Body Craft BCG 446-P User manual

GALENA PRO STRENGTH TRAINING SYSTEM
INSTRUCTION MANUAL
MODEL BCG 446-P
6850
Bodycraft is a division of Recreation Supply Inc.
P.O. BOX 181
Sunbury, OH 43074
QUESTION?
As a quality home gym supplier we are committed to your complete satisfaction. If you have
questions, or find missing or damaged parts, we will guarantee your complete satisfaction through
our authorized dealer service centers or our home office customer service department. Please call
your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained
technicians will provide immediate assistance to you, free of charge.

BEFORE YOU BEGIN
Congratulations and thank you for selecting the BODYCRAFT GALENA PRO
strength training system. The BODYCRAFT GALENA PRO offers an impressive
array of strength training exercises to develop every major muscle group of the
body.
Whether your goal is cardiovascular fitness, a shapely, toned body or dramatic
muscle size and strength, the BODYCRAFT GALENA PRO will help you
achieve the specific results you want.
For your safety and benefit, read this manual and the accompanying literature
before using the BODYCRAFT GALENA PRO. Keep this manual for future
reference. If you have additional questions, please call your local BODYCRAFT
dealer or our customer service department at 800-990-5556 Monday through
Friday, 9 a.m. until 5 p.m. Eastern Time.
IMPORTANT SAFETY NOTES
1
There is a risk assumed by individuals who use this type of equipment.
Before beginning this or any other exercise program consult your physician.
This is especially important for individuals over the age of 35 or persons
with pre-existing health problems. Recreation Supply, Inc. assumes no
responsibility for personal injury or property damage sustained by or
through use of this product.
1.This product must be assembled on a flat, level surface to assure its
proper function.
2.Clean pads and frame on a regular basis. We recommend warm,
soapy water. Do not use harsh or abrasive chemicals.
3.Inspect and tighten all parts before every use. Replace any worn
parts immediately. Failure to do so may result in serious injury.
4.Keep children away from the BODYCRAFT GALENA PRO at all times.
5.Keep your hands away from cables and pulleys during operation.
Keep your hands away from moving parts other than the designated
handles.
6.When adjusting the seat, make sure the spring pin is fully engaged.
If not, the seat may slip and cause serious injury.
7.Make certain all cables are seated within the pulleys before every use.
8.Exercise with care to avoid injury.
9.If unsure about the proper use of the BODYCRAFT GALENA PRO
strength training system call your local BODYCRAFT dealer or our
customer service department at 800-990-5556.

EXPLODED
22
78
90
32
10
32
32
82
82
18
49
86
89
18
49
90
87
90
90
28
56
79
65
65
97
33
35
90
90
75
32
33
97
56
87
82
57
26
87 90 85
88
71
88
49
32
32
55
36
90
24
24
75
51
60
60
60
60
22
37
60
37
60
37
37
37
37
90
21
87
75
75 90
52
35 24
35
20
55
36
32
32
90
57
66
66
96a
96a
96b
45a
90
2
96 96
3
53
49
90
90
78
58a
90
90
90
19
90
76
90
34
76
90
87
84 90 90
90
84
84
84 84
84
90 90
87
87
87
64
49
64
87
9
55
4
8
29
87
87
82
82
82
82
82
82
82
87
82
70
90
79
90
80
79
49
49 49
49
49 68
68
68
90
87
49
49
87
76
76 90
90
90 79
87
90 90
90
90
90
87 90
93
93
99
98
67
67
32
32
23
95
41
87
74
86
68
90
79
90
34
87
90
90
90
87
79
79
82
79
49
49
90
87
90
87
77
77
77
96a
29a
94a
45a
103
103
104
104
102
105
105
19a
40a
24a
30a
96b 96a
82
49
63
49
68
87
68
41
90
11a
94a
96b
96b 96a96b
48a
101
87
87
87
49
49
49
27a
90
39
87
54
87
12
86
86 93
93
92
89
89
89
65
72
72
14
59
59
40
33
65
27
33
65
65
90
98
90
90
87
69
81
69
69
69
87
81 90
27
90
65
90
98
61
91
91
61
73
32
73
93
40 91
91
93
17
89
16
15
89
86
86
89
89
93
14
17
32
65
32
65
65
13
89
92
87
49
38
42
82
82
82
87
49
82
7
32
32
25
101 100 100
34 34
62
5050
1
82
6
38
39
44
43 5858
43
64 64
6

