Beckhoff Cp69 series User manual

Manual | EN

CP69xx

Control Panel

2022-8-2 | Version: 3.0

Table of contents

CP69xx 3Version: 3.0

Table of contents

1 Notes on the documentation....................................................................................................................5

2 For your safety ..........................................................................................................................................6

2.1 Description of safety symbols ...........................................................................................................6

2.2 Intended use .....................................................................................................................................6

2.3 Fundamental safety instructions .......................................................................................................7

2.4 Operator's obligation to exercise diligence........................................................................................7

2.5 Notes on information security............................................................................................................8

3 Product overview ......................................................................................................................................9

3.1 Structure..........................................................................................................................................10

3.2 Interface description........................................................................................................................10

3.2.1 DVI Extended input ..........................................................................................................11

3.2.2 USB Extended input......................................................................................................... 12

3.2.3 USB input .........................................................................................................................12

3.2.4 USB output....................................................................................................................... 13

3.2.5 Power supply.................................................................................................................... 13

3.3 Status LEDs ....................................................................................................................................14

3.4 Name plate......................................................................................................................................15

3.5 Key functions...................................................................................................................................16

3.6 Connection kits................................................................................................................................18

4 Commissioning .......................................................................................................................................19

4.1 Transport and unpacking ................................................................................................................20

4.2 Control cabinet installation ..............................................................................................................21

4.3 Connecting the Control Panel .........................................................................................................24

4.3.1 Mounting power supply cable........................................................................................... 24

4.3.2 Grounding the Control Panel............................................................................................ 26

4.3.3 Connecting cables and power supply .............................................................................. 27

5 Decommissioning ...................................................................................................................................28

5.1 Disconnecting the power supply and cables ...................................................................................28

5.2 Disassembly and disposal...............................................................................................................29

6 Maintenance ............................................................................................................................................30

7 Troubleshooting......................................................................................................................................32

8 Technical data .........................................................................................................................................33

9 Appendix..................................................................................................................................................34

9.1 Service and support ........................................................................................................................34

9.2 Approvals ........................................................................................................................................35

Table of contents

CP69xx4 Version: 3.0

Notes on the documentation

CP69xx 5Version: 3.0

1 Notes on the documentation

This description is only intended for the use of trained specialists in control and automation engineering who

are familiar with the applicable national standards.

The following instructions and explanations must be followed during installation and commissioning of the

components. The responsible staff must ensure that the application or use of the products described satisfy

all the requirements for safety, including all the relevant laws, regulations, guidelines and standards.

Disclaimer

The documentation has been prepared with care. The products described are, however, constantly under

development. For that reason the documentation is not in every case checked for consistency with

performance data, standards or other characteristics. In the event that it contains technical or editorial errors,

we retain the right to make alterations at any time and without warning. No claims for the modification of

products that have already been supplied may be made on the basis of the data, diagrams, and descriptions

in this documentation. All illustrations shown are only examples. The configurations depicted may deviate

from the standard.

Trademarks

Beckhoff®, TwinCAT®, TwinCAT/BSD®, TC/BSD ®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®,

Safety over EtherCAT®, TwinSAFE®, XFC®, XTS® and XPlanar® are registered and licensed trademarks of

Beckhoff Automation GmbH.

Other designations used in this publication may be trademarks whose use by third parties for their own

purposes could violate the rights of the owners.

Patents

The EtherCAT Technology is covered, including but not limited to the following patent applications and

patents: EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 and similar applications and

registrations in several other countries.

grant of a patent, utility model or design.

Delivery state

All the components are supplied in particular hardware and software configurations appropriate for the

application. Changes to the hardware or software configuration are permitted, provided they are within the

specified limits for power consumption and power loss (please refer to the respective data sheet).

Currentness

Please check whether you are using the current and valid version of this document. The current version is

always available for download from the Beckhoff website. In case of doubt, contact Technical Support.

Delivery conditions

In addition, the general delivery conditions of the company Beckhoff Automation GmbH & Co. KG apply.

For your safety

CP69xx6 Version: 3.0

2 For your safety

The safety chapter explains the safety symbols used and their meanings. They contain fundamental safety

instructions that are essential for the avoidance of personal injuries and damage to property.

Exclusion of liability

Beckhoff shall not be liable in the event of non-compliance with this documentation and thus the use of the

devices outside the documented operating conditions.

2.1 Description of safety symbols

The following safety symbols are used in these operating instructions. In order to avoid personal injuries and

damage to property, read and follow the safety and warning notices.

Warning of personal injuries

DANGER

Disregarding the safety notice will lead to death or serious injuries.

WARNING

Disregarding the safety notice may lead to death or serious injuries.

CAUTION

Disregarding the safety notice may lead to minor injuries.

Warning of damage to property

NOTE

Disregarding the notice may lead to damage to property.

