BluDot 11 Series Quick start guide

Series 11 2 Door / 2 Drawer Console
DESIGNED IN 2005
ASSEMBLY NOTES | REV 00
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
FOR YOUR HI-FI, LO-FI, WI-FI OR NO-FI.
An elegant and refined approach with thin edges and thoughtful
proportions. Series Eleven. When ten just isn’t quite enough.

1 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 2 DOOR 2 DRAWER CONSOLE
Base Case
1 1QTY QTY
Pt. 1052
10QTY
Pt. 1053
4QTY
Pt. 3002
14QTY
Pt. 9001
1QTY
Pt. 9004
1QTY
Legs
2QTY
Parts & Hardware

[e-mail] | 2ASSEMBLY NOTES
Pt. 1053 x 4 Pt. 9001 x 1Pt. 3002 x 4
Step 01
ATTACH THE LEGS.
Attach legs to base using provided hardware
as shown.

3 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 2 DOOR 2 DRAWER CONSOLE
PT. 1052 X 10 PT. 3002 X 10 PT. 9004 X 1
Step 02
ATTACH THE BASE.
After the base has been attached, have a
second person help lift and bring the case
upright in order to prevent leg damage.

[e-mail] | 4ASSEMBLY NOTES
Step 03
REMOVING THE DRAWER.
Extend the drawer completely. Squeeze both
locks on the underside of the drawer while
pulling the drawer out.

5 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 2 DOOR 2 DRAWER CONSOLE
Step 04
REINSTALLING THE DRAWER.
Pull both sides Forward. Engage rear slide
catches. Lower drawer front into place and
push closed.

[e-mail] | 6ASSEMBLY NOTES
If door needs adjustment from
TOP TO BOTTOM, Use Screw #1.
If door needs adjustment from
SIDE TO SIDE, Use Screw #2.
If door needs adjustments from
FRONT TO BACK, Use Screw #3.
12
3
3
1
2
Step 05
DOOR ADJUSTMENT.
Hinges work in pairs. If you adjust one hinge,
chances are you will have to adjust all the
hinges.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt
and fingerprints, use a quality cleaner formulate for
wood furniture. Wipe completely dry with a soft cloth
in the direction of the wood grain.
