BestScope BS-6004 Series User manual

This instruction manual is for the Inverted Metallurgical microscope BS-6004 series. To ensure
the safety and obtain optimum performance and to familiarize yourself fully with use of this
microscope, we recommend that you study this manual thoroughly before operating the
microscope. Retain this instruction manual in an easily accessible place near the work desk for
future reference.
The instruction is according to industry standard JB/T10077-1999.
BS-6004 SERIES
INVERTED METALLURGICAL
MICROSCOPE INSTRUCTION

BestScope International Limited
1
Contents BS-6004 series
Before using
1. Nomenclature ...................................................................................................................4
2. Assemblage .......................................................................................................................6
2-1 Assemblage scheme..........................................................................................................6
2-2 Assemblage step...............................................................................................................7
3. Operation...........................................................................................................................10
3-1 Illumination......................................................................................................................10
3-2 Focusing...........................................................................................................................10
3-3 Adjust tension of focus.....................................................................................................10
3-4 Adjust diopter....................................................................................................................11
3-5 Adjust inter-pupillary distance...........................................................................................11
3-6 Use filter.............................................................................................................................11
3-7 Adjust field diaphragm.......................................................................................................12
3-8 Adjust aperture diaphragm................................................................................................12
3-9 Use simple polarizing kit....................................................................................................13
3-10 Replace fuse.....................................................................................................................13
3-11 Mount and use TV device.................................................................................................13
3-12 Mount and use photo device...........................................................................................14
4. Technical Parameter...........................................................................................................15
5. Troubleshooting .................................................................................................................16

BestScope International Limited
2
Before using BS-6004 series
Inverted metallurgical microscope is used to discern and analyze organizational structure from kinds of metal. It is
very important in the work of quality research for foundry, smelt, heat treatment and inspection for raw material
and analysis for metallurgical structure of material after processing. It is also the important tool of research work
for metal physics, which is wildly used in enterprise, university and R&D.
1. Attention:
1.1 As the microscope is precision instruments, it should be
taken carefully and avoid impact during transportation.
1.2 Do not expose the microscope in the sun directly,
either not in the high temperature, damp, dusty or
acute shake place. Make sure the worktable is
horizontal. Following environment is required: Indoor
temperature: 5℃～40℃, Max relative humidity:80%.
1.3 To move the microscope, please hold groove ①
behind and tube position ② and lay it carefully. (Fig. 1)
★It will be damaged by holding the stage, focusing knobs, tube or illuminator.
1.4 The lamp will be very hot during working, please make sure there is enough space around for dissipating.
1.5 Please connect the microscope with ground to avoid lighting strike.
1.6 Please make sure the power switch is “0”(Off)(See the left Fig) and the bulb cool down before replace the
bulb or fuse.
★Bulb: 3W LED bulb (Standard)
12V/30W halogen bulb (Philips 5761) (Optional)
1.7 It adopt wildly voltage 90~240V, and do not need any transformer. Please make sure the power supply before
using.
1.8 Please use special wires supplier by our company.
Fig.1

BestScope International Limited
3
BS-6004 series
2. Maintenance
2.1 Clean the lenses gently with a soft lens tissue. Carefully wipe off oil or fingerprints on the lens surfaces with
tissue moistened with 3:7 mixture of ethanol and aether or dimethylbenzene.
★Ethanol and Aether are both flammable. Please leave them away from fire or fire source, especially during
the power switch turn on and turn off.
2.2 Don’t use organic solution to clean the surfaces of the microscope, especially for plastic parts. Please use the
neutral detergent if necessary.
2.3 If the microscope damped by the liquid during working, please cut off the power immediately and make it
dry.
2.4 Do not disassemble or assemble the microscope to avoid damaging the capability.
2.5 After using, put on dust cover to protect microscope.
3. Safety sign
Sign
Signification
It shows the surface gets hot and don’t touch with bare hand.
Read the introduction before using. Unsuitable operation would lead person
hurt or instrument faulty.
|
Power switch ON
O
Power switch OFF

