Bosch Ultima 862 User manual

Solution Ultima 862
Quick Reference Guide
ISSUE 1.70

Solution Ultima 862
Quick Reference Guide
Copyright 2002 by Bosch Security Systems Pty Limited,
SYDNEY, AUSTRALIA
Document Part Number MA486Q
DOCUMENT ISSUE 1.70
Printed 23 May 2006
This documentation is provided to suit the Solution Ultima 862 control panels.
Firmware Revision 1.00 – 1.09
Hardware Revision A - J
Alarm Link required = 2.74 or higher
Control Panel Software Version 1.00 – 1.09 = S486_V10
Copyright Notice
All rights reserved. No part of this publication may be reproduced, transmitted or stored in a retrieval system in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Bosch Security Systems Pty Limited.
Trademarks
Throughout this document trademark names may have been used. Rather than put a trademark symbol in every
occurrence of a trademark name, we state that we are using the names only in an editorial fashion and to the
benefit of the trademark owner with no intention of infringement of the trademark.
Notice of Liability
While every precaution has been taken in the preparation of this document, neither Bosch Security Systems Pty
Limited nor any of its official representatives shall have any liability to any person or entity with respect to any
liability, loss or damage caused or alleged to be caused directly or indirectly by the information contained in this
book.
Bosch Security Systems Pty Limited reserves the right to make changes to features and specifications at any
time without prior notification in the interest of ongoing product development and improvement.
2 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Introduction
Thank you for choosing the Solution control panel for your installation. We are sure that you will
find this system extremely flexible, reliable and easy to use. The quick reference guide is supplied
with the system to provide users with enough basic information to wire, configure and program the
system. Due to the systems many programmable features and options, we suggest that you obtain
the complete installation manual that provides detailed information on system options and functions
and programming methods.
Programming
The programming options of the system are stored in a non-volatile EPROM. This memory will
hold all information during a total power loss and can be changed as many times as required.
In general, the entire programming sequence will consist of entering a location number and then
change the data as required.
Programming the system can be via the following methods:
• Codepad
• Hand Held Programmer
• Alarm Link Software
Programming Using A Codepad
The system needs to be disarmed (with no active alarm) to program the system. If there is an
active alarm or the system is armed, enter the code for User 1 (Default = 2580) followed by the #
key (User Code 1 is factory default as the Master Code).
To enter installer’s programming mode, enter the installer code (Default = 1234) followed by the #
key. Two beeps will be heard and both the STAY and AWAY indicators will flash simultaneously to
indicate that you have entered programming mode. The codepad indicators will display the current
data programmed in LOCATION 000 (First location of the Primary Telephone Number).
To move to another programming location, enter the location number followed by the # key. The
data in the new location will now be displayed via the codepad indicators (eg. If you entered 34#,
the system will jump you to LOCATION 034, the beginning of the Subscriber ID Number For
Receiver 1).
To move to the next location, press the # key. This will step you to the next location. The data in
the next location will now be displayed via the codepad indicators (eg. If you are currently
positioned at LOCATION 034, pressing the # key will take you to LOCATION 035).
To step back one location, press the * key (eg. If you are currently positioned at LOCATION 35,
pressing the * key will take you back to LOCATION 34).
To change data in the current location, enter the new value (0 – 15) followed by the * key. This will
store the new data into the location and leave you at the same location (eg. If you enter the value
14*, both the Zone 4 indicator and the MAINS indicator will display to represent the new data
value).
To move to the next location, press the # key. The data in the next location will now be displayed.
To exit Installer’s Programming Mode, enter 960#. Two beeps will be heard and the STAY and
AWAY indicators will no longer display. The system has now returned to the disarmed state and is
now ready for use.
The table below is a quick guide to programming:
Enter Installer’s Programming Mode 1234#
Exit Installer’s Programming Mode 960#
Step To Next Location #
Step Back One Location *
Program New Data Into Location Data + * (Data = 0 – 15)
Jump To Another Location Location No. + #
Solution Ultima 862 Quick Reference Guide 3
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Codepad Indicators
Data
Value Zone 1 Indicator Zone 2 Indicator Zone 3 Indicator Zone 4 Indicator Zone 5 Indicator Zone 6 Indicator Zone 7 Indicator Zone 8 Indicator MAINS Indicator
0
1X
2 X
3 X
4 X
5 X
6 X
7 X
8 X
9X X
10 X
11X X
12 X X
13 X X
14 X X
15 X X
Programming Option Bits
You will notice option bits throughout the quick reference guide. This allows you to program any
combination of the four different options in the one location by adding the options together.
Programming a zero (0) will disable all four options.
