BenQ RS232 Commands User manual

LU960
Projector RS232 Command Control
Installation Guide

2
Table of Contents
Introduction ............................................................................................................................................. 3
Wire arrangement........................................................................................................................................................3
RS232 pin assignment..................................................................................................................................................3
Connections and communication settings......................................................................................... 4
RS232 serial port with a crossover cable ...............................................................................................................4
Settings ..................................................................................................................................................................4
RS232 via LAN..............................................................................................................................................................6
Settings ..................................................................................................................................................................6
RS232 via HDBaseT.....................................................................................................................................................6
Settings ..................................................................................................................................................................6
Command table....................................................................................................................................... 8

3
Introduction
The document describes how to control your BenQ projector via RS232 from a computer. Follow the
procedures to complete the connection and settings first, and refer to the command table for RS232
commands.
Available functions and commands vary by model. Check the specifications and user manual of the purchased projector for
product functions.
Wire arrangement
Wire Arrangement
P1
Color
P2
1
Black
1
2
Brown
3
3
Red
2
4
Orange
4
5
Yellow
5
6
Green
6
7
Blue
7
8
Purple
8
9
Gray
9
Case
Drain wire
Case
RS232 pin assignment
Pin
Description
Pin
Description
1
NC
2
RXD
3
TXD
4
NC
5
GND
6
NC
7
RTS
8
CTS
9
NC

4
Connections and communication settings
Choose one of the connections and set up properly before RS232 control.
RS232 serial port with a crossover cable
Settings
On-screen images in this document are for reference only. The screens may vary depending on your Operating System,
I/O ports used for connection, and the specifications of the connected projector.
1. Determine the COM Port name used for the RS232 communications in Device Manager.
PC or laptop
Communication cable (crossover)
D-Sub 9 pin (female)
D-Sub 9 pin (male) on a projector

5
2. Choose Serial and the corresponding COM port as the communication port. In this given example,
COM6 is selected.
3. Finish Serial port setup.
Baud rate
9600 / 14400 / 19200 / 38400 / 57600 / 115200 bps
Check the baud rate of the connected projector from its OSD menu.
Data length
8 bit
Parity check
None
Stop bit
1 bit
Flow control
None

6
RS232 via LAN
Settings
1. Find the Wired LAN IP address of the connected projector from the OSD menu and make sure the
projector and the computer are within the same network.
2. Input 8000 in the TCP port # field.
RS232 via HDBaseT
Settings
1. Determine the COM Port name used for the RS232 communications in Device Manager.
2. Choose Serial and the corresponding COM port as the communication port. In this given example,
COM6 is selected.
PC or laptop
RJ45 port on a projector
LAN cable
PC or laptop
HDBaseT compatible device
D-Sub 9 pin
RJ45
RJ45 port on a projector
LAN cable
D-Sub 9 pin

7
3. Finish Serial port setup.
Baud rate
9600 / 14400 / 19200 / 38400 / 57600 / 115200 bps
Check the baud rate of the connected projector from its OSD menu.
Data length
8 bit
Parity check
None
Stop bit
1 bit
Flow control
None

