HS 200
Aviation Headset
APPLICATIONS
The HS 200 Trend is a closed-back aviation headset with an
excellent noise attenuation for the use in propeller and turboprop
aircrafts (HS 200 Trend) as well as helicopters (HS 200 Rotor). The
headphone features a very high reproduction precision and a
balanced sound. Another special feature is the wide frequency
response of 5 - 30,000 Hz, from which the intelligibility of speech
will benefit.
The soft, circumaural ear pads and the adjustable padded head-
band provide a high comfort. The microphone with adjustable gain
can be optimally positioned with the flexible gooseneck. The
figure-eight polar pattern ensures a very good noise cancellation.
The rotating microphone holder allows positioning the microphone
on the right or left hand side.
The single-sided connecting cable provides an integrated volume
control to adjust the volume of the headphone.
The HS 200 is available in two versions: As HS 200 Trend it provides
two jack plugs for connecting and as HS 200 Rotor it is fitted with
an U-174/U jack plug and a coiled cable.
FEATURES
• Excellent passive noise attenuation
• Made in Germany
• Noise-cancelling microphone with adjustable gain,
can be worn on the left or right hand side
• Balanced sound with high reproduction precision
to ensure excellent speech intelligibility
• Integrated volume control
• Rugged headband design made of spring steel with soft,
replaceable headband pad
• Moderate headband pressure (approx. 8 N) for
maximum comfort
• Light weight of approx. 325 g (without cable)
• Modular construction for easy servicing
• Supplied with padded case
• Five-year warranty
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 204
[email protected] | www.beyerdynamic.com
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E4/HS 200 (09.12)
1 of 2
TECHNICAL SPECIFICATIONS
Headphone
Transducer type . . . . . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . . Closed
Frequency response . . . . . . . . . . . . . . . . 5 - 30,000 Hz
Nominal impedance mono . . . . . . . . . . . 125 Ω
Nominal SPL . . . . . . . . . . . . . . . . . . . . . . 105 dB
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.2%
Power handling capacity . . . . . . . . . . . . . 100 mW
Sound coupling to the ear . . . . . . . . . . . Circumaural
Ambient noise attenuation . . . . . . . . . . . approx. 30 dBA
Nominal headband pressure . . . . . . . . . . 8 N
Microphone
Transducer type . . . . . . . . . . . . . . . . . . . Condenser
(back electret)
Frequency response . . . . . . . . . . . . . . . . 400 - 15,000 Hz
Polar pattern. . . . . . . . . . . . . . . . . . . . . . Figure-eight
Output voltage at 1 kHz . . . . . . . . . . . . . 1 - 11 mV/1 Pa,
adjustable
Max. SPL. . . . . . . . . . . . . . . . . . . . . . . . . 120 dB
Nominal impedance . . . . . . . . . . . . . . . . approx. 350 Ω
Current consumption . . . . . . . . . . . . . . . approx. 6 - 18 mA
Supply voltage . . . . . . . . . . . . . . . . . . . . typ. 16 V DC
(8 - 16 V DC,
acc. to RTCA/DO 214)
General
Weight without cable / audio box . . . . . . approx. 325 g
HS 200 Trend cable. . . . . . . . . . . . . . . . . 1.80 m, single-sided
HS 200 Trend connection
Headphone. . . . . . . . . . . . . . . . . . . . . . . 1/4" stereo jack plug
(6.35 mm)
Microphone . . . . . . . . . . . . . . . . . . . . . . PJ-068 jack plug
HS 200 Rotor cable. . . . . . . . . . . . . . . . . Coiled cable, single-sided
HS 200 Rotor connection . . . . . . . . . . . . U-174/U jack plug

HS 200
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 204
[email protected] | www.beyerdynamic.com
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E4/HS 200 (09.12)
2 of 2
FREQUENCY RESPONSE & POLAR PATTERN
This frequency response curve (measuring tolerance ± 2.5 dB) and polar pattern correspond to a typical production sample for this
microphone measured at a distance of 2 cm.
Frequency response curve ± 2.5 dB HS 200 microphone 0 dB = 1 - 11 mV / 1 Pa
HS 200 microphone
SPARE PARTS
EDT 770 S Ear pads, leatherette,
black . . . . . . . . . . . . . . . . . . . . . Order # 904.783
EDT 600 SS Ear pads, leatherette
viscoelastic, black. . . . . . . . . . . . Order # 904.872
EDT 300 GS Ear pads, gel-filled,
black . . . . . . . . . . . . . . . . . . . . . Order # 900.799
WS 20 sw Wind shield, black . . . . . . . . . . . Order # 439.975
BN 59-53/D Headband pad, leatherette,
black . . . . . . . . . . . . . . . . . . . . . . Order # 990.681
BN 59-74/A Headband pad, genuine leather,
with special shape to protect
the fontanelle, black. . . . . . . . . . . Order # 908.541
EDT Hygienic pads, 5 pairs of cloth covers,
black, suitable for all headsets . . . Order # 488.070
SUPPLIED ACCESSORIES
• Padded bag
• Wind shield for the microphone
• Screwdriver to adjust the microphone gain
• Manual
VERSIONS
HS 200 Trend Pilot headset with
two jack plugs. . . . . . . . . . . . . Order # 499.323
HS 200 Rotor Pilot headset with
U-174/U jack plug . . . . . . . . . . Order # 489.611