Example If at LOCATION 177 you only want options 1, 2 and 4, add the numbers together and the total is
the number to be programmed. In this example, the number to be programmed is 7 (eg. 1 + 2 + 4
= 7).
Option Description
1 Dialler Reporting Functions Allowed
2 Remote Arming Via Telephone Allowed
4 Answering Machine Bypass Only When Armed
8 Use Bell 103 For FSK Format (Disabled = CCITT V21)
Installer’s Programming Commands
These commands can only be used when you enter Installer’s Programming Mode. Enter the
command followed by the # key.
Command Description
958 Enable/Disable Zone Status (Hand Held Programmer Required)
959 Test Programming Key
960 Exit Installer’s Programming Mode
961 Default System Back To Factory Settings
962 Copy Panel Memory To Programming Key
963 Copy Programming Key To Panel Memory
964 Erase Programming Key
965 Default System For Domestic Dialling Format
966 Enable/Disable Automatic Stepping Of Locations When Programming
999 Display Software Version (Hand Held Programmer Required)
4 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Arming The System (On)
AWAY Mode
1. Press and hold the # key until two beeps are
heard.
Or
2. Enter your code followed by the # key.
[eg. 2580 + #].
STAY Mode 1
1. Press and hold the * key until two beeps are
heard.
Or
2. Enter your code followed by the * key.
[eg. 2580 + *].
STAY Mode 2
1. Press and hold the 0 key until two beeps are
heard.
Disarming The System (Off)
AWAY Mode
1. Enter your code followed by the # key.
[eg. 2580 + #].
STAY Mode 1
1. Press and hold the * key until two beeps are
heard (Only if no alarm).
Or
2. Enter your code followed by the # key.
[eg. 2580 + #].
STAY Mode 2
1. Press and hold the 0 key until two beeps are
heard (Only if no alarm).
Or
2. Enter your code followed by the # key.
[eg. 2580 + #].
Isolating Zones
Standard Isolating
1. Press the * key twice.
2. Enter the zone number that you want to
isolate followed by the * key.
Repeat step 2 if more than one zone is
required to be isolated.
3. Press the # key to exit when finished.
Code To Isolate
1. Press the * key once.
2. Enter your user code, followed by the * key .
3. Enter the zone number that you want to
isolate followed by the * key.
Repeat step 2 if more than one zone is
required to be isolated.
4. Press the # key to exit when finished.
Add/Delete RF Devices (Wireless Zones)
Add RF Device
1. Enter the Installer Code followed by 0 and the
# key [eg. 1234 + 0 + #].
2. Enter the Device Number (1 – 16) that you
want to add followed by the # key.
3. Enter the 9-digit RF device ID number
followed by the # key.
Delete RF Device
1. Enter the Installer Code followed by 0 and the
# key [eg. 1234 + 0 + #].
2. Enter the Device Number (1 – 16) that you
want to delete followed by the # key.
3. Press the * key to delete the RF device.
Solution Ultima 862 Quick Reference Guide 5
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Set First Test Report
1. Enter the Installer Code followed by 1 and the
key [eg. 1234 + 1 + #].
2. Enter the Number Of Days (0 – 15) to wait
until first test report followed by the # key.
Event Memory Recall
1. Enter the Installer Code or Master Code
followed by 8 and the # key.
[eg. 1234 + 8 + #].
The last 40 events (non partitioned) or last 10 events
(partitioned) will be displayed in reverse order (i.e.
most recent to least recent).
Walk Test Mode
1. Enter the Installer Code or Master Code
followed by 7 and the # key.
[eg. 1234 + 7 + #].
2. Test each zone as required.
3. Press the # key to exit.
Satellite Siren Service Mode
1. Enter the Installer Code followed by 5 and the
# key [eg. 1234 + 5 + #].
Telephone Monitor Mode (Toggle On/Off)
1. Enter the Installer Code followed by 6 and the
# key [eg. 1234 + 6 + #].
2. Press and hold the 9 key until two beeps are
heard to send a test report.
Zone LED Dialling Event
1 Telephone Line Seized
2 Dialling Telephone Number
3 Handshake Received
4 Data Being Sent
5 Kiss-Off Received
None Released Telephone Line
Add A User Code
1. Enter the Master Code followed by 1 and the
# key [eg. 2580 + 1 + #].
2. Enter the User Number (1 – 8) that you want
to add / change followed by the # key.
3. Enter the New Code followed by the # key.
Add RF Keyfob
1. Enter the Master Code followed by 1 and the
# key [eg. 2580 + 1 + #].
2. Enter the User Number (9 – 16) that you want
to add followed by the # key.
3. Enter the 9-digit RF keyfob ID number
followed by the # key.
