Belkin F5U303 User manual

Make sure you have the
following package contents:
Package Contents 1 Setup for Windows Vista Users 3Setup for Windows Vista Users 2
Wireless
USB Hub
Power
Supply
Mini-USB Cable
(A to Mini-B)
Quick
Installation
Guide
User Manual
A. Double-click the “Wireless USB Manager for Windows Vista” icon
found in the Windows system tray at the bottom-right corner of the
Windows desktop.
B. Once the Wireless USB Manager opens, click on the
“New Connection” button.
Note: You will be asked to select a method of Wireless Security Association.
The Belkin Hub currently supports two methods: PIN Association and Cable
Association. PIN Association requires you to enter the PIN number found
on the bottom of the Hub. Cable Association requires you to physically
connect (associate) the Hub to the computer with the enclosed mini-USB
cable. Either process will ensure a secure wireless connection for future use.
Numeric Compare Association is not applicable.
PIN-Association Process
1. Connect the power supply to the Hub.
2. Using the PIN-Association option, you will be prompted to enter the
PIN found on the bottom of your Belkin Wireless USB Hub. Enter this
number into the provided space and click “Next”.
3. Your Hub will now be wirelessly connected to your computer, and you
can now connect your devices to the Hub and access them wirelessly.
Setup for Windows Vista™ Users
Software and drivers for your Belkin Wireless USB Hub come preinstalled
on your computer. To set up the Hub, follow the instructions below.
Setup for Windows Vista Users 4
Now you can print, play music, scan, download photos, and burn CDs
without the hassle of connecting cables. With the Belkin Wireless USB
Hub, you have the freedom to roam and stay connected.

F5U303
Belkin Tech Support
US: 800-223-5546, ext. 2263
310-898-1100, ext. 2263
UK: 0845 607 77 87
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 65 64857620
Europe: www.belkin.com/support
© 2007 Belkin International, Inc. All rights reserved. All trade names are registered trademarks
of respective manufacturers listed. Windows Vista is either a registered trademark or
trademark of Microsoft Corporation in the United States and/or other countries. P75559-A
Wireless USB Hub
Start Here
Quick Installation Guide
Wireless USB Hub
This guide will lead you through the basic steps
needed to set up the Belkin Wireless USB Hub.
For further information or greater detail regarding
configuration, please refer to the Belkin User Manual
for this product.
Setup for Windows Vista Users 5 Setup for Windows Vista Users 6
Cable-Association Process
1. Connect the power supply to the Hub.
2. Attach the mini-USB cable to the mini-USB port on the side of the Hub
and the other end to your computer’s built-in USB port. This will allow
your computer to recognize the Hub.
3. The device setup will recognize your Hub as a “Belkin Wireless USB
Hub”. Change the device name if needed, for example, “Living Room”.
You can also change the detection method of the Wireless USB Hub.
Click “Finish”.
4. Remove the mini-USB cable.
5. Once this process is complete, return to the Wireless USB Manager.
You should see an icon for the Belkin Wireless USB Hub. If there
are two green arrows pointing to each other, you have successfully
connected to the Belkin Wireless USB Hub.
6. You can now plug your USB devices into the Hub and access
them wirelessly.
Connect the
power supply
Connect
mini-USB cable
