BluDot 11 Series Quick start guide

Series 11 Console
DESIGNED IN 2005
ASSEMBLY NOTES | REV 01
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
FOR YOUR HI-FI, LO-FI, WI-FI OR NO-FI.
An elegant and refined approach with thin edges and thoughtful
proportions. Series Eleven. When ten just isn’t quite enough.

1 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 CONSOLE
Pt. 8041
2QTY
Pt. 8042
1QTY
Leg
2QTY
Pt. 3002
14QTY
Pt. 9001
1QTY
Pt. 9004
1QTY
Pt. 1217 Pt. 1218 Pt. 1053 Pt. 1052
2QTY 2QTY QTY 10QTY4
8042
An�-�p Strap
8041
An�-�p Bracket
Parts & Hardware

[e-mail] | 2ASSEMBLY NOTES
Base
Case*
1
1
QTY
QTY
Parts & Hardware
The geometry of the case may vary depending on the product purchased.

3 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 CONSOLE
Pt. 1053 x 4 Pt. 9001 x 1Pt. 3002 x 4
Step 01
ATTACH THE LEGS.
Attach legs to base using provided hardware
as shown.

[e-mail] | 4ASSEMBLY NOTES
PT. 1052 X 10 PT. 3002 X 10 PT. 9004 X 1
Step 02
ATTACH THE BASE.
After the base has been attached, have a
second person help lift and bring the case
upright in order to prevent leg damage.

5 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 CONSOLE
ORIF YOUR DRAWER HAS A TRIGGER LOCK:
Extend the drawer completely. Squeeze
both triggers on the underside of the
drawer while pulling the drawer out.
IF YOUR DRAWER HAS A TAB LOCK:
Extend the drawer completely. Pull on
the plastic tabs underneath the drawer
to release the drawer lock. Lift drawer
upwards to remove.
Step 03
REMOVING THE DRAWER.
The method to remove the drawers may differ
depending on the unit that was purchased. See
instructions below for each method.

[e-mail] | 6ASSEMBLY NOTES
ORIF YOUR DRAWER HAS A TRIGGER LOCK:
Pull both sides of the slide forward.
Engage rear slide catches. Lower
drawer front into place and push
closed.
IF YOUR DRAWER HAS A TAB LOCK:
Lower drawer front to align with pin. Push on the plastic
tabs underneath the drawer to engage the drawer lock.
Step 04
REINSTALLING THE DRAWER.
The method to reinstall the drawers may
differ depending on the unit that was
purchased. See instructions below for each
method.

BLU DOT DESIGN & MANUFACTURING, INC. SERIES 11 CONSOLE
If door needs adjustment from
TOP TO BOTTOM, Use Screw #1.
If door needs adjustment from
SIDE TO SIDE, Use Screw #2.
If door needs adjustments from
FRONT TO BACK, Use Screw #3.
12
3
3
1
2
Step 05
DOOR ADJUSTMENT.
Hinges work in pairs. If you adjust one hinge,
chances are you will have to adjust all the
hinges.

[e-mail] | 8ASSEMBLY NOTES
PT. 8041 X 1 PT. 1218 X 2
8041
An�-�p Bracket
Step 06
ATTACH ANTI-TIP BRACKET TO
THE WALL.
Install anti-tip bracket to wall stud 1-inch
below case top panel height.
Side Panel
1” lower than
case top
Wall

9 | 8 4 4 . 4 2 5 . 8 3 6 8 SERIES 11 CONSOLE
PT. 1218 X 2
PT. 8041 X 1
8041
An�-�p Bracket
Top
Back
Panel
Step 07
INSTALL ANTI-TIP BRACKET
TO CASE.
Bracket must be installed to top panel
of case. In order to prevent damage, it is
recommended that 3/32” pilot holes be
drilled prior to installation.
8041
An�-�p Bracket

[e-mail] | 10ASSEMBLY NOTES
Step 08
SECURE THE CASE.
Install and tighten the strap
prior to using the product.
PT. 8042 X 1
8042
An�-�p Strap

DESIGNED IN MINNEAPOLIS, MNBLU DOT DESIGN & MANUFACTURING, INC.
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt
and fingerprints, use a quality cleaner formulated for
wood furniture. Wipe completely dry with a soft cloth
in the direction of the wood grain.
