Beko BKK 2127 P User manual

Household Steam Iron
Паровой утюг для
бытового применения
BKK 2126 P
BKK 2127 P

This product has been produced in environmentally friendly, modern facilities
Please read this manual first!
Dear Customer,
We hope that your product which has been manufactured in modern facili-
ties and passed through a strict quality control procedure will give you the
best results.
Therefore, we advise you to read through this manual carefully before using
your product and keep it for future reference.
This operation manual will...
...help you use your machine in a fast and safe way.
• Please read the Operation Manual before installing and starting your
machine.
• Particularly follow the instructions related to safety.
• Keep this Operating Manual within easy reach. You may need it in the
future.
• Please read all additional documents supplied with this machine.
Please note that this Operating Manual may be applicable for several other
models. Differences between models will be identified in the manual.

1
Contents
1 Safety Warnings 2
2 Technical Specifications 3-4
4 Operating The Iron 8-14
3 Important Points About Operating The Iron 4-7
5 Operations After Ironing 14-15

2
1Safety Warnings
• Always use earthed socket. When
using extension cable, make sure
that it is earthed and has a minimum
1 mm2 cable section.
• When the ironing is finished, always
pour out the remaining water. The
iron must be unplugged during this
operation.
• When filling and pouring water,
always unplug the iron.
• Do not leave the iron unattended
when plugged.
• Keep the iron in upright position
until it cools down after ironing and
in short periods when it is not used
during ironing.
• Check whether the network volt-
age is in line with the figure given in
the rating label at the backside of
your iron.
• Do not leave hot iron in reach of
children.
• If the network cable has been
damaged, the Authorised Service
must replace it in order to avoid any
dangerous situation.
• This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.

3
2Technical Specifications
1Network cable
Network warning light
Temperature setting button
Steam setting button
Transparent water tank
Sole plate
Water spray
Water filling cap
Shock steam button
Spray button
Auto-off and thermostat
warning light
Water softening unit
Water filling vessel
2
3
4
5
6
Voltage : 220 - 240 V ~ / 50 Hz.
Power : 1800 W
Soleplate : Stainless Steel (BKK 2127
P) CERAMICA (BKK 2126 P)
Temperature setting with automa-
tic thermostat : Yes
Dry ironing : Yes
Shock steam : Yes
Water spray : Yes
Auto-Off feature : Yes
Anti-drip feature : Yes
Thermal fuse : Yes
Vertical steaming : Yes
Water softening unit : Yes
7
8
9
1 0
1 1
1 2
1 3
Figures that have been stated in the product marking or in other printed documents provided
with the product are those that have been obtained in laboratory environment according to the
related standards. These figures may change according to the product operating conditions and
environmental conditions.
1
2
3
4
5
8
9
10
11
12
13
6
7

4
3Important Points About Operating The Iron
• Your iron can overflow when filled with too
much water. To avoid this, make sure that
while the iron is standing upright you fill water
only up to the maximum line on the transpar-
ent water tank.
• The soleplate temperature must reach a
certain level in order for the iron to generate
steam. When the temperature setting is on the
steam mark and the steam button is on, “anti
drip” feature will prevent water drips until the
iron is sufficiently hot.
• In the first use, fill the iron with tap water and
vaporize twice before ironing. At the same
time, use the shock steam button frequently.
This will both increase steam performance and
clear away the dust that may have accumulat-
ed in the steam channels. After this operation,
always use the softened water that you will
obtain from the water-softening unit provided
with your iron. Otherwise, steam channels of
the iron will calcify in time to finally become
unusable. Never use the commercial ironing
water with chemical additives and aroma.
• There may be a slight odour during the first
use of your iron which will disappear after
using a few times.
• If you run out of water during ironing, add
water after you unplug the iron. You do not
need to wait for cooling down.
• If spraying is not functioning properly, put
your finger over the spray hole and press the
spray button a few times in order to remove
the clogging.
• While ironing, start with the clothes that
need warm ironing and go along with the ones
that need hot ironing. When the setting is low-
ered at high temperatures, you have to allow
3-4 minutes for the temperature to fall.
• A “click” sound will be heard when the sole-
plate temperature is changed because of the
anti-drip feature of your iron. Which is normal
operating feature.
Operating The Iron
4
Start with filling water in the iron. Al-
ways do the following checks before
filling water:
Water tank must be completely emp-
ty and the iron must be unplugged.
You can pour out the water in the
iron by opening the water-filling cap
and tilting the iron forward.
Then fill tap water into the upper part
of the water-softening unit that was
provided with your iron and place it
over the lower part. In a short time,
the water in the upper part shall
be filtered down to the lower part.
(Figure 2)
Open the water filling cap on the iron
1
2