1
2
3
4
5
6
7
8
9
10
11a
12
13
14
15
16
17
18
19
19a
20
21
22
23
24
24a
25
26
27
27a
28
29
29a
30a
31
32
33
34
35
36
37
38
1
1
1
1
2
2
19
1
1
1
1
1
1
2
1
1
2
2
1
1
1
1
1
1
3
1
1
1
2
1
1
1
1
1
2
14
4
3
3
2
6
2
BASE FRAME
PEC DEC UPRIGHT
PRESS UPRIGHT
CENTER UPRIGHT
GUIDE ROD
STACK SPACER
WEIGHT PLATE
TOP PLATE
SELECTOR ROD
TOP FRAME
AB PULLEY TUBE
PEC DEC PULLEY BRACKET
PEC DEC SUPPORT
ADJ. CAM
LEFT PEC DEC ARM BRACKET
(pre-assembled)
RIGHT PEC DEC ARM BRACKET
(pre-assembled)
PEC DEC ARM
PULLEY GUIDE BRACKET
PEC DEC SEAT BAR
PRESS ARM SUPPORT
PRESS ARM
SEAT FRAME
CHROME SEAT ADJUSTER
LEG EXTENSION
ROLLER BAR
PRESS AXLE
CURL BAR
LAT BAR
BUSHING OF HAND GRIP
(pre-assembled)
DOUBLE PULLEY BRACKET
LAT BAR HOLDER
FLOATING PULLEY BLOCK
ADJ PULLEY BLOCK
CHROME BACK ADJUSTER
60mm SQ. END PLUG
50mm SQ. END PLUG
50mm SQ. END CAP
45 X 75mm RECT. END PLUG
1" X 2" RECT. END PLUG
1-1/4" ROUND END PLUG
1" ROUND END PLUG
RUBBER CUSHION
NO DESCRIPTION QTY
PARTS LIST
3
(25) (27) (27a)
(24) (24a)
(29) (29a) (30a)
(28)
(22)(21) (23)
(11a)
(17)
(26)
(20)(19) (19a)
(15) (16)
(5)
(4)
(3)
(2)
(1) (10)
(6) (7)
(8)
(12) (14)
(9)
(13)
(18)
(31) (32)
(33) (34) (35) (37)(36) (38)

39
40
40a
41
42
43
44
45a
46a
48a
49
50
51
52
53
54
55
56
57
58
58a
59
60
61
62
63
64
65
66
67
68
69
2
2
1
2
1
4
1
1
1
1
24
2
1
1
1
1
2
2
2
2
2
2
6
3
1
1
4
10
2
2
6
4
RUBBER STOPPER (pre-assembled)
POP PIN
RED POP PIN (pre-assembled)
KNOB
SELECT PIN
CLIP
LINK
TOP CABLE
PEC DEC CABLE
LOWER CABLE
PULLEY
NONSLIP
PRESS BACK PAD(SMALLER)
PRESS SEAT PAD(LARGER)
PEC DEC BACK PAD(LARGER)
PEC DEC SEAT PAD(SMALLER)
1-1/4" HAND GRIP(LONGER)
1" X 70mm HAND GRIP
(pre-assembled)
1" X 200mm ROUND HAND GRIP
(pre-assembled)
1-1/4" X 140mm ROUND HAND GRIP
LAT BAR HOLDER COVER
(pre-assembled)
4" X 14" FOAM PAD
4" X 7" FOAM PAD
SINGLE HANDLE
ANKLE STRAP
AB CRUNCH
1" ID BUSHING
3/4" ID BUSHING (pre-assembled)
5/8" ID BUSHING (pre-assembled)
1/2" ID BUSHING (pre-assembled)
3/8" ID X 10mm BUSHING
CAP FOR 3/8" NUT (pre-assembled)
NO DESCRIPTION QTY
PARTS LIST
4
(39) (40) (40a) (41) (42)
(50)
(64) (65) (66)
(67)
(57)(56) (58)
(62)
(68)
(49)
(59) (60) (61)
(63)
(44)(43)
(53)
(52)(51)
(54)
(55)
(45a)
(48a)
(94a)
(46a)
(96)
(69)
(58a)