Delete A User Code / RF Keyfob
1. Enter the Master Code followed by 1 and the
# key [eg. 2580 + 1 + #].
2. Enter the User Number (1 – 16) that you want
to delete followed by the # key.
3. Press the * key to delete the user code.
Change Domestic Telephone Numbers
1. Enter the Installer Code or Master Code
followed by 2 and the # key.
[eg. 1234 + 2 + #].
2. Enter the digits for the telephone number.
3. If more than one telephone number, press the
* key followed by the 4 key (inserts break
between phone numbers) and repeat Step 2,
else press the # key to exit.
Turn Outputs On/Off
1. Enter the Master Code followed by 5 and the
# key [eg. 2580 + 5 + #].
2. Enter the Output Number (1 – 3) that you
want to toggle on or off.
3. Press the # key to toggle On or the * key to
toggle Off.
4. Press the # key to exit.
Setting Date and Time
1. Enter the Master Code followed by 6 and the
# key [eg. 2580 + 6 + #].
2. Enter the day (DD), month (MM) and year
(YY) followed by the hour (HH) and minute
(MM).
3. Press the # key to exit.
Day Alarm – Toggle On/Off
1. Press and hold the 4 key until two beeps are
heard. Day alarm will toggle on or off.
6 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

STAY Mode 2 Zones - Program
1. Enter the Installer Code or Master Code
followed by 4 and the # key.
[eg. 1234 + 4 + #].
2. Enter the Zone Number that you want the
system to automatically isolate followed by the
* key.
Repeat if more than one zone to be
automatically isolated when armed in STAY
Mode 2.
3. Press the # key to exit.
Fault Analysis
1. Press and hold the 5 key until two beeps are
heard.
2. Zone Indicators will display FAULT condition
(see table below).
3. Press # key to exit.
Zone
LED FAULT Condition
Press and Hold Button 1
To Determine Fault
1 System Fault
1 = Battery Fail
2 = Date/Time
3 = RF Rx Jamming
RF Rx Tamper
RF Rx Comm’s Fail
4 = Horn Speaker Fail
5 = Telephone Line Fail
6 = E2 Fail
7 = Fuse Fail
8 = AC Fail
Press and Hold Button 2
To Determine Fault
2 RF Low Battery Displays Zones (1 – 8) that
registers RF Low Battery
Press and Hold Button 3
To Determine Fault
3 Zone Tamper Displays Zones (1 – 8) that
registers Zone Tamper
Press and Hold Button 4
To Determine Fault
4 Sensor Watch Displays Zones (1 – 8) that
registers Zone Tamper
Press and Hold Button 5
To Determine Fault
5 RF Sensor Watch Displays Zones (1 – 8) that
registers Zone Tamper
Press and Hold Button 6
To Determine Fault
6 Communication Fail 1 = Receiver 1 Fail (Dialler)
2 = Receiver 2 Fail (Dialler)
Modem Call (Alarm Link)
1. Press and hold the 6 key until two beeps are
heard.
Latching Outputs (Reset)
1. Press and hold the 7 key until two beeps are
heard.
Codepad Buzzer Tone
1. Press and hold the 8 key until the desired
buzzer tone has been reached.
2. Press the # key to exit.
Test Report
1. Press and hold the 9 key until two beeps are
heard.
Speaker Test
1. Press and hold the 1 key until two beeps are
heard. The speaker will sound for two
seconds.
Bell Test
1. Press and hold the 2 key until two beeps are
heard. The piezo will sound for two seconds.
Strobe Test (Toggle On/Off)
1. Press and hold the 3 key until three beeps are
heard to turn the strobe on.
2. Press and hold the 3 key until two beeps are
heard to turn the strobe off.
Telco Arm Sequence (Call Forward On)
1. Enter your Installer Code or Master Code
followed by 3 and the # key.
[eg. 1234 + 3 + #].
2. Press 1 followed by the # key.
3. Enter the Call Forward On sequence.
4. Press the # key to exit.
Telco Disarm Sequence (Call Forward On)
1. Enter your Installer Code or Master Code
followed by 3 and the # key.
[eg. 1234 + 3 + #].