8
Command table
•Available features differ by projector specification, input sources, settings, etc..
•Commands are working if the standby power is 0.5W or a supported baud rate of the projector is set.
•Uppercase, lowercase, and a mixture of both types of characters are accepted for a command.
•If a command format is illegal, it will echo Illegal format.
•If a command with correct format is not valid for the projector model, it will echo Unsupported item.
•If a command with correct format cannot be executed under certain condition, it will echo Block item.
•If RS232 control is performed via LAN, a command works whether it starts and ends with <CR>. All the commands and
behaviors are identical with the control through a serial port.
Function
Type
Operation
ASCII
Support
Power
Write
Power On
<CR>*pow=on#<CR>
Yes
Write
Power off
<CR>*pow=off#<CR>
Yes
Read
Power Status
<CR>*pow=?#<CR>
Yes
Source
Selection
Write
COMPUTER/YPbPr
<CR>*sour=RGB#<CR>
Yes
Write
COMPUTER
2/YPbPr2
<CR>*sour=RGB2#<CR>
No
Write
COMPUTER
3/YPbPr3
<CR>*sour=RGB3#<CR>
No
Write
Component
<CR>*sour=ypbr#<CR>
No
Write
Component2
<CR>*sour=ypbr2#<CR>
No
Write
DVI-A
<CR>*sour=dviA#<CR>
No
Write
DVI-D
<CR>*sour=dvid#<CR>
No
Write
HDMI(MHL)
<CR>*sour=hdmi#<CR>
Yes
Write
HDMI 2(MHL2)
<CR>*sour=hdmi2#<CR>
Yes
Write
Composite
<CR>*sour=vid#<CR>
No
Write
S-Video
<CR>*sour=svid#<CR>
No
Write
Network
<CR>*sour=network#<CR>
No
Write
USB Display
<CR>*sour=usbdisplay#<CR>
No
Write
USB Reader
<CR>*sour=usbreader#<CR>
No
Write
HDBaseT
<CR>*sour=hdbaset#<CR>
Yes
Write
DisplayPort
<CR>*sour=dp#<CR>
Yes
Write
3G-SDI
<CR>*sour=sdi#<CR>
No
Write
Smart System
<CR>*sour=smartsystem#<CR>
No
Read
Current source
<CR>*sour=?#<CR>
Yes
Audio
Control
Write
Mute On
<CR>*mute=on#<CR>
Yes
Write
Mute Off
<CR>*mute=off#<CR>
Yes

9
Read
Mute Status
<CR>*mute=?#<CR>
Yes
Write
Volume +
<CR>*vol=+#<CR>
Yes
Write
Volume -
<CR>*vol=-#<CR>
Yes
Write
Volume level for
customer
<CR>*vol=value#<CR>
Yes
Read
Volume Status
<CR>*vol=?#<CR>
Yes
Write
Mic.Volume +
<CR>*micvol=+#<CR>
No
Write
Mic.Volume -
<CR>*micvol=-#<CR>
No
Read
Mic.Volume Status
<CR>*micvol=?#<CR>
No
Audio source
select
Write
Audio pass Through
off
<CR>*audiosour=off#<CR>
Yes
Write
Audio-Computer1
<CR>*audiosour=RGB#<CR>
Yes
Write
Audio-Computer2
<CR>*audiosour=RGB2#<CR>
No
Write
Audio-Video/S-Video
<CR>*audiosour=vid#<CR>
No
Write
Audio-Component
<CR>*audiosour=ypbr#<CR>
No
Write
Audio-HDMI
<CR>*audiosour=hdmi#<CR>
Yes
Write
Audio-HDMI2
<CR>*audiosour=hdmi2#<CR>
Yes
Write
Audio-HDMI3
<CR>*audiosour=hdmi3#<CR>
No
Write
DisplayPort
<CR>*audiosour=dp#<CR>
Yes
Write
HDBaseT
<CR>*audiosour=hdbaset#<CR>
Yes
Read
Audio pass Status
<CR>*audiosour=?#<CR>
Yes
Picture Mode
Write
Dynamic
<CR>*appmod=dynamic#<CR>
No
Write
Presentation
<CR>*appmod=preset#<CR>
Yes
Write
sRGB
<CR>*appmod=srgb#<CR>
Yes
Write
Bright
<CR>*appmod=bright#<CR>
Yes
Write
Living Room
<CR>*appmod=livingroom#<CR>
No
Write
Game
<CR>*appmod=game#<CR>
No
Write
Cinema(Rec. 709)
<CR>*appmod=cine#<CR>
No
Write
Standard
<CR>*appmod=std#<CR>
No
Write
Football
<CR>*appmod=football#<CR>
No
Write
Football Bright
<CR>*appmod=footballbt#<CR>
No
Write
DICOM
<CR>*appmod=dicom#<CR>
Yes
Write
THX
<CR>*appmod=thx#<CR>
No
Write
Silence mode
<CR>*appmod=silence#<CR>
No
Write
DCI-P3
mode(D.Cinema)
<CR>*appmod=dci-p3#<CR>
No
Write
Vivid
<CR>*appmod=vivid#<CR>
No

