D9412GV4/D7412GV4/D7212GV4
Control Panels
en Program Entry Guide

D9412GV4/D7412GV4/D7212GV4 Table of Contents | en 3
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
Table of Contents
1 System Requirements 6
2 Introduction 7
2.1 Using this Program Entry Guide 7
2.2 Guide to UL 864 Programming Requirements for D9412GV4 and D7412GV4 Control Panels 7
2.3 Guide to UL 636 Programming Requirements for D9412GV4/ D7412GV4/D7212GV4 Control Panels 10
2.4 Guide to Programming Descriptions 11
2.5 Guide to Keypad Tools 11
2.5.1 Keypad Programming Menu 12
2.5.2 Service Bypass Menu 14
2.5.3 RF Points Menu 14
2.5.4 RF Repeaters Menu 15
2.5.5 RF Diagnostics Menu 15
2.5.6 IP Diagnostics Menu 16
3 Panel and Area Wide Parameters 17
3.1 Phone 17
3.2 Phone Parameters 19
3.2.1 Special Point/User Reporting 21
3.3 Routing 23
3.3.1 Call Party Disconnect 24
3.3.2 Route Number Groups: Which Has the Highest Priority? 24
3.3.3 Programming Primary and Backup Destinations 24
3.3.4 Enhanced Routing 24
3.3.5 Programming a Duplicate Report 25
3.3.6 Routing Destination Communication Failures 25
3.3.7 Message Prioritization within a Route Number 25
3.3.8 Route Group Parameters 29
3.3.9 Communication Attempts 30
3.3.10 Route Group Categories 33
3.4 Programming Path Numbers and Network Addresses for Enhanced Communications 40
3.4.1 Anti-Replay Security Feature 45
3.5 SDI RPS/Enhanced Communications Configuration 45
3.5.1 Configuration for RPS Over Network 46
3.6 Power Supervision 50
3.7 Printer Parameters 52
3.8 RPS Parameters 54
3.8.1 Uploading and Downloading Reports 54
3.8.2 Log Threshold Reports 54
3.8.3 Panel Initiated Unattended RPS 55
3.9 Miscellaneous 59
3.10 Area Parameters 61
3.10.1 Area Parameters 61
3.10.2 Shared-Area Characteristics 65
3.10.3 Bell Parameters 66
3.10.4 Open/Close Options 69

4en | Table of Contents D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
3.10.5 Arming Features 74
3.11 Keypad (Command Center) 78
3.11.1 Keypad (Command Center) Assignment 79
3.11.2 Area Text 88
3.11.3 Custom Function 89
3.12 User Interface 93
3.12.1 Commands 93
3.12.2 Command Authorization 93
3.12.3 Access Control Functions 96
3.12.4 Custom Functions 101
3.12.5 Configuration Authority 101
3.12.6 Authority Level Selections 102
3.12.7 General Functions 108
3.12.8 Report Levels 113
3.12.9 Access Control Levels 114
3.12.10 SIA Duress Passcode Options 116
3.13 Function List 116
3.14 Relay Parameters 117
3.14.1 Area Relays 118
3.14.2 Panel-Wide Relays 121
3.14.3 Relay/Output Configuration 124
4 Passcodes, Access Credentials, and User Groups 125
4.1 Passcode or Token Worksheet 125
4.1.1 User Credentials 125
4.1.2 Passcodes 125
4.1.3 User Group Window 125
4.1.4 User Name 125
4.1.5 Tokens and Cards 126
4.1.6 Reporting and Logging 126
5Points 130
5.1 Point Index 130
5.2 Point Responses 132
5.2.1 Applications for Point Responses 9, D, and E: 132
5.2.2 Characteristics of a Fire Point: 133
5.3 Point Assignments 146
5.4 Cross Point Parameters 149
5.5 COMMAND 7 and COMMAND 9 151
6 Schedules (Skeds) 154
6.1 Windows 154
6.1.1 Opening and Closing 154
6.1.2 User Group Windows 162
6.1.3 Holiday Indexes for User Group Windows 164
6.2 Schedules (Skeds) 164
6.3 Holiday Indexes 173