5
and slightly lean the horizontal iron
forward to fill the water tank with
the softened water whose lime has
been filtered as shown in Figure 2.
(Figure 3)
Make sure that when the iron is in
upright position the water does not
go above the maximum line on the
transparent water tank.
Even when ironing without steam,
fill the iron with water in order to use
the water spray when necessary.
When using the iron for the first time,
fill the water tank twice with tap wa-
ter and vaporize it. This is important
for cleaning the water channels and
for steam performance. Press shock
button and shake the iron from time
to time during vaporisation. Always
use softened water in the following
ironing operations.
Temperature setting
After inserting the plug in an earthed
socket, set the temperature setting
using the setting button according
to the type of clothes and place the
iron in upright position. When steam
ironing, temperature setting must be
at •• or above.
Network warning light will be on as
long as the iron remains plugged in.
When temperature setting is done;
thermostat light will be on until the
base reaches the set temperatu-
re and will remain on during the
periods in which the heating element
operates during ironing. You may
start ironing after the thermostat light
goes off.
Steam Ironing
When the thermostat light goes off
while the steam setting button is
in position, temperature is
sufficient to generate steam. You
can have continuous steam at this
position. (Figure 4)
Dry ironing
You can do dry ironing when the ste-
am setting button is in position.
Make sure you fill water in the tank in
order to use the spray button when
MAX
3
MAX
Min
Max
Auto
4

6
necessary.
(Figure 5)
Shock steam
During steam ironing, pressing the
shock steam button will generate
very powerful steam to smooth the
much-crinkled fabrics. Allow 5 to 10
seconds after pressing 4-5 times.
When using the iron for the first
time, the first few pushes may not
generate shock steam. Shock steam
can only be used when temperature
setting is at position •• or above.
(Figure 6)
Water spray
You can make the fabric wet with
water sprayed from the front of the
iron by pressing the spray button
while dry or steam ironing.
Vertical steam
Shock steam button operates also
when the iron is in upright position.
This helps refreshing the ironing of
some clothes while they are on the
hanger by taking the iron close to the
cloth and pressing the shock steam
button. This feature can be used for
creased curtains as well. (Figure 7)
Caution: Do not spray steam to
clothes or fabrics that are on people
or on pets. The steam has a very
high temperature. This function
generates extra steam to remove the
creases on the clothes on hangers,
the curtains or the hanging fabrics.
Water tank
Since your iron has a high steam
performance, the tank may run out
of water during ironing. In that case,
just unplug the iron to refill the tank.
The amount of water in the iron
can be viewed from the transparent
water tank when holding the iron in
vertical position.
Thermal fuse
Your iron has been equipped with an
additional thermal fuse as a further
safety device in order to prevent
overheating in case thermostat does
not operate for some reason. If your
iron fails to heat, the fuse may be off,
Max
Min
Auto
5
6
C_d
CWn
7kje
7

7
contact the technical service.
Temperature setting
The following table must be obser-
ved when doing temperature setting
and steam ironing.
Auto-off
The iron has been equipped with
automatic circuit breaker against the
risk of being forgotten when plugged
in.
8 minutes
When you plug in the iron and leave
it in vertical position, it will reach the
set temperature in 2-3 minutes. If it
is not moved for about 8 minutes,
the electric current will be discon-
nected and the iron shall cool down
as if it has been forgotten plugged.
(Figure 8)
2 minutes
When you plug in the iron and leave
it in horizontal, ironing position for
2 minutes, the electric current will
be disconnected and the iron shall
cool down as if it has been forgotten
plugged.
30 seconds
If, after the initial warming, your iron
is not moved for about 30 seconds
in horizontal, ironing position, electric
current will be disconnected. (Figure
9)
In all three cases, when the electric
current is disconnected, Auto-off
light will flash. In that case, if the
Fabric Type Temperature Setting Steam Setting
Synthetic • Dry iron
Silk • Dry iron
Woollen •• Steam iron
recommended
Cotton ••• Steam iron
Linen – Jean Max Steam iron
8
9

8
iron is moved in horizontal position,
heating will restart. (Figure 10)
Water softening unit
When the tap water in the iron has
been vaporised, its lime content shall
accumulate in the steam channels,
which will lower steam performance,
and to turn yellowish with the effect
of heat; and small particles that may
flow out with the steam from time to
time may stain the cloth.
More importantly, your iron may
become unusable if steam channels
are completely clogged in time.
Therefore, always use decalcified
water in your iron. You can use the
water-softening unit supplied with
your iron for that purpose. Place the
water-filling unit on the water-filling
vessel and fill it with tap water. Tap
water will be slowly filtered down
the water-filling vessel, leaving its
lime content on the filter. In order
to remove the lime on the filter, you
should dissolve 3 teaspoons of table
salt in water and pass this water
through the filter followed by rinsing
a few times, every 2-4 months
depending on the frequency of using
the iron.
10
Operations After Ironing
5
Unplug the iron after you have
finished the ironing.
Completely pour out the water in
the iron by holding it upside down.
(Figure 11)
Put the steam setting button at
maximum position.
Wipe the iron using a dry or damp
cloth after ironing.
It is recommended for the mainte-
nance of steam channels to fill the
iron with softened water twice or
three times a year, take the setting to
maximum, use the shock steam but-
ton frequently to vaporize the water
and shake the iron while doing so.
(Figure 12)
11
12
