Beyerdynamic MMX 100 User manual

User Manual |Bedienungsanleitung |Mode d’emploi
Inrucciones de use |Manuale d’uso |Bruksanvisning
Gebruiksaanwijzing |Руководство по эксплуатации
사용 설명서 |取扱説明書 |使用说明书
MMX 100
GAMING HEADSET
EN DE FR ES IT SV NL RU KO JA ZH

2MMX 100
EN
CONTENTS
Safety inructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Supplied accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Accessories / Replacement pas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connect the microphone to the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connect the cable to the headset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting cable with 4-pole jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting cable with two 3-pole jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mute and un-mute the microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Replacing the ear pads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Changing the volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3MMX 100
EN
Congratulations to your Meta Pick! We hope you will enjoy
your MMX 100 headset from beyerdynamic.
Please take some time to read carefully through this
manual before using the product.
ENJOY THE SOUND!
Your beyerdynamic Team
SAFETY INSTRUCTIONS
Risk of injury
uWe would like to point out that excessively
high volumes and long liening times may
cause hearing damage. Hearing defects
always conitute an irreversible impairment
of hearing ability. If you suer from tinnitus,
do not use headphones or reduce the
volume.
uWhen connecting the headset, please ensure
that the volume is turned down to minimum.
Adjust the volume after putting on the head-
set.
Danger to life
uHeadphones draically reduce perception
of external sounds. Using headphones in
road traic can be potentially dangerous.
The user’s hearing mu not be impaired to
the extent that it causes road safety risks.
Please also make sure that you do not use
the headphones in traic, especially within
an area of potentially dangerous machines
and tools.
uFuhermore, avoid using headphones in
situations where hearing mu not be
aected, especially when crossing a railway
crossing or at a conruction site.
Liability / intended use
uDo not use the product for any application which
is not described in this product information.
ubeyerdynamic is not liable for improper use of
the product and its accessories.
MAINTENANCE
uUse a so cloth moiened with water to clean
the suace.
uMake sure that no water enters the headset.
uDo not use cleaning agents containing solvents.
uNever use a vacuum cleaner for cleaning the
headset, as this may cause irreparable damage.
DISPOSAL
uAt the end of its operating life this product
may not be disposed of along with
normal household waste. Please take it
to a designated recycling point for
electric and electronic appliances.
uThis is indicated by the symbol on the
product, the operating instructions or
the packaging.
ACCESSORIES / REPLACEMENT PARTS
uAccessories and replacement equipment
can be found at: www.beyerdynamic.com
uIf you have technical queions while using
the headset or need fuher guidance,
please visit our FAQ website at:
suppo.beyerdynamic.com
SUPPLIED ACCESSORIES
u1 x 5-pole jack to 4-pole jack cable, 1.2 m (3.9 ),
to connect the headset to mobile devices
u1 x 5-pole jack to 2 x 3-pole jack cable, 2 m (6.5 ),
to connect the headset to a computer or console
u1 x Microphone pop shield
SERVICE
uIf you require service, please contact qualified
service personnel or directly:
beyerdynamic Service- und Logistik Center
E-mail: [e-mail]
uDismantling the headset yourself will invalidate
the guarantee.

4MMX 100
EN
CONNECT THE MICROPHONE
TO THE HEADSET
Observe
the position
of the jack.
CONNECT THE CABLE
TO THE HEADSET
Connect the
jack connector
to the headset.
Pull the connection
carefully to
disconnect, if
you want to use
another cable.

5MMX 100
EN
CONNECTING CABLE WITH 4POLE JACK
u Connect the flat 5-pole jack to the headset and the
round 4-pole jack to your device such as console
controllers, external soundcards, notebooks,
tablets etc.
u For devices with 1/4" jack (6.35 mm), please use a third-
pay adapter. Make sure that it is a 4-pole adapter, as
the microphone will not work with a 3-pole 1/4" (6.35 mm)
TRS adapter.
uCaution: Connect the round 4-pole jack connector of
the cable to a headphone socket only!
If you connect the headset to any other jack socket, the
headset could be damaged.
Connect to
headset
Connect to
device
CONNECTING CABLE WITH
TWO 3POLE JACKS
u Connect the flat 5-pole jack to the headset and the
two round 3-pole jack connectors to a headphone
output and microphone input of a PC or notebook,
which have a mini combination jack (3.5 mm).
u
For devices with 1/4" jack (6.35 mm), please use one of
ours or a third-pay adapter.
uCaution: Connect the round 3-pole jack connectors of
the cable to a headphone and microphone socket only!
If you connect the headset to any other jack sockets,
the headset could be damaged.
MUTE AND UNMUTE THE MICROPHONE
uPress the button to mute or unmute the microphone.
uWhen muted the button icks outward.
uWhen unmuted the button is inward.
Connect to device
Microphone
Headphone
Connect to
headset
Mute
activated.
Mute
deactivated.

6MMX 100
EN
CHANGING THE VOLUME
uThe headphone volume can easily be increased
by turning the control wheel up.
uTo decrease the volume, turn the control wheel
down.
Increase
volume
Decrease
volume
Turn counter-clockwise
and pull o.
Replace ear pad
and turn clockwise.
REPLACING THE EAR PADS
uTo remove the ear pad, gently turn
it counter-clockwise and pull it o.
uTo attach the ear pad, place it onto
the orange housing and gently turn it
clockwise until it sits tight.
TECHNICAL SPECIFICATIONS
Headphone
Transducer type . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . . . . . . . . . . . . Closed
Sound coupling to the ear. . . . . . . . . . . . . . . Circumaural
Frequency response. . . . . . . . . . . . . . . . . . . . . 5 - 30,000 Hz
Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Ω
Max. sound pressure level
@1 mW / 500 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 dB SPL
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.5%
Headband pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5 N
Connection . . . . . . . . . . . 5-pole mini jack plug (3.5 mm)
Weight (headphone). . . . . . . . . . . . . . . . . . . 296 g (10.44 oz)
Microphone
Transducer type . . . . . . . . . . . . . . . . . . Electret condenser
Capsule diameter. . . . . . . . . . . . . . . . . . . . . . . 9.9 mm (0.39")
Polar pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cardioid
Frequency response . . . . . . . . . . . . . . . . . . . . . 5 - 18,000 Hz
Max. sound pressure level . . . . . . . . . . . . . . . . . . . . . . 118 dB
Signal-to-noise ratio. . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 dB
