BluDot Modu-licious 3 Quick start guide

Modu-licious #3
DESIGNED IN 1999
ASSEMBLY NOTES | REV 00
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
YOU WANT CHOICES, WE GOT CHOICES.
Drawers and doors are your canvas with the award-winning
Modu-licious series.

1 | 844.425.8368 MODU-LICIOUS #3
Pt. 5005
24QTY
Pt. 4005
4QTY
Pt. 8017
4QTY
Pt. 5002
24QTY
Pt. 8018
4QTY
Pt. 1206
12QTY
Pt. 5001
QTY
Pt. 8016
4QTY24
8014
Modu-licious door kit
Steel Rod 374mm t7mm
Pt. 8014
QTY 4
8015
Modu-licious door kit
Rubber Stop
15mm
Pt. 8015
QTY 4
8041
Anti-tip Bracket
Pt. 8041
2QTY
8042
Anti-tip Strap
Pt. 8042
1QTY
Pt. 1217
QTY 2
Pt. 1218
2QTY
Parts & Hardware

[e-mail] | 2ASSEMBLY NOTES
Center Panel
1QTY
Bottom Panel
1QTY
Top Panel
1QTY
Foot
2QTY
Side Panel
2QTY
Back Panel
2QTY
*panel has grooves on both sides *panel has drilled holes on both sides
Pt. 8045
4QTY
Door
4QTY
Stretcher
QTY
Partition Panel
2QTY1
Parts & Hardware

3 | 844.425.8368 MODU-LICIOUS #3
354
1 2
How to use the cam lock system
Note direction of cam arrow. Turn cam clockwise 1/2 turn or until tight. Note direction of cam arrow.
How to use the cam lock system

[e-mail] | 4ASSEMBLY NOTES
PT. 5001 x 2PT. 5002 x 2PT. 4005 x 4
Finished edge
Step 01
ASSEMBLE BASE.
Using the stretcher and feet assemble the
base as shown. Refer to page 3 on how to use
the cam lock system.

5 | 844.425.8368 MODU-LICIOUS #3
PT. 5001 x 4PT. 5002 x 4
Bottom panel
Step 02
ATTACH BOTTOM PANEL.
Attach the bottom panel to the base using
the provided hardware as shown. Refer to
page 3 on how to use the cam lock system.

[e-mail] | 6ASSEMBLY NOTES
PT. 5001 x 6PT. 5002 x 6PT. 5005 x 8
Side panel
Center panel
Side panel
Step 03
BEGIN ASSEMBLING CASE.
Attach side panels to center panel as shown
using the provided hardware. Be sure to align
grooves on center and side panels. Refer to
page 3 on how to use the cam lock system.

7 | 844.425.8368 MODU-LICIOUS #3
PT. 8018 x 4
Step 04
INSERT BACK PANELS.
Add rubber grommets to each back panel
as shown. Insert back panels into grooves
in case.

[e-mail] | 8ASSEMBLY NOTES
PT. 5001 x 12 PT. 5002 x 12 PT. 5005 x 16
Top panel
Step 05
FINISH ASSEMBLING CASE.
Finish assembling the case by attaching the
top and bottom panels as shown using the
provided hardware. Refer to page 3 on how to
use the cam lock system.

9 | 844.425.8368 MODU-LICIOUS #3
PT. 1206 x 8PT. 8045 x 4PT. 8017 x 4
Step 06
INSERTING THE PARTITION PANELS.
Attach the metal brackets and magnet
catches as shown. Align partition panel
grooves with brackets and slide into place.

[e-mail] |10ASSEMBLY NOTES
Modu-liciousdoor kit
Ru b ber Stop
15mm
Modu-liciousdoor kit
Ru b ber Stop
15mm
8015
Modu-liciousdoor kit
Ru b ber Stop
15mm
8015
Modu-liciousdoor kit
Ru b ber Stop
15mm
8015
Modu-licious door kit
Rubber Stop
15mm
PT. 8015 x 4PT. 1206 x 4
Modu-liciousdoor kit
Ru b ber Stop
Step 07
ATTACH DOOR BUMPERS.
Attach the door bumpers as shown using
the provided hardware.

11 | 844.425.8368 MODU-LICIOUS #3
PT. 8014 X 4
8014
Modu-licious door kit
St eel Rod 374mm t7mm
PT. 8016 X 4
A
A
B
B
Step 08
INSTALL DOORS.
To install the doors, start by sliding the metal
rod through the brackets on the back of each
door. Next install doors as shown below.
Angle door and push rod into the pre-drilled
hole on the underside of the top panel.
Align rod with with lower pre-drilled hole.
Slide rod through plastic washer and into
pre-drilled hole.

[e-mail] |12ASSEMBLY NOTES
1” lower than
case top
Side Panel
Wall
8041
Anti-tip Bracket
PT. 8041 x 1PT. 1218 x 2
Step 09
ATTACH ANTI-TIP BRACKET TO THE WALL.
Install anti-tip bracket to wall stud 1-inch
below case top panel height.

13 | 844.425.8368 MODU-LICIOUS #3
8041
Anti-tip Bracket
PT. 8041 x 1PT. 1217 x 2
Back
Panel
Top
Step 10
INSTALL ANTI-TIP BRACKET TO CASE.
Bracket must be installed to top panel of case.
In order to prevent damage, it is recommended
that 3/32” pilot holes be drilled prior to
installation.

[e-mail] |14ASSEMBLY NOTES
8042
Anti-tip Strap
PT. 8042 x 1
Step 11
SECURE THE CASE.
Install and tighten the
strap prior to using the
product.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt
and fingerprints, use a quality cleaner formulate for
wood furniture. Wipe completely dry with a soft cloth
in the direction of the wood grain.