10
Write
Infographic
<CR>*appmod=infographic#<CR>
Yes
Write
User1
<CR>*appmod=user1#<CR>
Yes
Write
User2
<CR>*appmod=user2#<CR>
Yes
Write
User3
<CR>*appmod=user3#<CR>
No
Write
ISF Day
<CR>*appmod=isfday#<CR>
No
Write
ISF Night
<CR>*appmod=isfnight#<CR>
No
Write
3D
<CR>*appmod=threed#<CR>
Yes
Write
Sport
<CR>*appmod=sport#<CR>
No
Write
HDR10
<CR>*appmod=hdr10<CR>
Yes
Write
HLG
<CR>*appmod=hlg<CR>
Yes
Write
Video
<CR>*appmod=video<CR>
Yes
Read
Picture Mode
<CR>*appmod=?#<CR>
Yes
Setting
Write
Contrast +
<CR>*con=+#<CR>
Yes
Write
Contrast -
<CR>*con=-#<CR>
Yes
Write
Set Contrast value
<CR>*con=5#<CR>
Yes
Read
Contrast value
<CR>*con=?#<CR>
Yes
Write
Brightness +
<CR>*bri=+#<CR>
Yes
Write
Brightness -
<CR>*bri=-#<CR>
Yes
Write
Set Brightness value
<CR>*bri=5#<CR>
Yes
Read
Brightness value
<CR>*bri=?#<CR>
Yes
Write
Color +
<CR>*color=+#<CR>
Yes
Write
Color -
<CR>*color=-#<CR>
Yes
Write
Set Color value
<CR>*color=5#<CR>
Yes
Read
Color value
<CR>*color=?#<CR>
Yes
Write
Sharpness +
<CR>*sharp=+#<CR>
Yes
Write
Sharpness -
<CR>*sharp=-#<CR>
Yes
Write
Set Sharpness value
<CR>*sharp=5#<CR>
Yes
Read
Sharpness value
<CR>*sharp=?#<CR>
Yes
Write
Flesh Tone +
<CR>*fleshtone=+#<CR>
No
Write
Flesh Tone -
<CR>*fleshtone=-#<CR>
No
Write
Set Flesh Tone value
<CR>*fleshtone=5#<CR>
No
Read
Flesh Tone value
<CR>*fleshtone=?#<CR>
No
Write
Color
Temperature-Warmer
<CR>*ct=warmer#<CR>
No
Write
Color
Temperature-Warm
<CR>*ct=warm#<CR>
Yes
Write
Color
<CR>*ct=normal#<CR>
Yes

11
Temperature-Normal
Write
Color
Temperature-Cool
<CR>*ct=cool#<CR>
Yes
Write
Color
Temperature-Cooler
<CR>*ct=cooler#<CR>
No
Write
Color
Temperature-lamp
native
<CR>*ct=native#<CR>
No
Read
Color Temperature
Status
<CR>*ct=?#<CR>
Yes
Write
Aspect 4:3
<CR>*asp=4:3#<CR>
Yes
Write
Aspect 16:6
<CR>*asp=16:6#<CR>
No
Write
Aspect 16:9
<CR>*asp=16:9#<CR>
Yes
Write
Aspect 2.35:1
<CR>*asp=2.35#<CR>
No
Write
Aspect 16:10
<CR>*asp=16:10#<CR>
Yes
Write
Aspect Auto
<CR>*asp=AUTO#<CR>
Yes
Write
Aspect Real
<CR>*asp=REAL#<CR>
Yes
Write
Aspect Letterbox
<CR>*asp=LBOX#<CR>
No
Write
Aspect Wide
<CR>*asp=WIDE#<CR>
No
Write
Aspect Anamorphic
<CR>*asp=ANAM#<CR>
No
Write
Aspect Anamorphic
2.35
<CR>*asp=ANAM2.35#<CR>
No
Write
Aspect Anamorphic
16:9
<CR>*asp=ANAM16:9#<CR>
No
Write
Aspect 2.4:1
<CR>*asp=2.4#<CR>
Yes
Read
Aspect Status
<CR>*asp=?#<CR>
Yes
Write
Vertical Keystone +
<CR>*vkeystone=+#<CR>
Yes
Write
Vertical Keystone -
<CR>*vkeystone=-#<CR>
Yes
Write
Set Vertical Keystone
value
<CR>*vkeystone=value#<CR>
Yes
Read
Vertical Keystone
value
<CR>*vkeystone=?#<CR>
Yes
Write
Horizontal Keystone +
<CR>*hkeystone=+#<CR>
Yes
Write
Horizontal Keystone -
<CR>*hkeystone=-#<CR>
Yes
Write
Set Horizontal
Keystone value
<CR>*hkeystone=value#<CR>
Yes
Read
Horizontal Keystone
<CR>*hkeystone=?#<CR>
Yes

