Bosch D7212GV3 Quick start guide

EN
Operation and Installation Guide
Control Panel
D7212GV3

D7212GV3 |Operation and Installation Guide | Trademarks
2 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
Trademarks
Molex is a registered trademark of Molex
Incorporated.
Certifications and Approvals
The D7212GV3 Literature Pack includes the
D7212GV3 Approved Applications Compliance Guide
(P/N: F01U143080). Refer to this guide for additional
guidelines on installing the control panels in
Underwriters Laboratories Inc. (UL) and fire-specific
applications.
Fire
UL
Underwriters Laboratories, Inc. (UL) lists the
D7212GV3 Control Panel as a Control Unit for
Household Fire Warning.
The D7212GV3 is not UL Listed for
Commercial Fire (UL864).
Burglary
UL
UL lists the D7212GV3 Control Panel for: Central
Station, Local, Police Connect, Bank Safe and Vault,
Mercantile Safe and Vault, and Household Systems.
Federal Communications
Commission (FCC) Rules
Part 15
This equipment was tested and found to comply with
the limits for a Class A digital device, pursuant to Part
15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used
according to the instructions, can cause harmful
interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the
user is required to correct the interference at his or
her own expense.
Part 68
This equipment complies with Part 68 of FCC rules. A
label contains, among other information, the FCC
registration number and ringer equivalence number
(REN). If requested, this information must be provided
to the telephone company.
The D7212GV3 Control Panel is registered for
connection to the public telephone network using an
RJ38X or RJ31X jack.
The REN is used to determine the number of devices
that can be connected to the telephone line.
Excessive RENs on the telephone line may result in
the devices not ringing in response to an incoming
call. In most, but not all areas, the sum of the RENs
should not exceed five. To be certain of the number of
devices that can be connected to the line, as
determined by the RENs, contact the telephone
company to determine the maximum REN for the
calling area.
If you experience trouble with the D7212GV3 Control
Panel, please contact Bosch Security Systems, Inc.
Customer Service for repair and warranty information.
If the trouble is causing harm to the telephone
network, the telephone company might request that
the equipment be removed from the network until the
problem is resolved. User repairs must not be made,
and doing so will void the user’s warranty.
If the D7212GV3 Control Panel causes harm to the
telephone network, the telephone company attempts
to notify you in advance. If advance notice is not
practical, the telephone company notifies you as soon
as possible. Also, you will be advised of your right to
file a complaint with the FCC if you believe it is
necessary.
The telephone company might make changes in its
facilities, equipment, operations, or procedures that
affect the operation of the equipment. If this happens,
the telephone company provides advance notice in
order for the necessary modifications to be made in
order to maintain uninterrupted service.
This equipment cannot be used on public coin service
provided by the telephone company. Connection to
Party Line service is subject to state tariffs. (Contact
your state public utilities commission for information.)
FCC Registration Number:
US:ESVOT00BD9412GV3
Service Center in USA:
Bosch ST Service Center
8601 East Cornhusker Hwy
Dock B
Lincoln, NE 68507 - 9702 USA
Ringer Equivalence: 0.0B

D7212GV3 |Operation and Installation Guide | Contents
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 3
Contents
1.0 Introduction ......................................................6
2.0 Lightning Strikes..............................................7
2.1 Effects ..................................................................7
2.2 Precautions during Installation .........................7
3.0 Overview...........................................................8
3.1 Configuration and Parts.....................................8
3.1.1 Parts List..............................................................9
3.1.2 Parts Available by Separate Order...................9
3.2 Accessories........................................................10
3.3 Features in the D7212GV3 .............................11
3.3.1 SDI Molex Connector .....................................11
3.3.2 Tip and Ring Posts...........................................11
3.3.3 Telephone Line Sniff .......................................11
3.3.4 Points .................................................................11
3.3.5 Areas and Accounts .........................................11
3.3.6 Digital Communicator.....................................11
3.3.7 Keypads.............................................................11
3.3.8 Keyswitch..........................................................12
3.3.9 Event Memory..................................................12
3.3.10 Event Log..........................................................12
3.3.11 Ground Fault Detection...................................12
3.3.12 Ground Fault Detection Added Feature ........12
3.3.14 Conettix Functions...........................................12
3.3.15 Programming ....................................................12
3.3.16 Other Features..................................................13
4.0 Installation.......................................................13
4.1 Installation Preparation....................................13
4.2 Enclosure Options............................................13
4.3 Mounting Enclosure.........................................13
4.4 Installing the Control Panel ............................15
4.5 Connecting Earth Ground...............................15
4.5.1 Terminal 10.......................................................15
4.5.2 Ground Fault Detect Enable ...........................15
4.5.3 Enabling Ground Fault Detection ..................15
4.5.4 D7212GV3 Ground Fault Specifications .......15
4.5.5 Locking the Reset Pin......................................15
4.6 Completing the Installation.............................16
4.6.1 Charging the Battery........................................16
4.6.2 Installing and Wiring Detection Devices.......16
4.6.3 Installing Modules and Relays........................16
4.6.4 Connecting the On-board Points and Keypads
............................................................................16
4.6.5 Powering Up.....................................................17
4.7 Programming the Control Panel.....................17
4.8 Installing the Point Chart Label......................17
4.9 Testing the System...........................................17
4.10 Service Walk Test ............................................17
5.0 Power Supply .................................................20
5.1 Primary Power Terminals 1 and 2 .................20
5.1.1 Primary (AC) Power Circuit ...........................20
5.1.2 Installing the Transformer............................... 20
5.2 Secondary Power Terminals ........................... 20
5.2.1 Secondary (DC) Power.................................... 20
5.2.2 Installing the Battery........................................21
5.2.3 Replacing the Battery ......................................21
5.2.4 Battery Supervision..........................................21
5.2.5 Battery Charging Circuit .................................22
5.2.6 Battery Discharge and Recharge Schedule ...22
6.0 Power Outputs................................................ 24
6.1 Circuit Protection............................................. 24
6.2 Total Available Power..................................... 24
6.3 Continuous Power Output Terminals 3, 8,
and 32................................................................24
6.4 Programmable Power Output Terminals 6, 7,
and 8..................................................................24
6.4.1 Programming....................................................24
6.4.2 Terminals 6 and 7............................................ 25
6.4.3 Fire System Power Formula............................25
6.4.4 Terminal 8 ........................................................ 25
7.0 Telephone Connections ............................... 25
7.1 Registration.......................................................25
7.2 Notification .......................................................25
7.3 Location ............................................................26
7.4 Telephone Cord Connection..........................26
7.5 Phone LED (Red).............................................27
7.6 Operation Monitor LED (Green)...................27
7.7 Dialing Format .................................................27
7.8 Telephone Line Monitor................................. 27
7.9 Called Party Disconnect..................................27
7.10 Communication Failure...................................27
8.0 On-Board Points............................................. 28
8.1 Terminals 11 to 22 Description ...................... 28
8.2 Point Sensor Loops .......................................... 28
8.3 Point Parameters ..............................................28
8.4 Point Response Time.......................................29
8.5 Wiring Information for Installations Using the
Rothenbuhler 5110/4001-42 High Security
Bell.....................................................................29

