BCN3D Epsilon Series User manual

3
2
4
1
We would like to thank all users for trusting BCN3D, for helping us to reach our
dreams and to create a better product every day.
1. Unboxing
1. Cut the straps and
remove the top box
and the plastic bag
containing the printer.
2. Lean the printer
backwards holding it
from both side handles
and the front-bottom.
3. Lift with care and place it
on the table.
Quick Start Guide
BCN3D Epsilon Series
Use the handles to take
out the printer
2. Set up
Remove protections
•Remove the blue sticker from the door to open it.
•Remove the protective foam under the platform.
•Remove the belt clips that prevent the axes from moving during transportation.
There are four in total: two in the X belts (in front) and two in the Y belts
(one on the left and one on the right).
•Finally, remove the protective lms from the covers, door and side panels.
•Pivot the left and right spring clips away from the aluminium plate.
•Take the glass build plate from the bottom tray.
•Place the build plate on top of the aluminium plate.
•Insert the build plate with light force into the back spring clips.
•Fix it with the left and right spring clips.
Install build plate
Quick Start Guide in your
own language
Unboxing
Watch our video to see
how to correctly unbox.
Unboxing video
Install printing surface
Watch our video to see
how to correctly position
the build plate.
Set up video
Retain packaging and pallet for warranty service.
The printer is heavy and therefore this step needs to be performed by two people. Make sure
that the table where the printer is being installed, is close enough.
The glass build plate must be handled with care. In case of breakage, it may cause injuries.
Specications subject to change. EN-MES-2021-v1.2
For more detailed
information about the
processes, read the User
Manual.
User Guide

BCN3D Technical
Assistance Services
If you do not nd a solution to your
problem in this manual, please contact
the BCN3D Technologies support
team through Contact Support.
Turn on the printer
•Take the power cable out from the accessories box.
•Connect the power cable to the power socket at the back of the printer.
•Plug the other end of the cable into a wall outlet.
•Turn the printer on. The power switch is found on the left side of the printer.
Getting started
Scan the QR code to be guided through the Setup Assistant for network connectivity, loading
lament and calibrating your printer.
What is in the box?
•BCN3D Epsilon Series with 0.4mm
hotends
•Glass build plate
•2 PLA spools
•2 Spool holders
•Quick start guide and warranty
•SD card
•Ethernet cable
•USB cable
•Spatula
•3 Allen keys
•Pliers
•10 Hotend shims
•USB Wi dongle
•Power cable
•Nylon cleaning lament
•Calibration gauge
•Magigoo glue stick
•Sample part
1 If you have the option, we
recommend using the printer with
an Ethernet connection as it is more
stable than Wi.
Information
Online
Ethernet
•Take the ethernet cable out from the
accessories box.
•Connect the ethernet cable to the
ethernet port at the back of the printer.
•Connect the other end of the cable to a
network source.
Wi
•Find the USB WiFi Dongle in the
accessories box.
•Plug the USB WiFi Dongle into the USB
port at the back of the printer.
Ofine
SD Card
•Find the SD Card in the tool box.
•Insert the SD Card into the SD Card slot at
the front of the printer.
3. Using the printer
1. Teon tube
2. Purge Tank
3. Door handle
4. SD card reader
5. Touchscreen
6. Filament entry
7. Spool holder
8. Filament spool
9. Hotend
10. Glass build plate
11. Aluminium plate
12. Power switch
13. Power socket
14. USB port
15. Ethernet port
16. External lament spool
17. External spool holder
18. Filament Runout Sensor (FRS)
19. Extruder
20. Filter fan
21. HEPA/Carbon lter
3
5
4
13
20
19
15
Diagram
The BCN3D Epsilon Series can be used online or ofine. However connecting the printer to the
network is needed in order to register it and to use the BCN3D Cloud functionality.1
16
1
12
14
21
7
17
Setup Assistant
Watch our video to see
how to run the Setup
Assistant
Getting started
6
9
10
11
818
2