D9412GV4/D7412GV4/D7212GV4 Table of Contents | en 5
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
7AUXPARM 174
7.1 Automation 174
7.2 Miscellaneous 175
8SDI2Modules 179
8.1 B208 Octo-input Module 179
8.2 B308 Octo-output Module 179
8.3 B420 Ethernet Communication Module 179
8.3.1 IP Diagnostics Keypad Menu (B420) 189
8.4 B820 SDI2 Inovonics Interface Module 190
8.5 Wireless Repeater 190
8.5.1 RF Repeaters Keypad Menu (RFID Wireless Repeaters) 191
8.5.2 RF Diagnostics Keypad Menu (RFID Wireless Repeaters) 193
9 ACCESS CONTROL (D9412GV4/D7412GV4) 195
9.1 Door Profile 195
9.2 Strike Profile 198
9.3 Event Profile 200
10 SIA CP-01 Quick Reference 203
11 Keypad Tools Menu (Options Not Available in RPS) 204
11.1 Service Bypass Menu 204
11.1.1 Setting Service Bypass (PT NUM 1-247) 204
11.1.2 Resetting Service Bypass 204
11.2 RF Points Menu 205
11.2.1 Enroll RF Point 205
11.2.2 Replace RF Point 205
11.2.3 Remove RF Point 206

6en | System Requirements D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
1 System Requirements
WARNING!
Minimum system requirements for Classification in accordance with ANSI/SIA CP-01-2007: UL
Listed and Classified control unit Model D9412GV4 or D7412GV4 or D7212GV4.
UL Listed and Classified keypad Model D1256, D1257, D1260, D1255, D1255R, or D1255 RW.
UL Listed Local Bell.
Control Panel Firmware Version
D9412GV4 1.00 or later
D7412GV4 1.00 or later
D7212GV4 1.00 or later

D9412GV4/D7412GV4/D7212GV4 Introduction | en 7
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
2 Introduction
2.1 Using this Program Entry Guide
This guide is for programming the GV4 Series Control Panels.
Table 2.1 Referenced Literature
2.2 Guide to UL 864 Programming Requirements for D9412GV4 and
D7412GV4 Control Panels
This section identifies the programming requirements you must make in order to comply with
UL 864 Commercial Fire applications.
Features D9412GV4 D7412GV4 D7212GV4
Access Control Eight Doors Two Doors N/A
Passcodes 999 399 99
Cards/tokens 999 399 N/A
Passcode-protected custom functions 16 4 4
Numberofprinters 311
Number of points 246 75 40
Number of off-board relays 128 64 24
Areas 32 8 4
Document Name Part Numbers
D1255 Installation Instructions 74-06819-000
D1256/D1257 Installation Instructions 74-06925-000
D1255RB/D1256RB/D1257RB Installation Instructions F01U011791
D1260 Installation Guide 48101
D1260 Owner’s Manual 50410
D6500 Report Directory 74-04651-001
Conettix D6600/6100 Receiver/Gateway Program Entry Guide 4998122702
Conettix D6600/6100 Receiver/Gateway Computer Interface Manuals 4998122703
D720 Series Installation Guide 74-06918-000
D9210C Operation and Installation Guide F01U215244
D9210C Program Entry Guide F01U201526
D9412GV4/D7412GV4/D7212GV4 Installation and Operation Guide F01U201527
D9412GV4/D7412GV4/D7212GV4 Program Record Sheet F01U214958
RPS Installation Guide 4998141259
NOTICE!
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER
INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply
with the requirements in the Standard for Control Units and Accessories for Fire Alarm
Systems, UL 864, you must limit certain programming features or options to specific values.
Refer to Table 2.2, Page 10.
Product Feature/
Option
Permitted in
UL 864? (Y/N)
Possible
Settings
Settings Permitted
in UL 864
Refer to Page:
If using two phone lines:
Phone 1 through 4 Yes 24 characters Program a valid
phone number
17
Phone Supervision Yes 0 to 240 sec 10 to 200 sec 22
Alarm On Fail No Yes / No Set to No 22

