Security White Paper

2
March 2018
Table of Contents
Introduction........................................................................................................................... 3
The InstaShowTM System ........................................................................................................3
The InstaShowTM Setup ..............................................................................................................................3
System physical interface and firmware introduction ...............................................................................4
The InstaShowTM is a strong security system ..........................................................................5
Power Consumption Module System.........................................................................................................5
Video & Audio Module System..................................................................................................................5
Video & Audio Encoding/Decoding Module System .................................................................................5
Wireless Transmission Module System......................................................................................................6
WAN/LAN Module System .........................................................................................................................6
Web UI management module system........................................................................................................6
Light Module System..................................................................................................................................6
EMI/ESD Module System ...........................................................................................................................7
PCB Module System ...................................................................................................................................7
BenQ ecoFACTS Self-declaration................................................................................................................7
Streaming flow protection ..................................................................................................... 7
InstaShowTM system architecture ..............................................................................................................7
InstaShowTM network architecture ............................................................................................................8
Conclusion ........................................................................................................................... 12

3
March 2018
Introduction
InstaShowTM is a next-generation commercial display solution, which code is WDC10.This product is
primarily featured of high definition, plug-and-play, no driver software, and configurable security.
For a next-generation commercial display solution, a wireless connection method is used to replace a
traditional wired connection, and a security mechanism is added to this wireless streaming path to provide a
secure wireless transmission scheme. S ince InstaShowTM imaging interface is a high-definition multimedia
interface (HDMI), if a device on a client supports HDMI output, there is no need to worry about the
requirement for execution of additional software.As such, it prevents malicious software attacks or threats,
and may ensure that customers and users of InstaShowTM are protected. This is why we are concerned about
security, and streaming data protection is one of our major design criteria.
This white paper focuses on security, including details of architecture and technical control for InstaShowTM.
The InstaShowTM System
BenQ released WDP01, the first generation wireless video & audio transmission product, in the end of 2014,
followed by releasing InstaShowTM (WDC10), the first generation commercial wireless image transmission
display scheme, in the end of 2015. The release of InstaShowTM provides a new wireless image transmission
concept in the market.
The InstaShowTM Setup
Two main capabilities are implemented for InstaShowTM product. For the first capability, everyone is allowed
to have the opportunity to share contents by simply clicking the button on InstaShow Button to present a
content on the home screen. For the second capability, the content on the home screen is switched to a
content of another sharer quickly and easily without waiting for system installation.
InstaShowTM product consists of:
Host:This is the core of the entire system and the receiving equipment as well, which can establish wireless
connections with 16 Buttons concurrently, and is mainly responsible for receiving the streaming data
delivered by Button as well as for ensuring that video & audio is displayed on the display device correctly.
ITS staff of an enterprise can add Host to an enterprise domain through a LAN port.When Host becomes
one of the equipment in the enterprise domain, the Web UI provided by Host can allow the ITS staff to
monitor the status of InstaShowTM remotely.
Even if Host becomes one of the domain equipment in a local area network, the monitoring staff still cannot
obtain the content of the streaming data through intrusion or threat.
Button:This is the transmission device of the entire system. USB cable is mainly responsible for system
power supply, and HDMI cable is for receiving video & audio data in HDMI format, such as laptops, PS4,

4
March 2018
Blu-ray/DVD players etc.
By clicking the button on InstaShow Button, it will compress HDMI streaming signals as video & audio codes,
which are sent to the display device connected to Host side via Wi-Fi immediately.
System physical interface and firmware introduction
The operating system for InstaShowTM Host and Button is embedded Linux OS. Linux OS acts as
. Bootloader access
. Linux CLI access
Physical I/Os of Host include:
.LED
GPIO control
.Button(s)
GPIO Scan
.Ethernet:
Web UI
REST API
Communication with Client
.Wi-Fi:
Web UI
Communication with Client
.Micro USB
Power supply
.HDMI
Video / Audio output
LAN