12
value
Write
Overscan Adjustment
+
<CR>*overscan=+#<CR>
Yes
Write
Overscan Adjustment
-
<CR>*overscan=-#<CR>
Yes
Read
Overscan Adjustment
value
<CR>*overscan=?#<CR>
Yes
Write
4 Corners Top-Left-X
Decrease
<CR>*cornerfittlx=-#<CR>
Yes
Write
4 Corners Top-Left-X
Increase
<CR>*cornerfittlx=+#<CR>
Yes
Read
4 Corners Top-Left-X
Status
<CR>*cornerfittlx=?#<CR>
Yes
Write
4 Corners Top-Left-Y
Decrease
<CR>*cornerfittly=-#<CR>
Yes
Write
4 Corners Top-Left-Y
Increase
<CR>*cornerfittly=+#<CR>
Yes
Read
4 Corners Top-Left-Y
Status
<CR>*cornerfittly=?#<CR>
Yes
Write
4 Corners
Top-Right-X Decrease
<CR>*cornerfittrx=-#<CR>
Yes
Write
4 Corners
Top-Right-X Increase
<CR>*cornerfittrx=+#<CR>
Yes
Read
4 Corners
Top-Right-X Status
<CR>*cornerfittrx=?#<CR>
Yes
Write
4 Corners Top-Right-Y
Decrease
<CR>*cornerfittry=-#<CR>
Yes
Write
4 Corners Top-Right-Y
Increase
<CR>*cornerfittry=+#<CR>
Yes
Read
4 Corners Top-Right-Y
Status
<CR>*cornerfittry=?#<CR>
Yes
Write
4 Corners
Bottom-Left-X
Decrease
<CR>*cornerfitblx=-#<CR>
Yes
Write
4 Corners
Bottom-Left-X
Increase
<CR>*cornerfitblx=+#<CR>
Yes
Read
4 Corners
<CR>*cornerfitblx=?#<CR>
Yes

13
Bottom-Left-X Status
Write
4 Corners
Bottom-Left-Y
Decrease
<CR>*cornerfitbly=-#<CR>
Yes
Write
4 Corners
Bottom-Left-Y
Increase
<CR>*cornerfitbly=+#<CR>
Yes
Read
4 Corners
Bottom-Left-Y Status
<CR>*cornerfitbly=?#<CR>
Yes
Write
4 Corners
Bottom-Right-X
Decrease
<CR>*cornerfitbrx=-#<CR>
Yes
Write
4 Corners
Bottom-Right-X
Increase
<CR>*cornerfitbrx=+#<CR>
Yes
Read
4 Corners
Bottom-Right-X
Status
<CR>*cornerfitbrx=?#<CR>
Yes
Write
4 Corners
Bottom-Right-Y
Decrease
<CR>*cornerfitbry=-#<CR>
Yes
Write
4 Corners
Bottom-Right-Y
Increase
<CR>*cornerfitbry=+#<CR>
Yes
Read
4 Corners
Bottom-Right-Y Status
<CR>*cornerfitbry=?#<CR>
Yes
Write
Digital Zoom In
<CR>*zoomI#<CR>
Yes
Write
Digital Zoom out
<CR>*zoomO#<CR>
Yes
Write
Auto
<CR>*auto#<CR>
Yes
Write
Brilliant color +
<CR>*BC=+#<CR>
Yes
Write
Brilliant color -
<CR>*BC=-#<CR>
Yes
Write
Brilliant color set
value
<CR>*BC=value#<CR>
Yes
Read
Brilliant color status
<CR>*BC=?#<CR>
Yes
Write
Auto(HDR)
<CR>*hdr=auto#<CR>
Yes
Write
SDR
<CR>*hdr=sdr#<CR>
Yes
Write
HDR10
<CR>*hdr=hdr#<CR>
Yes

