BluDot Chassis Sofa Series Quick start guide

Chassis Sofa Collection
DESIGNED IN 2017
ASSEMBLY NOTES | REV 03
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
A WHOLE LOTTA SOMETHING SPECIAL.
Chassis is a configurable seating system that is capable of being a sectional,
a sofa, a loveseat, a lobby or an entire living room unto itself.You decide.

1 | 844.425.8368 CHASSIS SOFA COLLECTION
Tube Cap
1*QTY
Sectional Bracket
2QTY
Large Cushion Sling
1*QTY
Small Seat Cushion
1*QTY
End Cushion Sling
1*QTY
Small Cushion Sling
1*QTY
Seat Frame
1QTY
Back Frame
1QTY
Pt. 8048
4*QTY
* Hardware and part quantities can vary depending on your particular purchase. Feel free to
contact customer service if you have any questions or concerns regarding your purchase.
Parts & Hardware

[e-mail] |2ASSEMBLY NOTES
Table Top
1*QTY
Adjustable Foot
8*QTY
Small Back Cushion
1*QTY
Large Back Cuhsion
1*QTY
Large Seat Cushion
1*QTY
End Cushion
1*QTY
* Hardware and part quantities can vary depending on your particular purchase. Feel free to
contact customer service if you have any questions or concerns regarding your purchase.
Parts & Hardware

3 | 844.425.8368 CHASSIS SOFA COLLECTION
* Partial back frames can be installed on either the left or right side
depending on your seating needs.Partial back frame shown on right side.
*
Step 01
ATTACHING BACK FRAME.
Align back frame with seat frame holes and
slide into place.

[e-mail] |4ASSEMBLY NOTES
* Tube cap is included with some products.
Place tube cap in remaining rear leg frame
hole and attach leg as shown.
*
Sectional brackets are included for
connecting multiple product pieces.
Step 02
ATTACHING THE LEGS.
Align legs with seat frame holes and turn
clockwise until tight.

5 | 844.425.8368 CHASSIS SOFA COLLECTION
A
B
Step 03
ATTACHING THE CUSHION SLINGS.
Place cushion slings into seat frame as shown.
Next, wrap the sling around the back frame
and secure using the pre-attached zipper and
button snaps as shown.

[e-mail] |6ASSEMBLY NOTES
A B
Step 04
ATTACHING THE END CUSHION SLING, IF INCLUDED.
Follow the below step if an end cushion is included
with your purchase; if not, please move to Step 05.
Place end cushion sling into seat frame as shown.
Next, wrap the sling around the seat frame and
secure using the pre-attached zipper and button
snaps as shown.

7 | 844.425.8368 CHASSIS SOFA COLLECTION
* Some pieces within the collection ship with end cushions.End cushions
can easily be identified as they will be deeper than the other cushions.
*
Step 05
PLACING THE CUSHIONS.
Place the seat cushions onto the seat frame
first, push back until they touch the sling.
Place the back cushions on top of the seat
cushions and against the sling.

[e-mail] |8ASSEMBLY NOTES
PT. 8048 x 4
Step 06
ATTACHING THE TABLE, IF INCLUDED.
Some pieces within the collection ship with
integrated tables. Follow the below step if a
table is included with your purchase; if not,
please move to Step 07.

9 | 844.425.8368 CHASSIS SOFA COLLECTION
Step 07
LEVELING YOUR PURCHASE.
This product comes with adjustable leg
levelers. Rotate the levelers as needed based
on your floor prior to first use.

[e-mail] |10ASSEMBLY NOTES

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
Additional Information
CLEAN
Vacuum your upholstery regularly. For leather furniture dust
regularly with a dry cloth.
SPILLS
Act quickly with spills. Absorb the spill with a clean white cloth
or paper towel. Never rub the surface. Do not use water or other
liquids to clean, as they may cause stains. Consult a commercial
cleaning specialist for removal of stubborn stains.
AVOID
Keep furniture out of direct sunlight and away from heat sources;
excessive exposure to sunlight may cause color fading. Avoid
placing heavy or sharp objects on the furniture surface for long
periods of time; this can cause permanent surface indentations.
For snags in the fabric, tuck loose threads into fabric or carefully
push to reverse side. Never pull out or cut off loose threads.
