Bosch Bulls Cross Lite Evo User manual

TRANSLATION OF THE ORIGINAL OPERATING INSTRUCTIONS
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP SAFE TO CONSULT AT A LATER DATE
20-17-4029, 20-17-4030, 20-17-4031, 20-18-1888, 20-18-1950, 20-18-4044, 20-18-4045
MY20B01-22_1.0_21.06.2019
Bulls Cross Lite Evo, Bulls Iconic Evo TR 3 ABS, Bulls Adventure Evo AM, Bulls Iconic Evo TR 1,
Bulls Iconic Evo TR 2, Desert Falcon Evo, Cross Lite Evo Carbon, Sonic Evo AM5 Carbon,
Sonic Evo AM6 Carbon, Sonic Evo TR4 Carbon

MY20B01-22_1.0_21.06.2019 1
Contents
Contents
1 About these operating instructions 5
1.1 Manufacturer 5
1.2 Type number and model 5
1.3 Identifying the operating instructions 6
1.4 Laws, standards and directives 6
1.5 Subject to change 6
1.6 Language 6
1.7 For your safety 6
1.7.1 Instruction, training and customer service 6
1.7.2 Basic safety instructions 6
1.7.3 Warnings 6
1.7.4 Safety markings 7
1.8 For your information 7
1.8.1 Instructions for actions 7
1.8.2 Language conventions 7
1.8.3 Information on the nameplate 7
1.9 Nameplate 8
2 Safety 9
2.1 General warnings 9
2.2 Toxic substances 10
2.3 Requirements for the rider 11
2.4 Protection for vulnerable groups 11
2.5 Data privacy 11
2.6 Personal protective equipment 11
2.7 Safety markings and safety instructions 11
2.8 Emergency 12
2.8.1 What to do in an emergency 12
2.8.2 First aid treatment 12
2.8.3 Fighting fire 12
2.8.4 Leaking fluids 13
2.8.4.1 Brake fluid 13
2.8.4.2 Oils and lubricants from the fork 13
2.8.4.3 Oils and lubricants from the rear frame
damper 13
3Overview 14
3.1 Description 15
3.1.1 Wheel and suspension 15
3.1.1.1 Valve 15
3.1.2 Suspension 15
3.1.2.1 Steel suspension fork structure 16
3.1.2.2 Air suspension fork structure 16
3.1.2.3 Structure of the FOX rear frame damper 17
3.1.2.4 Structure of the Suntour rear frame
damper 17
3.1.3 Brake system 17
3.1.3.1 Rim brake 17
3.1.3.2 Disc brake 18
3.1.3.3 Back-pedal brake 18
3.1.3.4 ABS 19
3.1.4 Electric drive system 20
3.1.5 Rechargeable battery 20
3.1.5.1 Frame battery 21
3.1.5.2 Pannier rack battery 21
3.1.5.3 Integrated battery 22
3.1.6 Display 22
3.1.6.1 USB port 23
3.1.7 Riding light 23
3.1.8 Charger 23
3.2 Proper use 24
3.3 Improper use 25
3.4 Technical data 26
3.4.1 Pedelec 26
3.4.2 ActiveLine motor 26
3.4.3 ActiveLine Plus motor 26
3.4.4 Performance Line CX Cruise motor 26
3.4.5 Performance Line Speed motor 26
3.4.6 Performance Line CX motor 26
3.4.7 Lighting 27
3.4.8 PowerPack 300 battery 27
3.4.9 PowerPack 400 battery 27
3.4.10 PowerPack 500 battery 27
3.4.11 PowerTube 400 battery 27
3.4.12 PowerTube 500 battery 28
3.4.13 PowerTube 625 battery 28
3.4.14 KIOX display 28
3.4.15 USB port 28
3.4.16 BOSCH Pedelec ABS BAS100 28
3.4.17 Emissions 28
3.4.18 Tightening torque 28
3.5 Environmental requirements 29
3.6 Description of controls and screens 31
3.6.1 Handlebars 31
3.6.2 Battery level indicator 31
3.6.3 Control panel 31
3.6.4 On-screen indicators 31
3.6.4.1 Start screen 31
3.6.4.2 Status screen 32
3.6.4.3 Quick menu 32
3.6.4.4 Rechargeable battery charge status
indicator 32
3.6.4.5 Level of assistance 32
3.6.4.6 Power evaluation 33
3.6.4.7 Guidance bar 33
3.6.4.8 Settings 33
3.6.4.9 Additional journey information for
eShift Shimano DI2 and Rohloff 33
3.6.4.10 System settings and data 34
3.6.4.11 Additional eShift system setting 34
3.6.5 System message 34
3.6.6 ABS indicator lamp 34
4 Transportation and storing 36
4.1 Physical transport characteristics 36
4.1.1 Dimensions during transportation 36