2.2 Intended use

The CP69xx Economy built-in Control Panel is designed for industrial applications in machine and system

engineering. A TFT display and a single-finger touch screen or touch pad and optionally a PC keyboard are

built into the sheet-steel housing with aluminum front. The Control Panel is installed in the front of control

cabinets.

The DVI/USB extension technology integrated in the Control Panel enables the Panel to be located up to

50m away from the PC.

The front of the Control Panel is designed for an IP65 working environment. It offers full protection against

contact and against dust, as well as protection against water jets (nozzle) from any angle. The rear of the

Control Panel is designed for an IP20 working environment. It is protected against the penetration of fingers

and solid foreign bodies of 12.5 mm in diameter or larger in size. It is not protected against water. Operation

of the device in wet and dusty environments is not permitted. The specified limits for technical data must be

adhered to.

The Control Panel can be used within the documented operating conditions.

Improper use

Do not use the device outside the documented operating conditions.

For your safety

CP69xx 7Version: 3.0

2.3 Fundamental safety instructions

The following safety instructions must be observed when handling the device.

Application conditions

• Do not use the device under extreme environmental conditions. Protect the device from moisture and

heat.

• Never use the device in potentially explosive atmospheres.

• Do not carry out any work on the device while it is live. Always switch off the supply voltage for the

device before mounting it, replacing device components or rectifying malfunctions.

• Never connect the device during a thunderstorm. There is a risk of electric shock.

• Ensure that the device has a protective and functional earth connection.

Damage to property, loss of data and impairment of functions

• Ensure that only trained specialists with a control and automation engineering background, operate the

device. Use by unauthorized persons can lead to damage to property and loss of data.

• Fuse the power supply line to protect the supply line in the event of a short circuit according to its

cross-section.

• In case of fire, extinguish the device with powder or nitrogen.

2.4 Operator's obligation to exercise diligence

The operator must ensure that

• the products are used only for their intended purpose (see Chapter 2.2 Intended use [}6]).

• the products are only operated in sound condition and in working order.

• the products are operated only by suitably qualified and authorized personnel.

• the personnel is instructed regularly about relevant occupational safety and environmental protection

aspects, and is familiar with the operating instructions and in particular the safety instructions contained

herein.

• the operating instructions are in good condition and complete, and always available for reference at the

location where the products are used.

For your safety

CP69xx8 Version: 3.0

2.5 Notes on information security

The products of Beckhoff Automation GmbH & Co. KG (Beckhoff), insofar as they can be accessed online,

are equipped with security functions that support the secure operation of plants, systems, machines and

networks. Despite the security functions, the creation, implementation and constant updating of a holistic

security concept for the operation are necessary to protect the respective plant, system, machine and

networks against cyber threats. The products sold by Beckhoff are only part of the overall security concept.

The customer is responsible for preventing unauthorized access by third parties to its equipment, systems,

machines and networks. The latter should be connected to the corporate network or the Internet only if

appropriate protective measures have been set up.

In addition, the recommendations from Beckhoff regarding appropriate protective measures should be

observed. Further information regarding information security and industrial security can be found in our

https://www.beckhoff.com/secguide.

Beckhoff products and solutions undergo continuous further development. This also applies to security

functions. In light of this continuous further development, Beckhoff expressly recommends that the products

are kept up to date at all times and that updates are installed for the products once they have been made

available. Using outdated or unsupported product versions can increase the risk of cyber threats.

To stay informed about information security for Beckhoff products, subscribe to the RSS feed at https://

www.beckhoff.com/secinfo.

Product overview

CP69xx 9Version: 3.0

3 Product overview

The single-touch built-in Control Panel is designed for control cabinet installation and is available in a wide

range of diagonals. It can be used for a wide range of automation tasks.

The Control Panel has the following features:

• Various display sizes and resolutions:

◦ 5.7-inch, 640 x 480

◦ 6.5-inch, 640 x 480

◦ 12-inch, 800 x 600

◦ 15-inch, 1024 x 768

◦ 19-inch, 1280 x 1024

• TFT display

• Sheet-steel housing with aluminum front, front IP65, rear IP20

• Front laminate in different variants:

◦ only display without keys

◦ function keys, with 10 special PLC keys with LEDs

◦ numeric PC keyboard (US layout), with 10 special PLC keys with LEDs

◦ alphanumeric PC keyboard (US layout), with 10 special PLC keys with LEDs

• Control cabinet installation via pull-out clamping levers for fast installation without loose parts

• 24 V DC power supply unit

Product overview

CP69xx10 Version: 3.0

3.1 Structure

Fig.1: CP69xx_structure

Table1: Key: CP69xx structure

No. Component Description

1 Display and touch screen glass Operating the Control Panel

2 Clamping lever Mounting the Control Panel in the panel of the

control cabinet

3 Grounding bolt Functional earth of the Control Panel

4 Access to interfaces Interfaces on the underside

3.2 Interface description

In the basic configuration, the Control Panel includes the following interfaces:

• DVI Extended input (X101)

• USB Extended input (X102)

• USB input (X103)

• USB output (X104, X105)

• Power supply (X106)

The interfaces are located on the back of the Control Panel at the bottom of the connection section (see fig.