14
Write
HLG
<CR>*hdr=hlg#<CR>
Yes
Write
HDR status
<CR>*hdr=?#<CR>
Yes
Write
Reset current picture
settings
<CR>*rstcurpicsetting#<CR>
Yes
Write
Reset all picture
settings
<CR>*rstallpicsetting#<CR>
Yes
Operation
Settings
Write
Projector
Position-Front Table
<CR>*pp=FT#<CR>
Yes
Write
Projector
Position-Rear Table
<CR>*pp=RE#<CR>
Yes
Write
Projector
Position-Rear Ceiling
<CR>*pp=RC#<CR>
Yes
Write
Projector
Position-Front Ceiling
<CR>*pp=FC#<CR>
Yes
Read
Projector Position
Status
<CR>*pp=?#<CR>
Yes
Write
Quick cooling on
<CR>*qcool=on<CR>
No
Write
Quick cooling off
<CR>*qcool=off<CR>
No
Read
Quick cooling status
<CR>*qcool=?<CR>
No
Write
Quick auto search
<CR>*QAS=on#<CR>
Yes
Write
Quick auto search
<CR>*QAS=off#<CR>
Yes
Read
Quick auto search
status
<CR>*QAS=?#<CR>
Yes
Write
Menu Position -
Center
<CR>*menuposition=center#<CR>
Yes
Write
Menu Position -
Top-Left
<CR>*menuposition=tl#<CR>
Yes
Write
Menu Position -
Top-Right
<CR>*menuposition=tr#<CR>
Yes
Write
Menu Position -
Bottom-Right
<CR>*menuposition=br#<CR>
Yes
Write
Menu Position -
Bottom-Left
<CR>*menuposition=bl#<CR>
Yes
Read
Menu Position Status
<CR>*menuposition=?#<CR>
Yes
Write
Direct Power On-on
<CR>*directpower=on#<CR>
Yes
Write
Direct Power On-off
<CR>*directpower=off#<CR>
Yes
Read
Direct Power
<CR>*directpower=?#<CR>
Yes

15
On-Status
Write
Signal Power On-on
<CR>*autopower=on#<CR>
Yes
Write
Signal Power On-off
<CR>*autopower=off#<CR>
Yes
Read
Signal Power
On-Status
<CR>*autopower=?#<CR>
Yes
Write
Standby
Settings-Network on
<CR>*standbynet=on#<CR>
No
Write
Standby
Settings-Network off
<CR>*standbynet=off#<CR>
No
Read
Standby
Settings-Network
Status
<CR>*standbynet=?#<CR>
No
Write
Standby
Settings-Microphone
on
<CR>*standbymic=on#<CR>
No
Write
Standby
Settings-Microphone
off
<CR>*standbymic=off#<CR>
No
Read
Standby
Settings-Microphone
Status
<CR>*standbymic=?#<CR>
No
Write
Standby
Settings-Monitor Out
on
<CR>*standbymnt=on#<CR>
No
Write
Standby
Settings-Monitor Out
off
<CR>*standbymnt=off#<CR>
No
Read
Standby
Settings-Monitor Out
Status
<CR>*standbymnt=?#<CR>
No
Baud Rate
Write
2400
<CR>*baud=2400#<CR>
Yes
Write
4800
<CR>*baud=4800#<CR>
Yes
Write
9600
<CR>*baud=9600#<CR>
Yes
Write
14400
<CR>*baud=14400#<CR>
Yes
Write
19200
<CR>*baud=19200#<CR>
Yes
Write
38400
<CR>*baud=38400#<CR>
Yes
Write
57600
<CR>*baud=57600#<CR>
Yes