8en | Introduction D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
Two Phone Lines Yes Yes / No Set to Yes when
using PSTN
communications
23
Expand Test Report Yes Yes/No Set to Yes 23
Fire Reports Yes Yes / No Set to Yes 33
R# Fire Supervisory
Missing
Required Yes/No Set to Yes 35
Test Reports Yes Yes / No Set to Yes 35
AC Fail Report Yes Yes / No Set to Yes 51
AC Restoral Report Yes Yes / No Set to Yes 51
Battery Missing
Report
Yes Yes / No Set to Yes 37
Low Battery Report Yes Yes / No Set to Yes 37
Battery Restoral
Report
Yes Yes / No Set to Yes 51
AC Fail Time Yes 1:00 to 90:00
min
Enter 1:00 50
AC Fail Display Yes 10 to 300 sec 10 to 200 sec 50
AC Tag Along Yes Yes / No Set to Yes 51
AC/Battery Buzz Yes Yes / No Set to Yes 51
Bat Fail/Restoral
Report
Yes Yes / No Set to Yes 51
R# Service Start
Report
Required Yes / No Set to Yes 39
R# Service End
Report
Required Yes / No Set to Yes 39
R# Fire Walk St
Report
Required Yes / No Set to Yes 39
R# Fire Walk End
Report
Required Yes / No Set to Yes 39
R# Walk Test St
Report
Required Yes / No Set to Yes 39
R# Walk Test End
Report
Required Yes / No Set to Yes 39
AC Fail Time Yes 1:00 to 90:00
min
Enter 1:00 50
AC Fail Display Yes 10 to 300 sec 10 to 200 sec 50
AC Tag Along Yes Yes / No Set to Yes 51
AC/Battery Buzz Yes Yes / No Set to Yes 51
Bat Fail/Restoral
Report
Yes Yes / No Set to Yes 51
Area 1 Area On Required to
send system
status reports
Yes / No Set to Yes 61
A# Delay Restoral Yes Yes / No Set to Yes 62
Verify Time Yes 10 to 60 sec 60 sec 63
Area # Fire Time Yes 1 to 90 min 5 min (check with
AHJ)
67
CC# Supervised Yes Yes / No Set to Yes 79
CC# Trouble Tone Yes Yes / No Set to Yes 85
CC# Scroll Lock Yes Yes / No Set to Yes 87
Product Feature/
Option
Permitted in
UL 864? (Y/N)
Possible
Settings
Settings Permitted
in UL 864
Refer to Page:

D9412GV4/D7412GV4/D7212GV4 Introduction | en 9
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
Remote Program Disable /
Enable
-, E, or P Set to P 100
A# Fire Bell Yes 0 to 128, A, B, C0
to 128, A, B, C
Program with a
relay
118
A# Reset Sensors Yes Program with a
relay
119
U### Area # Auth Yes 0 to 8 Program an
Authority Level for
the Fire Area
127
U### Passcode Yes 3-, 4-, 5-, or 6-
digit passcode
Must program at
least one passcode
126
P## Silent Bell No Yes / No Set to No 135
P## Invisible Point No Yes / No Set to No 136
P## Local While
Disarmed
No Yes / No Set to No 139
P## Local While
Armed
No Yes / No Set to No 139
P## Disable
Restorals
No Yes / No Set to No 140
P## Bypassable No Yes / No Set to No 141
P## Swinger Bypass No Yes / No Set to No 142
P## Fire Point Yes Yes / No Set to Yes 143
P## Resettable Yes Yes / No As required 144
Sked## Function
Code
Required 1 to 11, 13 to 28 Sked Function
Code 9
165
Sked## Defer Test No Yes / No Set to No 165
Sked## Hourly
Test(Report?)
No Yes / No Set to No 165
Sked## Time Enter valid
time
00:00 to 23:59 00:00 to 23:59 171
Sked## Date No mm/dd Set to No 171
Sked## Sunday Yes Yes / No Set to Yes 171
Sked## Monday Yes Yes / No Set to Yes 172
Sked## Tuesday Yes Yes / No Set to Yes 172
Sked## Wednesday Yes Yes / No Set to Yes 172
Sked## Thursday Yes Yes / No Set to Yes 172
Sked## Friday Yes Yes / No Set to Yes 172
Sked## Saturday Yes Yes / No Set to Yes 172
Sked## Xept On
Holiday
No Yes / No Set to No 172
For IP
Communications to
a D6600 Receiver
Enhanced Comm Yes Yes / No Set to Yes 40
Path1 IP Add1 (2, 3
or 4)
Yes 000 to 255 Program a valid IP
address
41
Path 1 Poll Rate Yes 0, 5 to 65535
sec*
Program as
necessary
41
Path 1 Ack Wait Yes 0, 5 to 65535
sec*
Program as
necessary
45
Product Feature/
Option
Permitted in
UL 864? (Y/N)
Possible
Settings
Settings Permitted
in UL 864
Refer to Page:

