Troubleshooting Guide
for Bobrick B-840, B-842, B-845, B-846 or B-848
Designer Series Counter-Mounted Automatic, Top Fill Bulk Foam Soap Dispenser
Step 1: To determine cause: Unplug unit and reconnect unit look for Green LED light and sound of motor. Activate soap dispenser continually ve times.
Unit Not Dispensing
If motor running and LED does not stop ashing consistently when hand is in the activation zone.
Likely Cause Action Instruction Replacement
Part/Kit Needed
Fiber Optic Nut may be thread
too tight onto connector port in
the Bottom Housing.
Check Fiber Optic Nut to see if nut has
been overtightened
Tighten Fiber Optic Connector Nut hand tight and then rotate nut
counterclockwise by 1/4 turn (90°).
n/a
No change. All steps above completed. Contact Bobrick Customer Service. n/a
If motor running and LED stops ashing when hand is in the activation zone.
Likely Cause Action Instruction Replacement
Part/Kit Needed
Clogged Nozzle Tip. Remove Nozzle Tip. Clean with warm water and replace. Flush whole system. If Nozzle
continutes to be clogged replace.
828-310
Soap may be too viscous. Ensure that soap meets specified
viscosity range.
Viscosity less than 100cps (CPS = center-
poise) Adjust viscosity and Flush system.
Flush whole system. Replace with soap that is within recommended
viscosity range.
n/a
If unit requires multiple (more
than 5) activations to dispense
foam. Duckbill inside Foam
Mixer Housing may be stuck
open.
Flush whole system. If still requires multiple activations, order new Foam Mixer Housing. 828-322
No change. All steps above completed. Contact Bobrick Customer Service. n/a
If motor not running and LED stops ashing when hand is in the activation zone.
Likely Cause Action Instruction Replacement
Part/Kit Needed
Gear jamming. Check for dried soap. Purge system. Open Cover, pour warm water, and then purge by pressing Automatic
System Flush Button.
n/a
Flashing red LED. Indicates
sensor obstruction.
Ensure all obstructions have been
removed from sensor path.
Refer to mounting template 824-307. n/a
No change. All steps above completed. Contact Bobrick Customer Service. n/a
If motor not running No LED light.
Likely Cause Action Instruction Replacement
Part/Kit Needed
No power to the unit Check A/C adapter connection. If LED lights up then follow the steps listed under “If motor not running
and LED stops flashing when hand is in the activation zone”
n/a
No change. All steps above completed. Contact Bobrick Customer Service. n/a
Unit Leaking
Likely Cause Action Instruction Replacement
Part/Kit Needed
Loose Stem connection to
Bottle Cap.
Unscrew Stem Locking Nut. Push the Bottle Assembly up onto the Stem until it stops. While pushing
upwards on the Bottle, thread the Stem Locking Nut down onto the
Bottle Cap threads. Reference Instruction Sheet 848-191.
n/a
Leaking from bottom of Bottom
Housing.
Locate leak if from bottom of Bottom
Housing.
Unit needs to be returned. Replace with Bottom Housing Replacment Kit. 848-250
Soap
Likely Cause Action Instruction Replacement
Part/Kit Needed
Foam Soap too Airy. Adjust portion control knob. Also check
Nozzle Tip Mesh Screen.
Turn knob clockwise for less air in foam. Clean Mesh Screen and /or
replace.
828-310
Foam Soap too Liquidy/
Watery.
Adjust portion control knob. Also check
Nozzle Tip Mesh Screen.
Turn knob counter clockwise. If Mesh Screen is torn replace. 828-310

Parts List:
Item Description
1 Top Assembly with Spout, Door and Stem
2 LED Light Pipe
3 Foam Nozzle Tip with Mesh
4 Fiber Optic Insert with Sensor Lenses
5 Rubber Counter Gasket
6 Wave Washer
7 Mounting Nut
8 Stem Locking Nut
9 Foam Mixer Housing
10 Bottom Housing Assembly (includes
Soap Bottle)
11 (3) Fiber Optic Cables for Sensor and LED
Light Pipe
12 Fiber Optic Connector Tip Assembly
13 Fiber Optic Nut
14 Portion Control Knob
15 Automatic System Flush Button
16 Key Hole
17 BobKey
18 Air Tube Adapter
19 Air Tube
20 A/C Adapter Kit with U.S. Plug, order Part
No. 3974-57.
For outlets not compatible with U.S.
plugs, order Part No. 3974-58

In the U.S.A.: BOBRICK WASHROOM EQUIPMENT, INC.
200 Commerce Drive, Clifton Park, New York 12065-1350 • Tel: [phone] • FAX: [phone]
11611 Hart Street, North Hollywood, California 91605-5882 • Tel: [phone] • FAX: [phone]
or email [email protected]
In Canada: BOBRICK WASHROOM EQUIPMENT COMPANY
45 Rolark Drive, Scarborough, Ontario M1R 3B1 • FAX: [phone]
© 2020 by Bobrick Washroom Equipment, Inc.
Form No. TSG-B-840 Issued 12/16/20 Printed in U.S.A.
Replacement Parts List
Description Part #
A/C Adapter 3974-57
International AC Adapter Plug Kit (U. K., Europe, Australia) 3974-58
Mack Gasket Kit (To secure Top Assembly under the counter due to
irregular counter surface)
824-167
External A/C Multi Adapter Kit 824-201
Nozzle Tip Replacement Kit Foam 828-310
Foam Mixer Housing 828-322
Installation Hardware Packet with Foam Mixer Housing (Includes Wave
Washer, Counter Gasket, Mounting Nut, BobKey, Stem Locking Nut)
828-443
Bottom Housing Assembly Foam 848-250
Top Housing Assembly Foam, Polished Brass* 840-225
Top Housing Assembly Foam, Matte Black* 842-225
Top Housing Assembly Foam, Brushed Nickel* 845-225
Top Housing Assembly Foam, Polished Nickel* 846-225
Top Housing Assembly Foam, Polished Chrome* 848-225
*Top Housing Assemblies include Installation Hardware Packet and Foam Mixer Housing
Recommended Foam Soaps
Kutol Foaming Luxury Hand Soap
Kutol Foaming Antibacterial Handsoap
Chemcor Foaming Antibacterial Handsoap
State Chemical Gentle Fresh Foaming Hand Soap
State Chemical Gentle Fresh Defense Foaming Antibacterial Hand Soap
SCJ Professional - Refresh Azure Foam
Hillyard Cucumber-Melon, Premium Foam Soap
Hillyard Green Select, Foaming Hand Soap
Total Solutions, Green Apple Foam Soap
Novo Antibacterial Foaming Hand Soap, Lemon Scented
Spartan Lite'n Foamy, Citrus Fresh
Germ-X Antibacterial Foaming Hand Wash
Germ-X Green Foaming Hand Soap
Betco Pink Foaming Skin Cleanser
BETCO Green Earth Clear Foaming Skin Cleanser
Enviro-Chem Foam Care Hand Soap
DAYCON Foaming Hand Soap