2. Press 2 followed by the # key.
3. Enter the Call Forward Off sequence.
4. Press the # key to exit.
Solution Ultima 862 Quick Reference Guide 7
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Location 000 – 015
Phone Number 1 - Receiver 1
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 016 – 031
Phone Number 2 – Receiver 1
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 032
Handshake Tone
For Receiver 1
Location 033
Transmission Format
For Receiver 1
Location 034 - 039
Subscriber ID Number For Receiver 1
(right justified)
Location 040 – 055
Phone Number 1 - Receiver 2
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 056 – 071
Phone Number 2 - Receiver 2
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 072
Handshake Tone
For Receiver 2
Location 073
Transmission Format
For Receiver 2
Location 074 - 079
Subscriber ID Number For Receiver 2
(right justified)
Location 80
Dialling Format
Location 081 – 112
Reserved
Location 113 – 142
Telco Arming Sequence (Call Forward On)
Location 143 – 158
Telco Disarm Sequence (Call Forward Off)
Location 159 – 174
Call Back Telephone Number
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 175
Ring Count
Location 176
Telephone Line Fail Options
0000000000000000
0000000000000000
1 = HI-LO Handshake (Contact ID) 4 = No Handshake
2 = 1400 Hz (Ademco TX @ 1900 Hz) 5 = Pager
3 = 2300 Hz (Sescoa TX @ 1800 Hz) 1
1 = Contact ID 4 = Domestic 7 = Reserved
2 = 4 + 2 Expressed 5 = Basic Pager 8 = 4+2 Pulsed
3 = FSK 300 Baud 6 = Reserved 1
0 0 0 0 0 0
0000000000000000
0000000000000000
1 = HI-LO Handshake (Contact ID) 4 = No Handshake
2 = 1400 Hz (Ademco TX @ 1900 Hz) 5 = Pager
3 = 2300 Hz (Sescoa TX @ 1800 Hz) 1
1 = Contact ID 4 = Domestic 7 = Reserved
2 = 4 + 2 Expressed 5 = Basic Pager 8 = 4+2 Pulsed
3 = FSK 300 Baud 6 = Reserved 1
0 0 0 0 0 0
1 = Australian DTMF 4 = International DTMF
2 = Australian Decadic 5 = Reversed Decadic
3 = Alternate DTMF & Decadic (Aust) 6 = Alternate DTMF & Reversed Decadic 1
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0000000000000000
0000000000000000
0 = Panel Will Not Answer 14 = Answering Machine Bypass 2
1 – 13 = No Of Rings Until Panel Answers 15 = Answering Machine Bypass 1 8
0
1 = Display FAULT Indicator When Telephone Line Fails
2 = Sound Alarm When System Is Armed
4 = Sound Alarm When System Is Disarmed
Note: Option 2 & 4 Must Be Used In Conjunction With Option 1
(Eg. Program a 1, 3, 5 or 7)
8 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Location 177
Dialler Options 1
Location 178
Dialler Options 2
Location 179
Dialler Options 3
Location 179
Dialler Options 3 (V1.04+)
Location 180
Alarm Link Options
Location 181 - 184
Installer Code
Location 185 - 264
User Codes
Location 185 - 188 189 Location 190 - 193 194 Location 195 - 198 199
User #01 2 5 8 0 10 User #02 15 15 15 15 2User #03 15 15 15 15 2
Authority
Level Authority Level Authority Level
Location 200 - 203 204 Location 205 - 208 209 Location 210 - 213 214
User #04 15 15 15 15 2 User #05 15 15 15 15 2User #06 15 15 15 15 2
Authority
Level Authority Level Authority Level
Location 215 - 218 219 Location 220 - 223 224 Location 225 - 228 229
User #07 15 15 15 15 2 User #08 0151515 3RF User #09 15 15 15 15 2
Authority
Level Authority Level Authority Level
Location 230 - 233 234 Location 235 - 238 239 Location 240 - 243 244
RF User #10 15 15 15 15 2 RF User #11 15 15 15 15 2RF User #12 15 15 15 15 2
Authority
Level Authority Level Authority Level
Location 245 - 248 249 Location 250 - 253 254 Location 255 - 258 259
RF User #13 15 15 15 15 2 RF User #14 15 15 15 15 2RF User #15 15 15 15 15 2
Authority
Level Authority Level Authority Level
Location 260 - 263 264
RF User #16 15 15 15 15 2
Authority
Level
Authority
Level Description
0 Arm/Disarm
1 Arm Only
2 Arm/Disarm + Open/Close Reports
3 Arm Only + Close Reports
