BeLuce SCALA User manual

INSTALLATION INSTRUCTIONS
BeLuce Canada Inc., 3900 14th Avenue, Unit 1, Markham, ON L3R 4R3 P: [phone] F: [phone]
SCALA
STAIRWELL LED
30W & 40W MODELS
120V-277V
AC & EM, 2FT
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
1.Do not let power cords touch hot surfaces.
2.Do not mount near gas or electric heaters.
3.Equipment should be mounted in locations and at heights where unauthorized personnel will not readily subject it to tampering.
4.The use of accessory equipment not recommended by BeLuce Canada Inc., may cause an unsafe condition, and will void the warranty.
5.Do not use this equipment for other than its intended purpose.
6.Servicing of this equipment should be performed by qualified service personnel.
SAVE THESE INSTRUCTIONS!
First make sure power is turned off!
1. Remove lens.
2. Carefully remove the LED reflector from housing. You’ll find the mounting hardware bag needed for step 9.
3. Extract mounting hardware.
4. Fasten fixture to mounting surface.
5. Prepare fixture for wiring / hang reflector from internal clips. Connect AC supply and ground as labeled on the provided wire leads. CAP unused
wires!
CAUTION! Failure to insulate unused wire may result in a shock hazard or unsafe condition as well as equipment failure. Route wires and secure
them in place.
6. Install lens clips.
7. Install sensor’s gasket and lens.
8. Secure lens with clips. Reposition the lens and snap each of the four (4) clips into place (a “clack” sound is made).
9. Remove protective film from sensor.
10. Secure sensor with locknut and install sensor’s lens.
11. Turn on AC.
SAVE THESE INSTRUCTIONS!
No user serviceable parts. Refer service to a qualified service technician.
Read instructions prior to installing and/or operating this device. Installation
should be performed by a licensed electrician/installer in accordance with
local codes.
926000388
LED | Wet | 2 FT

TYPICAL INSTALLATION
BeLuce Canada Inc., 3900 14th Avenue, Unit 1, Markham, ON L3R 4R3 P: [phone] F: [phone]
1. REMOVE LENS 2. REMOVE LED REFLECTOR FROM HOUSING
BE CAREFUL TO NOT TOUCH THE LEDs!
3. EXTRACT MOUNTING HARDWARE,
INSTALL CONDUIT FITTING
4. CONNECT TO POWER
5. INSTALL LENS CLIPS 6. INSTALL SENSOR’S GASKET & LENS
N
L
CONNECT CABLES
FROM MAIN AC
INSIDE UNIT
G
926000388

TYPICAL INSTALLATION
BeLuce Canada Inc., 3900 14th Avenue, Unit 1, Markham, ON L3R 4R3 P: [phone] F: [phone]
7. SECURE LENS WITH CLIPS 8. REMOVE PROTECTIVE FILM FROM SENSOR
9. SECURE SENSOR WITH LOCKNUT. INSTALL SENSOR’S LENS.
926000388

MOUNTING
BeLuce Canada Inc., 3900 14th Avenue, Unit 1, Markham, ON L3R 4R3 P: [phone] F: [phone]
926000388

MOUNTING
BeLuce Canada Inc., 3900 14th Avenue, Unit 1, Markham, ON L3R 4R3 P: [phone] F: [phone]
926000388

MOUNTING
BeLuce Canada Inc., 3900 14th Avenue, Unit 1, Markham, ON L3R 4R3 P: [phone] F: [phone]
L
G
N
1/2” IP STEM
1/2” IP LOCKNUT
CONNECT POWER IN ACCORDANCE
WITH ALL CODES AND LABELS
(120-277VAC)
J-BOX PROVIDED AND INSTALLED BY OTHERS
INSTALL CROSS BAR WITH
SCREWS FROM THE J-BOX
(2) SCREWS IN J-BOX (BY OTHERS)
CANOPY
SET SCREW FOR SLIP RING
SLIP RING (TO POSITION CANOPY)
LOCK NUT (FOR DOUBLE LOCK ON STEM)
SINGLE PENDANT
926000388
