BluDot Modu-licious 5 Quick start guide

Modu-licious #5
DESIGNED IN 1999
ASSEMBLY NOTES | REV 00
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
YOU WANT CHOICES, WE GOT CHOICES.
Drawers and doors are your canvas with the award-winning
Modu-licious series.

1 | 844.425.8368 MODU-LICIOUS #5
Pt. 5005
32QTY
Pt. 4005
4QTY
Pt. 5002
30QTY
Pt. 8018
6QTY
Pt. 5001
QTY 30
8041
Anti-tip Bracket
Pt. 8041
2QTY
8042
Anti-tip Strap
Pt. 8042
1QTY
Pt. 1217
QTY 2
Pt. 1218
2QTY
Pt. 1023
QTY 24
Parts & Hardware

[e-mail] | 2ASSEMBLY NOTES
Partition Panel
2QTY
Bottom Panel
1QTY
Top Panel
1QTY
Side Panel
2QTY
Drawer
6QTY
Back Panel
3QTY
*panel has grooves on both sides *panel has drilled holes on both sides
Drawer Slide
12QTY
Stretcher
1QTY
Foot
2QTY
Parts & Hardware

3 | 844.425.8368 MODU-LICIOUS #5
354
1 2
How to use the cam lock system
Note direction of cam arrow. Turn cam clockwise 1/2 turn or until tight. Note direction of cam arrow.
How to use the cam lock system

[e-mail] | 4ASSEMBLY NOTES
PT. 5001 x 2PT. 5002 x 2PT. 4005 x 4
Finished edge
Step 01
ASSEMBLE BASE.
Using the stretcher and feet assemble the
base as shown. Refer to page 3 on how to use
the cam lock system.

5 | 844.425.8368 MODU-LICIOUS #5
PT. 5001 x 4PT. 5002 x 4
Bottom panel
Step 02
ATTACH BOTTOM PANEL.
Attach the bottom panel to the base using
the provided hardware as shown. Refer to
page 3 on how to use the cam lock system.

[e-mail] | 6ASSEMBLY NOTES
PT. 1023 x 24
Right side panel
Step 03
ATTACH DRAWER SLIDES.
Attach drawer slides to side panels as shown
using the provided hardware. Repeat for left
side panel.

7 | 844.425.8368 MODU-LICIOUS #5
PT. 5001 x 6PT. 5002 x 6PT. 5005 x 8
Step 04
BEGIN ASSEMBLING CASE.
Attach partition panels to left side panel
as shown using the provided hardware. Be
sure to align grooves on partition panels
and side panel. Refer to page 3 on how to
use the cam lock system.

[e-mail] | 8ASSEMBLY NOTES
PT. 5001 x 6
PT. 5002 x 6
PT. 5005 x 8
Step 05
ATTACH RIGHT SIDE PANEL.
Slide back panel into place as shown. Attach
right side panel as shown using the provided
hardware. Refer to page 3 on how to use the
cam lock system.

9 | 844.425.8368 MODU-LICIOUS #5
PT. 8018 x 6
Step 06
INSERT REMAINING BACK PANELS.
Add rubber grommets to each back panel
as shown. Insert back panels into grooves
in case.

[e-mail] |10ASSEMBLY NOTES
PT. 5001 x 12 PT. 5002 x 12 PT. 5005 x 16
Step 07
FINISH ASSEMBLING CASE.
Finish assembling the case by attaching
the top and bottom panels as shown using
the provided hardware. Refer to page 3 on
how to use the cam lock system.

11 | 844.425.8368 MODU-LICIOUS #5
Step 08
INSTALL DRAWERS.
To install the drawers extend drawer slides out
from case, align with drawer slides as shown,
and slide drawer in. Be sure to push until
drawer is completely closed and engaged.

[e-mail] |12ASSEMBLY NOTES
8041
Anti-tip Bracket
PT. 8041 x 1PT. 1218 x 2
1” lower than
case top
Side Panel
Wall
Step 09
ATTACH ANTI-TIP BRACKET TO THE WALL.
Install anti-tip bracket to wall stud 1-inch
below case top panel height.

13 | 844.425.8368 MODU-LICIOUS #5
8041
Anti-tip Bracket
PT. 8041 x 1PT. 1217 x 2
Back
Panel
Top
Step 10
INSTALL ANTI-TIP BRACKET TO CASE.
Bracket must be installed to top panel of case.
In order to prevent damage, it is recommended
that 3/32” pilot holes be drilled prior to
installation.

[e-mail] |14ASSEMBLY NOTES
8042
Anti-tip Strap
PT. 8042 x 1
Step 11
SECURE THE CASE.
Install and tighten the strap prior to using the
product.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulate
for wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
Additional Information
TO REMOVE DRAWERS
Pull lever up on the right side and push down on the left side
of the drawer slide. With levers engaged pull drawer out.
TO ADJUST DRAWER FRONTS
Loosen the acorn nuts, adjust drawer front, re-tighten acorn nuts.
