Bedfont FeNObreath CaliBag User manual

Annual Service Kit Quick Start Guide
CONTENTS:
Important Informaon Page 3
How to Calibrate the FeNObreath™ with the CaliBag® Page 4
How to replace the NO Scrubber Page 6
Disposal Informaon Page 7
CaliBag®
b
ac
defg
a) CaliAdapter x1 b) Bung x1
c) CaliBag® x1 d) Bag Adapter
e) Blue Plugs x2 f) Bag Clamps x2
g) NO Scrubber x1
THIS KIT CONTAINS:
FeNObreath CaliBag®

PAGE 2 PAGE 3
Important Informaon
Before calibrang your FeNObreath™, it is important to read the following informaon:
• Please ensure you charge the FeNObreath for 24 hours prior to use if it has not been used in a while.
NOTE: The device will only charge whilst switched o.
• Please keep this Annual Service Kit at 17-24 °C (63°F to 77°F) for 24 hours prior to use.
• Please make sure the FeNObreath™ is not plugged into the mains before following any of the advice in
this document.
• Please ensure your FeNObreath™ monitor is updated with rmware version 3.0 and above.
The latest version of rmware can be downloaded from www.nobreathfeno.com
• Please ensure the gas has not expired and that the date has not surpassed the ‘Expiry Date’ labelled on
the CaliBag®
• Please ensure the atmospheric temperature is between 17-24 °C (63°F to 77°F) before calibrang. If it is
too cold to calibrate (<17°C or 63°F), a blue thermometer will be shown on-screen. Move the FeNObreath™
to a warmer area and try again later. If it is too hot to calibrate (>25°C or 77°F), a red thermometer will be
shown on-screen. Move the FeNObreath™ to a cooler area and try again later.
Safety Informaon
CAUTION: NO scrubber contains potassium permanganate and should be disposed of as hazardous waste
in accordance with local waste disposal regulaons.
CAUTION: NO scrubber contains potassium permanganate and should not be tampered with and should not
be exposed to skin.
NOTE: Refer to main manuals for explanaons.
For any further enquiries please contact MGC by visiting: www.mgcdiagnoscs.com
Aach the Bag Adapter to the rubber end of the
CaliAdapter.
Ensure both Bag Clamps on the CaliBag® are closed
and remove one Blue Plug.
Insert the Bag Adapter into the CaliBag®. Insert the Bung into the boom vent hole on the
back of the FeNObreath and turn the device on.
Press the Sengs icon , followed by the
Service Area icon .
Press the Calibraon icon to begin.
Use the arrows to adjust the NO concentraon
onscreen to match the value of the NO
concentraon wrien on the CaliBag®.
Press the arrow icon twice to connue.
With the CaliBag® aached, insert the CaliAdapter
into the FeNObreath. Press the next arrow once
to connue.
4
56
7 8
12
3
How to Calibrate the FeNObreath™ with the CaliBag®

PAGE 4 PAGE 5
Open the Bag Clamp and press the next arrow to
connue.
An hourglass will display onscreen as the device
will automacally calibrate, drawing the gas
from the CaliBag®.
A successful calibraon is shown by a green ck.
Press Save to complete the calibraon.
An unsuccessful calibraon is shown by a red cross.
If an unsuccessful calibraon is shown by a red
cross, contact MGC Diagnoscs Corporaon or the
local distributor.
Ensure both Bag Clamps are closed before
removing the CaliBag® and remove all adapters
from the FeNObreath.
Remove the Bung from the FeNObreath.
11
109
12
13 14
Please ensure the FeNObreath™ monitor is
switched o before removing the back cover.
Using the screwdriver provided with the
FeNObreath™, unscrew the screw on the back of
the monitor.
Remove the back cover by sliding
and liing it o.
To remove the scrubber, rst press down on
clip at the top le-hand side of the monitor.
Slide out the scrubber then li to remove. Remove all packaging from the new NO
Scrubber and insert it into the FeNObreath.
Re-aach the back cover of the
FeNObreath monitor.
To secure the FeNObreath™ back cover, use the
screwdriver to resecure the screw into place.
How to replace the NO Scrubber
4
56
7
1 2
3
8
(CAUTION: NO scrubber contains potassium permanganate and
should not be tampered with and should not be exposed to
skin.)

PAGE 6
CaliAdapter
The CaliAdapter can be pulled apart. The part in green is made of silicone
and can be recycled in some places. Please follow local waste guidelines on
how to recycle or dispose of silicone.
The part in red cannot be recycled unfortunately and should be disposed of
with normal waste.
Bung
The Bung is made of silicone and can be recycled in some places. Please
follow local waste guidelines on how to recycle or dispose of silicone.
CaliBag®
The CaliBag® is made from a mixture of materials; aluminium,
polypropylene, and polyethylene. Unfortunately, due to the way the
CaliBag® is structured, the materials cannot be separated and therefore the
CaliBag® cannot be recycled and should be disposed of with normal waste.
Bag Adapter
The Bag Adapter is made of polypropylene which is widely recycled.
Please follow local waste guidelines on how to recycle or dispose of
polypropylene.
Blue Plugs
The Blue Plugs are made of polyethylene, this is recyclable.
Please follow local waste guidelines on how to recycle or dispose of
polyethylene.
Bag Clamps
The Bag Clamps are made of polypropylene which is widely recycled.
Please follow local waste guidelines on how to recycle or dispose of
polypropylene.
NO Scrubber
CAUTION: The NO scrubber contains potassium permanganate and should
be disposed of as hazardous waste in accordance with local waste disposal
guidelines.
Packaging
The CaliBag® Annual Service Kit comes in carboard packaging, this is widely
recycled. Please follow local waste guidelines on how to recycle or dispose
of carboard.
The NO Scrubber comes in a plasc bag which is made of polyethylene, this
is also recyclable. Please follow local waste guidelines on how to recycle or
dispose of polyethylene.
This CaliBag® Quick Start Guide is made of paper and can also be recycled
once you are nished with the kit. Please follow local waste guidelines on
how to recycle or dispose of paper.
Disposal Informaon
CaliBag®
Issue 2- August 2022, Part No: LAB836_MGC
