Behringer 130 DUAL VCA User manual

Quick Start Guide
130 DUAL VCA
Legendary Analog Dual VCA
Module for Eurorack
Controls
(1) SIG IN input jacks accept audio signals over cables with
3.5 mm TS connectors.
(2) SIG IN knobs control the gain level at the SIG IN inputs.
(3) VCA OUT (HIGH/LOW) outputs connect to the inputs
of external equipment over cables with 3.5 mm TRS
connectors. (Note that these connections are both
mono and not left/right). The HIGH mono output can be
connected to the line-level inputs of mixers, keyboard
ampliers or powered speakers. The LOW output is an
instrument-level signal that can be connected to the HI-Z
inputs of equipment such as guitar ampliers or mixers.
(4) LINEAR/EXPONENTIAL switch toggles between linear
and exponential output modes.
(5) INITIAL GAIN knob controls the gain level at the VCA
OUT jacks.
(6) MOD IN knobs control the amount of carrier signal
allowed through from the MOD IN jacks.
(7) MOD IN jacks accept carrier signals from other modules
(e.g., a sine wave at 500 Hz) to shape the volume
envelopes and waveforms of the SIG IN signals. For these
jacks, use cables with 3.5 mm TS connectors.
Power Connection
The 130 DUAL VCA comes with the required power cable for
connecting to a standard Eurorack power supply system.
Follow these steps to connect power to the module. It is easier to
make these connections before the module has been mounted
into a rack case.
1. Turn the power supply or rack case power o and
disconnect the power cable.
2. Insert the 16-pin connector on the power cable into the
socket on the power supply or rack case. The connector has
a tab that will align with the gap in the socket, so it cannot
be inserted incorrectly. If the power supply does not have
a keyed socket, be sure to orient pin 1 (-12 V) with the red
stripe on the cable.
3. Insert the 10-pin connector into the socket on the back of
the module. The connector has a tab that will align with the
socket for correct orientation.
4. After both ends of the power cable have been securely
attached, you may mount the module in a case and turn on
the power supply.
Installation
The necessary screws are included with the module for mounting
in a Eurorack case. Connect the power cable before mounting.
Depending on the rack case, there may be a series of xed holes
spaced 2 HP apart along the length of the case, or a track that
allows individual threaded plates to slide along the length
of the case. The free-moving threaded plates allow precise
positioning of the module, but each plate should be positioned in
the approximate relation to the mounting holes in your module
before attaching the screws.
Hold the module against the Eurorack rails so that each of the
mounting holes are aligned with a threaded rail or threaded
plate. Attach the screws part way to start, which will allow
small adjustments to the positioning while you get them all
aligned. After the nal position has been established, tighten the
screws down.
(1)
(2)
(4)
(6)
(7)
(5)
(3)

Specications
Signal Connections
Signal in 6 x 3.5 mm jack, summed
Impedance > 50 kΩ unbalanced
Maximum input level +18 dBu @ unity gain
VCA out high / low 4 x 3.5 mm jack
High output
Impedance 1 kΩ unbalanced
Low output
Impedance 3 kΩ unbalanced
High maximum
output level +18 dBu
Low maximum
output level -2 dBu
High output noise < -66 dBu, 22 Hz - 22 kHz
Low output noise < -86 dBu, 22 Hz - 22 kHz
Mod in 6 x 3.5 mm jack
Impedance > 50 kΩ unbalanced
CV input range 0 V to +10 V
CV scaling in
EXP mode Typically 1 V/10 dB
Controls
Initial gain
2 x rotary knob
Linear / exponential,
switchable
Sig in level 6 x rotary knob
Mod in level 6 x rotary knob
Linear / exponential CV 2 x sliding switch
Power
Power supply Eurorack
Current draw 30 mA (+12 V), 20 mA (-12 V)
Physical
Dimensions (H x W x D) 44 x 81 x 129 mm
(1.7 x 3.2 x 5.1")
Rack units 16 HP
Weight 0.18 kg (0.4 lbs)