5
March 2018
Physical I/Os of Button include:
.LED
GPIO control
.Button(s)
GPIO Scan
.Wi-Fi:
Communication with Host
.USB:
Power supply
.HDMI
Video / Audio input
The InstaShowTM is a strong security system
For InstaShowTM product, in the early stage of development, system designers and R&D engineers provided a
number of solutions for threat and security of wireless transmission, modules which eliminate security
threats by system modularization, together with several module improvements to result in the InstaShowTM
architecture.
Power Consumption Module System
The power system for Button and Host of InstaShowTM uses DC 5V to DC 3.3V conversion as the main
supply voltage for the system.According to the law of energy conservation, the supply current is increased
by reducing the voltage, such that low power is sufficient to support the operation of the entire system. The
power consumption module system passes 20,000 hours of long-term MTBF power supply verification, and
Host complies with (EC) No 107/2009 Regulation.
Video & Audio Module System
The source interface of InstaShowTM video & audio is HDMI. HDMI is an all digital image & sound
transmission interface, which is capable of transmitting uncompressed audio and video signals. HDMI can
transmit audio and video signals simultaneously and is protected by HDCP regulation.The HDMI input
source or output source for InstaShowTM system is compliant with regulations for HDMI 1.4b and HDCP
1.4b certifications. Devices of Source and Sink support HDMI 1.4b / HDCP 1.4b, both of which are
compatible with InstaShowTM.
The certification number obtained for InstaShowTM is ATCTW-16031 (Host),ATCTW-16032 (Button).
Video & Audio Encoding/Decoding Module System
HDMI interface is for uncompressed audio and video signals.The amount of data for uncompressed
1080p@60Hz audio and video signals is huge. If wireless transmission is used for this large amount of
streaming data without compression, a considerable bandwidth will be occupied inevitably. In order to solve
such a dilemma, InstaShowTM imports video & audio encoding and decoding methods for compressing the

6
March 2018
bandwidth required for video & audio to 40Mbps. Also, R&D engineers are devoted to the balance between
audio & video quality and transmission bandwidth usage, and further import dynamic encoding techniques to
adjust the compression ratio dynamically in conjunction with the quality of the wireless bandwidth in the
environment.
Wireless Transmission Module System
The Wi-Fi transmission protocol for InstaShowTM is 802.11ac with WPA2 AES 128 bits encryption mode, and
WPA2 is the best encryption technology for Wi-Fi connection at present stage.
However, existence of vulnerabilities for WPA2 is reported recently: "An attacker in the wireless range of
Wi-Fi network can exploit these vulnerabilities through Key Reinstallation Attack (KRACKs). According
to the research report for KRACKs provided by Mathy Vanhoef, the attack is targeted to the 4-way
handshake mechanism of WPA2 for client equipment (for example, laptops, smart phones or tablets etc.),
instead of using the base station." For more information about KRACK, click this link:
https://www.krackattacks.com
Host of InstaShowTM is a base station, and Button is a client equipment.Although Button is affiliated to the
client equipment, Button system is a closed system, so that external threats cannot reside in and attack the
system through HDMI interface or pure power supply purposed USB interface.
Wireless transmission module system also passes certifications of RF security regulations of various
countries, such as CE (EN 301 893), FCC (47 CFR FCC Part 15.407), NCC (NCC LP0002),TELEC (ARIB
STD-T71) and so forth.
WAN/LAN Module System
InstaShowTM is a closed wireless local area commercial display scheme, and Host is not capable of WAN
access. When the WAN port of Host is connected to an enterprise router, the enterprise router provides
Host with access to the Internet. However, any wireless equipment, such as a smart phone or a laptop etc.,
which connects to SSID of Host, cannot access information of Internet through Host, so that external
hackers cannot intrude into the wireless equipment on a client by Host.
The WAN/LAN module of InstaShowTM is provided mainly for users to configure the system.The interface
for configuration is Web UI.
Web UI management module system
InstaShowTM is capable of Web UI management.Web UI can query system status,Wi-Fi settings, system
updates, etc. A device of a user can connect to the SSID of Host through Wi-Fi or connect to Host by using
LAN.The user is required to provide an account and a password to login the home page of Web UI.
Light Module System
InstaShowTM provides a friendly indication system.A light indicator is the most direct prompt approach for
InstaShowTM.The ring light on a button displays current status of the system intuitively. System designers and
R&D engineers use special means to soften point light sources, which do not stimulate vision, so that the
user feels comfortable to read the status.