D7212GV3 |Operation and Installation Guide | Contents
4 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
9.0 Off-Board Points.............................................32
9.1 Point (Zonex) Bus: D7212GV3 Terminals ....32
9.1.1 POPIT Modules ...............................................32
9.1.2 POPEX Modules..............................................32
9.1.3 Missing Conditions ..........................................32
9.1.4 Extra Point Events............................................32
9.1.5 D7212GV3 Responses to Missing Point
Conditions.........................................................33
9.2 D8125, D9127 POPIT Modules .....................33
9.3 Installing the D8125 POPEX Module............35
9.3.1 Mounting...........................................................35
9.3.2 Wiring the D8125 to the Control Panel.........35
9.3.3 Wiring POPITs to the Data Expansion Loop35
9.3.4 Wiring Data Expansion Loops to POPEX
Modules.............................................................36
9.3.5 POPIT Sensor Loops .......................................36
9.3.6 POPIT Module Point Assignments ................36
9.3.7 Program Record Sheet.....................................36
9.3.8 POPIT Labels ...................................................37
9.4 D8128D OctoPOPIT Module.........................37
9.4.1 Description........................................................37
9.4.2 Listings...............................................................37
9.4.3 Installation.........................................................38
9.4.4 Setting the OctoPOPIT Switches....................38
9.4.5 Mounting OctoPOPITs ...................................39
9.4.6 Wiring OctoPOPITs ........................................39
9.4.7 OctoPOPIT Sensor Loops...............................42
9.5 Testing Off-Board Points .................................42
10.0 Off-Board Relays............................................43
10.1 D8129 OctoRelay.............................................43
10.1.1 Configuring the D8129 OctoRelay.................43
10.1.1 Relay Outputs...................................................44
10.1.2 Installation.........................................................44
10.1.3 Wiring Connections.........................................44
11.0 Arming Devices..............................................44
11.1 Description........................................................44
11.2 Keypad Terminals 29 to 32.............................44
11.2.1 Assigning an Address for the Keypad............45
11.2.2 Installation.........................................................45
11.3 D279A Independent Zone Control................47
11.4 Keyswitch..........................................................47
11.4.1 Description........................................................47
11.4.2 Programming ....................................................47
11.4.3 Installation.........................................................47
11.4.4 Operation..........................................................47
12.0 SDI Devices..................................................... 48
12.1 Description .......................................................48
12.2 Installation ........................................................48
12.3 D9131A Parallel Printer Interface Module ... 48
12.3.1 Switch Settings.................................................. 48
12.3.2 Supervision .......................................................48
12.4 SDI Address 88 and 92 ...................................48
12.4.1 Network Interface Modules ............................48
12.4.2 Address Settings ...............................................49
12.4.3 Supervision .......................................................49
13.0 Programmer Connections............................49
13.1 Programmer Connector...................................49
13.2 Installer Keypad and Local Programmers
Mode .................................................................50
13.3 Programmer Access Reports........................... 50
14.0 D7212GV3 Faceplate ....................................51
Appendix A: System Wiring Diagrams, Issue A ... 52
Appendix B: Point Address Chart............................55
Specifications ................................................................ 56
SDI Bus A (+):................................................................ 56
Connection: ....................................................................56
Discharge Cycle..............................................................56

D7212GV3 |Operation and Installation Guide | Figures
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 5
Figures
Figure 1: System Configuration .................................8
Figure 2: Enclosure Mounting..................................14
Figure 3: Ground Fault Detect (S4) .........................15
Figure 4: Reset Pin ....................................................16
Figure 5: Service Walk Test Flow Chart.................19
Figure 6: Battery Terminals .....................................21
Figure 7: Charging and Battery LEDs.....................22
Figure 8: RJ31X Wiring............................................26
Figure 9: Phone Connector, Phone LED, and
Operation Monitor LED Locations.........26
Figure 10: On-board Point Sensor Loop Wiring......28
Figure 11: Rothenbuhler 5110/4001-42 High Security
Bell Wiring Configuration........................30
Figure 12: Wiring the Rothenbuhler 5110/4001-42
High Security Bell to the D7212GV3
Control Panel.............................................31
Figure 13: Connecting the D8125 POPEX to the
D7212GV3 Control Panel........................34
Figure 14: Program Record Sheet..............................37
Figure 15: D8128D OctoPOPIT Layout...................38
Figure 16: Connecting D8128D OctoPOPITs to the
D7212GV3.................................................40
Figure 17: Wiring Multiple D8128Ds Using Molex®
Connectors.................................................41
Figure 18: D8128D OctoPOPIT Sensor Loops........42
Figure 19: D8129 Connections to the D7212GV3...43
Figure 20: Power at Keypads .....................................46
Figure 21: Keyswitch Wiring......................................47
Figure 22: DX4020 DIP Switch Settings ..................49
Figure 23: Reset Pin ....................................................49
Figure 24: D7212GV3 Faceplate ...............................51
Figure 25: D7212GV3, Power Supply Side System
Wiring .........................................................52
Figure 26: D7212GV3, Input Points and Peripheral
Devices System Wiring.............................53
Figure 27: D7212GV3, SDI Devices System Wiring
....................................................................54
Tables
Table 1: Related Documentation ............................. 6
Table 2: GV3 Series Control Panel Differences ..... 8
Table 3: Compatible Accessories ...........................10
Table 4: Compatible Keypads ................................ 12
Table 5: Ground Fault Impedance Specifications 15
Table 6: Battery Discharge and Recharge Schedule
....................................................................22
Table 7: Charging Status and Low Battery LEDs. 23
Table 8: Point Parameters ....................................... 28
Table 9: POPEX Modules.......................................32
Table 10: Extra Point Events ....................................32
Table 11: Off-Board Point Errors.............................33
Table 12: Data Expansion Loop Wire Specifications
....................................................................35
Table 13: D8128D OctoPOPIT Switch Settings.....38
Table 14: Switch 5 Settings for Line Termination .. 39
Table 15: Terminal Strip Connections.....................39
Table 16: D8129 OctoRelay Switch Settings ..........43
Table 19: Keypad Address Settings........................45
Table 18: Keypad Connections ................................45
Table 19: SDI Device Connections..........................48
Table 20: Printer Address Switch Settings...............48
Table 21: Zonex 1, Points 9 to 40 ............................55
Table 22: Specifications.............................................56

