BDI sequel 6001 Desk User manual

1
Designed by Matthew Weatherly.
‘Sequel’ is a trademark of Becker Designed, Inc.
All rights reserved. ©2014 Becker Designed, Inc.
Made in Taiwan. 6001REV082115v10
I - Adhesive Foam/Magnet x 4
Pre-installed on Upper
Horizontal Beam (N)
G - 1/4-20 x 63 mm Screw x 7
H-1/4-20 x 12 mm Screw x 16
F- 4mm Hex Wrench x 1
Placement and Maintenance
Sequel™ Home Office Furniture is designed for indoor use on level floors. Clean glass with
glass cleaner, and steel parts and wood veneer with a moist cloth. Your Sequel™ Home
Office Furniture is engineered for easy assembly. Carefully follow this procedure to prevent
any damage.
Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace should be a non-
marring surface such as carpet. For missing hardware pieces, please contact BDI Customer
Service at [email protected]. For all other concerns, please contact your BDI
Retailer.
Component List
6001
6
00
2
6005
5
6
6
6006
6
6
6007
7
6
B - Top Glass x 1
D - Front Kick Panel x 1
C-Back Panel x 1
L -Right Leg x 1
K -Left Leg x 1
M - Glides x 4
A - Drawer Assembly x 1
E - Lower Horizontal Beam x 1
N - Upper Horizontal Beam x 1
J - Center Drawer Liner x 2
sequel®
6001
desk
assembly instructions
bdiusa.com [email protected]

2assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
Step 1
Install Glides (M) to the bottom of Left Leg (K) and Right Leg (L).
M x 4
LK

3assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
H
H
H
K
L
A
A
Step 2
Attach Left Leg (K) to Drawer Assembly (A) using Screw (H) and
Hex Wrench (F).
Step 3
Attach Right Leg (L) to Drawer Assembly (A) using Screw (H)
and Hex Wrench (F).
H

4assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
Step 4
Attach Upper Horizontal Beam (N) to inside of Left and Right Leg using
Screw (H) and Hex Wrench (F).
H
H
N

5assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
Step 5
Attach Lower Horizontal Beam (E) to inside of Left and Right Leg
using Screw (H) and Hex Wrench (F).
E
H
H
2 Person Task

6assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
G
GG
GGG G
B
Step 6
With the help of another person, gently lower Assembly onto Top Glass
(B). Both parts will be placed upside down for the assembly process and
fasten into place using Screw (G) and Hex Wrench (F) at all (7) fastener
locations. DO NOT OVERTIGHTEN! With the help of another person, turn
desk upright onto its base.
2 Person Task

7assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
Step 7 (optional)
Attach Magnets to AC power strip/surge protector
Remove Adhesive Foam/Magnets (I) from the Upper Horizontal Beam (N). Peel
film from side of the Adhesive Foam/Magnets (I) and attach to clean, dry back side
of AC power strip (not included). Cleaning of power strip surface with rubbing
alcohol will ensure best adhesive bond. **UNPLUG POWER STRIP FROM
POWER SOURCE BEFORE CLEANING**
Attach AC power strip/surge protector to inside of Upper Horizontal Beam
(N) as shown in illustration above.
Use the slot holes provided to run all wires to and from the desk. Keep all
wires behind folded metal lip—failure to do so will prevent Back Panel (C)
and/or Front Kick Panel (D) from attaching properly.
4.
1.
2.
3.
I
N
1.
2.
3.
4.

8assembly instructions
bdiusa.com [email protected]
sequel®
6001 DESK
Step 11
Place Sequel Desk in desired location. Once all of the electrical wires are
routed, install Kick Panel (D) as shown above. The rear side of panel
has magnets that will hold the panel in place. Note: The Sequel Desk
is designed to permit placement in front of an electrical outlet for easier
wiring access.
Optional Step
The Back Panel (C) is provided to conceal wire management, if desk is
located in the middle of a room.
C
C
With the grippy side facing
down, insert Center Drawer
Liner (J) into the center
drawer.
J x 1