70
71
72
73
74
75
76
77
78
79
80
81
82
84
85
86
87
88
89
90
91
92
93
94a
95
96
96a
96b
97
98
99
100
101
102
103
104
105
1
1
2
2
1
4
4
4
4
10
1
2
19
6
1
7
44
2
12
58
4
2
8
1
2
2
6
6
2
3
1
2
2
1
2
2
2
7/16" X 1-1/2" TOP PLATE BOLT
5/8" X 7-1/2" HEX HEAD BOLT
1/2" X 4-1/4" HEX HEAD BOLT
1/2" X 3-1/2" HEX HEAD BOLT
1/2" X 3-1/4" HEX HEAD BOLT
3/8" X 1-3/4" HEX HRAD BOLT (ALL)
3/8" X 4" HEX HEAD BOLT
3/8" X 3-3/4" HEX HEAD BOLT
3/8" X 3-1/8" HEX HEAD BOLT
3/8" X 2-3/4" HEAX HEAD BOLT
3/8" X 2-1/2" HEX HEAD BOLT
3/8" X 1-1/4" HEX HEAD BOLT (ALL)
3/8" X 1-3/4" HEX HEAD BOLT
3/8" X 3/4" HEX HEAD BOLT
5/8" NYLON NUT
1/2" NYLON NUT
3/8" NYLON NUT
5/8" WASHER
1/2" WASHER
3/8" WASHER
1/2" TEFLON WASHER
1/2" SPRING WASHER
CAP FOR 1/2" NUT
AB CABLE
5/16" X 1/2" INNER HEX SCREW
(pre-assembled)
WEIGHT STACK GUARD
5/16" X 1/2" HEX HEAD BOLT
5/16" WASHER
3/8" X 3/4" INNER HEX SCREW
(pre-assembled)
3/8" X 5/8" SET SCREW
BUMPER (pre-assembled)
1-1/4" HAND GRIP (pre-assembled)
1" T SHAPE END PLUG
HOOK PLATE
COLLAR
SEALING RING
M6 INNER HEX SCREW
NO DESCRIPTION QTY
PARTS LIST
5
(91)
(92)
(87)(86)
(85)
(90)
(89)
(88)
(84)
(82)
(96a) (98) (100)
(101) (102) (103) (104) (105)
(99)(96b) (97)
(70)
(75)
(76)
(77)
(78)
(79)
(80)
(81)
(72)
(73)
(74)
(71)
0
(inch)
1" 2" 3" 4" 5" 6" 7"1/21/4 3/4 1/2 1/2 1/2 1/2 1/2 1/2 1/21/4
(95)
(93)

1
1
2 34
4
32
79 79
87 87
87
3434
50 50
90 90
90 90
90
90
90
90 90
90
90
32
84
84
84
6
STEP 1 ASSEMBLE BASE FRAME
1. Attach PEC DEC UPRIGHT(2) to BASE FRAME(1) using two 3/8" X 2-3/4" HEX
HEAD BOLTS(79), four 3/8" WASHERS(90) and two 3/8" NYLON NUTS(87).
2. Attach PRESS UPRIGHT(3) to BASE FRAME(1) using two 3/8" X 2-3/4" HEX
HEAD BOLTS(79), four 3/8" WASHERS(90) and two 3/8" NYLON NUTS(87).
3. Attach CENTER UPRIGHT(4) to BASE FRAME(1) using three 3/8" X 3/4" HEX
HEAD BOLTS(84) and three 3/8" WASHERS(90).

To ease the assembly process, do not tighten bolts until instructed.