MY20B01-22_1.0_21.06.2019 2
Contents
4.1.2 Transport weight 36
4.1.3 Designated handles/lifting points 36
4.2 Transportation 36
4.2.1 Transporting the battery 37
4.2.2 Shipping the battery 37
4.2.3 Using the brake transport securing
system 37
4.3 Storing 37
4.3.1 Break in operation 38
4.3.1.1 Preparing a break in operation 38
4.3.1.2 Taking out of operation 38
5 Assembly 39
5.1 Required tools 39
5.2 Unpacking 39
5.2.1 Scope of delivery 39
5.3 Commissioning 40
5.3.1 Checking the battery 40
5.3.2 Installing the wheel in the Suntour fork 40
5.3.2.1 Installing the wheel with screw-on axle
(15 mm) 40
5.3.2.2 Installing the wheel with screw-on axle
(20 mm) 41
5.3.2.3 Installing the wheel with a quick release
axle 42
5.3.3 Installing the wheel with a quick release 43
5.3.4 Installing the wheel in the FOX fork 44
5.3.4.1 Wheel with quick release (15 mm) 44
5.3.4.2 Adjusting the FOX quick release 45
5.3.4.3 Installing the wheel with Kabolt axles 45
5.3.4.4 Checking the stem and handlebars 45
5.3.5 Pedelec sale 46
6Operation 47
6.1 Risks and hazards 47
6.1.1 Tips for a greater range 48
6.1.2 Personal protective equipment 48
6.2 Error messages 49
6.2.1 Error message display 49
6.2.2 Battery error message 51
6.3 Before the first ride 52
6.3.1 Adjusting the saddle 52
6.3.1.1 Adjusting the saddle tilt 52
6.3.2 Determining the seat height 52
6.3.2.1 Adjusting the seat height with quick
release 52
6.3.2.2 Height-adjustable seat post 53
6.3.2.3 Adjusting the seat position 53
6.3.3 Adjusting the handlebars 54
6.3.3.1 Adjusting the stem 54
6.3.3.2 Adjusting the height of the handlebars 54
6.3.3.3 Turning the handlebars to the side 54
6.3.3.4 Checking the clamping force in quick
releases 55
6.3.3.5 Adjusting the quick release clamping
force 55
6.3.4 Adjusting the brake lever 55
6.3.4.1 Adjusting the pressure point on a
Magura brake lever 55
6.3.4.2 Adjusting the grip distance 55
6.3.4.3 Adjusting the grip distance on a
Magura brake lever 56
6.3.5 Adjusting the suspension of the
Suntour fork 56
6.3.5.1 Adjusting the negative deflection 56
6.3.5.2 Adjusting the air suspension fork
negative deflection 57
6.3.5.3 Adjusting the steel suspension fork
negative deflection 57
6.3.5.4 Adjusting the rebound 58
6.3.6 Adjusting the suspension of the
FOX fork 58
6.3.6.1 Adjusting the negative deflection 58
6.3.6.2 Adjusting the rebound 59
6.3.7 Setting the Suntour rear frame damper 60
6.3.7.1 Adjusting the negative deflection 60
6.3.7.2 Adjusting the rebound 60
6.3.7.3 Setting the compression 60
6.3.8 Setting the FOX rear frame damper 61
6.3.8.1 Adjusting the negative deflection 61
6.3.8.2 Adjusting the rebound 61
6.3.9 Retracting the brake linings 62
6.4 Accessories 63
6.4.1 Child seat 63
6.4.2 Bicycle trailers 64
6.4.3 Pannier rack 64
6.5 Before each ride 65
6.6 Check list before each ride 65
6.7 Using the kickstand 66
6.7.1 Raising the kickstand 66
6.7.1.1 Parking the pedelec 66
6.8 Using the pannier rack 66
6.9 Rechargeable battery 67
6.9.1 Frame battery 68
6.9.1.1 Removing the frame battery 68
6.9.1.2 Inserting the frame battery 68
6.9.2 Pannier rack battery 68
6.9.2.1 Removing the pannier rack battery 68
6.9.2.2 Inserting the pannier rack battery 68
6.9.3 Integrated battery 68
6.9.3.1 Removing the integrated battery 68
6.9.3.2 Inserting the integrated battery 69
6.9.4 Charging the battery 69
6.9.5 Charging the dual battery 70
6.9.5.1 Charging process when two batteries
are used 70

MY20B01-22_1.0_21.06.2019 3
Contents
6.9.5.2 Charging process when one battery
is used 71
6.9.6 Waking the battery 71
6.10 Electric drive system 72
6.10.1 Switching on the electric drive system 72
6.10.2 Switching off the drive system 72
6.10.3 Control panel with display 73
6.10.4 Charging the display rechargeable
battery 73
6.10.4.1 Charging the display battery on
pedelec 73
6.10.4.2 Charging the display rechargeable
battery via the USB port 73
6.10.5 Storage mode 73
6.10.5.1 Activating the storage mode 73
6.10.5.2 Deactivating the storage mode 73
6.10.5.3 Removing and attaching the display 74
6.10.5.4 Removing the display 74
6.10.5.5 Inserting the display 74
6.10.5.6 Securing the display 74
6.10.5.7 Using the USB port 74
6.10.6 Switching on the display 75
6.10.7 Switching off the display 75
6.10.8 Using the push assist system 75
6.10.9 Using the riding light 75
6.10.10 Selecting the level of assistance 75
6.10.11 Operating the display 75
6.10.12 Opening the start screen 76
6.10.13 Opening the status screen 76
6.10.14 Opening the settings 76
6.10.15 Changing the settings 76
6.10.16 Opening the quick menu 76
6.10.16.1Resetting the journey data 76
6.10.16.2Changing the start gear 76
6.10.16.3Changing the desired pedalling
frequency 77
6.10.16.4Changing defined gears 77
6.11 Brake 78
6.11.1 Using the brake lever 79
6.11.2 Using the back-pedal brake 80
6.11.3 Using ABS 80
6.11.3.1 While riding 81
6.12 Suspension and damping 81
6.12.1 Adjusting the compression of the
Fox fork 81
6.12.2 Adjusting the compression of the
Fox damper 82
6.12.3 Adjusting the compression of the
Suntour fork 82
6.12.4 Adjusting the compression of a
Suntour damper 82
6.12.5 Adjusting the rebound in a Rock
Shox damper 83
6.12.6 Adjusting the compression in a
Rock Shox damper 83
6.13 Gear shift 83
6.13.1 Using the derailleur gears 84
6.13.2 Using a hub gear 84
6.13.3 Use eShift 84
6.13.3.1 eShift with Shimano DI2 automatic
hub gears 84
6.13.3.2 eShift with manual Shimano DI2
hub gears 85
6.13.3.3 eShift with Shimano DI2 automatic
hub gears 85
6.13.3.4 eShift with NuVinci H|Sync/enviolo
with Optimized H|Sync 85
6.13.3.5 eShift with Rohloff E-14 Speedhub
500/14 85
7 Cleaning and servicing 86
7.1 Cleaning after each ride 86
7.1.1 Cleaning the suspension fork 86
7.1.2 Cleaning the rear frame damper 86
7.1.3 Cleaning the pedals 86
7.2 Basic cleaning 87
7.2.1 Cleaning the frame 87
7.2.2 Cleaning the stem 87
7.2.3 Cleaning the rear frame damper 87
7.2.4 Cleaning the wheel 87
7.2.5 Cleaning the drive elements 87
7.2.6 Cleaning the chain 88
7.2.7 Cleaning the battery 88
7.2.8 Cleaning the display 88
7.2.9 Cleaning the drive unit 88
7.2.10 Cleaning the brake 89
7.3 Servicing 89
7.3.1 Servicing the frame 89
7.3.2 Servicing the stem 89
7.3.3 Servicing the fork 89
7.3.4 Servicing the drive elements 89
7.3.5 Servicing the pedals 89
7.3.6 Servicing the chain 89
7.3.7 Servicing the drive elements 89
7.4 Maintenance 90
7.4.1 Wheel 90
7.4.2 Checking the tyres 90
7.4.3 Checking the rims 90
7.4.4 Check and correct tyre pressure 90
7.4.4.1 Dunlop valve 90
7.4.4.2 Presta valve 91
7.4.4.3 Schrader valve 91
7.4.5 Brake system 91
7.4.6 Checking the brake linings for wear 91