7
March 2018
EMI/ESD Module System
InstaShowTM can prevents network hacking attacks.Also, the engineers further adhere to security regulations
for products. InstaShowTM is compliant with EN55032 and EN55024 regulations.
PCB Module System
InstaShowTM is also dedicated to the prevention of hazardous substances and environmental pollution, such
that PCB meets lead-free, halogen-free environment friendly processes for printed circuit boards; there is a
comprehensively planned control mechanism from control of raw materials, material picking process to post
inspection and inventory check.
BenQ ecoFACTS Self-declaration
Since 2011, ecoFACT green labels have been added on all products of BenQ, which clearly indicate green
designs and green materials used by BenQ products.
To develop earth friendly green products, BenQ vitalizes all of its products by promoting green policy
actively, instead of making products compliant with green regulations passively!
InstaShowTM adheres to ecoFACTS regulation, indicating that the best effort has been made for replacement
of hazardous substances, material selection, package design, energy-saving design and other aspects.
Streaming flow protection
Through threat analysis of system modeling, the security of the system can be divided into external hacking
and internal protection management. Regardless of the threat, its purpose is nothing but destruction and
theft.
InstaShowTM is a wireless network transmission display system.The network system of InstaShowTM is not
capable of external network access and can avoid invasion of external hackers. InstaShowTM video & audio
transmission interface is based on HDMI, and software support is not required for video & audio streaming
path.The biggest security threat in an enterprise is software. InstaShowTM does not have the software
requirement about which an enterprise is worried, and can meet the need of an enterprise which requires
wireless multi-user screen sharing.
InstaShowTM system architecture
For the operation flow of InstaShowTM, Button receives video & audio streaming signals from Source device
HDMI, and transmits the video & audio streaming signal to Host in a wireless manner, followed by
transmitting the video & audio streaming signal to Sink equipment by HDMI.
According to the procedure of process, InstaShowTM system architecture is categorized into:
(1) HDMI signal decode
(2) Video and audio signal compress
(3) Video and audio stream with encryption over Wi-Fi
(4) Video and audio signal decompress
(5) HDMI signal encode

8
March 2018
Flow Transmission medium/interface Note
HDMI source HDMI Connect Laptop, PS4 or BD/DVD player
↓HDMI cable HDCP 1.4b or not(by content)
Button HDMI Connect
1. HDCP decode or not
2. Video and audio encode
3. Double encryption encode
InstaShowTM
↓Wi-Fi 802.11ac WPA2 PSK AES 128
Host HDMI Connect
1. Double encryption decode
2. Video and audio decode
3. HDCP encode
↓HDMI cable HDCP 1.4b or not(by content)
HDMI sink HDMI Connect Display
InstaShowTM network architecture
For InstaShowTM, in the operation flow, the system architecture must comply with confidentiality, integrity,
and availability to ensure that it is a secure system. Transmission can be divided into wired and wireless
transmissions.Wired connection is advantageous of high immunity to interference.An environmental space
with wireless communication can be often interfered with intentional or unintentional electromagnetic
waves. InstaShowTM, which is a wireless transmission system allowing the system to operate normally by
reducing electromagnetic interference, is very applicable to conference or home environment. The
architecture of InstaShowTM transmission system may be divided into physical layer, network layer and
application layer, which architecture and operation will be explained later.

9
March 2018
1. Physical Layer
The physical interfaces supported by InstaShowTM include USB/Micro USB, HDMI and Ethernet.The security
issue with the most direct impact in a system is the physical interface.An intruder might utilize the interface
to perform firmware interpretation of reverse-engineering, as well as to load malicious malware on
equipment. The physical interface of the protection system equipment has the same importance as other
layers for protecting the system.
USB: It provides 5V/0.9A power supply for Button simply without providing one-way and two-way data
exchange mechanisms.
Micro USB: It provides 5V/1.5A power requirement for Host without providing one-way and two-way data
exchange mechanisms.
HDMI: Entrance and exit for video & audio transmission, supporting HDCP protection.
Ethernet:Web UI login settings are provided, and updating firmware does not support Internet function.
The verification mechanism for Host and Button transmissions is not performed through the above interface
function. Hackers cannot steal all data and parameters shared by Host and Button through the physical
interface.
For firmware upgrade procedure, format integrity and signature for firmware will be verified, otherwise the
upgrade procedure is not supported.
Another hidden interface of the system is Wi-Fi, which has an integral security control. In this system,Wi-Fi
of Host provides Button with incoming verification and video & audio transmission.Additional controls for
authentication, confidentiality, and integrity are required for other devices to access the application layer of
Host.
2. Network Layer
The network system of InstaShowTM can be divided into WAN (Wide Area Network) and LAN (Local Area
Network).
The method for WAN is to connect network server through Ethernet interface. InstaShowTM cannot access