BestScope International Limited
4
1. Nomenclature BS-6004 series
Mechanical stage
Eyepiece
Knob for adjustment
tension
Coarse knob
Fine knob
Analyser
Knob for
brightness
Pole for field
diaphragm
Pole for aperture
diaphragm
Polarizer slide
Filter slide
Metal stage

BestScope International Limited
5
BS-6004 series
Objective
BS-6004 stand
Power
switch
Trinocular
head
Centering screw for
field diaphragm
Diopter
adjustment ring
Reflected
illuminator
Nosepiece
Lamp
holder

BestScope International Limited
6
2 ． Assemblage BS-6004 series
2-1 Assemblage scheme
The below numbers shows the assemblage order.
★Before assemblage, please make sure all parts are without any dust or dirt..
★Be careful during assemblage and do not scrap or touch the optical lens.
Plug
Lamp holder
Objective
Metal stage
Clips
Eyepiece
analyser
Polarizer slide/filter slide

BestScope International Limited
7
BS-6004 series
2-2 Assemblage step
2-2-1 Set lamp holder
b Make sure the pin ① and ③ facing to the hole ② and ④,
then lock. (Fig. 2)
★LED bulb: 3W
★Halogen bulb: 6V30W (Philips 5761)
2-2-2 Set or replace bulb
Use clean glove or gauze to hold the bulb and make sure the
bulb pin ① facing to hole ③ and lock. Please make sure the
bulb should be vertical. (Fig. 3)
★Do not touch the bulb by finger directly.
Clean by gauze if there is finger print on bulb.
★Whenever replace the bulb, please cut off the power first
and wait the illuminator part cool down.
2-2-3 Set objectives
Turn the coarse knob to make the nosepiece to lowest.
Through the hole on stage to set the objectives ① on
nosepiece from low magnification to high magnification with
the direction. (Fig. 4)
★Clean the objectives regularly. It is very sensitive of dust
for objective of Inverted microscope.
★Please use low magnification objective, such as 5X or 10X
to find image, then use high one for observation.
★Make sure to hear click when turning to show the
objective on correct position.
Fig.3
Fig.4
Fig.2

BestScope International Limited
8
BS-6004 series
2-2-4 Set the metal stage
⑴Set the metal stage ① on mechanical stage as the
direction showed. (Fig. 5)
⑵Turn the metal stage to make the V hole ② direct to the
user.
2-2-5 Set clips
⑴Take out clips ① from pole ②. (Fig. 6)
⑵Screw pole ② into hole ③ on mechanical stage, then lock
by screw nut ④.
⑶Set the clips ① into pole ② and make it direct to center
of stage.
2-2-6 Set eyepiece
⑴Take off eyepiece cap ①. (Fig. 7)
⑵Insert the eyepiece ② to tube.
Fig.5
Fig.7
Fig.6

BestScope International Limited
9
BS-6004 series
2-2-7 Set Analyzer
Insert the analyzer ① into hole ② on microscope stand with
its face up to hear click. (Fig.8)
2-2-8 Set polarizer and filter
Insert the polarizer or filter ① into hole ② on connector
between microscope stand and illuminator with its face up to
hear click. (Fig.9)
2-2-9 Connect power supply
⑴Make sure the main power switch is at “O” (OFF) position.
⑵Insert one side of power plug ① into microscope socket
② and the other side connecting to power supply. (Fig. 10)
★Don’t over exert with the wires when it is bendy or
voluble.
★Use the wire supplied by our company only. If it is lost or
damaged, choose another suitable one.
★Connect all wires correctly, make sure the microscope is
connected with ground.
Fig.8
Fig.10
Fig.9