16
Write
115200
<CR>*baud=115200#<CR>
Yes
Read
Current Baud Rate
<CR>*baud=?#<CR>
Yes
Lamp
Control
Read
Lamp Hour
<CR>*ltim=?#<CR>
Yes
Read
Lamp2 Hour
<CR>*ltim2=?#<CR>
No
Write
Normal mode
<CR>*lampm=lnor#<CR>
Yes
Write
Eco mode
<CR>*lampm=eco#<CR>
Yes
Write
SmartEco mode
<CR>*lampm=seco#<CR>
No
Write
SmartEco mode 2
<CR>*lampm= seco2#<CR>
No
Write
SmartEco mode 3
<CR>*lampm= seco3#<CR>
No
Write
Dimming mode
<CR>*lampm=dimming#<CR>
Yes
Write
Custom mode
<CR>*lampm=custom#<CR>
Yes
Write
Light level for custom
mode
<CR>*lampcustom=value#<CR>
Yes
Read
Light level status for
custom mode
<CR>*lampcustom=?#<CR>
Yes
Write
(dual
lamp)
Dual Brightest
<CR>* lampm =dualbr#<CR>
No
Write
(dual
lamp)
Dual Reliable
<CR>* lampm =dualre#<CR>
No
Write
(dual
lamp)
Single Alternative
<CR>* lampm =single#<CR>
No
Write
(dual
lamp)
Single Alternative Eco
<CR>* lampm =singleeco#<CR>
No
Read
Lamp Mode Status
<CR>*lampm=?#<CR>
Yes
Miscellaneous
Read
Model Name
<CR>*modelname=?#<CR>
Yes
Read
System F/W Version
<CR>*sysfwversion=?#<CR>
Yes
Read
Scaler F/W Version
<CR>*scalerfwversion=?#<CR>
Yes
Read
Format F/W Version
<CR>*formatfwversion=?#<CR>
No
Read
Lan F/W Version
<CR>*lanfwversion=?#<CR>
Yes
Read
MCU F/W Version
<CR>*mcufwversion=?#<CR>
Yes
Read
Ballast F/W Version
<CR>*ballastfwversion=?#<CR>
No
Write
Blank On
<CR>*blank=on#<CR>
Yes
Write
Blank Off
<CR>*blank=off#<CR>
Yes

17
Read
Blank Status
<CR>*blank=?#<CR>
Yes
Write
Freeze On
<CR>*freeze=on#<CR>
Yes
Write
Freeze Off
<CR>*freeze=off#<CR>
Yes
Read
Freeze Status
<CR>*freeze=?#<CR>
Yes
Write
Menu On
<CR>*menu=on#<CR>
Yes
Write
Menu Off
<CR>*menu=off#<CR>
Yes
Read
Menu Status
<CR>*menu=?#<CR>
Yes
Write
Up
<CR>*up#<CR>
Yes
Write
Down
<CR>*down#<CR>
Yes
Write
Right
<CR>*right#<CR>
Yes
Write
Left
<CR>*left#<CR>
Yes
Write
Enter
<CR>*enter#<CR>
Yes
Write
Back
<CR>*back#<CR>
Yes
Write
Source Menu On
<CR>*sourmenu=on#<CR>
Yes
Write
Source Menu Off
<CR>*sourmenu=off#<CR>
Yes
Read
Source Menu Status
<CR>*sourmenu=?#<CR>
Yes
Write
3D Sync Off
<CR>*3d=off#<CR>
Yes
Write
3D Auto
<CR>*3d=auto#<CR>
Yes
Write
3D Sync Top Bottom
<CR>*3d=tb#<CR>
Yes
Write
3D Sync Frame
Sequential
<CR>*3d=fs#<CR>
Yes
Write
3D Frame packing
<CR>*3d=fp#<CR>
Yes
Write
3D Side by side
<CR>*3d=sbs#<CR>
Yes
Write
3D inverter disable
<CR>*3d=da#<CR>
Yes
Write
3D inverter
<CR>*3d=iv#<CR>
Yes
Write
2D to 3D
<CR>*3d=2d3d#<CR>
No
Write
3D nVIDIA
<CR>*3d=nvidia#<CR>
Yes
Read
3D Sync Status
<CR>*3d=?#<CR>
Yes
Write
Remote Receiver On
<CR>*rr=on#<CR>
No
Write
Remote Receiver Off
<CR>*rr=off#<CR>
No
Write
Remote
Receiver-front+rear
<CR>*rr=fr#<CR>
No
Write
Remote
Receiver-front
<CR>*rr=f#<CR>
Yes
Write
Remote Receiver-rear
<CR>*rr=r#<CR>
No
Write
Remote Receiver-top
<CR>*rr=t#<CR>
Yes
Write
Remote
<CR>*rr=tf#<CR>
Yes