MY20B01-22_1.0_21.06.2019 4
Contents
7.4.7 Checking the pressure point 91
7.4.8 Checking the brake discs for wear 92
7.4.9 Electrical cables and brake cables 92
7.4.10 Gear shift 92
7.4.11 Stem 92
7.4.12 USB port 92
7.4.13 Checking the belt and chain tension 92
7.4.14 Checking the handlebar grip position 92
8 Maintenance 93
8.1 Axle with quick release 94
8.1.1 Checking the quick release 94
8.2 Adjusting the gear shift 94
8.2.1 Cable-operated gear shift, single-cable 95
8.2.2 Cable-operated gear shift, dual-cable 95
8.2.3 Cable-operated twist grip, dual-cable 95
9 Troubleshooting, fault clearance
and repair 96
9.1 Troubleshooting and fault clearance 96
9.1.1 The drive system or display do not
start up 96
9.1.2 Error messages 96
9.2 Repair 97
9.2.1 Use original parts and lubricants only 97
9.2.2 Replacing the lighting 97
9.2.3 Setting the headlight 97
10 Recycling and disposal 98
11 Documents 99
11.1 Parts list 99
11.2 Assembly report 100
11.3 Maintenance log 102
11.4 Charger operating instructions 105
12 Keyword index 114
13 Glossary 115
Appendix 118
I. Translation of the original EC
declaration of conformity 118
1 About these operating instructions 8
1.1 Manufacturer 8
1.2 Type number and model 8
1.3 Identifying the operating instructions 9
1.4 Laws, standards and directives 9
1.5 Subject to change 9
1.6 Language 9
1.7 For your safety 9
1.7.1 Instruction, training and customer service 9
1.7.2 Basic safety instructions 9
1.7.3 Warnings 9
1.7.4 Safety markings 10
1.8 For your information 10
1.8.1 Instructions for actions 10
1.8.2 Language conventions 10
1.8.3 Information on the nameplate 10
1.9 Nameplate 11
2 Safety 12
2.1 General warnings 12
2.2 Toxic substances 13
2.3 Requirements for the rider 14
2.4 Protection for vulnerable groups 14
2.5 Data privacy 14
2.6 Personal protective equipment 14
2.7 Safety markings and safety instructions 14
2.8 Emergency 15
2.8.1 What to do in an emergency 15
2.8.2 First aid treatment 15
2.8.3 Fighting fire 15
2.8.4 Leaking fluids 16
2.8.4.1 Brake fluid 16
2.8.4.2 Oils and lubricants from the fork 16
2.8.4.3 Oils and lubricants from the rear frame
damper 16
3 Overview 17
3.1 Description 18
3.1.1 Wheel and suspension 18
3.1.1.1 Valve 18
3.1.2 Suspension 18
3.1.2.1 Steel suspension fork structure 19
3.1.2.2 Air suspension fork structure 19
3.1.2.3 Structure of the FOX rear frame damper 20
3.1.2.4 Structure of the Suntour rear frame
damper 20
3.1.3 Brake system 20
3.1.3.1 Rim brake 20
3.1.3.2 Disc brake 21
3.1.3.3 Back-pedal brake 21
3.1.3.4 ABS 22
3.1.4 Electric drive system 23
3.1.5 Rechargeable battery 23
3.1.5.1 Frame battery 24
3.1.5.2 Pannier rack battery 24
3.1.5.3 Integrated battery 25
3.1.6 Display 25
3.1.6.1 USB port 26
3.1.7 Riding light 26
3.1.8 Charger 26
3.2 Proper use 27
3.3 Improper use 28
3.4 Technical data 29
3.4.1 Pedelec 29
3.4.2 ActiveLine motor 29
3.4.3 ActiveLine Plus motor 29
3.4.4 Performance Line CX Cruise motor 29
3.4.5 Performance Line Speed motor 29
3.4.6 Performance Line CX motor 29
3.4.7 Lighting 30
3.4.8 PowerPack 300 battery 30
3.4.9 PowerPack 400 battery 30
3.4.10 PowerPack 500 battery 30
3.4.11 PowerTube 400 battery 30
3.4.12 PowerTube 500 battery 31