D7212GV3 |Operation and Installation Guide | 1.0 Introduction
6 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
1.0 Introduction
This manual addresses the operation and installation of the D7212GV3 Control Panel only. Throughout this
guide, the words “control panel” refer to the D7212GV3 Control Panel.
To obtain any of the documents in Table 1, contact Bosch Security Systems, Inc. Customer Service
at [phone] and request the documentation by its corresponding part number.
Table 1: Related Documentation
Product Type Name of Documentation Part Number
D7212GV3 Release Notes F01U143081
D7212GV3 Approved Applications Compliance Guide F01U143080
D7212GV3 Operation and Installation Guide (this document) F01U143079
D7212GV3 Program Entry Guide F01U170808
D7212GV3 Program Record Sheet F01U170810
Control Panel
UL Certificated Bank Safe and Vault Applications Technogram 73-07302-000
D1255RB/D1256RB/D1257RB Installation Instructions F01U011791
D1255/D1255B Installation Instructions 74-06819-000
D1256/D1257 Installation Instructions 74-06925-000
D1260/D1260B Installation Guide 48101
D1260/D1260B Owner’s Manual 50410
D720 Series Installation Instructions 74-06918-000
D279A Operation and Installation Instructions 46458
Security System Owner's Manual 71-06633-000
Keypads
GV3 Series Owner's Manual Supplement F01U143082
Programming
Tools
RPS Installation Guide 4998141259
D8128D Installation Guide F01U070537
D8125MUX Operation & Installation Guide F01U034973
Expansion
Devices
ISW-D8125CW-V2 Installation & Operation Guide F01U161691

D7212GV3 |Operation and Installation Guide | 2.0 Lightning Strikes
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 7
2.0 Lightning Strikes
The control panel is designed to significantly reduce
electromagnetic interference and malfunction
generally caused by lightning.
2.1 Effects
Any electronic system can be struck directly by
lightning or be adversely affected by a lightning strike
near the system. When lightning strikes, several
things happen:
•An electromagnetic wave spreads from the point
of the strike inducing high voltages in nearby
conductors.
•The voltage changes substantially on electrical
grounds near the lightning strike.
•High voltages are induced upon anything directly
struck by lightning.
Symptoms of installations that lightning might strike or
affect are Missing Trouble, Missing Alarm, or Point
Bus Trouble events. Occasionally, Reboot and
Watchdog events might be sent because the control
panel tried to reset itself.
Electronic systems, including control panels, cannot
be completely immune to direct or indirect lightning
strikes; however, some proven installation practices
might greatly reduce the risk of undesirable affects.
2.2 Precautions during Installation
To minimize the risk of undesirable effects from
lightning strikes on high risk installations that use a
point-bus technology:
•Do not run wiring outside the building.
•If you must install the unit in a metal building,
keep the wiring at least 2 ft away from external
metal surfaces.
•Earth ground the unit correctly. Do not use an
electrical ground or telephone ground.
•Avoid running wires near telephone, data, or
power lines inside a building. Historical evidence
shows that locating control panel wiring at least 2
ft away from telephone, data, or power lines is
successful at minimizing lightning damage. When
your data lines must cross the path of AC or other
wiring, cross the lines perpendicularly.

D7212GV3 |Operation and Installation Guide | 3.0 Overview
8 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
3.0 Overview
3.1 Configuration and Parts
Figure 1: System Configuration
Use keypads or keyswitches to arm the control
panel by area. Each control panel can have up to four
areas. Each area can have its own account number or
areas can be grouped together with a common account
number. Points of protection are assigned to areas.
Control
Panel
On- oard Points
1 to 8
D9131A Module connects
to a parallel printer to print
the event log.
D8129 OctoRelay provides alarm
and auxilliary relay output.
(Other functions available.)
D8125, ISW-D8125CW-V2,
or D8125MUX Interface
used for point expansion.
Each D8128D OctoPOPIT combines
eight POPIT points in one module.
D8132 Modules (two 12 VDC) provide
additional power for keypads and other
powered devices.
DX4020 or ITS-DX4020-G allows
communication over a Local or
Wide Area network (LAN/WAN).
Table 2: GV3 Series Control Panel Differences
Features D9412GV3 D7412GV3 D7212GV3
Access Control Yes - 8 doors Yes - 2 doors No
Arm/Disarm Passcodes 249 99 99
Cards/Tokens 996 396 N/A
Passcode-Protected Custom
Functions 16 4 4
Number of Printers 3 1 1
Number of Points 246 75 40
Number of Relays 128 64 24
Number of Areas 32 8 4
Number of D1255 Keypads 16 16 8
Number of D1260 Keypads 8 8 8

D7212GV3 |Operation and Installation Guide | 3.0 Overview
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 9
3.1.1 Parts List
The D7212GV3 Control Panel is shipped pre-
assembled from the factory with the following parts:
Literature Pack
•D7212GV3 Program Record Sheet
(P/N: F01U170810)
•7000/9000 Series Point Chart Label
(P/N: 79-06660-000)
Assembly
•PC board
•Faceplate shield
•Mounting skirt
•One #6 x 1/4-in. screw
3.1.2 Parts Available by Separate Order
Order the following components separately to
complete a basic 8-point installation.
The D1260 and D1260B Keypads must
have firmware version 1.03 or higher for
use with the D7212GV3.
•D1255B, D1255, D1256, D1260, D1260B
Keypad, or D720 Keypad
•D1255RB Fire Keypad, D1256RB Fire Keypad,
or D1257RB Fire Alarm Annunciator
•D1640 Transformer
•D126 or D1218 Battery
•D161 or D162 Phone Cord
•D8103, D8108A, or D8109 Enclosure
Configured packages are also available. Please
consult the Bosch Security Systems, Inc. Product
Catalog.
The following literature is available in a separate
literature package for dealers.
•D7212GV3 Operation and Installation Guide
(P/N: F01U143079)
•D7212GV3 Approved Applications Compliance
Guide (P/N: F01U143080)
•D7212GV3 Program Entry Guide
(P/N: F01U170808)
•D7212GV3 Program Record Sheet
(P/N: F01U170810)