18
Receiver-top+front
Write
Remote
Receiver-top+rear
<CR>*rr=tr#<CR>
No
Read
Remote Receiver
Status
<CR>*rr=?#<CR>
Yes
Write
Instant On-on
<CR>*ins=on#<CR>
No
Write
Instant On-off
<CR>*ins=off#<CR>
No
Read
Instant On Status
<CR>*ins=?#<CR>
No
Write
Lamp Saver Mode-on
<CR>*lpsaver=on#<CR>
No
Write
Lamp Saver Mode-off
<CR>*lpsaver=off#<CR>
No
Read
Lamp Saver Mode
Status
<CR>*lpsaver=?#<CR>
No
Write
Projection Log In
Code on
<CR>*prjlogincode=on#<CR>
No
Write
Projection Log In
Code off
<CR>*prjlogincode=off#<CR>
No
Read
Projection Log In
Code Status
<CR>*prjlogincode=?#<CR>
No
Write
Broadcasting on
<CR>*broadcasting=on#<CR>
No
Write
Broadcasting off
<CR>*broadcasting=off#<CR>
No
Read
Broadcasting Status
<CR>*broadcasting=?<CR>
No
Write
AMX Device
Discovery-on
<CR>*amxdd=on#<CR>
Yes
Write
AMX Device
Discovery-off
<CR>*amxdd=off#<CR>
Yes
Read
AMX Device
Discovery Status
<CR>*amxdd=?#<CR>
Yes
Read
Mac Address
<CR>*macaddr=?#<CR>
Yes
Read
Serial Number
<CR>*serialnumber=?#<CR>
Yes
Write
High Altitude mode on
<CR>*Highaltitude=on#<CR>
Yes
Write
High Altitude mode off
<CR>*Highaltitude=off#<CR>
Yes
Read
High Altitude mode
status
<CR>*Highaltitude=?#<CR>
Yes
Installation
Write
Load Lens memory 1
<CR>*lensload=m1#<CR>
No
Write
Load Lens memory 2
<CR>*lensload=m2#<CR>
No
Write
Load Lens memory 3
<CR>*lensload=m3#<CR>
No
Write
Load Lens memory 4
<CR>*lensload=m4#<CR>
No