MY20B01-22_1.0_21.06.2019 5
Contents
3.4.13 PowerTube 625 battery 31
3.4.14 KIOX display 31
3.4.15 USB port 31
3.4.16 BOSCH Pedelec ABS BAS100 31
3.4.17 Emissions 31
3.4.18 Tightening torque 31
3.5 Environmental requirements 32
3.6 Description of controls and screens 34
3.6.1 Handlebars 34
3.6.2 Battery level indicator 34
3.6.3 Control panel 34
3.6.4 On-screen indicators 34
3.6.4.1 Start screen 34
3.6.4.2 Status screen 35
3.6.4.3 Quick menu 35
3.6.4.4 Rechargeable battery charge status
indicator 35
3.6.4.5 Level of assistance 35
3.6.4.6 Power evaluation 36
3.6.4.7 Guidance bar 36
3.6.4.8 Settings 36
3.6.4.9 Additional journey information for
eShift Shimano DI2 and Rohloff 36
3.6.4.10 System settings and data 37
3.6.4.11 Additional eShift system setting 37
3.6.5 System message 37
3.6.6 ABS indicator lamp 37
4 Transporting and storing 39
4.1 Physical transport characteristics 39
4.1.1 Dimensions during transportation 39
4.1.2 Transport weight 39
4.1.3 Designated handles/lifting points 39
4.2 Transporting 39
4.2.1 Transporting the battery 40
4.2.2 Shipping the battery 40
4.2.3 Using the brake transport securing
system 40
4.3 Storing 40
4.3.1 Break in operation 41
4.3.1.1 Preparing a break in operation 41
4.3.1.2 Taking out of operation 41
5 Assembly 42
5.1 Required tools 42
5.2 Unpacking 42
5.2.1 Scope of delivery 42
5.3 Commissioning 43
5.3.1 Checking the battery 43
5.3.2 Installing the wheel in the Suntour fork 43
5.3.2.1 Installing the wheel with screw-on axle
(15 mm) 43
5.3.2.2 Installing the wheel with screw-on axle
(20 mm) 44
5.3.2.3 Installing the wheel with a quick release
axle 45
5.3.3 Installing the wheel with a quick release 46
5.3.4 Installing the wheel in the FOX fork 47
5.3.4.1 Wheel with quick release (15 mm) 47
5.3.4.2 Adjusting the FOX quick release 48
5.3.4.3 Installing the wheel with Kabolt axles 48
5.3.4.4 Checking the stem and handlebars 48
5.3.5 Pedelec sale 49
6 Operation 50
6.1 Risks and hazards 50
6.1.1 Tips for a greater range 51
6.1.2 Personal protective equipment 51
6.2 Error messages 52
6.2.1 Error message display 52
6.2.2 Battery error message 54
6.3 Before the first ride 55
6.3.1 Adjusting the saddle 55
6.3.1.1 Adjusting the saddle tilt 55
6.3.2 Determining the seat height 55
6.3.2.1 Adjusting the seat height with quick
release 55
6.3.2.2 Height-adjustable seat post 56
6.3.2.3 Adjusting the seat position 56
6.3.3 Adjusting the handlebars 57
6.3.3.1 Adjusting the stem 57
6.3.3.2 Adjusting the height of the handlebars 57
6.3.3.3 Turning the handlebars to the side 57
6.3.3.4 Checking the clamping force in quick
releases 58
6.3.3.5 Adjusting the quick release clamping
force 58
6.3.4 Adjusting the brake lever 58
6.3.4.1 Adjusting the pressure point on a
Magura brake lever 58
6.3.4.2 Adjusting the grip distance 58
6.3.4.3 Adjusting the grip distance on a
Magura brake lever 59
6.3.5 Adjusting the suspension of the
Suntour fork 59
6.3.5.1 Adjusting the negative deflection 59
6.3.5.2 Adjusting the air suspension fork
negative deflection 60
6.3.5.3 Adjusting the steel suspension fork
negative deflection 60
6.3.5.4 Adjusting the rebound 61
6.3.6 Adjusting the suspension of the
FOX fork 61
6.3.6.1 Adjusting the negative deflection 61
6.3.6.2 Adjusting the rebound 62
6.3.7 Setting the Suntour rear frame damper 63
6.3.7.1 Adjusting the negative deflection 63
6.3.7.2 Adjusting the rebound 63
6.3.7.3 Setting the compression 63
6.3.8 Setting the FOX rear frame damper 64
6.3.8.1 Adjusting the negative deflection 64
6.3.8.2 Adjusting the rebound 64
6.3.9 Retracting the brake linings 65
6.4 Accessories 66

MY20B01-22_1.0_21.06.2019 6
Contents
6.4.1 Child seat 66
6.4.2 Bicycle trailers 67
6.4.3 Pannier rack 67
6.5 Before each ride 68
6.6 Check list before each ride 68
6.7 Using the kickstand 69
6.7.1 Raising the kickstand 69
6.7.1.1 Parking the pedelec 69
6.8 Using the pannier rack 69
6.9 Rechargeable battery 70
6.9.1 Frame battery 71
6.9.1.1 Removing the frame battery 71
6.9.1.2 Inserting the frame battery 71
6.9.2 Pannier rack battery 71
6.9.2.1 Removing the pannier rack battery 71
6.9.2.2 Inserting the pannier rack battery 71
6.9.3 Integrated battery 71
6.9.3.1 Removing the integrated battery 71
6.9.3.2 Inserting the integrated battery 72
6.9.4 Charging the battery 72
6.9.5 Charging the dual battery 73
6.9.5.1 Charging process when two batteries
are used 73
6.9.5.2 Charging process when one battery
is used 74
6.9.6 Waking the battery 74
6.10 Electric drive system 75
6.10.1 Switching on the electric drive system 75
6.10.2 Switching off the drive system 75
6.10.3 Control panel with display 76
6.10.4 Charging the display rechargeable
battery 76
6.10.4.1 Charging the display battery on
pedelec 76
6.10.4.2 Charging the display rechargeable
battery via the USB port 76
6.10.5 Storage mode 76
6.10.5.1 Activating the storage mode 76
6.10.5.2 Deactivating the storage mode 76
6.10.5.3 Removing and attaching the display 77
6.10.5.4 Removing the display 77
6.10.5.5 Inserting the display 77
6.10.5.6 Securing the display 77
6.10.5.7 Using the USB port 77
6.10.6 Switching on the display 78
6.10.7 Switching off the display 78
6.10.8 Using the push assist system 78
6.10.9 Using the riding light 78
6.10.10 Selecting the level of assistance 78
6.10.11 Operating the display 78
6.10.12 Opening the start screen 79
6.10.13 Opening the status screen 79
6.10.14 Opening the settings 79
6.10.15 Changing the settings 79
6.10.16 Opening the quick menu 79
6.10.16.1Resetting the journey data 79
6.10.16.2Changing the start gear 79
6.10.16.3Changing the desired pedalling
frequency 80
6.10.16.4Changing defined gears 80
6.11 Brake 81
6.11.1 Using the brake lever 82
6.11.2 Using the back-pedal brake 83
6.11.3 Using ABS 83
6.11.3.1 While riding 84
6.12 Suspension and damping 84
6.12.1 Adjusting the compression of the
Fox fork 84
6.12.2 Adjusting the compression of the
Fox damper 85
6.12.3 Adjusting the compression of the
Suntour fork 85
6.12.4 Adjusting the compression of a
Suntour damper 85
6.12.5 Adjusting the rebound in a Rock
Shox damper 86
6.12.6 Adjusting the compression in a
Rock Shox damper 86
6.13 Gear shift 86
6.13.1 Using the derailleur gears 87
6.13.2 Using a hub gear 87
6.13.3 Use eShift 87
6.13.3.1 eShift with Shimano DI2 automatic
hub gears 87
6.13.3.2 eShift with manual Shimano DI2
hub gears 88
6.13.3.3 eShift with Shimano DI2 automatic
hub gears 88
6.13.3.4 eShift with NuVinci H|Sync/enviolo
with Optimized H|Sync 88
6.13.3.5 eShift with Rohloff E-14 Speedhub
500/14 88
7 Cleaning and servicing 89
7.1 Cleaning after each ride 89
7.1.1 Cleaning the suspension fork 89
7.1.2 Cleaning the rear frame damper 89
7.1.3 Cleaning the pedals 89
7.2 Basic cleaning 90
7.2.1 Cleaning the frame 90
7.2.2 Cleaning the stem 90
7.2.3 Cleaning the rear frame damper 90
7.2.4 Cleaning the wheel 90
7.2.5 Cleaning the drive elements 90
7.2.6 Cleaning the chain 91
7.2.7 Cleaning the battery 91
7.2.8 Cleaning the display 91
7.2.9 Cleaning the drive unit 91
7.2.10 Cleaning the brake 92
7.3 Servicing 92