1
5
6
6
9
8
7
64
70
42
64
38
38
7
STEP 2 ASSEMBLE WEIGHT STACK
1. Insert 1" ID BUSHING(64) into the holes on BASE FRAME(1), insert GUIDE
ROD(5) to 1" ID BUSHING(64) then slide STACK SPACER(6) and RUBBER
CUSHION(38) onto GUIDE ROD(5).
2. Attach TOP PLATE(8) to SELECTOR ROD(9) using 7/16" X 1-1/2" TOP PLATE
BOLT(70). Slide WEIGHT PLATES(7) onto GUIDE ROD(5).
3. Slide TOP PLATE(8) onto GUIDE ROD(5) and insert SELECTOR ROD(9) into
center hole of WEIGHT PLATES(7) using SELECT PIN(42).

2
3
4
5 5
10
11a
32
32
28
96a
96b
90
90
90
64 64
39
90
90
87
87
87
34
90
87
90
90
90
90
90
87
90
87
78
84 84
79
90 90
78
8
STEP 3 ASSEMBLE TOP FRAME
1. Insert two 1" ID BUSHINGS(64) into the holes on TOP FRAME(10), then place
TOP FRAME(10) down onto GUIDE RODS(5) and CENTER UPRIGHT(4).
2. Attach TOP FRAME(10) to CENTER UPRIGHT(4) using three 3/8" X 3/4" HEX
HEAD BOLTS(84) and three 3/8" WASHERS(90). (NOTE: Do Not tighten)
3. Attach PEC DEC UPRIGHT(2) and PRESS UPRIGHT(3) to TOP FRAME(10) each
using two 3/8" X 3-1/8" HEX HEAD BOLTS(78), four 3/8" WASHERS(90) and two
3/8" NYLON NUTS(87).
4. Please check the TOP FRAME(10) is EVENLY seated on CENTER UPRIGHT(4),
PRESS UPRIGHT(3) and PEC DEC UPRIGHT(2).
5. Attach AB PULLEY TUBE(11a) to PRESS UPRIGHT(3) using two 3/8" X 2-3/4"
HEX HEAD BOLTS(79), four 3/8" WASHERS(90) and two 3/8" NYLON NUTS(87).

17 16
15
14
19
12
2
13
17
17R
17R
40
91
91
73 32
32
93
17 89
16 89 93
86
17L
17L 93
73
93 40
91
91
15
89
86
89
17
32
32
93
92
93
92
86
86
89 89
72
76
76
89
89
90
90
90
87
27
27
96b
96b
98
98
33
33 59
59
34
86
9
STEP 4 ASSEMBLE PEC DEC STATION
1. Attach PEC DEC SUPPORT(13) and PEC DEC PULLEY BRACKET(12) to PEC
DEC UPRIGHT(2) using two 1/2" X 4-1/4" HEX HEAD BOLTS(72), two 1/2"
WASHERS(89) and two 1/2" NYLON NUTS(86).
2. Slide ADJ. CAM(14) onto the axle of RIGHT PEC DEC ARM BRACKET(16). Then
thread the axle of RIGHT PEC DEC ARM BRACKET(16) through the hole on PEC
DEC SUPPORT(13) and attach using 1/2" WASHER(89), 1/2" SPRING WASHER(92)
and 1/2" NYLON NUT(86). Attach PLASTIC CAPS(93) on top of 1/2" NYLON
NUT(86).
3. Tighten 1/2" NYLON NUT(86) and back off approximately 1/2 tum so that arm
moves freely. Repeat the same process to PEC DEC ARM(17).
4. Be certain the two ADJ. CAMS(14) are evenly seated on PEC DEC SUPPORT(13)
and two PEC DEC ARMS(17) are WORKING SMOOTHLY before tighten with 1/2"
WASHER(89), 1/2" SPRING WASHER(92) and 1/2" NYLON NUT(86).
5. Moisten FOAM PAD(59) with water and slide onto PEC DEC ARMS(17). Attach
50mm SQ CAP(33) and the BUSHING OF HAND GRIP(27) to the bottom of PEC
DEC ARMS(17), tighten by 5/16" WASHERS(96b) and 5/16" BOLTS(98).
6. Attach PEC DEC SEAT BAR(19) to PEC DEC UPRIGHT(2) using two 3/8" X 4" HEX
HEAD BOLTS(76), four 3/8" WASHERS(90)
and two 3/8" NYLON NUTS(87).