D7212GV3 |Operation and Installation Guide | 3.0 Overview
10 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
3.2 Accessories
Refer to the Bosch Security Systems, Inc. Product Catalog for additional information.
Table 3: Compatible Accessories
Model Title Fire Intrusion
D122/D122L Dual Battery Harness X X
D125B Powered Loop Interface Module X X
D127 Reversing Relay X X
D129 Dual Class A Initiation Circuit Module X X
D130 Relay Module X X
D185 Reverse Polarity Module X X
D192G Bell Circuit Supervision Module X X
D279A Independent Zone Control (on-bBoard and OctoPOPIT points) X
D720 LED Keypad X X
D720R LED Keypad (red) X X
D720W LED Keypad (white) X X
D1255RB Fire Keypad X X
D1256RB Fire Keypad X X
D1257RB Fire Alarm Annunciator X X
D1218 12 V, 17.2 Ah Rechargeable Battery X X
D1255/D1255B Keypads (general purpose) X X
D1255R Text Keypad (red) X X
D1255W Text Keypad (white) X X
D1256 Fire Keypad X
D1257 Fire Alarm Annunciator X
D1260/D1260B1Keypads X X
D1640 16.5 VAC 40 VA Transformer X X
D8004 Transformer Enclosure X X
D8125 POPEX Module X X
D8125MUX Multiplex Bus Interface
ITS-D8125CW-V2 Commercial Wireless Interface Module X X
D8128D OctoPOPIT Module X X
D8129 OctoRelay Module X X
D8130 Release Module X X
D8132 Battery Charger Module X X
D9127U/T POPIT Module X X
D9131A Parallel Printer Interface Module X X
DX4020 Network Interface Module X X
ITS-DX4020-G GPRS/GSM Communicator X X
ZX776Z PIR Motion Sensor [15 m (50 ft)] with POPIT X
ZX794Z PIR Motion Sensor [24 m (80 ft)] with POPIT X
ZX865 PIR/Microwave Motion Sensor [+1.7°C (+35°F)] with POPIT X
ZX938Z PIR Motion Sensor [18 m (60 ft)] with POPIT X
ZX970 PIR/Microwave Motion Sensor [+1.7°C (+35°F)] with POPIT
1Version 1.04 or above

D7212GV3 |Operation and Installation Guide | 3.0 Overview
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 11
3.3 Features in the D7212GV3
3.3.1 SDI Molex Connector
Use the SDI Molex Connector to easily connect an
SDI device with the SDI bus. Possible applications
include:
•Connecting a DX4010i to program the control
panel with Remote Programming Software
(RPS) at the premises
•Connecting a keypad to test the control panel.
Do not connect the D5200 Programmer to
the SDI Molex connector.
Control panel firmware v8.11 or later
does not support the D5200.
UL requires that the DX4010i be used for
programming only.
3.3.2 Tip and Ring Posts
The tip and ring posts allow connecting a phone or
buttset for the purpose of troubleshooting
communications between the control panel and the
central station. This connection allows monitoring of
the dial tone, handshaking tones from the receiver,
and communications signals.
3.3.3 Telephone Line Sniff
The D7212GV3 Control Panel monitors the phone line
for the programmed supervision interval before
indicating a phone line trouble.
3.3.4 Points
The Bosch Security Systems, Inc. D7212GV3 Control
Panel provides up to 40 points of protection. Point
programming parameters determine the control
panel’s response to open and shorted conditions on
the sensor loop for the point. Several options allow
individual point programming to custom-fit the
protection to the installation.
Points 1 to 8 are located on the circuit board (on-
board points). They are standard sensor loops. The
remaining off-board points are POPIT points using
D8128D OctoPOPITs, D8125 POPEX Modules and
D9127 POPITs, or the ISW-D8125CW-V2
Commercial Wireless Interface Module. MUX devices
can also be used with the D8125MUX.
Any points programmed as fire
supervisory points are latching.
3.3.5 Areas and Accounts
The system supports up to four separate areas. You
can assign all points to a single area or distribute
them over as many as four areas.
The control panel is armed and disarmed by area,
and several areas can be armed and disarmed with
one menu function. A passcode can also be assigned
an authority level that allows a user to arm an area
from a remote keypad in another area. Assigning
each area its own account number creates four
separate accounts in one control panel. Assigning the
same account number to different areas groups them
together in a single account.
Area options include exit tone and delay, separate fire
and burglary outputs, and multiple opening and
closing windows. Area type can be used to create
area interdependencies for arming purposes.
3.3.6 Digital Communicator
The control panel uses a built-in digital communicator
to send reports to the receiver. The control panel
sends reports in either the Modem IIIa2ANSI-SIA
Contact ID format. All software versions for the D6600
can be used with the control panel.
The control panel connects to an RJ31X or RJ38X
jack for telephone line seizure. Connecting to the
RJ31X complies with FCC regulations for using the
public telephone network. The control panel can be
programmed to direct reports to four separate
telephone numbers.
The system can route groups of Event Reports to four
different destinations. Each report group can be
programmed to send reports to one or more
destinations. Primary and backup reporting paths can
be programmed for each destination and each report
group. A custom option allows specification of
individual Event Reports to be sent.
3.3.7 Keypads
Up to 32 unsupervised keypads can be connected to
the system. The available power, number of
supervised keypads, and number of areas covered
affect the total number of keypads that can be
connected.
The system can supervise up to eight keypads. The
control panel sends a Serial Device Trouble Report,
SDI FAILURE in the Modem IIIa2format or
Expansion Module Failure (333) in Contact ID format,
if it loses communication with a supervised keypad.
More than 8 keypads can be added, but the system
can only supervise up to 8 keypads. Table 4 on
page 12 shows the compatible keypads with the
D7212GV3 Control Panel. Refer to Keypad in the
D7212GV3 Program Entry Guide (P/N: F01U170808)
for complete details on programming keypad options.

