Bobrick B-3574 Instruction manual

continued . . .
The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. Rev. 10/4/16R/A, S/C Printed in U.S.A.
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2016 by Bobrick Washroom Equipment, Inc.
Technical Data
17-3/16''
435mm
30-5/8''
780mm
S
S
15-3/16''
385mm
11-7/16''
290mm
1''
25mm
Ty p .
3-3/4''
95mm
S
S
Toilet-Seat-Cover
Dispenser
Toilet Tissue
Dispenser (2)
3-15/16''
100mm
S
28-3/4''
730mm
Recommended Cutout Height Off Floor
59'' 1500mm
3''
75mm
Grab Bar
(Not Furnished)
33''
840mm
to
Floor
Sanitary
Napkin
Disposal
Panel
Lock
& Key (2)
3/16''
5mm
Finish Face of Wall
Recommended Cutout Height Off Floor For Accessible Design
42-3/8'' 1075mm
Shelf
Upper
Door
Centerline of Toilet Tissue
Dispenser shall be 7'' to 9''
(180 to 230mm) in Front of Toilet.
C
L
Removable
Waste
Receptacle
27-13/16''
705mm
16-3/8''
415mm
Lower
Door
C
L
Outlet of Toilet Tissue Roll
shall be 18'' (460mm) ICC/ANSI
or 15'' (380mm) ADA Above Floor
5-5/8''
140mm
Rough Wall Opening
16'' (405mm) wide
29-1/4'' (745mm) high
4'' (102mm) minimum recessed depth
See Designer's Notes under Installation for
Rough Wall Opening Location Information
MATERIALS:
Cabinet —18-8, Type-304, heavy-gauge stainless steel. All-welded construction. Exposed surfaces have satin finish.
Flange —18-8, Type-304, 22-gauge (0.8mm) stainless steel with satin finish. Drawn and beveled, one-piece, seamless
construction.
Doors (2) —18-8, Type-304, 18-gauge (1.2mm) stainless steel with satin finish. One-piece, seamless construction. Secured to
cabinet with a full-length stainless steel piano-hinge. Equipped with a tumbler lock keyed like other Bobrick washroom
accessories.
Toilet Tissue Dispensers (2) — .100" (2.5mm) thick ABS. Equipped with two theft-resistant, heavy-duty, one-piece molded
ABS spindles.
Disposal Panel — 18-8, Type-304, 22-gauge (0.8mm) stainless steel with hemmed edges; exposed surface has satin finish.
Secured to cabinet with a spring-loaded, full-length stainless steel piano-hinge. Equipped with an international graphic symbols
identifying napkin disposal.
Waste Receptacle — Leak-proof molded polyethylene. Removable for servicing. Capacity: 0.8-gal. (3.0-L).
OPERATION:
Doors unlock with key provided and swing open for filling. Toilet seat-cover dispenser holds 500 single- or half-fold paper
covers. Spindles may be removed from cabinet only when door is open. Receptacle is removable for servicing. Unit holds two
standard-core toilet tissue rolls up to 5-1/4'' (135mm) diameter (1800 sheets).
Designer's Note: It is recommended that one full toilet tissue roll remain wrapped until the other roll has been depleted to avoid
wasting ends of both rolls.
ClassicSeries®
RECESSED
TOILET SEAT-COVER DISPENSER,
SANITARY NAPKIN DISPOSAL,
AND TOILET TISSUE DISPENSER
B-3574

The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. B-3574 Rev. 10/1/16R/A, S/E Printed in U.S.A.
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2016 by Bobrick Washroom Equipment, Inc.
INSTALLATION:
Provide framed rough wall opening 16'' wide x 29-1/4'' high (405 x 745mm). Minimum recessed depth required from finish
face of wall is 4'' (102mm). Top of wall opening should be 42-3/8'' (1075mm) from finish face of floor to allow placement of
horizontal grab bar at 33'' (840mm) height across front of unit and installation of 18" vertical grab bar (ICC A117.1-2009). Allow
clearance for construction features that may protrude into rough wall opening from opposite wall. Coordinate with
mechanical engineer to avoid pipes, vents, and conduits in wall. If unit projects above top of wainscot, provide aluminum
channel or other filler to eliminate gap between flange and finish face of wall. Mount unit in wall opening with shims between
framing and cabinet at all points indicated by an S, then secure unit with #8 x 1-1/4" (4.2 x 30mm) sheet-metal screws
(not furnished).
Designer's Notes:
1. Recessed B-3574 mounts flush against side wall in accessible toilet compartment has toilet tissue dispenser on right side
of unit.
2. Position unit on wall with centerline of toilet tissue dispenser 7" - 9" (180 - 230mm) in front of leading edge of toilet.
3. For unit to mount on right side of toilet (when seated on toilet) see model B-35745.
4. For visual placement of models inside toilet compartment, refer to Technical Bulletin TB-92.
SPECIFICATION:
Recessed toilet seat-cover dispenser, sanitary napkin disposal, and toilet tissue dispenser shall be Type-304 stainless steel with
all-welded construction; exposed surfaces shall have satin finish. Toilet tissue dispensers shall be ABS plastic. Flange shall be
drawn and beveled, one-piece, seamless construction. Unit shall mount flush against side wall in accessible toilet compartment
to allow clearance for grab bar across front of unit and installation of 18" vertical grab bar (ICC A117.1-2009). Doors shall be
one-piece, seamless construction; secured to cabinet with a full-length stainless steel piano-hinge; and equipped with a tumbler
lock keyed like other Bobrick washroom accessories. Toilet seat-cover dispenser holds 500 paper covers. Self-closing disposal
panel shall be secured to door with a spring-loaded, full-length stainless steel piano-hinge, has hemmed edges and equipped
with an international graphic symbol identifying napkin disposal. Sanitary napkin disposal shall be furnished with a removable,
leak-proof, molded polyethylene receptacle with a capacity of 0.8-gal. (3.0-L). Unit shall be equipped with two theft-resistant,
heavy-duty, one-piece molded ABS toilet tissue spindles that hold standard-core rolls up to 5-1/4'' (135mm) diameter
(1800 sheets). Spindles shall be removable from cabinet only when door is open.
Recessed Seat-Cover Dispenser, Sanitary Napkin Disposal, And Toilet Tissue Dispenser shall be Model B-3574
of Bobrick Washroom Equipment, Inc., Clifton Park, New York; Jackson, Tennessee; Los Angeles, California;
Bobrick Washroom Equipment Company, Scarborough, Ontario; Bobrick Washroom Equipment Pty. Ltd.,
Australia; and Bobrick Washroom Equipment Limited, United Kingdom.