10
19a
20
21
93
41
76
32
32
32
97
40a
32
32
32
85
71
24a
88
89
89
88
76
90
90
90
87
93
86
74
23
3
10
STEP 5 ASSEMBLE PRESS STATION
1. Attach the PRESS ARM SUPPORT(19a) to the TOP FRAME(10) by aligning the
holes and inserting the 5/8" x 7-1/2" HEX BOLT(71) with two 5/8" WASHERS(88),
and one 5/8" NYLON NUT(85). Plug the openings in the TOP FRAME(10) and top
of the PRESS ARM SUPPORT(19a) with 50mm SQ. PLUGS(32).
2. Attach the PRESS ARM(20) to the PRESS ARM SUPPORT(19a) by aligning the
holes and inserting the PRESS AXLE(24a). Tighten the pre-installed 3/8" x 3/4" SET
SCREWS(97) on the back of the PRESS ARM(20). Make sure the RED POP
PIN(40a) is seated in one of the adjustment holes on the PRESS ARM
SUPPORT(19a). Plug the top of the PRESS ARM(20) with two 50mm SQ.
PLUGS(32).
3. Attach PRESS SEAT FRAME(21) to PRESS UPRIGHT(3) using two 3/8" X 4" HEX
HEAD BOLTS(76), four 3/8" WASHERS(90) and two 3/8" NYLON NUTS(87).
4. Attach LEG EXTENSION(23) to PRESS SEAT FRAME(21) using 1/2" X 3-1/4" HEX
HEAD BOLT(74) and 1/2" NYLON NUT(86), then cap 1/2" bolt and nut with CAP
FOR 1/2" NUT(93).

11
(45a)
T1 T3
T5
T4
T6
T7
T8
T2
T2,T4
3
10
82
87
49
T6
3
79
68 68
49
90
90
87
82
87
49
T9,T10
10
82
87
T8
29
87
82
49
STEP 1
T4
T2
T5
T3
Figure 1
T7
T8
T9 T10
T11
Figure 1
T1
45a
10
82
49
87
20
T3, T5
90 79
87
49
STEP 6 INSTALL TOP CABLE
T11
82
87
49
T7
10
Insert the threaded end of the TOP CABLE(45a) into the pulley slot in the front of the TOP
FRAME(10) over pulley T1 and back to pulley T2 on the PRESS UPRIGHT(3). Route cable
over and around Pulley T2, exiting from bottom. Then route cable over top of Pulley T3 [you
will mount two pulleys side-by-side here. T3 is the right side (as if sitting on seat) pulley],
around to bottom of pulley T4. Route cable from bottom of T4, exiting on top, to top of
Pulley T5. Exit from bottom of T5 and route to bottom of pulley T6 mounted in the PRESS
UPRIGHT(3). Run cable along the bottom of T6, and the up and over pulley T7 mounted in
TOP FRAME(10). Attach a pulley in the top hole (closed end) of a FLOATING PULLEY
BLOCK(29). This will be pulley T8 and will dangle from the TOP CABLE(45a) as shown in
Figure 1. Route cable under pulley T8, and over top of Pulleys T9 and T10. The screw end
of cable into the Top Plate about 1/2 way. The cable must always be screwed into the TOP
PLATE(8) at least 1/3 of the way, and locked into place with the locking nut.
Attach Pulley T6 to the PRESS UPRIGHT(3) using one 3/8" x 2-3/4" HEX BOLT(79), two 3/8"
WASHERS(90), two 3/8" ID x 10mm PLASTIC BUSHINGS(68), and one 3/8" NYLON NUT(87).