D7212GV3 |Operation and Installation Guide | 3.0 Overview
12 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
Table 4: Compatible Keypads
Model Display Application
D1255/
D1255B/
D1255RB
16-character
alphanumeric
Fire/Burglary/Access
D1256/
D1256RB
16-character
alphanumeric
Fire
D1257/
D1257RB
16-character
alphanumeric
Fire
D1260/
D1260B
4-line by 20-
character
Fire/Burglary
D720/
D720B
8 LED Fire/Burglary
3.3.8 Keyswitch
Maintained or momentary closure devices such as
keyswitches allow any of the four available areas to
be armed or disarmed. Point programming
determines the loop responses and which area a
keyswitch controls.
3.3.9 Event Memory
The control panel retains point alarm and trouble
events in memory for each area. A D1255 (any
model) or a D1260 (any model) can be used to view
event memory by using COMMAND 40. The control
panel clears the previous events for an area from the
event memory when the area is armed.
3.3.10 Event Log
The system stores 800 events from all areas in its
event log. For example, the system adds at least two
items to the log each time an area is armed or
disarmed, the open (or close) event that also contains
the previous arming state.
All events can be stored even if the control panel
does not send a report for them. The log can be
viewed at a keypad, printed locally using the D9131A
Parallel Printer Interface Module and a parallel printer,
or uploaded using Remote Programming Software
(RPS).
For a list of the log events, refer to the appendix in the
user’s guide for the keypad.
3.3.11 Ground Fault Detection
The Earth Ground Terminal on the control panels is
electrically isolated from all other terminals to allow
the D7212GV3 to detect ground fault conditions. A
Ground Fault Detect Enable switch (S4) is located just
under Terminal 10, Earth Ground, on the control
panel. Refer to Section 4.5.2 Ground Fault Detect
Enable on page 15 for information on operating this
function.
3.3.12 Ground Fault Detection Added Feature
When Ground Fault Detect is enabled (S4 closed),
Points 1 to 8 can be used for non-powered fire-
initiating devices such as heat detectors, four-wire
smoke detectors, and pull stations. A D125B Powered
Loop Interface or a D129 Dual Class A Interface
Module is not required when connecting the non-
powered fire-initiating devices to Points 1 to 8.
3.3.13 Conettix Functions
The D6600 Conettix System supports data network
communications. Conettix allows the D6600 Receiver
to connect to various network technologies including
Ethernet and GPRS (General Packet Radio System).
Connecting to a data network is possible using the
COM4 or COM1 connection from the D6600 Receiver
to the D6680 Network Adapter. Control panels can
send reports through telephone lines, Ethernet,
Token-Ring or GPRS networks to the D6600 receiver
at the central station. Once events are received, they
can then be issued to automation software or a
network printer through a local area network (LAN) or
wide area network (WAN).
Sending events to the central station over a LAN or
WAN requires a network interface module (NIM), such
as the DX4020. Sending events over GPRS requires
a special NIM, the ITS-DX4020-G.
3.3.14 Programming
Use the Remote Programming Software (RPS) to
program the D7212GV3 Control Panel.
Refer to the D7212GV3 Program Entry Guide
(P/N: F01U170808) for programming options.

D7212GV3 |Operation and Installation Guide | 4.0 Installation
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 13
3.3.15 Other Features
The D7212GV3 Control Panel has many
programmable features. Some of the features are
listed below. Complete details on all features are in
the D7212GV3 Program Entry Guide
(P/N: F01U170808).
•Supervision of AC (primary power), battery
(secondary power), Zonex and SDI buses,
central processing unit (CPU), up to three
printers, and two telephone lines
•Automatic System Test Reports
•Remote access for programming, diagnostics,
and log uploads using the remote programming
software (RPS)
•Fire alarm verification
•Programmable alarm output
•Programmable relay output using the D8129
OctoRelay Module
•Opening and closing windows
•Skeds (scheduled events)
•Limited local programming available in the
Service Menu
4.0 Installation
4.1 Installation Preparation
This section contains a general installation procedure
and refers to other sections of the document for
detailed instructions.
Review this document and the D7212GV3 Program
Entry Guide (P/N: F01U170808) before beginning the
installation to determine the hardware and wiring
requirements for the features used.
Have the following documentation available when
reading through this guide:
•D7212GV3 Program Record Sheet
(P/N: F01U170810)
•Security System Owner’s Manual
(P/N: 71-06633-000) and GV3 Series Owner’s
Manual Supplement (P/N: F01U143082)
•Installation manual for keypad or annunciator
(D1255 all models, D1255RB, D1256, D1256RB,
D1257, D1257RB, D1260 all models, or D720 all
models)
Before installation, become familiar with RPS or the
Local Programmers menu.
4.2 Enclosure Options
Mount the control panel assembly in any of the Bosch
Security Systems, Inc. enclosures listed:
•D8103 Universal Enclosure (tan)
•D8108A Attack Resistant Enclosure (tan)
Refer to the D7212GV3 Approved Applications
Compliance Guide (P/N: F01U143080) to determine if
the application requires a specific enclosure.
4.3 Mounting Enclosure
1. Run the necessary wiring throughout the
premises.
2. Mount the enclosure in the desired location. Use
all five enclosure mounting holes. Refer to
Figure 2.
3. Pull the wires into the enclosure.
Electromagnetic interference (EMI) can
cause problems on long wire runs.

D7212GV3 |Operation and Installation Guide | 4.0 Installation
14 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
Figure 2: Enclosure Mounting
8
2
1324
3
7
5
9
6
1 - Point chart label
2 - Mounting skirt hooks (2)
3 - Module mounting holes (12)
4 - Tamper switch mounting holes (5)
5 - Skirt mounting hole (1)
6- Enclosure mounting holes (5)
7 - Mounting skirt hook holes (2)
8 - Back of D7212GV3 Control Panel
9 - Lock down tab