10 en | Introduction D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
The following programmable parameters are recommended by Bosch when installing a
commercial fire alarm system. Always check with your local Authority Having Jurisdiction.
Table 2.2 UL 864 Programming Requirements
2.3 Guide to UL 636 Programming Requirements for D9412GV4/
D7412GV4/D7212GV4 Control Panels
When using a D9412GV4/D7412GV4/D7212GV4 control panel for hold-up operation, a hold-up
point should have the following setting applied to it:
– P## Type = 0 (Point is constantly armed regardless of the status of the system.)
Path 1 Retry Count Yes 0 to 255 Program as
necessary
45
For Ground Fault
Enable Switch
(Refer to the
D9412GV4/
D7412GV4/
D7212GV4 Operation
and Installation Guide
(P/N: F01U201527)
Yes Closed = Enabled
Open = Disabled
Closed N/A
* Set the Path 1 Poll Rate to 65535 for 24 hr.
Prompt Possible Settings Recommendations
Phone Line Fail Report Yes / No Yes
Phone Line Restoral Report Yes / No Yes
Fire Walk Start Report Yes / No Yes
Fire Walk End Report Yes / No Yes
Cancel Report Yes / No Yes
CC# Scope Panel Wide, Account Wide, Area
Wide, Custom, No Keypad
Do not program No
Keypad
CC# Enhanced CommandCenter Yes / No Set to Yes, if
applicable
CC# Menu Key Lock Yes / No If using D1256RB, set
to No
Reset Sensors Disable/Enable/Passcode Protect Enable
Fire Test Disable / Enable / Passcode
Protect
Enable
L## Reset Sensors Disable / Enable If Reset Sensor is set
to Passcode Protect,
set this to Enable
L## Fire Test Disable / Enable If Fire Test is set to
Passcode Protect,
set this to Enable
U### User Group 0 to 8 Program as 0
P## Ring Until Restored Yes / No May be required for
Waterflow, otherwise
No
P## Cross Point Yes / No Set to No for Fire
devices.
D# Fire Unlock Yes / No No
Product Feature/
Option
Permitted in
UL 864? (Y/N)
Possible
Settings
Settings Permitted
in UL 864
Refer to Page:

D9412GV4/D7412GV4/D7212GV4 Introduction | en 11
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
– P## Invisible Point = Yes (Keypads do not display alarm activity from this point.)
When using Modem IIIa2 communication type, the unique point text should be set to “Hold-
Up”, or equivalent language per the AHJ.
When using ContactID communication type, because the ContactID system doesn’t provide
custom text, the hold-up point should be associated as a “hold-up” point at the receiving
station. Set Area # Delay Restorals as follows:
– Area # Delay Restorals = No (Restoral report is sent when point restores.)
2.4 Guide to Programming Descriptions
Full configuration of the control panel is only achieved through use of the Remote
Programming Software (RPS). A limited set of Tools are available via the keypad to modify
some of the more commonly changed parameters.
This guide is set up in a specific order. Related program entries are grouped together in
modules as they appear in RPS.
This guide shows the programming options for each programming prompt. Each option is
listed with:
– The Program Item Prompt. Each prompt is shown as it appears in RPS. Refer to the RPS
Installation Guide (P/N: 4998141259).
– Program Entry Default Setting. Because defaults are set for the typical installation,
programming each prompt might not be necessary. Review the default entries in the
program record sheet shipped with the control panel to determine which prompts must
be programmed.
– Program Entry Selections. Only the selections listed can be used for a particular program
item.
– Program Entry Description. Describes the various entry selections. Read the descriptions
carefully to avoid improperly programmed equipment.
2.5 Guide to Keypad Tools
GV4 now offers a series of tools for configuration and diagnostics through the use of the
keypad with the Service Passcode only. The five configuration tools are:
– Programming. For a list of program items you can set using keypad Programming, refer to
Section 2.5.1 Keypad Programming Menu, page 12. To access the Programming menu, the
Keypad Programming option must be set to P (refer to Section 3.12.5 Configuration
Authority, page 101), and all control panel areas must be disarmed.
– Service Bypass. For instructions to bypass a point using the keypad’s Service Bypass
menu, refer to Section 2.5.2 Service Bypass Menu, page 14.
– RF Points. For a list of program items you can set using the keypad’s RF Points menu,
refer to Section 2.5.3 RF Points Menu, page 14.
– RF Repeaters. For a list of program items you can set using the keypad’s RF Repeaters
menu, refer to Section 2.5.4 RF Repeaters Menu, page 15.
– RF Diagnostics. For a list of diagnostic items you can perform using the keypad’s RF
Diagnostics menu, refer to Section 2.5.5 RF Diagnostics Menu, page 15.
– IP Diagnostics. For a list of diagnostic items you can perform using the keypad’s IP
Diagnostics menu, refer to Section 8.3.1 IP Diagnostics Keypad Menu (B420), page 189.