(46a)
P1
P1, P5
P5
14
17R
2
17L
46a
P3
29a
87
49
82
P2
P2, P4
P4
12
18
18
82
82
87
87
49
12
STEP 7 INSTALL PEC DEC CABLE
Loosely attach pulley P2 and P4 and CABLE GUIDE(18) to PEC DEC PULLEY
BRACKET(12).
Insert one end of PEC DEC CABLE(46a) into receiver on right ADJ. CAM(14)
as shown and route cable over pulley, behind PEC DEC UPRIGHT(2), over
pulley and insert opposite end into receive on left ADJ. CAM(14).
Place pulley P3 over the PEC DEC CABLE(46a) and attach FLOATING PULLEY
BLOCK(29a) as shown and let it dangle behind PEC DEC UPRIGHT(2).
Tighten bolts. Make certain the CABLE GUIDE(18) do not rub on the cable
throughout the entire range of motion.
P1
P2
P3
P4
P5

(94a) eyelet endball end
C2
T8
A1
3
79
68
68
49
90
90
87
A1
A2
A3
A5
A4
A6
A7
11a
79
68
68
90
90
87
A2
49
A3
49
87
82
27a
A4
T8
29
87
82
49
A5
1
82
87
49
A6
C2
82
49
87
29a
2
A7
80
90
90
87
13
STEP 8 INSTALL AB CABLE
DO NOT USE THIS CABLE IF YOU PURCHASED THE OPTIONAL LEG PRESS. THE LEG
PRESS CABLE IS INSTALLED HERE INSTEAD. REFER TO THE LEG PRESS MANUAL.
Run the eyelet end of the AB CABLE(94a) through the slot in the FRONT UPRIGHT(3) and
attach a pulley inside the slot as shown in fig. A1, using one 3/8" X 2-3/4" HEX HEAD BOLT(79),
two 3/8" WASHERS(90), two plastic 3/8" ID X 10mm BUSHINGS(68) and one 3/8" NYLON
NUT(87). The cable should run over top of this pulley. Repeat this process for step A2 as
shown. Route the cable down and around Pulley A3 mounted inside the DOUBLE PULLEY
BLOCK(27a) [using one 3/8" X 1-3/4" HEX BOLT(82) and one 3/8" NYLON NUT(87)] as shown in
A3. Continue routing the cable up and over a pulley mounted in adjustable FLOTING PULLEY
BLOCK T8 (mounted in second hole from bottom for now) as shown in A4. The cable then runs
down the BASE FRAME(1) as shown in A5. Then up and over a pulley mounted in the bottom
of the ADJ PULLEY BLOCK(29a) as shown in A6. Then tie off the ball end inside the slot in
the PEC DEC UPRIGHT(2) using a 3/8" X 2-1/2" HEX BOLT(80), two 3/8" WASHERS(90) and a
3/8" NYLON NUT(87) as shown in A7.

A3
L1
L2
L4
L3
L5
L6
L1
1
82
87
49
48a
L5
1
82
87
49
L2,L4
1
82
87
49
L3
A3
49
87
82
27a
48a
L6
14
STEP 9 INSTALL LOWER CABLE
(48a)
Insert ball end of LOWER CABLE(48a) using 3/8" x 1-3/4" HEX HEAD BOLT(82)
and 3/8" NYLON NUT(87) and route cable under pulley L1, L2, up and around
pulley L3, down and around pulley L4, under pulley L5 then attach the eyelet end
under the cam of LEG EXETESION(23) through the "U" shape bracket of foot rest
in front of BASE FRAME(1) as shown in inset L6.
ball End eyelet End