D7212GV3 |Operation and Installation Guide | 4.0 Installation
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 15
4.4 Installing the Control Panel
1. Place the control panel over the inside back of the
enclosure, aligning the large rectangular openings
of the mounting skirt with the mounting hooks of
the enclosure. Slide the control panel down so
that it hangs on the hooks. Refer to Figure 2, Item
2on page 14.
2. Remove the tape from the #6 x 1/4-in. screw in
the mounting tab on the control panel. The screw
passes through the mounting tab and into the
skirt mounting hole in the enclosure. Tighten the
screw to secure the control panel in the
enclosure.
3. Connect earth ground to the control panel before
making any other connections. Refer to Section
4.5 Connecting Earth Ground.
4.5 Connecting Earth Ground
4.5.1 Terminal 10
To help prevent damage from electrostatic charges or
other transient electrical surges, connect the system
to earth ground at Terminal 10 before making other
connections. Recommended earth ground references
are a grounding rod or a cold water pipe.
Warning:
Do not use telephone or electrical ground
for the earth ground connection. Use
1.8 mm (14 AWG) to 1.5 mm (16 AWG)
wire when making the connection.
Do not connect other control panel
terminals to earth ground.
4.5.2 Ground Fault Detect Enable
A ground fault is a circuit impedance to earth ground.
The control panel has a ground fault detection circuit
that, when enabled, detects ground faults on
Terminals 1 to 9 and 11 to 32. The control panel also
detects and annunciates ground faults on any device
connected to it.
•If a ground fault condition occurs, the keypads
display SERVC GND FAULT and the control panel
sends a GROUND FAULT TROUBLE, AREA 1.
When the control panel recognizes that the
ground fault condition is corrected, and remains
corrected for between 5 to 45 consecutive sec, a
Restoral Report is sent.
The D7212GV3 Control Panel logs and
prints a Ground Fault event as a Trouble
Point 256 if communicating in Modem IIIa2
format. If communicating in Contact ID
format, the D7212GV3 generates a
Ground Fault (310) event.
4.5.3 Enabling Ground Fault Detection
To enable the Ground Fault Detect Enable feature,
lock (close) the S4 Ground Fault Detect Pin on the
control panel (Figure 3).
Figure 3: Ground Fault Detect (S4)
Re se t Pi n
Disab le Al l Exc ept Battery
ChargingAndProgramming
27
PR OG
CONN
26
25
24
Re set Pi n
Disab le Al l Exc ept Battery
Ch ar gingAndProg ramming
27
PRO G
CO NN
26
25
24
2
1
EAR TH G RO UND
COMMON
BA TTER Y NEG AT IVE ONLY
BAT TER Y POSITIVE ONLY
REL AY A
REL AY B
REL AY C
+AUXPOWER
CLAS S2 TRAN SFORM ER
16.5 VAC 40VA 60Hz
Model D1640
Int er na llyFused - Do no t shor t
Requi res UnswitchedOutlet
Do no t sharewithot her equi pment
S4 GROUND FAU LTDETECT
Enabl ed
Di sabled
RED
ON whencommunicating
OFFwhen idl e
Co mmercialPr ot ec t ed- Pr em isesControlPa nel
D9412G V3ControlPanel is ULListed ForCe nt r al Stat ion, Local , Aux iliar y, Prop r i etary,and Househol d
Fi re Al arm,andCen t r alStat ion, Local , PoliceSt ationCo nnect,House h o l d Burgl ar Al armandEncr yp t ed
Li neSe cur i ty whencommunicat ing via anet work.
Systemisintended tobe checkedby aQualifiedTechni cian at least ever y3 years.
Th e typesof initiat ing ci rcui ts the cont rol panel has been approve d f or are A, M,W,SS.
Th e typesof si gnalingthe controlpanel has beenappr ov ed for are DAC, OT,NC
VOLTA GERANGES
O pen 3. 7 - 5. 0VDC Short 0.0-1. 3 VDC
Normal 2.0-3. 0VDC
ResetPin
Disab le al l except Bat t ery
Ch ar gingan dProgramming
PERI PHER AL DEVI CE CONNECTIONS
RED P OWER +
YELLO W DATA BU SA
GREEN DATABU S B
BLAC K C OMMON
ZON EXOUT 1
ZONEXIN1
N. F.P. A.
St yle 4.0
Si gnaling
Li ne
Ci rcu its
F01U143074- 02
LE Ds O ffWh enNormal
YE L LO W -ChargingStatus
RED - Low Batter y - 12. 1 VDC
10. 2VDC-Batter y Loa dShed
Thi sequi pment should beinstal led inaccordancewiththeNFPA70 (NationalElectr ical Code) a n d
NF PA72 (NationalFireAlar mCode) forLocal , Ce nt ral St ation,Pr opr ietary andHousehold Fire Warning
Syst e ms and underthelimitsof theLocal Author ity Having Jur isdi ction(National Fi re Prot ec tion
Ass o ciation, Bat t e rmarch Par k, Qui ncy,M A 02269).Pr int ed information describing pr oper instal lat ion,
oper a t ion, testing,mai nt enance, evacu ationpl anning and repai rser viceistobe provi dedwiththis
equi pmen t.
D7212GV3
26
25
ZO NEX POWER +
24
ZO NEX COMMON
23
PHONE LINE SEIZED LED
TIP RING
TELCOCORD MODELD161
SDI Conn ector
ZON EX OUT 2
ZONEXIN 2
Refer tothe D9 4 1 2 GV3/D 7412G V3 Ap pr oved App lication sComplian ceGuide (P/N:F01U 143069)
forSy stem Wiring Di agram,Iss ueAan dfor compatible sm oke det ector s.
PO W ER S UPPLYREQUIREMENTS
ThePowerSu ppl yprovide sa m axi mumof 1. 4 Amps forthe Control Panelan dal l
A ccesso ryDevice s. For Syst em Loading,referto theD 9412G V3/ D74 12GV3O perat ion
an dI nstal lati on Gui de (P/N:F0 1U1430 70).
( P/ N: F01U1 43070) for PowerRe qu i remen ts relat ingto Terminals 6 an d 7 .
CA UTION: Ref e r to theD 9412G V3/ D741 2GV3Operationan dI nst al lat i on Gui de
All externalconn ect ion sexc eptTe r m i nal 5 (battery positive) areinherentlypower
limited.Re qui remen ts f or ba tterystan dby timemightr ed uce allowableou tput.
WARNING!
Mu lti-Ba tte ryi n st al lat i on re qu ires
Mo de lD 122/ D 122 L Du al Ba ttery
Harness .Improper installationcan
beafire h azard .
B at t er y: R epl ac e ever y 3to
5yearswithoneortw o Mod el
D126or D121812 V Le ad A ci d
Batteries.
Inco rrect wiring will
dam age this equi pm ent .
PR OGRAMMABLE
ALARMOUTPUTS
Ter m inal s
SW I TCH ED AUX
and67
Ter minal 8
Oper at ion Moni torLED
Pul seswhen Nor m a l
Flickerswhen Ri nging
GREEN
D5200/D5360
PRO GCONN
Po int 8, S3 Option
Cl os ed= 1kΩ EO L
Nor mal Operation
Open =AB- 12 UL
Bel l Bo x 220 kΩ
25
Poi nt 3Point 4
161514
Point1 Poi nt 2
1211 13
Poi nt 5Point 6
1817 19
Point 7 Poi nt 8
21
20 22
Suitabl e fordr y ind oor
useonly.
Devi c es po w e r ed bythe
AUX power out put must
besupervised.
Mini mum sy st emreq uirement sforCl assificat ion inaccordancewithAN SI/SIACP -01-2000:
UL List ed andCl assified control uni t ModelD9412GV3, D7412G V3, or D7212G V3;
UL List ed andCl assified keypadModelD1256, D1257, D1260, D1255,D 1255R, orD1255RW;
UL List ed Local Bell
WARNING !
To pr even t risk of
el ect ri c shock,
di sc onn e ct AC po wer
and telephon elines
before servicing .
CA UTI ON:Avoi ddam a geto Panel.
Do no t connect 24Vtoterminals.
Max imumch ar gingcu rrent 1.4 A
1 - S4 Locked (Closed). Control panel detects
ground faults.
2 - S4 Unlocked (Open). Control panel does not
detect ground faults.
4.5.4 D7212GV3 Ground Fault Specifications
Table 5 provides the impedance specifications for
detecting ground faults when any terminal or field
wiring is shorted to ground.
Table 5: Ground Fault Impedance
Specifications
Impedance Control Panel Detects Ground Fault
≤ 300 ΩYes
300 Ωto
200 kΩDetection depends upon the terminal
≥200 kΩNo
4.5.5 Locking the Reset Pin
Locking the reset pin disables the control panel
(Figure 4). When the control panel is disabled, the
system ignores most keypad commands and points.
CALL FOR SERVICE appears in keypad displays
when the pin is locked down.
On-board relays (Terminals 6 and 7) and off-board
relays deactivate when the control panel is reset.
Terminal 8 has power when the relay is deactivated.
Activation interrupts power at that terminal. The on-
board relay (Terminal 8) remains deactivated when
the reset pin is locked in the disable position.