BestScope International Limited
10
3. Operation BS-6004 series
3-1 Illumination
⑴After connect the microscope with power supply, set main
switch at “-“position.
⑵Turn the knob ① for brightness to suitable. Clockwise
turning of the adjusting knob is to bright and counter to dark.
(Fig 11)
★It can protect the bulb if using under low power supply.
3-2 Focusing
⑴Put the specimen on metal stage and use objective 5X.
★Please make sure the specimen should be vertical with the
objective. If not, please fix the specimen by plasticine
⑵Adjust the diopter of right tube to “0” (See 3-4 Adjust
diopter). Observe through right eyepiece and turn the coarse
knob ① to find the image (Fig 12)
⑶Turn the fine knob ② to make the image clear.
3-3 Adjust tension of focus
If the tension is too tight or image is out of focus plane or the
stage slips down during focusing, please adjust the tension
knob ① of focus. (Fig. 13)
★The knob ① direction indicated is for loose and opposite
direction for tight.
Fig.12
Fig.11
Fig.13

BestScope International Limited
11
BS-6004 series
3-4 Adjust diopter
Diopter is ±5 and it is point to the line on tube. After getting
the clear image through right eyepiece, Please obverse
through left eyepiece with left eye. If the image is not clear,
please adjust the left diopter adjusting ring ①. (Fig 14)
★When both eyepieces have diopter, select one for
standard and adjust another. Please make sure the diopter of
standard one should be at “O” position before focusing.
3-5 Adjust inter-pupillary distance
When two eyes observe, please turn the two prism house with
the direction indicate to adjust the inter-pupillary till suitable.
(Fig. 15)
The mark “·” on left tube indicates the inter-pupillary.
The inter-pupillary range: 50~76mm
★Please remember your inter-pupillary for next observe.
3-6 Use filter
It can make the background of image softly and improve the
image more clearly through using filters. (Fig. 16)
Filter: Green, blue, red
BS-6004 series
Fig.14
Fig.15
Fig.16

BestScope International Limited
12
3-7 Adjust field diaphragm
Field diaphragm can strength the image contrast by
preventing the diameter of bean of light into condenser and in
order to strength the image contrast. When the image is in the
edge of field, the objective can bring out the supper image.
⑴Turn the pole ② for field diaphragm adjusting to the most
left with counter clockwise to make the field smallest. (Fig 17)
⑵Through the eyepieces, here you can find the image of field
diaphragm.
⑶Adjust the both centering screws ① of field diaphragm to
make the diaphragm image to the center.
⑷Open the field diaphragm slowly, if the field inscribed with
its image, it indicates the diaphragm centered. (Fig 18)
⑸Please increase the diaphragm a little during operation to
make the field as circumcircle with its image.
3-8 Adjust aperture diaphragm
Aperture diaphragm controls the aperture of illumination.
The aperture of illumination should be suitable with
objective’s, then it can provide the best image and
increase depth of field.
The adjustment of aperture diaphragm is the same as
field diaphragm. Please use knob ①. Please adjust
aperture diaphragm to suitable through the contrast of
image. (Fig. 19)
BS-6004 series
Fig.17
Fig.19
Fig.18

BestScope International Limited
13
3-9 Use simple polarizing kit
Simple polarizing kits includes polarizer and analyzer. (Fig. 20)
⑴Set analyzer and polarizer as 2-2-7 and 2-2-8. (Please take
off filter slide when using polarizer slide)
⑵It can change position of polarizing light to rotate analyzer.
⑶When analyzer is at zero position, the analyzer and
polarizer are crossed.
3-10 Replace fuse
Before replace fuse, please make sure the power switch is at
“0” (Off) and cut off the power supply. Use screwdriver to take
off the fuse ①from fuse holder ② and replace a new one.
(Fig 21)
★The rating for fuse: 250V, 8A.
3-11 Mount and use TV device
⑴Loose the lock-screw ① on tri-tube and take off the tri-cap
②. (Fig 22)
⑵Take off the caps of TV adapter ③ and settle on tri-tube
and lock by screw ①.
⑶Loose the lock-screw ④ on TV adapter and take off
C-mount ⑤. Then set the C-mount to CCD or camera and
connect to TV adapter again, lock on.
⑷Adjust the image clear through binocular then obverse
through CCD. If it is not clear, you can adjust the adjusting ring
⑥ till clear
BS-6004 series
Fig.21
Fig.22
Fig.20