15
STEP 10 INSTALL ACCESSORIES
1. Attach SMALLER PRESS BACK PAD(51) to CHROME BACK ADJUSTER(30a), using
two 3/8" X 1-3/4" BOLTS(75) and two 3/8" WASHERS(90). Insert ROLLER BAR(24)
through the bottom of CHROME BACK ADJUSTER(30a), moisten FOAM PAD(60)
with water and slide onto the ROLLER BAR(24). Attach 1" ROUND END PLUG(37)
to both end of ROLLER BAR(24). Slide CHROME BACK ADJUSTER(30a) through
bracket on PRESS UPRIGHT(3) and lock in place by KNOB(41).
2. Attach LARGER PRESS SEAT PAD(52) to CHROME SEAT ADJUSTER(22), using
two 3/8" X 1-3/4" BOLTS(75) and two 3/8" WASHERS(90). Insert ROLLER BAR(24)
through the front end of CHROME SEAT ADJUSTER(22), moisten FOAM PAD(60)
with water and slide onto the ROLLER BAR(24). Attach 1" ROUND END PLUG(37)
to both end of ROLLER BAR(24). Repeat same process to LEG EXTENSION(23).
Slide CHROME SET ADJUSTER(22) into SEAT FRAME(21) and lock in place by
KNOB(41).
3. Attach LARGER PEC DEC BACK PAD(53) to PEC DEC UPRIGHT(2), using two
3/8" X 3-3/4" HEX BOLTS(77) and two 3/8" WASHERS(90). Attach SMALLER PEC
DEC SEAT PAD(54) to PEC DEC SEAT BAR(19), using two 3/8" X 3-3/4" BOLTS(77)
and two 3/8" WASHERS(90).
35
60
51
52
60
95
60
60
60
60
48a
37
37
37
37
37
37
24
24
24
35
75
75
75
45a
90
90
41
41
75
90
35
77
77
77 77
90
90
90
53
54
90
23
22
21
2
19
3
30a
43
43
48a
44
25
26
43 45a
94a
61
63
62
43
94a

96
96
10
1
96a
96a
96a
96a
96b
96b
96b
96b
16
STEP 11 INSTALL OPTIONAL WEIGHT STACK GUARDS
(96) OPTIONAL WEIGHT STACK GUARDS
If you did not purchase the optional WEIGHT STACK GUARDS, please
skip this step.
Attach WEIGHT STACK GUARD(96) to BASE FRAME(1) and TOP
FRAME(10) using 5/16" HEX HEAD BOLT(96a) and 5/16" WASHER(96b).

a. The Cables should be tightened to the point just before the Top Plate lifts off the
stack. In other words, if the Top Plate is not resting on the stack, you will need to
add length, or, if there is slack in the cables, you will need to shorten the cables.
There are several adjustment points. If only minor adjustments need to be made,
you can adjust the Screw ends on the Top Cable (at the Top Plate), the Low Cable
(where it screws into the Single Pulley Block), or the Bench Press cable (where it
screws into the Single Pulley Block with Stopper). These ends of these cables
must be screwed in at least 1/3 of their length for safety purposes. Once you
are done with these adjustments, lock them into place using the jam nuts.
b. Broader adjustments are made at the FLOATING PULLEY BLOCK(29). Moving the
bottom pulley toward the center decreases length (takes up slack). Conversely,
moving the bottom pulley outward gains cable length.
c. Once the cables have been adjusted to remove all slack, adjust the RUBBER
STOPPERS(39) in the Top Frame to where they just touch the FLOATING PULLEY
BLOCK(29), and the ADJ. PULLEY BLOCK(29a). The RUBBER STOPPERS(39) aid
in the function of the gym by eliminating the need to engage all cables in any
given exercise routine.
Step 12 The Cable Adjustment
29
17
39
29a

18
Assembly is complete! Please take the following steps before using the gym:
1.
2.
3.
4.
5.
6.
7.
Make certain all bolts are tightened securely.
Make certain all cables are seated into all pulley grooves. A cable rubbing
against steel will peel the nylon coating, voiding warranty and resulting in
a need for replacement.
Pre-stretch the cables. Put the Weight Selector Pin(42) in the bottom hole on the
weight stack. Pull on the cables with great force, helping remove any kinks and
providing any initial cable stretch.
Be aware the cables can loosen and slightly stretch upon initial use.
The cables should be adjusted as tight as possible, but no so tight as to lift the
Top Plate(8) above the weight stack. Be certain to secure the jam nuts after
adjustments are made.
For better performance, apply a household lubricant (such as silicone) to
any adjustable areas and to the Guide Rods(5).
Enjoy many years of a Fit Lifestyle.
Thank you for purchasing the Bodycraft Galena Pro Home Gym. If
you have any questions, please call your local BodyCraft dealer,
call our customer service department at 800-990-5556 or at
http://www.bodycraft.com.