D7212GV3 |Operation and Installation Guide | 4.0 Installation
16 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
Releasing the reset pin from the closed position
resets the control panel. The control panel resets all
its timers, counters, indexes, and buffers. Any points
that restore after a reset do not generate Restoral
Reports.
If the reset pin is placed in the disable position when
all areas are armed, there must be an entry in the
Answer Armed program item. Refer to RPS
Parameters in the D7212GV3 Program Entry Guide
(P/N: F01U170808).
Locking the pin in the disable position applies power
to the control panel and charges the battery while the
detection devices and keypads are installed.
Figure 4: Reset Pin
1 - Reset pin locked (closed.
2 - Reset pin normal (open)
4.6 Completing the Installation
If not already complete, make the earth ground
connection to Terminal 10 and lock the reset pin in
the closed position.
4.6.1 Charging the Battery
Connect the battery, then the transformer to allow the
control panel to charge the battery while you complete
the installation. Refer to Section 5.0 Power Supply on
page 20 for instructions.
On-board Buzzer Sounds at Power Up and Reset:
The system performs a series of self-diagnostic tests
of hardware, software, and programming at power up
and at reset. The buzzer on the control panel sounds
during the tests. The self-diagnostics tests complete
in approximately 1 to 3 sec.
If the control panel fails any test, the buzzer continues
sounding and a System Trouble message appears at
the keypads.
Touch Terminal 10 First: If the on-board buzzer
sounds briefly when the control panel is touched, any
static charge you carry discharges to the control
panel.
Avoid electrostatic discharge. Always touch
Terminal 10, the earth ground connection,
before beginning work on the control panel.
If the control panel receives an electrostatic
discharge, it might generate Watchdog Reset and
Param Fail events.
4.6.2 Installing and Wiring Detection Devices
Install and wire detection devices and keypads at their
locations throughout the premises. Do not connect
the control panel yet.
Section 8.0 On-Board Points on page 28 contains
instructions for wiring the on-board points to detection
devices. Section 11.0 Arming Devices on page 44
contains instructions for wiring the keypads.
Instructions for wiring the off-board point POPIT
sensor loops are found in the instructions packaged
with the POPIT modules.
4.6.3 Installing Modules and Relays
1. Power down the unit by unplugging the
transformer and disconnecting the battery.
Always power down the unit when installing
modules or relays, or when making wiring
connections to the control panel.
2. Install and wire any modules required for the
installation as described in the module’s
installation instructions.
Instructions for the D8125 POPEX Module,
D8128D OctoPOPIT Module, D8129 OctoRelay
Module, and D811 Arm Status Relay Module
appear in this guide.
Refer to Section 9.0 Off-Board Points on page
for D8125 and D8128D instructions. Refer to
Section 10.0 Off-Board Relays on page 43 for
D8129 and D811 instructions.
3. If using the power outputs at Terminals 7 or 8,
refer to Section 6.4 Programmable Power Output
Terminals 6, 7, and 8 on page 24 for
instructions.
4.6.4 Connecting the On-board Points and
Keypads
Connect the on-board points and keypad wiring to the
system. Refer to Section 8.0 On-Board Points on
page 28 and Section 11.0 Arming Devices on page
44 for instructions.

D7212GV3 |Operation and Installation Guide | 4.0 Installation
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 17
4.6.5 Powering Up
Reconnect the battery, then plug in the transformer.
The buzzer sounds for two sec when the control panel
is powered up. Leave the reset pin in the locked
position.
Yellow Charging Status LED Remains Lit: If the
yellow charging status LED remains lit after five
minutes of powering up the control panel, either the
battery is deeply discharged, or too many powered
devices were connected to the control panel.
Combined continuous current draw for Terminals 38,
24, and 32, and the accessory connector cannot
exceed 1.4 A. Refer to Section 6.0 Power Outputs on
page 24 for help.
4.7 Programming the Control Panel
If the control panel is not already programmed, review
the D7212GV3 Program Entry Guide
(P/N: F01U170808). Ensure that all accessory
modules for desired features are available for
installation.
Use RPS to load a custom program into the control
panel as needed.
4.8 Installing the Point Chart Label
The point chart label is required for fire
systems with verifications points.
A point chart label is included in the literature pack.
Install the point chart label for fire or combined fire-
and-burglary systems that use verification points.
Use the D7212GV3 Program Record Sheet
(P/N: F01U170810) to gather the necessary
information for completing the point chart. Fill out the
label and install it on the inside of the enclosure door
(refer to Figure 2 on page 14).
Avoid smearing the entries on the chart.
Use the peel-off backing to press the label
in place.
4.9 Testing the System
After installing and programming the control panel,
test the system completely. Test the control panel and
all devices for proper operation.
Test after initially programming the control
panel and after subsequent programming
changes.
Refer to Section 4.10 Service Walk Test for complete
Service Walk Test instructions.
Clear after Test: To clear the event memory and
report buffer, momentarily close the reset pin. Events
stored in the control panel’s event log are not cleared.
4.10 Service Walk Test
The Service Walk Test differs from the standard Walk
Test. In the standard Walk Test, POPITs whose
switches are set for a point number not programmed
in the control panel do not appear in the test. In the
Service Walk Test, POPITs whose switches are set
for a point number that is not programmed in the
control panel do appear in the test.
The Service Walk Test allows the installer to walk test
all points from a control-panel-wide keypad,
regardless of the point index type.
A Service Walk Test can also be initiated by account-
wide or area-wide keypads but test only those points
that are within the scope of the keypad that initiated
the function. The Service Walk Test does not test
points in armed areas.
Only Walk Test Start and Walk Test End
are reported to the central station.
The D9131A can be configured for local
printing. Refer to the D7212GV3 Program
Entry Guide (P/N: F01U170808).
During a Service Walk Test, the summary
alarm and summary fire remain off, because
there are no Fire or Burg alarm conditions
to summarize. The P# Relay Response
Type feature operates as programmed.