12 en | Introduction D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
2.5.1 Keypad Programming Menu
D1255 Keypad Programming Menu
99 [ENT] [NEXT] or [PREV] TOOLS MENU [ENT] ENTER PASSCODE (Installer) [ENT]
PROGRAMMING Refer to
Page
NOTICE!
To move
through the
PROGRAMMING
menu and
submenus, press
[NEXT] or [PREV].
To open a
menu or submenu,
press [ENT].
To exit to the
previous level, press
[ESC].
To send saved
changes to the
control panel,
exit from
PROGRAMMING
mode.
PHONE NUMBERS [ENT] PHONE 1 - 4 ........................................................... 17
PHONE PARAMETERS [ENT] PHONE 1 - 4 ........................................................... 19
ENHANCED COMM [ENT] 40
COMMUNICATIONS ........................................... 40
PATH 1 - 4 .......................................................... 40
IP MODULE CONFIG [ENT] B420 MODULE (1-2)
MODULE PARAM
DHCP ENABLE 180
UPnP ENABLE 184
ADDRESS PARAM
IP ADDRESS .. 180
SUBNET
MASK ................ 181
DEFAULT
GATEWAY .......... 182
PORT
NUMBER ........... 184
DNS PARAM
SERVER
ADDRESS .......... 183
MODULE
HOSTNAME ....... 186
ENCRYPTION
AES KEY SIZE 185
AES KEY ......... 185
ROUTING [ENT] ROUTING GRP 1 - 4 ............................................... 30
RPS PARAMETERS [ENT]
RPS PASSCODE ................................................ 55
RPS PHONE NUMBER ....................................... 58
RPS IP ADDRESS .............................................. 41
RPS IP PORT ..................................................... 48
AREA PARAMETERS [ENT] AREA NUMBER 1-32 .............................................
(1 - 8 for D7412GV4)(1 - 4 for D7212GV4)
61
COMMAND CENTER [ENT] CC NUM 1 - 16 ...................................................... 80 and
81
USER PASSCODE [ENT]............................................................................................. 126
POINT PARAMETERS [ENT] PT NUM 1-247 .......................................................
(1-75 for D7412GV4)(1-40 for D7212GV4)
146
DISABLE KP PROG [ENT].......................................................................................... 101

D9412GV4/D7412GV4/D7212GV4 Introduction | en 13
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
D1260 Keypad Programming Menu
99 [ENTER] [Next] Tools Menu [ENTER] ENTER PASSCODE (Installer) [ENTER]
Programming Refer to
Page
NOTICE!
To move
through the
Programming
menu and
submenus, press
the Next softkey.
To open a
menu or submenu,
press [ENTER].
To exit to the
previous level,
press the Exit
softkey.
To send saved
changes to the
control panel,
exit from
Programming
mode.
Phone Numbers [ENTER] Phone 1-4.................................................................. 17
Phone Parameters [ENTER] Phone 1-4.................................................................. 19
Enhanced Comm [ENTER] 40
Communications.................................................... 40
Select IP Path Path 1-4............................ 40
IP Module Config [ENTER] B420 Module (1-2)
Module Parameters
DHCP Enable.. 180
UPnP Enable.. 184
Address Parameters
IP ADDRESS... 180
Subnet Mask.. 181
Default
Gateway............. 182
Port Number.. 184
DNS Parameters
Server
Address.............. 183
Module
Hostname.......... 186
Encryption
AES Key Size.. 185
AES
Encryption Key... 185
Routing [ENTER] Route Group 1-4....................................................... 30
RPS Parameters [ENTER]
RPS Passcode....................................................... 55
RPS Phone Number............................... 58
RPS IP Address..................................... 41
RPS IP Port........................................... 48
Area Parameters [ENTER] Area Number 1-32.....................................................
(1 - 8 for D7412GV4)(1 - 4 for D7212GV4)
61
Command Center [ENTER] CC Number 1-16...................................................... 80 and
81
User Passcode [ENTER].............................................................................................. 126
Point Parameters [ENTER] PT NUM 1-247..........................................................
(1-75 for D7412GV4)(1-40 for D7212GV4)
146
Disable Keypad Programming [ENT]........................................................................... 101