4 Arm/Disarm + Code Required To Isolate
6 Arm/Disarm + Open/Close Reports + Code Required To Isolate
8 Master Code + Arm/Disarm
10 Master Code + Arm/Disarm + Open/Close Reports
12 Master Code + Arm/Disarm + Code Required To Isolate
14 Master Code + Arm/Disarm + Code Required To Isolate + Open/Close Reports
9
1 = Dialler Reporting Functions Allowed
2 = Remote Arming Via Telephone Allowed
4 = Answering Machine Bypass Only When Armed
8 = Use Bell 103 For FSK Format (Disabled = CCITT V21)
0
1 = Open/Close Reports Only If Previous Alarm
2 = Open/Close Reports For STAY Mode 1 and STAY Mode 2
4 = Delay Siren Until Transmission Complete
8 = Extend Handshake Wait Time From 30 To 55 Seconds
0
1 = Set DTMF Dialling Pulses To 1 Digit/Second
2 = Lockout Telephone Line Fail Alarm (V1.03+)
4 = Change Decadic Dialling To 60/40
8 = Reserved
2
1 = Set DTMF Dialling Pulses To 1 Digit/Second
2 = Lockout Telephone Line Fail Alarm (V1.03+)
4 = Change Decadic Dialling To 60/40
8 = External Modem Module (CC811) Required For FSK (V1.09+)
3
1 = Upload/Download Allowed
2 = Call Back Phone Number Required For Upload/Download
4 = Exit Upload/Download Connection On Alarm
8 = External Modem Module (CC811) Required For Alarm Link
1234
Solution Ultima 862 Quick Reference Guide 9
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Location 265
Day Alarm Zones
Location 266
EOL Resistor Value
Location 267 - 322
Zone Defaults
Location 267 268 269 270 271 272 273
Zone #01 2 0 0 1 14 1 1
(Default=Delay-1) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 274 275 276 277 278 279 280
Zone #02 1 0 0 1 14 1 1
(Default = Handover) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 281 282 283 284 285 286 287
Zone #03 1 0 0 1 14 1 1
(Default = Handover) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 288 289 290 291 292 293 294
Zone #04 1 0 0 1 14 1 1
(Default = Handover) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 295 296 297 298 299 300 301
Zone #05 0 0 0 1 14 1 1
(Default = Instant) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 302 303 304 305 306 307 308
Zone #06 0 0 0 1 14 1 1
(Default = Instant) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 309 310 311 312 313 314 315
Zone #07 13 0 0 1 12 1 1
(Default = 24 Hr Fire) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
Location 316 317 318 319 320 321 322
Zone #08 9 0 0 1 12 1 1
(Default = 24 Hr Tamper) Zone
Type Zone Pulse Count Zone Pulse Count Time Zone Options 1 Zone Options 2 Report Code Dialler Options
1 = Zone 1 4 = Zone 3
2 = Zone 2 8 = Zone 4 0
0 = No EOL 6 = 4K7 12 = Reserved
1 = 1K 7 = 5K6 13 = Reserved
2 = 1K5 8 = 6K8 14 = Split EOL (3K3/6K8 With Tamper (1K)
3 = 2K2 9 = 10K 15 = Split EOL (3K3/6K8)
4 = 3K3 10 = 12K
5 = 3K9 11 = 22K 15
10 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Zone Types
Zone Type Description Zone Type Description
0 Instant 8 24 Hr Hold-Up
1 Handover 9 24 Hr Tamper
2 Delay-1 10 Reserved
3 Delay-2 11 Keyswitch
4 Reserved 12 24 Hr Burglary
5 Reserved 13 24 Hr Fire
6 24 Hr Medical 14 Chime
7 24 Hr Panic 15 Not Used
Zone Pulse Count
The pulse count allows you to program how many pulses (0 – 15) need to be registered within the pulse count
time to activate an alarm.
Zone Pulse Count Time
Option 20ms Loop Response Time Option 150 ms Loop Response Time
0 0.5 Seconds 8 20 Seconds
1 1 Second 9 30 Seconds
2 2 Seconds 10 40 Seconds
3 3 Seconds 11 50 Seconds
4 4 Seconds 12 60 Seconds
5 5 Seconds 13 90 Seconds
6 10 Seconds 14 120 Seconds
7 15 Seconds 15 200 Seconds
Zone Options 1 Zone Options 2
Option Description
Option Group
1 Lockout Siren/Dialler 1 Isolated In STAY Mode 1
2 Delay Alarm Report 2 Zone Isolation Allowed
4 Silent Alarm 4 Forced Arming Allowed
8 Sensor Watch 8 Zone Restore Report Allowed
Zone Dialler Options
Option Group
0 No Zone Reports Allowed
1 Report To Receiver 1