MY20B01-22_1.0_21.06.2019 7
Contents
7.3.1 Servicing the frame 92
7.3.2 Servicing the stem 92
7.3.3 Servicing the fork 92
7.3.4 Servicing the drive elements 92
7.3.5 Servicing the pedals 92
7.3.6 Servicing the chain 92
7.3.7 Servicing the drive elements 92
7.4 Maintenance 93
7.4.1 Wheel 93
7.4.2 Checking the tyres 93
7.4.3 Checking the rims 93
7.4.4 Check and correct tyre pressure 93
7.4.4.1 Dunlop valve 93
7.4.4.2 Presta valve 94
7.4.4.3 Schrader valve 94
7.4.5 Brake system 94
7.4.6 Checking the brake linings for wear 94
7.4.7 Checking the pressure point 94
7.4.8 Checking the brake discs for wear 95
7.4.9 Electrical cables and brake cables 95
7.4.10 Gear shift 95
7.4.11 Stem 95
7.4.12 USB port 95
7.4.13 Checking the belt and chain tension 95
7.4.14 Checking the handlebar grip position 95
8 Maintenance 96
8.1 Axle with quick release 97
8.1.1 Checking the quick release 97
8.2 Adjusting the gear shift 97
8.2.1 Cable-operated gear shift, single-cable 98
8.2.2 Cable-operated gear shift, dual-cable 98
8.2.3 Cable-operated twist grip, dual-cable 98
9 Troubleshooting, fault clearance
and repair 99
9.1 Troubleshooting and fault clearance 99
9.1.1 The drive system or display do not
start up 99
9.1.2 Error messages 99
9.2 Repair 100
9.2.1 Use original parts and lubricants only 100
9.2.2 Replacing the lighting 100
9.2.3 Setting the headlight 100
10 Recycling and disposal 101
11 Documents 102
11.1 Parts list 102
11.2 Assembly report 103
11.3 Maintenance log 105
11.4 Charger operating instructions 108
12 Keyword index 117
13 Glossary 118
Appendix 121
I. Translation of the original EC
declaration of conformity 121

MY20B01-22_1.0_21.06.2019 8
About these operating instructions
1 About these operating instructions
Thank you for your trust!
BULLS pedelecs are sporting equipment of the
highest quality – you have made a good choice.
Your specialist dealer has advised you and
assembled your product. Whether maintenance,
inspection, conversion or repair, your specialist
dealer will also be happy to assist you in the
future.
You receive these operating instructions with your
new pedelec. Please take a little time to become
familiar with your new pedelec and follow the tips
and suggestions in the operating instructions.
They will help you to enjoy your BULLS pedelec
for a long time to come. We hope you have fun
and wish you well on all of your rides!
These operating instructions are designed for the
rider and the operator of the pedelec to ensure
that non-professionals can use the pedelec safely.
You can download the operating instructions onto
your mobile phone at the following address, so
that you can use them when you are out riding:
www.bulls.de/service/
downloads
1.1 Manufacturer
The pedelec manufacturer is:
ZEG Zweirad-Einkaufs-Genossenschaft eG
Longericher Straße 2
50739 Köln, Germany
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.zeg.de
1.2 Type number and model
The operating instructions are an integral part of
pedelecs with the following type numbers:
*The type number was not available when we
went to press.
Notice
The operating instructions are not a substitute for
personal instruction by the supplying specialist
dealer.
The operating instructions are an integral part of
the pedelec. Therefore, if it is re-sold at a later
time, they must be handed over to the subsequent
owner.
Instructions for the specialist dealer are highlighted in grey and
marked with a symbol. Specialist dealers have specialist
training and qualifications and are thus able to identify risks and
prevent hazards which may arise during maintenance, servicing
and repairs on the pedelec. Information for specialist staff does
not require non-professionals to take any action.
Type no. Model Pedelec type
20-17-4029 Bulls Cross Lite Evo Mountain bike
20-17-4030 Bulls Cross Lite Evo Mountain bike
20-17-4031 Bulls Cross Lite Evo Mountain bike
20-18-1888 Bulls Iconic Evo TR 3 ABS City and trekking
bicycle
20-18-1950 Bulls Adventure Evo AM City and trekking
bicycle
20-18-4044 Bulls Iconic Evo TR 1 City and trekking
bicycle
20-18-4045 Bulls Iconic Evo TR 2 City and trekking
bicycle
t.b.a.* Desert Falcon Evo Racing bicycle
t.b.a.* Cross Lite Evo Carbon Mountain bike
t.b.a.* Sonic Evo AM5 Carbon Mountain bike
t.b.a.* Sonic Evo AM6 Carbon Mountain bike
t.b.a.* Sonic Evo TR4 Carbon Mountain bike
Table 1: Type number, model and pedelec type

