BluDot Open Plan Large Low Bookcase Quick start guide

Open Plan Large Low Bookcase
DESIGNED IN 2019
ASSEMBLY NOTES | REV 01
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
@BLUDOT
We design all our pieces in our Minneapolis studio. Follow
along on Instagram for some sneak peeks into the process.

1 | 844.425.8368 OPEN PLAN LARGE LOW BOOKCASE
8041
An�-�p Bracket
8042
An�-�p Strap
Back Panel
2QTY
Front Corner Upright
2QTY
Pt. 8054
Pt. 8053
4
8
QTY
QTY
Pt. 4022
6QTY
Pt. 1690
Pt. 1693
Pt. 9016
6
1
QTY
QTY12
Parts & Hardware
Pt. 1217
4QTY
Pt. 1218
4QTY
Pt. 8041
QTY
Pt. 8042
2QTY4
Parts & Hardware

[e-mail] |2ASSEMBLY NOTES
Rear Left Corner Upright
Front Center Upright
1
1
QTY
QTY
Rear Right Corner Upright
Rear Center Upright
Shelf Panel
Top Panel
1
1
2
1
QTY
QTY
QTY
QTY
Parts & Hardware
pin holes
pin holes
pin holes on both sides
Parts & Hardware

3 | 844.425.8368 OPEN PLAN LARGE LOW BOOKCASE
PT. 1690 x 4PT. 1693 x 2PT. 9016 x 1
front corner
upright
front corner
upright front center
upright
Step 01
ATTACH SHELF PANELS TO FRONT UPRIGHTS.
Attach the shelf panels to the front uprights using the
provided hardware as shown.
Note that front uprights do not have pin holes.

[e-mail] |4ASSEMBLY NOTES
PT. 1693 x 2PT. 9016 x 1
Step 02
ATTACH REAR CENTER UPRIGHT.
Attach the rear center upright to the shelf
panels using the provided hardware as shown.

5 | 844.425.8368 OPEN PLAN LARGE LOW BOOKCASE
PT. 8053 x 8
Step 03
ATTACH BACK PANELS TO REAR CENTER UPRIGHT.
Place metal pins in the center rear upright and align
with back panel pieces as shown.

[e-mail] |6ASSEMBLY NOTES
PT. 1690 x 4PT. 9016 x 1
Step 04
ATTACH REMAINING UPRIGHTS.
Attach the remaining rear corner uprights
using the provided hardware as shown.
Ensure that the back panel pins align with
the uprights.

7 | 844.425.8368 OPEN PLAN LARGE LOW BOOKCASE
PT. 4022 x 6
Step 05
INSTALL ADJUSTABLE GLIDES.
Install adjustable glides to the bottom of
the uprights as shown. Ensure that the
uprights are level prior to using the product.

[e-mail] |8ASSEMBLY NOTES
PT. 1690 x 4PT. 1693 x 2PT. 9016 x 1
Step 06
ATTACH TOP PANEL.
Attach the top panel using the provided
hardware as shown.

9 | 844.425.8368 OPEN PLAN LARGE LOW BOOKCASE
PT. 1217 x 4
8041
An�-�p Bracket
PT. 8041 x 2
Step 07
ATTACH ANTI-TIP BRACKETS TO BOOKCASE.
Brackets must be installed to the back rail of the top
panel. In order to prevent damage, it is recommended
that 3/32” pilot holes be drilled prior to installation.
Note: Ensure that the depth of the pilot hole does not
exceed 1/2”. A deeper pilot hole may be visible on the
opposite side.

[e-mail] |10ASSEMBLY NOTES
PT. 1218 x 4PT. 8054 x 4
8041
An�-�p Bracket
PT. 8041 x 2
1” lower than
top panel
OR
wall
wall
Step 08
ATTACH ANTI-TIP BRACKETS TO WALL.
Wall anchors and fasteners are included for installation
into drywall. Please consult your local hardware
professional to determine the hardware best suited for
your wall type.
If the mounting locations are positioned on a stud, the
installation of wall anchors may be skipped. Instead,
drill 7/64” pilot holes in the marked positions and install
anti-tip bracket with provided hardware as shown.
If the mounting locations are not positioned on a stud,
drill 15/64” holes into the marked locations and press
wall anchors into the drilled holes and install anti-tip
bracket with provided hardware as shown.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
8042
An�-�p Strap
PT. 8042 x 2
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use quality cleaners formulated for
wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
Step 09
SECURE BOOKCASE.
Install and tighten wall straps prior to using the product.