2 Report To Receiver 2
4 Report To Both Receiver 1 & Receiver 2
8 Report To Receiver 2 Only If Receiver 1 Fails
Keyswitch Zone Options
The keyswitch zone options replace Zone Options 1 only for the zones that have been programmed to operate
as a keyswitch zone. Option Description
0 Latching Arm and Disarm In AWAY Mode
1 Latching Arm In AWAY Mode
2 Latching Disarm From AWAY Mode Or STAY Mode
4 Latching Arm and Disarm In STAY Mode
5 Latching Arm In STAY Mode
6 Latching Disarm From STAY Mode
8 Momentary Arm and Disarm In AWAY Mode
9 Momentary Arm In AWAY Mode
10 Momentary Disarm From AWAY Mode Or STAY Mode
12 Momentary Arm and Disarm In STAY Mode
13 Momentary Arm In STAY Mode
14 Momentary Disarm From STAY Mode
Solution Ultima 862 Quick Reference Guide 11
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Location 323
Swinger Shutdown Count For Siren
Location 324
Swinger Shutdown Count For Dialler
Location 325 - 326
Zone Status – Zone Tamper Report
Location 327 - 328
Zone Status – Walk Test Report
Location 329 - 330
Zone Status - Bypass Report
Location 331 - 332
Zone Status - Trouble Report
Location 333 - 334
Zone Status - Sensor Watch Report
Location 335
Zone Status - Alarm Restore Code
Location 336
Zone Status Reporting Options
Location 337
RF Supervision Time
Location 338 - 339
RF Low Battery Report
Location 340 - 341
RF Receiver Trouble Report
Location 342 - 343
RF Receiver Trouble Restore Report
Location 344
RF Dialler Options
Location 345 - 346
Open/Close Reports
Location 347
Open/Close Reporting Options
3
0 = Unlimited / 1 - 15 = Number Of Times Siren Operate Till Lockout
6
0 = Unlimited / 1 - 15 = Number Of Times Dialler Operate Till Lockout
Location 325 = Zone Tamper Report
Location 326 = Zone Tamper Restore Report 0 0
Location 327 = Walk Test Start Report
Location 328 = Walk Test End Report 0 0
9 8
Location 329 = Zone Bypass Report
Location 330 = Zone Bypass Restore Report
Location 331 = Zone Trouble Report
Location 332 = Zone Trouble Restore Report 2 3
4 5
Location 333 = Sensor Watch Report
Location 334 = Sensor Watch Restore Report
14
1
0 = No Zone Status Reports Allowed
1 = Report To Receiver 1
2 = Report To Receiver 2
4 = Report To Both Receiver 1 & Receiver 2
8 = Report To Receiver 2 Only If Receiver 1 Fails
0
Location 337 = Increments Of 6 Hours (0 - 90 Hours)
68
Location 338 = RF Low Battery Report
Location 339 = RF Low Battery Restore Report
79
Location 340 = RF Receiver Trouble Report (Tens Digit)
Location 341 = RF Receiver Trouble Report (Units Digit)
711
Location 342 = RF Receiver Trouble Restore Report (Tens Digit)
Location 343 = RF Receiver Trouble Restore Report (Units Digit)
1
0 = No Zone Status Reports Allowed
1 = Report To Receiver 1
2 = Report To Receiver 2
4 = Report To Both Receiver 1 & Receiver 2
8 = Report To Receiver 2 Only If Receiver 1 Fails
Location 345 = Open Report
Location 346 = Close Report 11 12
1
0 = No Open/Close Reports Allowed
1 = Report To Receiver 1
2 = Report To Receiver 2
4 = Report To Both Receiver 1 & Receiver 2
8 = Report To Receiver 2 Only If Receiver 1 Fails
12 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Location 348
Codepad Duress Report
Location 349 - 350
Codepad Panic Report
Location 351 - 352
Codepad Fire Report
Location 353 - 354
Codepad Medical Report
Location 355
Codepad Reporting Options
Location 356 - 357
System Status - Fuse Fail Report
Location 358 - 359
System Status - Fuse Fail Restore Report
Location 360 - 361
System Status - AC Fail Report
Location 362 - 363
System Status - AC Fail Restore Report
Location 364 - 365
System Status - Low Battery Report
Location 366 - 367
System Status - Low Battery
Restore Report
Location 368 - 370
System Status - Access Denied (Code Retry)
Location 371
System Status Reporting Options
Location 372 - 378
Test Report Time (Automatic)
Location 379