MY20B01-22_1.0_21.06.2019 9
About these operating instructions
1.3 Identifying the operating
instructions
You will find the operating instructions
identification number at the bottom left-hand side
of each page. The identification number consists
of the document number, the version number and
the release date.
1.4 Laws, standards and directives
The operating instructions comply with the
essential requirements specified in:
• Machinery Directive 2006/42/EC
• Electromagnetic Compatibility Directive
2014/30/EU
• ISO/DIS 20607:2018 Safety of machinery –
Instruction handbook – General drafting
principles
• EN 15194:2018 Cycles – Electrically power
assisted cycles – pedelec bicycles
• EN 11243:2016, Cycles – Luggage carriers for
bicycles – Requirements and test methods
• EN ISO 17100:2016-05, Translation Services –
Requirements for translation service.
1.5 Subject to change
The information contained in these operating
instructions are the approved technical
specifications at the time of printing. Any
significant changes will be included in a new issue
of the operating instructions.
You will find any modifications to these operating
instructions:
www.bulls.de/service/downloads
1.6 Language
The original operating instructions are written in
German. A translation is not valid without the
original operating instructions.
1.7 For your safety
The pedelec's safety concept comprises four
elements:
• rider and/or operator instruction, and bicycle
maintenance and repair by the specialist dealer
• the section on general safety
• the warnings in these operating instructions
• the safety markings on the nameplate and the
pedelec.
1.7.1 Instruction, training and customer
service
The supplying specialist dealer will provide
customer service. Contact details can be found on
the back page of these operating instructions and
on the data sheet. If you are unable to contact
your specialist dealer, you will find other specialist
dealers online at www.bulls.de.
The rider or the operator of the pedelec will be
instructed on the pedelec's functions in person
when the supplying specialist dealer hands over
the pedelec, if not before. In particular, this
instruction will cover the pedelec's electrical
functions and correct use of the charger.
Each rider to whom this bicycle is provided must
receive instruction on the pedelec's functions. A
printed copy of these operating instructions must
be provided to each rider, who must take note of
and observe them.
1.7.2 Basic safety instructions
These operating instructions explains all general
safety instructions in Section 2.
1.7.3 Warnings
Hazardous situations and actions are marked with
warnings. The warnings in these operating
instructions are indicated as follows:
Identification number MY20B01-22_1.0_21.06.2019
Table 2: Identification number
Will lead to serious or even fatal injuries if
ignored. High-risk hazard.
May lead to serious or even fatal injuries if
ignored. Medium-risk hazard.
May lead to minor or moderate injuries. Low-risk
hazard.
Notice
May lead to material damage if ignored.
DANGER
!
WARNING
!
CAUTION
!

MY20B01-22_1.0_21.06.2019 10
About these operating instructions
1.7.4 Safety markings
The following safety markings are used on the
pedelec's nameplates:
1.8 For your information
1.8.1 Instructions for actions
Instructions for actions are structured in
accordance with the following pattern:
Requirements (optional)
Instruction for action
Result of the action (optional)
1.8.2 Language conventions
The pedelec described in these operating
instructions may be equipped with alternative
equipment. The pedelec equipment is defined by
its respective type number. Where applicable, the
word Alternative beneath the heading indicates
alternatively used components. The following terms
are used for better legibility:
The following conventions are used in these
operating instructions:
1.8.3 Information on the nameplate
Alongside the warnings, product nameplates also
contain other important information about the
pedelec:
General warning
Adhere to the instructions for use
Table 3: Meaning of safety markings
Term Meaning
Operating
instructions
Original operating
instructions or translation
of the original operating
instructions
Pedelec Electric motor driven cycle
Motor Drive motor
Convention Use
Italics Glossary terms
SPACED Indicators on the display
screen
[Example, page
numbering]
Cross references
• Bulleted lists
Read the instructions
Separate collection of
electrical and electronic
devices
Separate collection of
batteries
Must not be thrown into fire
(burning prohibited)
Battery must not be opened
Device of protection class II
Only suitable for use indoors
Fuse (device fuse)
EU conformity
Recyclable material
Protect from temperatures
above 50 °C and direct
sunlight
Table 4: Relevance of safety instructions
max. 50°C

MY20B01-22_1.0_21.06.2019 11
About these operating instructions
1.9 Nameplate
The nameplate is situated on the frame. You will
find the precise position of the nameplate in
Figure 2. You will find thirteen pieces of
information on the nameplate.
Figure 1: Nameplate, example
No. Designation Description
1 CE marking The manufacturer uses the CE marking to declare that the pedelec complies with
applicable requirements.
2 Manufacturer's contact details You can contact the manufacturer at this address. You can find more information in
Section 1.1.
3 Type number All pedelec models have an eight-digit type number, which is used to specify the design
model year, the type of pedelec and the version. You can find further information in
Section 1.9.1.
4 Maximum continuous power The maximum continuous power is the maximum power for the electric motor output shaft
during 30 minutes.
5 Permitted total weight The permitted total weight is the weight of the fully assembled pedelec with the rider and
baggage.
6Year of manufacture The year of manufacture is the year in which the pedelec was manufactured. The
production period is from August 2019 to July 2020.
7 Pedelec type You can find further information in Section 1.9.3.
8 Safety markings You can find more information in Section 2.6.
9 Disposal instructions You can find more information in Section 9.
10 Area of use You can find further information in Section 1.9.4.
11 Model year The model year refers to the first production year that the series-manufactured pedelec
was produced in the version and is not always identical with the year of manufacture.
The year of manufacture may be before the model year in some cases. If no technical
modifications are introduced to the series, production may continue of pedelecs from a
previous model year.
12 Weight of the ready-to-ride pedelec The indicated weight for a ready-to-ride pedelec refers to the weight of a pedelec at the
time of sale. The weight of each additional accessory must be added to this weight.
13 Shut-off speed Speed reached by the pedelec at the moment when the current has dropped to zero or to
the no load current value.
ZEG Zweirad-Einkaufs-
Genossenschaft eG
Longericher Str. 2
50739 Köln, Germany
Typ:
20-16-0001
EN 15194
0,25 kW / 25 km/h
zGG 180 kg
EPAC 25 kg
BJ 2019 / MJ 2020
nach
EPAC
2
3
1
4
5
6
7
89
12
13
10
11