D7212GV3 |Operation and Installation Guide | 4.0 Installation
18 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
Service Walk Test Procedure
Refer to Figure 5 on page 19 for Service Walk Test
options. Refer to the Walk Test procedures in the
GV3 Series Owner’s Manual Supplement
(P/N: F01U143082) when using a D1260 or D1260B
Keypad.
1. Choose a keypad to conduct the test. Ensure that
the display shows the idle disarmed text.
2. Press the [MENU] key to enter the Function List.
Press [NEXT] repeatedly until the SERVICE
WALK ? prompt appears.
3. Press [ENT].
The D7212GV3 does not include the
Service Walk Test in the Service Menu.
Enabling the Service Walk Test function
Function List provides access to the
Service Walk Test.
4. The display shows ### PTS TO TEST .Test the
first detection device.
5. When a detection device is faulted, the keypad
emits a brief tone and displays the point text of
the point tested for 60 sec. After 60 sec, the
display returns to the ### PTS TO TEST
message.
Extra Points display default text: If the switches on
a POPIT are set incorrectly to a point number that is
not in the program for the control panel, the default
text for that point number (PT ###) appears when the
point is faulted. Refer to the control panel’s program
record sheet for the default text for all points.
Faulting the point a second time produces the tone
and shows the point text, but does not decrease the
count in the ## PTS TO TEST message.
1. To see the points that remain untested during the
Service Walk Test:
a. Press [ESC] when point text appears. The
display shows ## PTS TO TEST.
b. Press the [ESC] key. VIEW UNTESTED ?
appears.
c. Press [ENT]. ## PTS UNTESTED appears.
d. Press [NEXT] to see a list of the points that
have not yet been tested. Move through this
list by pressing the [NEXT] key.
e. To resume the Service Walk Test, press
[ESC]. ## PTS UNTESTED appears.
f. Press [ESC]. ## PTS TO TEST appears.
g. Resume testing points. To end the Service
Walk Test, press [ESC] twice.
2. After the last point is tested, 0 PTS TO TEST
appears. Press [ESC]. The display shows ALL
PTS TESTED briefly before returning to idle text.
Automatic time-out returns the system to
idle text. If there is no point or keypad
activity for 20 min, the Service Walk Test
ends automatically. The keypad returns to
idle text.

D7212GV3 |Operation and Installation Guide | 4.0 Installation
.
Bosch Security Systems, Inc. | 10/10 | F01U143079-03 19
Figure 5: Service Walk Test Flow Chart
ENT
ENT
ESC
ESC
ESC
ESC
NEXT
Test a device
Test a device
Test a device
Test a device
(Text displays for 60 seconds)
(Text displays for 60 seconds)
IDLE TEXT
SERVICE WALK?
40 PTS TO TEST
POINT TEXT
39 PTS TO TEST
POINT TEXT
38 PTS TO TEST
POINT TEXT
1 PTS TO TEST
VIEW UNTESTED?
0 PTS TO TEST
# PTS UNTESTED
POINT TEXT
ESC
ESC
ESC

D7212GV3 |Operation and Installation Guide | 5.0 Power Supply
20 Bosch Security Systems, Inc. | 10/10 | F01U143079-03
5.0 Power Supply
5.1 Primary Power Terminals 1 and 2
5.1.1 Primary (AC) Power Circuit
The primary source is a 16.5 VAC, 40 VA, internally-
fused transformer (Bosch Security Systems, Inc.
Model D1640). The control panel draws 200 mA when
idle and 500 mA when in an alarm state. The total
available auxiliary current is 1.4 A.
Transient suppressors and spark gaps protect the
circuit from power surges. This protection relies on
the ground connection at Terminal 10. Ensure that
you connect Terminal 10 to a proper ground. Refer to
Section 4.5 Connecting Earth Ground on page 15.
AC Power Fail
The system indicates an AC power failure when
Terminals 1 and 2 do not have power. The AC Fail
Time parameter sets the number of minutes or
seconds without AC power before the control panel
acknowledges the failure and the number of minutes
or seconds after the power returns before the control
panel acknowledges restored power. Refer to the
D7212GV3 Program Entry Guide (P/N: F01U170808)
for additional information about AC Fail Time.
5.1.2 Installing the Transformer
Do not short-circuit the terminals of the
transformer: Shorting the terminals opens
the internal fuse, causing permanent failure.
Connect the transformer to Terminals 1 and
2 of the control panel before plugging it into
the power source.
1. Use 1.22 mm (18 AWG) wire (minimum) to
connect the transformer to the control panel.
The wire length should be as short as possible.
The maximum length is 15 m (50 ft). Connect the
battery and plug in the transformer.
2. Route telephone and sensor loop wiring away
from any AC conductors, including the
transformer wire.
AC wiring can induce noise and low level voltage
into adjacent wiring. Route data wiring away from
AC and telephone wiring.
Always connect the battery first and then
plug in the transformer.
3. Connect the battery. Refer to Section 5.2.2
Installing the Battery on page 21.
4. Plug the transformer into an unswitched, 120
VAC, 60 Hz power outlet only.
5. Secure the transformer to the outlet with the
screw provided.
D8004 Transformer Enclosure Required for Fire
Systems: Use the D8004 Transformer Enclosure for
the D1640 Transformer in fire and combined
fire/burglary applications.
Check with the Authority Having
Jurisdiction (AHJ) about mounting
transformers on specific circuits.
5.2 Secondary Power Terminals
5.2.1 Secondary (DC) Power
A 12 V, 7 Ah (up to 14 Ah) sealed lead-acid
rechargeable battery supplies secondary power for
auxiliary and alarm outputs, and powers the system
during interruptions in primary (AC) power.
Warning - Use Lead Acid Batteries Only:
The charging circuit is calibrated for lead-
acid batteries. Do not use gel-cell or nicad
batteries.
Extra Batteries Increase Back-up Time
To increase battery back-up time, connect a second
12 V battery of equal capacity in parallel to the first
battery. Use a D122 Dual Battery Harness to ensure
proper and safe connection. Refer to the Standby
Battery and Curent Rating Chart in the D7212GV3
Approved Applications Compliance Guide
(P/N: F01U143080).
D1218 Battery
The D1218 is a 12 V, 17.2 or 18 Ah battery for use in
applications requiring extended battery standby time.
Up to two D1218 batteries can be connected when
used with a D122 Dual Battery Harness.
Caution: When connecting two D1218
Batteries to the control panel, both must have
the same capacity (use two 17.2 Ah batteries
or two 18 Ah batteries).
When using two D1218 batteries, use a
separate enclosure, a D122L Dual Battery
Harness, and long leads.