14 en | Introduction D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
2.5.2 Service Bypass Menu
2.5.3 RF Points Menu
D1255 Service Bypass Menu
99 [ENT] [NEXT] or [PREV] TOOLS MENU [ENT] ENTER PASSCODE (Installer) [ENT]
SERVICE BYPASS [ENT] (Refer to Page 204.)
NOTICE!
Press [NEXT] to move through the list of bypassed points (when points are bypassed).
Press [ESC] to exit to the previous level.
D1260 Service Bypass Menu
99 [ENTER] [Next] Tools Menu [ENTER] Enter Passcode (Installer) [ENTER]
Service Bypass [ENTER] (Refer to Page 204.)
NOTICE!
Press the Next softkey to move through the list of bypassed points (when points are bypassed).
Press [Exit] to exit to the previous level.
D1255 RF Points Menu
99 [ENT] [NEXT] or [PREV] TOOLS MENU [ENT] ENTER PASSCODE (Installer) [ENT]
RF POINTS [ENT] Refer to Page
ENROLL RF POINT [ENT]......................................................................... 205
REPLACE RF POINT [ENT]....................................................................... 205
REMOVE RF POINTS [ENT]...................................................................... 206
NOTICE!
Press [NEXT] or [PREV] to move through the RF POINTS menu and submenus.
Press [ENT] to open a menu or submenu.
Press [ESC] to exit to the previous level.
D1260 RF Points Menu
99 [ENTER] [Next] Tools Menu [ENTER] ENTER PASSCODE (Installer) [ENTER]
RF Points [ENTER] Refer to Page
Enroll RF Point [ENT]......................................................................... 205
Replace RF Point [ENT]....................................................................... 205
Remove RF Points [ENT]...................................................................... 206
NOTICE!
Press the Next softkey to move through the RF Points menu and submenus.
Press [ENTER] to open a menu or submenu.
Press the Exit softkey to exit to the previous level.

D9412GV4/D7412GV4/D7212GV4 Introduction | en 15
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
2.5.4 RF Repeaters Menu
2.5.5 RF Diagnostics Menu
D1255 RF Repeaters Menu
99 [ENT] [NEXT] or [PREV] TOOLS MENU [ENT] ENTER PASSCODE (Installer) [ENT]
RF REPEATERS [ENT] Refer to Page
ADD REPEATER [ENT]............................................................................. 191
REPLACE REPEATER [ENT]..................................................................... 192
REMOVE REPEATER [ENT]...................................................................... 192
NOTICE!
Press [NEXT] or [PREV] to move through the RF REPEATERS menu and submenus.
Press [ENT] to open a menu or submenu.
Press [ESC] to exit to the previous level.
D1260 RF Repeaters Menu
99 [ENTER] [Next] Tools Menu [ENTER] Enter Passcode (Installer) [ENTER]
RF Repeaters [ENTER] Refer to Page
Add Repeater [ENTER]............................................................................ 191
Replace Repeater [ENTER]..................................................................... 192
Remove Repeater [ENTER]...................................................................... 192
NOTICE!
Press Next softkey to move through the RF Repeaters menu and submenus.
Press [ENTER] to open a menu or submenu.
Press the Exit softkey to exit to the previous level.
D1255 RF Diagnostics Menu
99 [ENT] [NEXT] or [PREV] TOOLS MENU [ENT] ENTER PASSCODE (Installer) [ENT]
RF DIAGNOSTICS [ENT] Refer to Page
RF POINTS [ENT]
STATES ....................... 193
SIGNAL STRENGTH..... 193
RF REPEATER ........................................................................................
NOTICE!
Press [NEXT] or [PREV] to move through the RF DIAGNOSTICS menu and submenus.
Press [ENT] to open a menu or submenu.
Press [ESC] to exit to the previous level.
D1260 RF Diagnostics Menu
99 [ENTER] [Next] Tools Menu [ENTER] Enter Passcode (Installer) [ENTER]
RF Diagnostics [ENTER] Refer to Page
RF Points [ENTER]
States ........................ 193
Signal Strength........... 193
RF Repeater ..........................................................................................
NOTICE!
Press Next softkey to move through the RF Diagnostics menu and submenus.
Press [ENTER] to open a menu or submenu.
Press the Exit softkey to exit to the previous level.

16 en | Introduction D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
2.5.6 IP Diagnostics Menu
D1255 IP Diagnostics Menu
99 [ENTER] [Next] Tools Menu [ENTER] ENTER PASSCODE (Installer) [ENTER]
IP DIAGNOSTICS [ENT] B420 MODULE (1-2) Refer to
Page
SETTINGS [ENT]..................................................... 189
CONNECTION TEST [ENT]...................................... 189
NOTICE!
Press [NEXT] or [PREV] to move through the IP DIAGNOSTICS menu and submenus.
Press [ENT] to open a menu or submenu.
Press [ESC] to exit to the previous level.
D1260 IP Diagnostics Menu
99 [ENTER] [Next] Tools Menu [ENTER] Enter Passcode (Installer) [ENTER]
IP Diagnostics [ENT] B420 Module (1-2) Refer to
Page
Settings [ENT].......................................................... 189
Connection Test [ENT]................................................... 189
NOTICE!
Press Next softkey to move through the IP Diagnostics menu and submenus.
Press [ENTER] to open a menu or submenu.
Press the Exit softkey to exit to the previous level.

