Behringer 112 DUAL VCO User manual

Quick Start Guide
112 DUAL VCO
Legendary Analog Dual VCO
Module for Eurorack
Controls
(1) PW MOD IN – Accepts a voltage from another module to
control the pulse width.
(2) VCO OUT – Send the VCO signal to one or two sources via
3.5 mm TS cables.
(3) WAVEFORM – Select pulse, triangle or sawtooth
waveforms for the VCO.
(4) PULSE WIDTH – Adjusts the pulse width modulation
based on the voltage received at the PW MOD IN jack.
(5) MOD MANUAL – Sets the ratio between the upper and
lower portions of the pulse wave.
(6) SYNC OUT – Sends a synchronization signal via 3.5 mm
TS cable.
(7) RANGE – Sets the pitch range of the VCO in octave steps.
(8) SYNC IN – Accepts a synchronization signal via 3.5 mm
TS cable.
(9) WEAK/STRONG – Determines the accuracy
of synchronization.
(10) PITCH – Fine tunes the pitch.
(11) MOD LEVEL – Adjusts the level of the signal connected
to the associated MOD IN jack.
(12) MOD IN – Accepts voltages that control or modulate
the VCO pitch.
Power Connection
The module comes with the required power cable for connecting
to a standard Eurorack power supply system. Follow these
steps to connect power to the module. It is easier to make
these connections before the module has been mounted into
a rack case.
1. Turn the power supply or rack case power o and
disconnect the power cable.
2. Insert the 16-pin connector on the power cable into the
socket on the power supply or rack case. The connector has
a tab that will align with the gap in the socket, so it cannot
be inserted incorrectly. If the power supply does not have
a keyed socket, be sure to orient pin 1 (-12 V) with the red
stripe on the cable.
3. Insert the 10-pin connector into the socket on the back of
the module. The connector has a tab that will align with the
socket for correct orientation.
4. After both ends of the power cable have been securely
attached, you may mount the module in a case and turn on
the power supply.
(3)
(4)
(1) (2)
(12)
(10)
(11)
(5)
(6)
(7)
(8)
(9)
V 1.0

Installation
The necessary screws are included with the module for mounting
in a Eurorack case. Connect the power cable before mounting.
Depending on the rack case, there may be a series of xed holes
spaced 2 HP apart along the length of the case, or a track that
allows individual threaded plates to slide along the length
of the case. The free-moving threaded plates allow precise
positioning of the module, but each plate should be positioned in
the approximate relation to the mounting holes in your module
before attaching the screws.
Hold the module against the Eurorack rails so that each of the
mounting holes are aligned with a threaded rail or threaded
plate. Attach the screws part way to start, which will allow
small adjustments to the positioning while you get them all
aligned. After the nal position has been established, tighten the
screws down.
Specications
Pulse Width Input
Type 2 x 3.5 mm TS jacks,
DC coupled
Impedance 70 kΩ, unbalanced
Maximum input level ±10 V, 4% per volt
VCO Output
Type 4 x 3.5 mm TS jacks,
DC coupled
Impedance 1 kΩ, unbalanced
Maximum output level 10 V p-p
Frequency range with no
external CV
10 Hz to 500 Hz
Frequency range using
external CV
1 Hz to 30 kHz
Sync Input
Type 2 x 3.5 mm TS jacks,
DC coupled
Impedance 100 kΩ, unbalanced
Maximum input level 10 V p-p
Minimum input to trigger 2.5 V p-p
Sync Output
Type 2 x 3.5 mm TS jacks,
DC coupled
Impedance 1 kΩ, unbalanced
Maximum output level 10 V p-p
Control Inputs
Type 6 x 3.5 mm TS jacks,
summed
Impedance 50 kΩ, unbalanced
CV range ±10 V, 1 V/oct
Controls
PW level -∞ to unity gain
PW manual 50% to min
Waveform Triangle, sawtooth, pulse
Range 32', 16', 8', 4', 2'
Pitch ±1 octave
Weak/strong Sync mode select
Mod level -∞ to unity gain
Power
Power supply Eurorack
Current draw 90 mA (+12 V),
70 mA (-12 V)
Physical
Dimensions 81 x 129 x 46 mm
(3.2 x 5.1 x 1.8")
Rack units 16 HP
Weight 0.2 kg (0.44 lbs)
