Bobrick Classic Series User manual

Installation Instructions
For Models:
Model Number / Description File Name
B-155 ClassicSeries® Surface-Mounted LiquidMate® Soap Dispenser B-150.pdf
1

Designer’s Notes:
These dispensers should be mounted over a sink or
lavatory. Provide 1-1/2" (38mm) minimum clearance
above container for refilling. The four #8 x 1-1/4" (4.5 x
32mm) screws furnished with unit should be used for
mounting unit on most wall surfaces. In some cases, wall
anchors will be required (not furnished).
HOW TO INSTALL DISPENSER:
1. Align the assembled unit vertically.
2. Mark the bottom edge and two bottom mounting holes.
3. Remove the container and realign the bracket with
your marks.
4. Mark the two top mounting holes.
5. Predrill mounting holes with 1/16" to 3/32" (1.6–
2.4mm) drill bit.
6. Screw bracket into place.
7. Fill container per instructions and return to bracket.
HOW TO REMOVE AND FILL CONTAINER:
1. Unscrew retaining collar under bracket until container
is free.
2. Turn container upright and unscrew liquid valve.
3. Fill container with thin, free-flowing liquid soap or
detergent, then reinstall dispenser mechanism. Finger
tighten liquid valve onto bracket.
4. Finger tighten retaining collar onto container.
MAINTENANCE:
Use warm water and mild soap to clean all parts. NEVER
USE ABRASIVE CLEANERS.
REPLACEMENT PARTS LIST
Part Name Part No.
Liquid Valve – Charcoal 150-4
Liquid Valve – Beige 151-4
24-fl oz (0.7-L) Container 155-7
© 2010 by Bobrick Washroom Equipment, Inc.
Form No. 150-69 r12/29/10 Printed in U.S.A.
24-fl oz (0.7-L)
Bottle
155-7
Washer
150-4
151-4
Liquid
Valve
Mounting
Screw
Bracket
Retaining
Collar
Mounting
Screw
INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
BOBRICK MODELS B-155 AND B-156 LiquidMate®SOAP DISPENSERS
LiquidMate®Soap Dispensers
In the U.S.A.: BOBRICK WASHROOM EQUIPMENT, INC.
#OMMERCE$RIVE#LIFTON0ARK.EW9ORKs4ELs&!8
(ART3TREET.ORTH(OLLYWOOD#ALIFORNIAs4ELs&!8
In Canada: BOBRICK WASHROOM EQUIPMENT COMPANY
2OLARK$RIVE3CARBOROUGH/NTARIO-2"s/NTARIO%AST4EL&!8
s-ANITOBA7EST4EL&!8
716954 00008 8
B-156
716954 00003 3
B-155
QA010511