D9412GV4/D7412GV4/D7212GV4 Panel and Area Wide Parameters | en 17
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
3 Panel and Area Wide Parameters
This section has fourteen programming categories.
– Phone
– Phone Parameters
–Routing
– Enhanced Communications
– SDI Enhanced Communications
– Power Supervision
– Printer parameters
– RPS Parameters
– Miscellaneous
– Area Parameters
–Keypad
– User Interface
–FunctionList
– Relay Parameters
3.1 Phone
The control panel can dial as many as four different telephone numbers when sending event
reports. Refer to Section 3.3 Routing, page 23 for information about event report routing and
communication protocols.
Phone #
This is the telephone number the control panel dials to contact the central station receiver
when sending event reports. This number is Phone 1 referred to in the prompts in
Section 3.3 Routing, page 23.
The control panel waits for a break in the dial tone after dialing the first digit. If the control
panel must dial a digit (for example, 9) to access an outside line, place a C before the phone
number. The control panel waits 2 sec and does not wait for the dial tone break.
The control panel is programmed with a 7-sec dial tone detect period. When a dial tone is
detected or the waiting period ends, the control panel begins to dial. To extend the dial tone
detect period, place a D before the phone number. To insert a pause during or after dialing,
use C in the number sequence. For example, if the control panel hangs up before it hears the
NOTICE!
When using PSTN telephone lines, program two telephone numbers to meet UL 864
requirements (D9412GV4 and D7412GV4).
Default: Blank
Selection: Up to 24 characters
0 to 9 Numbers 0 through 9
C 3-sec pause
D 7-sec dial-tone detection
# or * Used for the same purpose as pressing this key on a telephone keypad
when manually dialing. For example, an asterisk (*) may be needed to
access your long distance service. Do not use these characters when
pulse dialing.
Blank Control panel dials no phone number.
Programming this item Blank does not disable phone routing. To
disable reporting to this phone, refer to Section 3.3 Routing, page 23.

18 en | Panel and Area Wide Parameters D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
ModemIIIa2ACK tone from the D6500 or D6600, program extra Cs after the phone number.
The control panel waits on line for two extra seconds for each C programmed.
Enter up to 24 of the characters shown in the Phone # table to define dialing characteristics.
For SIA CP-01 Compliance
Call Waiting Disable
If the telephone system at the installation site uses the Call Waiting feature, ensure that the
primary telephone reporting number is programmed to disable Call Waiting.
If you program the primary phone number with a sequence to temporarily disable Call Waiting
(typically *70 pause, but verify with the phone service provider) followed by the phone
number, you should program the backup phone number without the Call Waiting cancel
sequence. If the subscriber cancels Call Waiting without notifying their alarm installing
company, the control panel can still send reports using the backup number.
Keypad Programming of Phone #
D1255
1. Refer to Section 3.2 Phone Parameters, page 19 to access Programming and navigate to
the PHONE NUMBERS option.
2. At the PHONE 1 - 4 prompt, enter the phone number you wish to configure and press
[ENT]. The current phone number shows.
3. Press [ENT] to change the phone number.
4. The [PREV] button acts as a [Backspace] key and the [COMMAND] key scrolls through
special characters. Press [PREV] to delete the characters of the phone number, and then
enter the new phone number. Press [COMMAND] to cycle through the special dialing
characters {*, #, C, D}, then press [NEXT] to choose a character.
5. Press [ENT] to save the phone number.
When the keypad reads PARAMETER SAVED, your selection has been configured.
D1260
1. Refer to Section 3.2 Phone Parameters, page 19 to access Keypad Programming and
navigate to the Phone Numbers option and press the corresponding softkey.
2. At the Phone (1-4) prompt, enter the phone number you wish to configure and press
[ENTER]. The current phone number shows.
3. Press the Edit softkey to change the phone number.
CAUTION!
Dialing a Call Waiting sequence on a non-Call Waiting line prevents the system from dialing the
central station receiver successfully.
NOTICE!
Example: If the central station telephone number is 555-1234, and the primary Route Group
destination is Phone 1, program Phone 2 with the following sequence: *70C5551234.
NOTICE!
If the current phone number is longer than 20 characters, use the [PREV] and [NEXT] keys to
scroll to view the additional characters.
NOTICE!
If the current phone number is longer than 20 characters, the Previous and Next softkeys
appear. Use the softkeys to scroll to view the additional characters.

