  9. BluDot LAKE ROUND DINING TABLE User manual

BluDot LAKE ROUND DINING TABLE User manual

WWW.BLUDOT.COM LAKE ROUND DINING TABLE rev02 - PAGE 1 OF 2
have your lake
and eat on it too.
PARTS
& HARDWARE
x1
x1
x1
x2
Connect each Minor
Leg to the Major
Leg Assembly using:
#1067 allen bolt,
#3001 lock washer,
#3002 washer,
#8028 cresent moon
standoff.
x4
#4011
x4
#1067
x3
#1068
x2
#5020
x1
#9015
x4
#3001
x4
#3002
x1
#5022
x4
#8028
x4
8028
x4
3002
x4
3001 x4
1067
x2
5020
x1
9015
x1
5022
ASSEMBLE
UPSIDE DOWN
Glass Top Major Leg Minor Leg Bracket
Insert wooden
dowels first, #5022
is shared and one
#5020 for each
Minor Leg
1
LAKE
ROUND
DINING
TABLE
ASSEMBLY NOTES
GLASS
First, remove dirt or
debris from surface of glass
with a slightly damp, soft cloth.
To remove fingerprints or streaks,
use a quality glass cleaner.
Don’t forget about the
underside of the glass,
for the perfect clean.
Clean with a slightly
damp, soft cloth. To remove
dirt and fingerprints, use a
quality cleaner formulated
for wood furniture. Wipe
completely dry with a soft
cloth in the direction of
the wood grain.
WOOD
FRAME
#5022
#5020
WWW.BLUDOT.COM LAKE ROUND DINING TABLE rev02 - PAGE 2 OF 2
Space rubber
bumpers evenly
and on center of
rails as shown.
Gently place
glass top on
rubber bumpers.
2 3
Secure Minor
and Major Leg
Assemblies, with
Steel Bracket and
#1068 Allen Bolts.
x3
1067
x1
9008
x4
4011
Use 2 or more
persons to set
glass on frame.