BestScope International Limited
14
3-12 Mount and use photo device
⑴Loose the lock-screw ① on tri-tube and take off the tri-cap
②. (Fig 23)
⑵Mount the photo device as the direction indicated into
tri-tube, then lock on screw ①.
⑶Loose the lock-screw ③ on photo adapter and take off
photo tube ④. (Fig. 24)
⑷Insert 3.2X photo eyepiece ⑤ into tube ⑥. Then mount
photo tube ④ and lock on screw ③.
⑸Adjust the image clear through binocular then use camera
as its manual.
4.Technical Parameter BS-6004 seris
Technical Parameter for BS-6004 Inverted metallurgical microscope.
Fig.24

BestScope International Limited
15
5 ． Troubleshooting BS-6004 series
The performance of the microscope can’t be made fully because of unfamiliar using, this table will give some
advices.
eyepiece
PL10X/18mm plan eyepiece
Objective
195mm normal metallurgical objective (5X, 10X, 20X, 40X)
195mm LWD professional plan metallurgical objective (5X, 10X, 20X, 50X, 100X)
Head
Gemel trinocular head, 45 degrees inclined, with 8:2 prismatic
Inter-pupillary distance: 55-75mm
Nosepiece
Build-in quadruple nosepiece (Build-in quintuple nosepiece)
Focus
Fine and coarse coaxial, moving range: 33mm, fine precision: 0.001mm
Stage
Size: 180*155mm, moving range: 75*40mm
φ12 metal stage (φ25metal stage for selection)
Illumination
Reflected Kohler illuminator with iris aperture diaphragm and centering field diaphragm.
100-240VAC power supply with 3W LED bulb (6V30W halogen bulb is optional). Adjustment
for brightness.
Polarizing set
Analyzer can be rotatable and both polarizer and analyzer can be moved into light path.
Filter
Blue, green, yellow
Operation
Environment
● Indoor
● Altitude: 2000m Max.
● Temperature: 5℃－40℃(41°F－104°F)
● Humidity: 80% for 31℃(88°F)
70% for 34℃(93°F)
60% for 37℃(99°F)
50% for 40℃(104°F)
● Pollution: 2 (Refer to IEC664)

BestScope International Limited
16
Trouble
Cause
Remedy
1. Optical parts
⑴bulb works, but
the light is not
enough
Field diaphragm is not enough large
Turn it larger
The knob for brightness is too low
Adjust to suitable
The polarizer and analyzer is pulled
inside
Take them off
⑵the edge of field
dark or not equal
Nosepiece is not fixed
Fix the nosepiece
Dirt on lens or eyepiece or objective
Clean them
Filter, polarizer or analyzer are not at
right position
Pull the slides in or pull in the light path
selection pole
⑶dirt inside of field
Dirt on specimen
Clean specimen
Dirt on lenses
Clean lenses
⑷image blur
Slide cover on sample
Take the cover away
Sample is not upright to objective
Adjust the sample
Nosepiece is not fixed
Fix the nosepiece
Aperture diaphragm opened too large
Adjust it
Dirt on lens of eyepiece
Clean it
⑸image blur
somewhere or image
moving during
focusing
Sample is not set correctly
Set it again
Nosepiece is not fixed
Fix the nosepiece
⑹eye tired easily or
double image
Interpupillary is not correct
Adjust interpupillary
Diopter is not correct
Adjust diopter
Not the same magnification for both
eyepiece
Use same eyepiece
BS-6004 series

BestScope International Limited
17
Trouble
Cause
Remedy
2. Mechanics
⑴too tight of coarse
knob
Tension knot is too tight
Loose it to suitable
⑵stage slips down
during obverse
Tension knot is too loose
Tight it to suitable
3. Electrical parts
⑴bulb does not work
There is not power supply
Connect the power supply
The wires do not connect right
Connect it correctly
Faulty setting of bulb
Set the bulb correctly
Bulb burn out
Replace bulb
⑵Not enough
brightness
Faulty adjusting of brightness
Re-adjust the brightness
Bulb is not standard
Use standard bulb
⑶bulb always burns
out
Bulb is not standard
Use standard bulb
⑷light flickered
Bulb is going to burn out
Replace the bulb
The wires do not connect right
Connect it correctly
