BDI LINQ 9186 User manual

LINQ™9186
DRESSER
DESIGNED BY MATTHEW WEATHERLY
LET’S GET STARTED.
INSTRUCTION MANUAL

Congratulations on the purchase of your LINQ Dresser 9186 from BDI. Your dresser has
been designed to provide a lifetime of enjoyment. This manual will provide assembly
instructions and other helpful information to ensure you get the most out of your
product. Please save it for future reference.
Your LINQ Dresser has been engineered for simple assembly. Please follow these
directions carefully to prevent any damage.
Should you need further assistance, contact BDI at customerservic[email protected]om.
ENJOY!

BDIUSA.COM | 3NEED ASSISTANCE? customerservic[email protected]om
HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS
Wood Screw (H4) QTY: 4
HARDWARE REQUIRED (NOT INCLUDED)HARDWARE REQUIRED (NOT INCLUDED)
Drywall Screw* QTY: 1
Thumb Screw (H5) QTY: 1
Drywall Anchor* QTY: 1
M6 x 16 Screw (H1) QTY: 8 M6 x 80 Screw (H2) QTY: 6 M4 x 35 Screw (H3) QTY: 12
Leveler Wrench (T2) QTY: 1 Phillips Screwdriver
TOOL REQUIRED (NOT INCLUDED)
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at
customerservic[email protected]om. For all other concerns, please contact your BDI retailer.
Do not use power tools for the assembly of this product.
*Use appropriate wall anchor and screw.
Hex Wrench (T1) QTY: 1

4 | BDIUSA.COM LINQ 9186
Drawer Pull (C4) QTY: 6Cabinet (C3) QTY: 1
KLEET (C5) QTY: 2 Anchor Strap (C6) QTY: 1
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
Leg (C2) QTY: 2Spanner (C1) QTY: 2

BDIUSA.COM | 5NEED ASSISTANCE? customerservic[email protected]om
Lay the Spanners (C1) on a soft, non-marring
surface, like carpet. Attach the Legs (C2) to the
Spanners (C1) using 8 Screws (H1) and tighten
with Hex Wrench (T1).
HEX WRENCH – T1 QTY
1
SCREW – H1 QTY
8
STEP 1. ASSEMBLE BASE ASSEMBLY
H1
H1
H1
H1
C1
C1
C2
C2

6 | BDIUSA.COM LINQ 9186
STEP 2. ATTACH BASE TO CABINETASSEMBLY
HEX WRENCH – T1 QTY
1
SCREW – H2 QTY
6
With help from another person, carefully
position the Cabinet (C3) onto a layer of
honeycomb packing material and orient it on its
back as shown.
Position the Base as shown and attach with
6 Screws (H2). Tighten with Hex Wrench (T1).
NOTE: The packing material creates finger space to
lift the cabinet after attaching the base.
2 PERSON TASK
C3
Honeycomb packing material
H2
H2
H2
H2
H2
H2

BDIUSA.COM | 7NEED ASSISTANCE? customerservic[email protected]om
ASSEMBLY
STEP 3. ATTACH DRAWER PULLS
With the help of another person, carefully turn
the Dresser onto its feet. One row at a time,
open the drawers, cut the ribbon off the drawer,
and install the 6 Drawer Pulls (C4) using
12 Screws (H3). Tighten with Phillips Head
Screwdriver (not included).
NOTE: Drawers have an interlocking mechanism to
prevent multiple drawers in a single column from
being opened simultaneously. This greatly reduces
the risk of tip over.
NOT INCLUDED
PHILLIPS SCREWDRIVER
QTY
1
SCREW – H3 QTY
12
H3
H3
C4
C4

8 | BDIUSA.COM LINQ 9186
Install the KLEETS (C5) to the back of the
Cabinet using 4 Wood Screws (H4). Tighten
with Phillips Head Screwdriver (not included).
STEP 4. INSTALL KLEETSASSEMBLY
NOT INCLUDED
PHILLIPS SCREWDRIVER
QTY
1
SCREW – H4 QTY
4
C5
C5
H4
H4

BDIUSA.COM | 9NEED ASSISTANCE? customerservic[email protected]om
ASSEMBLY
STEP 5. INSTALL ANCHOR STRAP & SECURE CABINET
With help from another person, carefully walk
the cabinet into the desired position against
the wall.
It is strongly recommended that you anchor your
LINQ Dresser to the wall using the provided
Anchor Strap (C6). Use painter’s tape to mark
the upper left corner of the unit, as shown.
With help from another person, carefully move
the cabinet away from the wall. Measure and
mark the wall as shown.
Attach one end of the Anchor Strap (C6) to the
wall at the marked location with an appropriate
wall anchor and screw (not included).
NOT INCLUDED
PHILLIPS SCREWDRIVER
QTY
1
NOT INCLUDED
WALL ANCHOR
QTY
1
NOT INCLUDED
SCREW
QTY
1
THUMB SCREW – H5 QTY
1
2 PERSON TASK
34.5"
876 mm
32.5"
824 mm
C6
Carefully move your Dresser close
to the wall and attach the loose
end of the Anchor Strap (C6) to
the back edge of the top panel
with the Thumb Screw (H5).
C6
H5

10 | BDIUSA.COM LINQ 9186
FINE TUNING LEVEL DRESSER
Once the unit is completely assembled and in its
final position, adjust the levelers using Leveler
Wrench (T2). Using a level (not provided), level
your cabinet first side to side and then front to
back. If your cabinet is on carpeting, check your
front to back level after loading the cabinet and
opening the heaviest drawers. This will ensure the
cabinet remains level during operation and
reduce the risk of tip-over.
PART/DESCRIPTION QTY
LEVELER WRENCH – T2 1
Dial down
T2