2).

Fig.2: CP69xx_connection section

Product overview

CP69xx 11Version: 3.0

3.2.1 DVI Extended input

The Control Panel has a DVI Extended input (X101). It is used to transmit the graphics signal from the

Industrial PC to the Control Panel.

The graphics signal is transferred directly via a DVI cable over a distance of 50 m max. Such a cable length

leads to strong distortion of the graphics signal on arrival at the Control Panel. A signal processor is used in

the Control Panel to fully restore the DVI signal. The Industrial PC requires a conventional DVI output.

X101

Fig.3: CP69xx_DVI-E input Pin numbering

Table2: DVI Extended interface pin assignment

Pin Connection Pin Connection Pin Connection

1 TDMS Data 2 - 9 TDMS Data 1 - 17 TDMS Data 0 -

2 TDMS Data 2 + 10 TDMS Data 1 + 18 TDMS Data 0 +

3 TDMS Data 2/4 Shield 11 TDMS Data 1/3 Shield 19 TDMS Data 0/5 Shield

4 TDMS Data 4 - 12 TDMS Data 3 - 20 TDMS Data 5 -

5 TDMS Data 4 + 13 TDMS Data 3 + 21 TDMS Data 5 +

6 DDC Clock 14 + 5V Power 22 TDMS Clock Shield

7 DDC Data 15 Ground (+ 5 V, Analog H/V

Sync)

23 TDMS Clock +

8 Analog Vertical Sync 16 Hot Plug Detect 24 TDMA Clock -

C5 GND

Setting the Transmission Rate

If the distance between the PC and the Control Panel is large, the transfer rate for the DDC file must be

limited. The DDC file is transferred from the Control Panel to the PC to tell the PC the properties of the

display such as timing and resolution.

The VideoBIOS in the graphics card, or in case of on-board graphics the VideoBIOS in the motherboard,

contains the definition of the transfer rate for the DDC file. This value must be 50kHz or less. If this value is

too high, the image is either not displayed or only displayed after Windows starts.

Windows graphics drivers also contain a value for the transfer rate of the DDC file. If no image is displayed

under Windows, a graphic driver must be used that contains a value of 50 kHz or less for the DDC file

transfer.

Product overview

CP69xx12 Version: 3.0

3.2.2 USB Extended input

The Control Panel has a USB extended input (X102) in the form of an RJ45 socket. The Control Panel is

connected to the CU8801 USB-to-USB extended converter box via the interface. The interface transmits

USB 2.0 with 480Mbit/s.

To realize a distance of 50 m without hubs, USB Extended converts the USB signal so that it can be

transmitted via a 50 m CAT-5 cable. In the Control Panel the signal is converted back to USB. This is not an

Ethernet connection. No Ethernet switch or hub can be integrated in the USB-Extended cable.

8 1

X102

Fig.4: CP69xx_USB-E input pin numbering

Table3: USB E input pin assignment

Pin Signal Description

1 T2 + Pair 2

2 T2 -

3 T3 + Pair 3

4 T1 + Pair 1

5 T1 -

6 T3 - Pair 3

7 T4 - Pair 4

8 T4 -

3.2.3 USB input

The Control Panel has a USB input (X103) with socket type B. The USB input is used to connect the Control

Panel directly to the standard output of an Industrial PC at distances of up to 5m. USB specification 2.0 is

supported.

X103

Fig.5: CP69xx_USB input pin numbering

Table4: USB interface pin assignment

Pin Connection

Shield GND

1 Vbus

2 D -

3 D +

4 GND

Product overview

CP69xx 13Version: 3.0

3.2.4 USB output

The Control Panel has two USB outputs (X104, X105) with socket type A. The interfaces are used to connect

peripheral devices with USB connection. USB specification 2.0 is supported.

1 2 3 4

321

X104

X105

Fig.6: CP69xx_USB output pin numbering

Table5: USB interface pin assignment

Pin Connection

Shield GND

1 Vbus

2 D -

3 D +

4 GND

3.2.5 Power supply

The Control Panel is supplied with a nominal input voltage of 24VDC. The power supply and the protective

earth of the device are connected via the 5-pin voltage socket (X106).