Test Reporting Dialler Options
6
715
Location 349 = Tens Digit
Location 350 = Units Digit
714
Location 351 = Tens Digit
Location 352 = Units Digit
713
Location 353 = Tens Digit
Location 354 = Units Digit
1
0 = No Codepad Alarm Reports Allowed
1 = Report To Receiver 1
2 = Report To Receiver 2
4 = Report To Both Receiver 1 & Receiver 2
8 = Report To Receiver 2 Only If Receiver 1 Fails
10 3
Location 356 = Tens Digit
Location 357 = Units Digit
10 8
Location 358 = Tens Digit
Location 359 = Units Digit
10 2
Location 360 = Tens Digit
Location 361 = Units Digit
10 7
Location 362 = Tens Digit
Location 363 = Units Digit
10 1
Location 364 = Tens Digit
Location 365 = Units Digit
10 6
Location 366 = Tens Digit
Location 367 = Units Digit
368 369 370
6712
Location 368 = Code Retry Limit (0 = Unlimited)
Location 369 = Tens Digit
Location 370 = Units Digit
1
0 = No Codepad Alarm Reports Allowed
1 = Report To Receiver 1
2 = Report To Receiver 2
4 = Report To Both Receiver 1 & Receiver 2
8 = Report To Receiver 2 Only If Receiver 1 Fails
Location 372 = Hour Of Day (Tens Digit)
Location 373 = Hour Of Day (Units Digit)
Location 374 = Minute Of Day (Tens Digit)
Location 375 = Minute Of Day (Units Digit)
Location 376 = Test Report (Tens Digit)
Location 377 = Test Report (Units Digit)
Location 378 = Repeat Interval In Days
372 373 374 375 376 377 378
0000 71 0
H H M M Tens/Units
Report Code Interval
1
0 = No Codepad Alarm Reports Allowed
1 = Report To Receiver 1
2 = Report To Receiver 2
4 = Report To Both Receiver 1 & Receiver 2
8 = Report To Receiver 2 Only If Receiver 1 Fails
Solution Ultima 862 Quick Reference Guide 13
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Location 368 - 397
Outputs
Location 380 381 382 383 384 385 Location 386 387 388 389 390 391
Output 1 1 14 0 0 0 0 Output 2 27 10 2 15
Default = Horn
Speaker Event
Code Polarity Time Base Time Base Multiplier Default = Fire Alarm
With Verification Event
Code Polarity Time Base Time Base Multiplier
Location 392 393 394 395 396 397 Location 398 399 400 401 402 403
Strobe Output 2 0 6 4 0 8 Relay Output 115 1 0 0 0
Default = Strobe
(Reset After 8 Hrs) Event
Code Polarity Time Base Time Base Multiplier Default = Sirens
Running Event
Code Polarity Time Base Time Base Multiplier
Location 404 405 406 407 408 409
Codepad
Buzzer 0 13 2 1 0 1
Default = Entry/Exit
Warning + Day
Alarm
Event
Code Polarity Time Base Time Base Multiplier
Event Codes
Event
Code Description Event
Code Description
0 0 BOSCHSAT – Satellite Siren (Output 1 Only) 3 1 Dialler Disabled
0 1 System Armed 3 2 Dialler Active (On-Line)
0 2 System Disarmed 3 3 Ring Detect
0 3 Armed In STAY Mode 3 4 Codepad Panic (Multibreak) V1.05+
0 4 Armed In AWAY 3 5 Mimic Zone 1
0 5 Pre-Arming Alert 3 6 Mimic Zone 2
0 6 Exit Warning (All Zones Sealed) + Entry Warning 3 7 Mimic Zone 3
0 7 Exit Warning 3 8 Mimic Zone 4
0 8 Exit Warning Finished 3 9 Mimic Zone 5
0 9 Kiss-Off After End Of Exit Time 3 10 Mimic Zone 6
0 10 Reserved 3 11 Mimic Zone 7
0 11 Entry Warning 3 12 Mimic Zone 8
0 12 Entry Warning + Day Alarm Resetting 3 13 Reserved
0 13 Exit Warning + Entry Warning + Day Alarm Resetting 3 14 Reserved
0 14 Day Alarm Resetting 3 15 Reserved
0 15 Day Alarm Latching 4 0 Reserved
1 0 Day Alarm Enabled 4 1 Reserved
1 1 Telephone Line Fail 4 2 Reserved
1 2 Kiss-Off Received 4 3 Reserved
1 3 Fuse Fail 4 4 Reserved
1 4 AC Fail 4 5 Chime
1 5 Low Battery 4 6 Zone Not Sealed
1 6 Horn Speaker Fail 4 7 Zone Not Sealed After Exit Time
1 7 Sensor Watch Alarm 4 8 Reserved
1 8 Codepad Medical Alarm 4 9 AC Mains Cycle (60 Hz Or 50 Hz)
1 9 Codepad Fire Alarm 4 10 Area 1 - Zone Unsealed (Solution 880 Only)
1 10 Codepad Panic Alarm 4 11 Area 2 – Zone Unsealed (Solution 880 Only)
1 11 Codepad Duress Alarm 4 12 Reserved
1 12 Access Denied (Code Retries) 4 13 Reserved
1 13 Reserved 4 14 Reserved