19
Write
Load Lens memory 5
<CR>*lensload=m5#<CR>
No
Write
Load Lens memory 6
<CR>*lensload=m6#<CR>
No
Write
Load Lens memory 7
<CR>*lensload=m7#<CR>
No
Write
Load Lens memory 8
<CR>*lensload=m8#<CR>
No
Write
Load Lens memory 9
<CR>*lensload=m9#<CR>
No
Write
Load Lens memory 10
<CR>*lensload=m10#<CR>
No
Read
Read Lens memory
status
<CR>*lensload=?#<CR>
No
Write
save Lens memory 1
<CR>*lenssave=m1#<CR>
No
Write
save Lens memory 2
<CR>*lenssave=m2#<CR>
No
Write
save Lens memory 3
<CR>*lenssave=m3#<CR>
No
Write
save Lens memory 4
<CR>*lenssave=m4#<CR>
No
Write
save Lens memory 5
<CR>*lenssave=m5#<CR>
No
Write
save Lens memory 6
<CR>*lenssave=m6#<CR>
No
Write
save Lens memory 7
<CR>*lenssave=m7#<CR>
No
Write
save Lens memory 8
<CR>*lenssave=m8#<CR>
No
Write
save Lens memory 9
<CR>*lenssave=m9#<CR>
No
Write
save Lens memory 10
<CR>*lenssave=m10#<CR>
No
Write
Reset Lens to center
<CR>*lensreset=center#<CR>
No
Color
Calibration
Write
Tint +
<CR>*tint=+#<CR>
Yes
Write
Tint -
<CR>*tint=-#<CR>
Yes
Write
Set Tint value
<CR>*tint=value#<CR>
Yes
Read
Get Tint value
<CR>*tint=?#<CR>
Yes
Write
Set gamma value
<CR>*gamma=value#<CR>
Yes
Read
Gamma value status
<CR>*gamma=?#<CR>
Yes
Write
Set HDR Brightness
value
<CR>*hdrbri=value#<CR>
Yes
Read
Get HDR Brightness
value
<CR>*hdibri=?#<CR>
Yes
Write
Red Gain +
<CR>*RGain=+#<CR>
Yes
Write
Red Gain -
<CR>*RGain=-#<CR>
Yes
Write
Set Red Gain value
<CR>*RGain=value#<CR>
Yes
Read
Get Red Gain value
<CR>*RGain=?#<CR>
Yes
Write
Green Gain +
<CR>*GGain=+#<CR>
Yes

20
Write
Green Gain -
<CR>*GGain=-#<CR>
Yes
Write
Set Green Gain value
<CR>*GGain=value#<CR>
Yes
Read
Get Green Gain value
<CR>*GGain=?#<CR>
Yes
Write
Blue Gain +
<CR>*BGain=+#<CR>
Yes
Write
Blue Gain -
<CR>*BGain=-#<CR>
Yes
Write
Set Blue Gain value
<CR>*BGain=value#<CR>
Yes
Read
Get Blue Gain value
<CR>*BGain=?#<CR>
Yes
Write
Red Offset +
<CR>*ROffset=+#<CR>
Yes
Write
Red Offset -
<CR>*ROffset=-#<CR>
Yes
Write
Set Red Offset value
<CR>*ROffset=value#<CR>
Yes
Read
Get Red Offset value
<CR>*ROffset=?#<CR>
Yes
Write
Green Offset +
<CR>*GOffset=+#<CR>
Yes
Write
Green Offset -
<CR>*GOffset =-#<CR>
Yes
Write
Set Green Offset value
<CR>*GOffset=value#<CR>
Yes
Read
Get Green Offset
value
<CR>*GOffset=?#<CR>
Yes
Write
Blue Offset +
<CR>*BOffset=+#<CR>
Yes
Write
Blue Offset -
<CR>*BOffset=-#<CR>
Yes
Write
Set Blue Offset value
<CR>*BOffset=value#<CR>
Yes
Read
Get Blue Offset value
<CR>*BOffset=?#<CR>
Yes
Write
Primary Color
<CR>*primcr=value#<CR>
Yes
Read
Primary Color Status
<CR>*primcr=?#<CR>
Yes
Write
Hue +
<CR>*hue=+#<CR>
Yes
Write
Hue -
<CR>*hue=-#<CR>
Yes
Write
Set Hue value
<CR>*hue=value#<CR>
Yes
Read
Get Hue value
<CR>*hue=?#<CR>
Yes
Write
Saturation +
<CR>*saturation=+#<CR>
Yes
Write
Saturation -
<CR>*saturation=-#<CR>
Yes
Write
Set Saturation value
<CR>*saturation=value#<CR>
Yes