MY20B01-22_1.0_21.06.2019 12
Safety
2 Safety
2.1 General warnings
Risk of fire and explosion due to faulty battery
The safety electronics on a damaged or faulty
battery may fail. The residual voltage can cause a
short circuit. The battery may self-ignite and
explode.
Remove batteries with external damage from
service immediately and never charge them.
Only operate the battery and accessories if
they are in perfect condition.
Only use batteries which are approved for use
on your pedelec.
Do not use the battery with defective
connecting cables or defective contacts.
Use the battery with BOSCH Systems
pedelecs only. This is the only way that the
battery will be protected from dangerous
overloading.
If the battery becomes deformed or begins to
smoke, keep at a safe distance, disconnect the
power supply at the socket, and notify the fire
service immediately.
Never extinguish a damaged battery with
water or allow it to come into contact with
water.
If a battery is dropped or struck but shows no
signs of external damage, remove it from
service and observe it for at least 24 hours.
Faulty batteries are hazardous goods.
Dispose of faulty batteries properly and as
quickly as possible.
Store in a dry place until disposal. Never store
in the vicinity of flammable substances.
Never open or repair the battery.
Charge the battery before use. Only use the
charger included in the scope of delivery.
WARNING
!
Electric shock in case of damage
Damaged chargers, cables and plug connectors
increase the risk of electric shock.
Check the charger, cable and plug connector
before each use. Never use a damaged
charger.
Risk of fire and explosion due to short circuit
Small metal objects may jumper the electrical
connections of the battery. The battery may self-
ignite and explode.
Keep paper clips, screws, coins, keys and
other small parts away and do not insert them
into the battery.
Risk of fire and explosion due to incorrect
charger
Batteries which are recharged with an unsuitable
charger may become damaged internally. This
may result in fire or an explosion.
Only ever use the battery with the supplied
charger.
Mark the supplied charger clearly to prevent
mix-ups – with the pedelec frame number or
type number, for example.
Risk of fire and explosion due to penetration by
water
The battery is only protected from simple spray
water. Penetration by water can cause a short
circuit. The battery may self-ignite and explode.
Never immerse the battery in water.
If there is reason to believe that water may
have entered into the battery, the battery must
be removed from service.
CAUTION
!

MY20B01-22_1.0_21.06.2019 13
Safety
2.2 Toxic substances
Risk of fire and explosion due to high
temperatures
Excessively high temperatures will damage the
battery. The battery may self-ignite and explode.
Protect the battery against heat.
Never expose the battery to sustained direct
sunlight.
Fire caused by overheated charger
The charger heats up when charging the battery.
In case of insufficient cooling, this can result in
fire or burns to the hands.
Never use the charger on a highly flammable
surface (e.g. paper, carpet etc.).
Never cover the charger during the charging
process.
Never leave the battery unattended during
charging.
Electric shock caused by penetration by
water
If water penetrates into the charger, there is a risk
of electric shock.
Never charge the battery outdoors.
Notice
If you leave a key inserted when riding or
transporting the pedelec, it may break off or the
locking system may open accidentally.
Remove the key from the battery lock
immediately after use.
We recommend that you attach the key to a
key ring.
CAUTION
!
Intoxication from suspension oil
Suspension oil in the rear frame damper is toxic to
the touch, irritates respiratory tracts and causes
cancer, sterility and mutation in germ cells.
Never disassemble the rear frame damper.
Never allow suspension oil to come into
contact with the skin.
Chemical burns to the skin and eyes caused by
faulty battery
Liquids and vapours may leak from damaged or
faulty batteries. They can irritate the airways and
cause burns.
Avoid contact with leaked liquids.
Ventilate with fresh air and consult a doctor if
you suffer any pain or discomfort.
Immediately consult a doctor in case of
contact with the eyes or any discomfort.
In case of contact with the skin, rinse off
immediately with water.
Ventilate the room well.
Hazard for the environment due to leaking
brake fluid
The brake system contains a toxic, environmentally
harmful brake fluid. Such fluids will contaminate if
they enter the sewers or groundwater.
The brake system must be repaired
immediately if brake fluid leaks out. Contact
your specialist dealer about repair.
Dispose of leaking brake fluid in an
environmentally responsible way in
accordance with statutory regulations. Ask a
specialist dealer for more information.
WARNING
!
CAUTION
!

MY20B01-22_1.0_21.06.2019 14
Safety
2.3 Requirements for the rider
If there are no legal requirements for riders of
electrically power-assisted cycles, we recommend
that the rider should be a minimum 15 years of
age and have experience with muscle-powered
bicycles.
The rider's physical and mental abilities must be
adequate to use a muscle-powered pedelec.
2.4 Protection for vulnerable groups
You must keep batteries and charger away from
children and people with reduced physical,
sensory or mental capabilities or lacking in
experience and knowledge.
If minors are to use the pedelec, comprehensive
instruction should be provided by or in the
presence of the legal guardians. Supervised use
should also be scheduled until it is certain that the
pedelec is being used as per these operating
instructions.
2.5 Data privacy
During maintenance, the pedelec is connected to
the diagnosis tool and data is transferred to Bosch
Pedelec Systems (Robert Bosch GmbH) about the
use of electric drive components to help improve
the product. You will find more information on the
Bosch Pedelec website
https://www.bosch-ebike.com/en/
2.6 Personal protective equipment
We recommend that you wear a suitable cycling
helmet. We also recommend that you wear sturdy
footwear and typical, close-fitting clothing for
bicycles.
2.7 Safety markings and safety
instructions
The nameplate contains the following safety
markings and safety instructions:
Environmental hazard posed by oil and
lubricants from the fork
The fork contains toxic, environmentally harmful oils
and lubricants. Such fluids will contaminate if they
enter the sewers or groundwater.
The fork must be repaired immediately if oils
and lubricants are leaking out. Contact your
specialist dealer about repair.
Dispose of leaked oils and lubricants in an
environmentally responsible way in
accordance with statutory regulations. Ask a
specialist dealer for more information.
Environmental hazard posed by oil and
lubricants from rear frame damper
The rear frame damper contains toxic and
environmentally harmful oils and lubricants. Such
fluids
will contaminate if they enter the sewers or
groundwater.
Dispose of oils and lubricants which have
leaked from the rear frame damper in an
environmentally responsible way in
accordance with statutory regulations. Ask a
specialist dealer for more information.
CAUTION
!
Symbol Explanation
General warning
Adhere to the instructions for use
Table 5: Meaning of safety markings

