process and
unforeseen ongoing operating results may indicate
hazardous conditions (clogged products, poorly
secured guides, etc.).
• Check that there are no mirrors in poor condition
prior to turning the machine on.
• The whistling heard after the machine is in
operation indicates that the cooling system has
been activated. This whistling should stop after a
few seconds.
• Check the machine’s movements when there are
any unusual movements of the guides, stop the
process using the emergency push button.
• Check that the transparent cover on the machine is
not damaged.
• If any of the previous cases take place, stop
the machine immediately and contact the
manufacturer.
• Reckless actions can cause personal injuries and/or
damage to the machine.
• Shadows, reflections and poor cleaning increase
the risk of accidents.
• An accumulation of previous process residue can
cause risks.
• The work area must always be kept clean and dry.
• If the machine is stopped, the front cover must be
kept shut.
• Performing operations while missing any part of
the machine can cause damage to the machine,
grave personal injuries or even death.
• Check that the machine is fully assembled and
all components, mirrors, parts of the structure,
cutting base...etc.
Disconnect the key switch when the machine
is not being used.
Never cover the mirrors.
Do not leave any foreign object on the ma-
chine (tools, etc.). Objects which interrupt or
modify the beam direction can cause grave
damage.
Operators must ensure that all devices are
operating correctly prior to using the machine
(Maintenance, page 37).
In the event of identifying a missing compo-
nent, do not turn the machine on and contact
the manufacturer immediately.

16 Instruction Manual
The machine must be maintained
correctly and kept clean following the
instruction contained in this manual.
Missing or worn signs
Processing toxic materials
Trapping
Handling loads
Warnings
• All warning signs and luminous indicators are es-
sential for guaranteeing the safety of the users.
• Performing operations without the existing signs
can cause personal injuries and/or damage to the
machine.
• We recommend the use of gloves and safety boots
when handling heavy pieces.
• Processing materials which are not permitted
could cause risks due to inhaling toxic substances.
• Closing the machine’s upper cover without paying
sufficient attention could entail risk of trapping
body parts.
• Dropping and sliding loads can entail body injuries
and/or damage to the machine.
• Closing the back panel and the front doors without
paying sufficient attention could entail risk of trap-
ping fingers and/or hands.
• Removing the work base without paying sufficient
attention could entail risk of trapping fingers and/
or hands.
The manufacturer must be informed of any
wear and tear or broken warning pictograms.
The manufacturer must be informed of
failures in any of the LED indicators on the
control panel.
Follow the occupational health and safety
specifications established by the risk
prevention manager according to applicable
Law, on Occupational Risk Prevention.
Operators are not allowed to process
materials which are not included in the
Processable Materials list of this manual.
Before closing the cover, ensure that all
personnel is out of reach of the cover.
Do not handle heavy or unstable loads close
to the machine.
Before closing the panel and doors, ensure
that all personnel is out of reach of the hazard
area.
Before removing the base, ensure that all
personnel is out of reach of the hazard area.
Appropriate work clothing or lack of
protective equipment

Instruction Manual 17
Warnings
ATENTION
Any modifications made to the machine without the approval of the manufacturer will
invalidate the Statement of Compliance provided for the product and its warranty.
Connect the machine to a wire with 230 AC volts and a ground and only use cables
from the manufacturer.
Connect the machine to a 6 bar air supply.
It is prohibited to use the machine for any use not listed in the present manual.
It is prohibited to exceed the maximum dimensions for a part that can be processed.
It is prohibited to process parts whose work surface is not flat.
It is prohibited to process any materials not listed in this instructions manual.
It is prohibited to make any changes to the vender settings.
Contact the manufacture if you have any questions or concerns.
• The improper removal of residues may cause
environmental damages.
• Dispose of residues in accordance with applicable
legal regulations.
The basic functioning parameters, or vender settings,
which are set by the manufacturer, guarantee the pro-
per functioning and safety.
These can be accessed with software and from the
display and they are protected with a password. Any
modification of them may cause dangerous situation or
cause severe risks.
It is totally prohibited to make any changes to these
parameters.
Improper removal of residues and
productions materials Modifications in the vender settings

3
3
18 Instruction Manual
Safety pictograms
1
4
5
6
7
1
2
3
7
2
3
1Laser radiation
emission hazard
3Trapping hazard
6
7
4Fire hazard
2Electrical hazard
5

Instruction Manual 19
Transport
Storage conditions
Installation conditions
Transport - Storage - Installation
The machine will be transported by the manufacturer or, otherwise, by an authorised distributor.
The manufacturer is responsible for unloading, adjusting and tuning the components.
In the event of damage or missing parts, the machine shall not be released. The procedure for checking compo-
nents and inspecting damage shall be carried out by the manufacturer or, otherwise, by an authorised distributor.
The buyer is responsible for demanding the machine to be appropriately tuned and adjusted.
The buyer is responsible for alerting of any error, missing or damaged component of the machine after its installa-
tion and tuning.
The storage condition should not generate any risk to the integrity or functionality of the machine or its compo-
nents, and the user is responsible for ensuring the machine is stored appropriately. The machine should be stored
in a dry environment and at temperatures ranging between 10ºC (min. temp.) and 40ºC (max. temp.). The machine
should be kept away from traffic areas where it may suffer blows. Never store objects on top or inside the machine.
The final location of the machine should comply with
the minimum distances for installation as shown in the
image to the left.
The machine does not come with a smoke filter for the
ventilation system.
It is recommended to place the machine close to the
ventilation system, a pneumatic extraction system or
exterior access to make it easier to extract any smoke.
Never operate the machine without a filter or exterior
access.
It is recommended to place a fire extinguisher in an area
close to the machine to eliminate any risk caused by the
existence of a flame.
1 m
1 m
m1
m1

20 Instruction Manual
Assembly and Installation
The machine will be assembled by an authorised dis-
tributor, which may be the transport company itself or
BCN3D personnel.
The machine’s initial adjustment and calibration activi-
ties will be carried out by the company responsible for
the assembly process.
The assembly activities must be
performed by professionals qualified
in completing this task and never by
the user.