10
March 2018
Internet through this network server but only allows system network administrator to control the system
fully in the application layer through enterprise web server and authentication mechanism. The network
system and other access controls for InstaShowTM are independentVLAN separated from enterprise data
network.
LAN establishes local area connection with Button or other Wi-Fi devices by using Wi-Fi. The protection
mechanism of Wi-Fi is based on the IEEE 802.11i security standard that provides WPA2-PSK with a
pre-shared key (PSK) authentication. WPA2-PSK encryption ensures confidentiality and integrity of all data
over wireless channel. The encryption mode uses AES having a 128-bit key with a character length greater
than 8 and less than 63. Integrity is achieved by using Counter Mode CBC-MAC Protocol (CCMP) plus a
check method called MIC (Message Integrity Check). WPA2-PSK password and SSID are used, both of which
can be configured by the administrator on the network interface of Host.
3. Application Layer
The core operating system for Host and Button of InstaShowTM is the Linux OS. This application layer
provides system setup, wireless pairing management, wireless screen transmission network &
communication performance management, video & audio format conversion and video & audio format
decoding/encoding.
Wireless pairing management: Before full operation of the system, Host and Button must establish a
Wi-Fi connection. The network connection is established at the TLS (Transport Layer Security) layer on the
network level.When the authentication is created on the Host side, Button has to be identified with respect
to whether the security verification code of InstaShowTM is matched.After connection is established
between both sides, Host still needs an additional Button verification step (MAC address).
Wireless screen transmission network & communication performance management: The
content of the wireless screen transmission runs through UDP (User Datagram Protocol) because UDP
does not need to establish a connection like three-way handshake, such that communication is very efficient.
In UDP frame architecture diagram, a client requires only two steps (socket and sendto) to initiate a request,
while the server also requires only three steps to receive messages (socket, bind, recvfrom) from the client.

11
March 2018
Video & audio format conversion and video & audio format decoding/encoding: Conversion of
video & audio stream data is an important part in InstaShowTM.The amount of HDMI data with 1080p
lossless compression is about 6GB. InstaShowTM cannot reach 6GB transmission amount by using 802.11ac.
With respect to the four steps for video & audio format - conversion, compression, decompression and
video & audio format recovery, the system is allowed to operate smoothly with excellent image quality
through high-performance core processor, dynamic video & audio compression ratio adjustment, in
conjunction with wireless screen transmission network & communication performance management.
System setup: The system setup for InstaShowTM uses a Web interface to ensure authentication
connection with Host via only HTTP service. HTTP performs transmission with device browser through
plain text directly, and performs interactive conversation in a general (non-secure) mode.Therefore, the
content on internet may be intercepted by intentional people.This is a vulnerability that needs to be
improved in this system. Login of Web interface is bound to a cookie session that remains effective until
logout or expiry.
Security level: Three security levels are used for InstaShowTM. Security levels are divided based on the
number of provided functional protections. It is described as follows
Level 1,
.The identity authentication and password required for connection of Button to Host Wi-Fi
.Account and password required for Web UI login (HTTP)
Level 2,
. Connection can be established only if Button Mac Address is in Host List.
. Screen Lock on Web UI setting
Level 3,
. No access to Web UI via Wi-Fi

12
March 2018
Conclusion
Design of InstaShowTM is based on all HW solution, plug & play, no SW executed and nothing to learn.We
believe that InstaShowTM can provide a certain degree of data protection, environmental maintenance and
friendly products, and promise no implementation of back door or hidden transmission. BenQ will continue
to invest in our platform, allowing you to benefit from our products in a secure and transparent manner.