X106

1 2 345

Fig.7: CP69xx_voltage socket pin numbering

Table6: Voltage socket pin assignment

Pin Signal Description

1 NC not used

2 NC not used

3 Protective earth

4 - 24 V power supply, negative pole

5 + 24V 24 V power supply, positive pole

The plug for the power supply is specified for 16A and can accommodate wire cross-sections of up to

1.5mm2. For long supply lines, use 1.5 mm2 cables to achieve a low voltage drop on the supply line. There

should be at least 22V at the power supply plug of the Control Panel, so that the Control Panel remains

switched on during voltage fluctuations. The plug is included in the delivery. You can obtain a replacement

plug from your Beckhoff Sales using the following ordering option:

• C9900-P927: power supply connector for CP69xx Control Panel, 5-pin connector with strain relief for

the external supply cable

Product overview

CP69xx14 Version: 3.0

3.3 Status LEDs

The Control Panel has six status LEDs. They are located on the rear side in the connection section of the

panel (see fig. 8).

Fig.8: CP69xx_Status LEDs

The LEDs have the following meanings:

Table7: LED functions

LED Name Meaning

1 No function

2 No function

3 USB 1 USB 1 interface in operation

4 USB 2 USB 2 interface in operation

5 Power Good Input voltage OK

6 24 V in Power supply established

Product overview

CP69xx 15Version: 3.0

3.4 Name plate

The name plate provides information about the Control Panel equipment.

8 9 10 11 12 13 14 15

Fig.9: CP69xx_name plate

Table8: Key CP69xx name plate

No. Description

1 Model: The last four digits indicate the device generation.

2 Serial number (BTN)

3 Date of manufacture

4 Display

5 Touch screen

6 Touch pad

7 Power supply: 24VDC, NEC class 2

8 Grounding bolt for functional earthing of the Control Panel

9 DVI Extended interface (X101)

10 USB Extended Interface (X102)

11 USB input (X103)

12 Status LEDs P101 and P102 without function

13 USB output (X104, X105)

14 Status LEDs for USB and power supply (P103-P106)

15 Connection of the power supply and protective earth of the Control Panel (X106)

16 Symbols

Note: here are the symbols applicable to the device such as CE, EAC, UKCA, . The

approvals of your device can be found on the name plate and in chapter 9.2 Approvals [}35].

17 FCC approval

18 Address of the vendor

Product overview

CP69xx16 Version: 3.0

3.5 Key functions

You can order your Control Panel with different versions of the front laminate. You can choose between a

panel without buttons and a panel with different button configurations. Please refer to the current price list for

specific ordering options.

The following table provides information about the functions of the available keys.

Table9: Key functions CP69xx

Key Function

Move the cursor one step in the corresponding direction

EndHome

Home = cursor to beginning of the line

End = cursor to end of the line

Pg Up Pg Dn

Pg Up = scroll forward one page

Pg Dn = turn back one page

Tabulator = cursor to next input field

Shift + Tab = cursor to previous input field

Del

Del = delete character to the right of the cursor

Ins

Ins = overwrite character to the right of the cursor (function then deactivated again)

Print = print a hardcopy of the text screen

Pause

Pause = pause PC until another key is pressed (MS-DOS only)

Enter

Enter = confirm input

Backspace =delete character to the left of the cursor

Shift

Shift pressed with letter = upper case instead of lower case letter

Shift pressed with number = mapped character instead of number

Caps

Lock

Caps Lock = permanent pressing of the Shift key (pressing the Shift key deactivates

the function)

Ctrl Alt

Ctrl, Alt = change the meaning of a key pressed at the same time

Open the start menu of the operating system in use

Product overview

CP69xx 17Version: 3.0

Opening the properties window of a selected object

Esc

Esc = close dialog box, cancel operations

…

Set printed character to the cursor position

F1 F2 F3 F4

F5 F6 F7 F8

F9 F10 F11 F12

Function keys F1-F10 = functions of the keys determined by the software and

displayed in the lower display edge

Einschub

Streifen

Einschub

Streifen

Einschub

Streifen

Einschub

Streifen

Special keys = function of the keys determined by the software and displayed in the

upper display margin

Product overview

CP69xx18 Version: 3.0

3.6 Connection kits

The following optional connection kits are available:

Table10: CP69xx connection kits

Connection kits Description

C9900-K560 1 m connection kit for CP69xx, consisting of:

DVI cable 1m, USB cable 1m

C9900-K513 3 m connection kit for CP69xx, consisting of:

DVI cable 3m, USB cable 3m

C9900-K515 5 m connection kit for CP69xx, consisting of:

DVI cable 5m, USB cable 5m

C9900-K625 10m connection kit for CP29xx-0000, CPX29xx-0000 and CP69xx-xxxx-0010

consisting of:

10 m DVI cable, 10 m Cat.5 cable for USB-E-2.0, CU8801 USB-to-USB-E-2.0

converter for DIN rail mounting next to the PC and 1m USB cable for connecting the