D9412GV4/D7412GV4/D7212GV4 Panel and Area Wide Parameters | en 19
Bosch Security Systems, Inc. Program Entry Guide F.01U.218.312 | 04 | 2012.03
4. The Pause (3-sec pause - "C") and DT Detect (Dial Tone Detect - "D") softkeys enter
special characters. The Backspace softkey allows you to erase characters. The Clear
softkey allows you to clear the entire phone number. The [COMMAND] and [ENTER] keys
allow you to enter an * or a #. Use the softkeys, the number buttons, and the
[COMMAND] and [ENTER] keys on the keypad to enter the new phone number.
5. Press the Save softkey.
When the keypad reads Parameter Saved, your selection has been configured.
3.2 Phone Parameters
The program items in this category describe panel wide characteristics for telephone dialing,
receiver format, and supervision.
Phone # Format
Central Station Receiver Format for Transmission of Reports: Modem format provides many
reporting advantages over the Contact ID format. Refer to the D6500 Report Directory (P/N:
74-04651-001) for more information about the effect of reporting formats.
Reports identify points as 001 through 247 and passcode User ID codes as 000 through 999 at
the D6500 or D6600 Receiver (unless Point/User Flag is programmed Yes; refer to
Section Point/User Flag, page 19 in this section). When reporting point events, ModemIIIa2
Communication Format also sends point text to the D6500 or D6600 as programmed in Point
Assignments.
Keypad Programming of Phone # Format
D1255
1. Refer to Section 2.5.1 Keypad Programming Menu, page 12 to access Keypad Programming
and navigate to the PHONE PARAMETERS option.
2. At the PHONE 1 - 4 prompt, enter the phone route number you wish to configure and
press [ENT].
3. Press [NEXT] or [PREV] to toggle between Contact ID and ModemIIIa2and press [ENT] to
select the desired phone format.
When the keypad reads PARAMETER SAVED, your selection has been configured.
D1265
1. Refer to Section 2.5.1 Keypad Programming Menu, page 12 to access Keypad Programming
and navigate to the Phone Parameters option and press the corresponding softkey.
2. At the Phone (1 - 4) prompt, enter the phone route number you wish to configure and
press [ENTER]. The current configuration shows.
3. Press the Edit softkey to change the phone format.
4. Select the softkey for the option you wish to change. Press the Save softkey.
When the keypad reads Parameter Saved, your selection has been configured.
Point/User Flag
Default: ModemIIIa2
Selection: ModemIIIa2or Contact ID
ModemIIIa2ModemIIIa2Communication Format
Contact ID ANSI-SIA Contact ID
Default: No
Selection: Yes or No

20 en | Panel and Area Wide Parameters D9412GV4/D7412GV4/D7212GV4
F.01U.218.312 | 04 | 2012.03 Program Entry Guide Bosch Security Systems, Inc.
This program item determines how point and User ID numbers are presented at the D6500 or
D6600 display, printer, and computer RS-232 output.
When Phone # Format is ModemIIIa2, the control panel sends expanded Bosch ModemIIIa2
Communication Format reports to the D6500 or D6600. If your central station data files are
not set up for point and User ID number reporting, you can use this program item to convert
these numbers to COMEX Reports.
When Phone # Format is ModemIIIa2, the control panel sends expanded Bosch ModemIIIa2
Communication Format Reports to the receiver. Point/User Flag affects Bosch ModemIIIa2
Communication Format data as shown in Table 3.1, Page 20. The Bosch Security Systems, Inc.
D6500 or D6600 Receiver adds the leading zero in the User ID number with Point/User Flag
programmed No.
Table 3.1 ModemIIIa2 Communication Format Data - User ID Numbers
Yes The control panel sends a flag with each report telling the D6500 or
D6600 to convert point numbers and User ID numbers to COMEX
format. Refer to Table 3.1, Page 20 and Table 3.2, Page 21 for
conversion information. When this parameter is programmed Yes,
points and User ID numbers are converted, regardless of the
programming of the D6500 or D6600 Receiver for output to the
computer system. Refer to Appendix C in the Conettix D6600/D6100
Receiver/Gateway Computer Interface Manual (P/N: 4998122703).
No The control panel does not send the flag. The D6500 or D6600 outputs
point numbers as 001 to 247 (rather than 100 to 732) and User ID
numbers as 000 to 999 (rather than 000 to F08), as indicated in
Table 3.1, Page 20 and Table 3.2, Page 21.
Point/User Flag No Point/User Flag Yes
001 to 005 001 to 005
006 to 013 601 to 608
014 to 021 701 to 708
022 to 029 801 to 808
030 to 037 B01 to B08
038 to 045 C01 to C08
046 to 053 D01 to D08
054 to 061 E01 to E08
062 to 069 F01 to F08
070 to 999 000