MY20B01-22_1.0_21.06.2019 15
Safety
2.8 Emergency
2.8.1 What to do in an emergency
In the event of a hazard or danger in road
traffic, apply the brakes on the pedelec until it
comes to a halt. The brake acts as an
emergency stop system in such cases.
2.8.2 First aid treatment
Symptoms which are caused by combustion
gases or leaking fluids require medical attention.
After inhalation
Vapours may emit if the battery is damaged or
used improperly Get into fresh air and consult a
doctor if you suffer any pain or discomfort. The
vapours may cause respiratory tract irritation.
After skin contact
Remove any solid particles immediately. Rinse
the affected area with plenty of water for at least
15 minutes. Then dab the affected skin gently. Do
not rub dry. Remove contaminated clothing
immediately. Immediately consult a doctor if there
is any redness or abnormalities.
After contact with eyes
Rinse eyes with plenty of water for at least
15 minutes. Protect unaffected eye. Seek medical
advice immediately.
After swallowing
Drink plenty of milk or water and induce vomiting.
Seek medical advice immediately.
2.8.3 Fighting fire
The safety electronics on a damaged or faulty
battery may fail. The residual voltage can cause a
short circuit. The battery may self-ignite and
explode.
Keep your distance if the battery becomes
deformed or starts to emit smoke.
Evacuate everyone from the immediate area of
the fire.
Contact the fire service immediately!
Use Class fire extinguishers to put out the fire.
Never extinguish damaged batteries with water
or allow them to come into contact with water.
Symbol Explanation
Read the instructions
Separate collection of electrical
and electronic devices
Separate collection of ordinary
and rechargeable batteries
Must not be thrown into fire
(burning prohibited)
It is forbidden to open any
batteries
Device of protection class II
Only suitable for use indoors
Fuse (device fuse)
EU conformity
Recyclable material
Protect from temperatures
above 50 °C and direct sunlight
Table 6: Relevance of safety instructions
max. 50°C
Intoxication
Inhaling vapours can cause
intoxication.
Stand on the side of the fire
where the wind is blowing from.
Use breathing apparatus if
possible.
WARNING
!

MY20B01-22_1.0_21.06.2019 16
Safety
2.8.4 Leaking fluids
2.8.4.1 Brake fluid
The brake system must be repaired
immediately if brake fluid leaks out. Contact
your specialist dealer about repair.
Dispose of leaking brake fluid in an
environmentally responsible way in
accordance with statutory regulations. Ask a
specialist dealer for more information.
2.8.4.2 Oils and lubricants from the fork
The brake system must be repaired
immediately if brake fluid leaks out. Contact
your specialist dealer about repair.
Dispose of leaking brake fluid in an
environmentally responsible way in
accordance with statutory regulations. Ask a
specialist dealer for more information.
2.8.4.3 Oils and lubricants from the rear frame
damper
Dispose of oils and lubricants which have
leaked from the rear frame damper in an
environmentally responsible way in
accordance with statutory regulations. Ask a
specialist dealer for more information.

MY20B01-22_1.0_21.06.2019 17
Overview
3Overview
Figure 2: Pedelec viewed from the right, example
1Front wheel
2Fork
3 Front guard
4 Headlight
5Handlebars
6Stem
7Frame
8 Seat post
9 Saddle
10 Pannier rack
11 Rear light and reflector
12 Rear guard
13 Kickstand
14 Rear wheel
15 Chain
16 Frame number
17 Battery and nameplate
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15 16 17

MY20B01-22_1.0_21.06.2019 18
Overview
3.1 Description
3.1.1 Wheel and suspension
Figure 3: Components of the wheel, example of front
wheel
1 Tyre
2 Rim
3 Suspension fork head with setting wheel
4 Shock absorber
5 Spoke
6 Quick release
7Hub
8Valve
9 Fork end of the shock absorber
3.1.1.1 Valve
Each wheel has a valve. It is used to fill the tyre
with air. There is a valve cap on each valve. The
screw-on valve cap keeps out dust and dirt.
The pedelec either has a conventional Dunlop
valve, a Presta valve or a Schrader valve.
3.1.2 Suspension
Both forks and suspension forks are fitted in this
model series. A suspension fork is based either on a
steel spring or air suspension. Unlike a rigid fork, a
suspension fork has two functions which improve
floor contact and comfort: suspension and damping.
Figure 4: Pedelec without suspension (1) and with
suspension (2) when riding over an obstacle
The suspension prevents an impact, such as one
caused by a stone lying in the bike's path, from
being channelled directly into the rider's body via
the fork. The impact is absorbed by the
suspension system instead. This causes the
suspension fork to compress. The compression
can be disabled so that a suspension fork reacts
like a rigid fork. The switch to disable the fork is
called a remote lockout.
After compressing, the suspension fork returns to
its original position. If there is a damper, it
decelerates movement, preventing the
suspension system from springing back in an
uncontrolled manner and stopping the fork from
vibrating up and down. Dampers which dampen
compressive deflection movements, i.e. a
compression load, are called compression
dampers or compression dashpots.
Dampers which dampen rebound deflection
movements, i.e. a rebound load, are called
rebound dampers or dashpots.
1
2
4
5
8
7
3
9
6
12

MY20B01-22_1.0_21.06.2019 19
Overview
3.1.2.1 Steel suspension fork structure
Figure 5: Example showing Suntour fork
The stem and handlebars are fastened to the fork
steerer (1). The wheel is fastened to the quick
release axle (6). Other elements: the compression
setting (2), crown (3), Q-Loc (5), dust seal (6),
fork end for quick release (7), stanchion (8) and
spring (9)
3.1.2.2 Air suspension fork structure
The pedelec's fork features both air suspension and
a compression damper plus a rebound damper in
some cases.
Figure 6: Example showing Yari fork
You can see the following components in the
diagram: Air valve (1), valve cap (2) fork lock (3),
quick release (4) and rebound damper
adjuster (5) and the assembly groups: Air
suspension fork (A), compression damper
assembly group (B) and rebound damper
assembly group (C)
1
1
2
3
4
5
6
7
8
7
A
B
C
1
2
3
4
5
A
B
C