1 14 Horn Speaker (Output 1 Only) 4 15 Reserved
1 15 Sirens Running 5 0 Reserved
2 0 Strobe 5 1 Reserved
2 1 Silent Alarm 5 2 Area 1 In Alarm (Solution 880 Only)
2 2 Alarm In STAY Mode 5 3 Area 2 In Alarm (Solution 880 Only)
2 3 Alarm In AWAY Mode 5 4 Reserved
2 4 System Fault 5 5 Reserved
2 5 Fire Alarm (Resetting) 5 6 Area 1 Armed (Solution 880 Only)
2 6 Fire Alarm (Latching) 5 7 Area 2 Armed (Solution 880 Only)
2 7 Fire Alarm (Verification) 5 8 Reserved
2 8 Remote Control 1 5 9 Reserved
2 9 Remote Control 2 5 10 Area 1 Disarmed (Solution 880 Only)
2 10 Remote Control 3 5 11 Area 2 Disarmed (Solution 880 Only)
2 11 Radio Control Output 1 5 12 Reserved
2 12 Radio Control Output 2 5 13 Reserved
2 13 Radio Control Output 1 - Not In AWAY Mode 5 14 Any Areas Armed (Solution 880 Only)
2 14 Radio Control Output 2 - Not In AWAY Mode 5 15 Any Areas Disarmed (Solution 880 Only)
2 15 Communications Fail After 3 Attempts 6 0 Area 1 Codepad Data Terminal (Solution 880 Only)
3 0 Communications Fail 6 1 Area 2 Codepad Data Terminal (Solution 880 Only)
14 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Time Base
Choose one of the options in the table below for the time base.
Option Description
1200 ms
21 Second
31 Minute
41 Hour
Time Base Multiplier
Enter a value between 01 – 99.
One Shot Mode
When you program the output polarity as a one shot, the time base is multiplied by the time base multiplier (eg.
If the time base = 2 and the multiplier = 05, the output will operate for 5 seconds)
Pulsing Mode
When you program the output polarity as pulsing, the time base becomes the ‘ON’ time and the multiplier
becomes the ‘OFF’ time. The ‘OFF’ time is the time base x the multiplier (eg. If you want the output to pulse
one (1) second ‘ON’ and five (5) seconds ‘OFF’, you would program time base as one (1) and the multiplier as
five (5)).
Solution Ultima 862 Quick Reference Guide 15
SOL ULTIMA 862 QUICK REF GUIDE
Polarity (Modes)
Option Description Option Description
0Disabled
1Normally Open, Going Low 8Normally Low, Going Open
2Normally Open, Pulsing Low 9Normally Low, Pulsing Open
3Normally Open, One Shot Low 10 Normally Low, One Shot Open
4Normally Open, One Shot Low (Reset) 11 Normally Low, One Shot Open (Reset)
5Normally Open, One Shot Low (Re-trigger) 12 Normally Low, One Shot Open (Re-trigger)
6Normally Open, One Shot Low (Alarm) 13 Normally Low, One Shot Open (Alarm)
7Normally Open, Latching Low 14 Normally Low, Latching Open

Location 410 - 411
Entry Time 1
Location 412 - 413
Entry Time 2
Location 414 - 415
Exit Time (AWAY/STAY Modes)
Location 416 - 417
Entry Guard Time For STAY Mode
Location 418 - 419
Delay Alarm Report Time
Location 420 - 421
Sensor Watch Time
Location 422
Codepad Lockout Time
Location 423
Siren Run Time
Location 424
Siren Sound Rate
Location 425
Auto Arming Pre-Alert Time
Location 426 - 429
Auto Arming Time
Location 430 - 433
Auto Disarming Time
Location 434
Kiss-Off Wait Time
Location 435
Speaker Beep Volume
Location 436
System Options 1
Location 437
System Options 2
4 1
Location 410 = Increments Of 1 Second (0 – 15 Seconds)
Location 411 = Increments Of 16 Seconds (0 – 240 Seconds)
Location 412 = Increments Of 1 Second (0 – 15 Seconds)
Location 413 = Increments Of 16 Seconds (0 – 240 Seconds) 8 2
12 3
Location 414 = Increments Of 1 Second (0 – 15 Seconds)
Location 415 = Increments Of 16 Seconds (0 – 240 Seconds)
Location 416 = Increments Of 1 Second (0 – 15 Seconds)
Location 417 = Increments Of 16 Seconds (0 – 240 Seconds) 0 0
Location 418 = Increments Of 1 Second (0 – 15 Seconds)
Location 419 = Increments Of 16 Seconds (0 – 240 Seconds) 0 0
Location 420 = Increments Of Days (Tens Digit)
Location 421 = Increments Of Days (Units Digit) 0 0
0Location 422 = Increments Of 10 Seconds (0 – 150 Seconds)
5
Location 423 = Increments Of 1 Minute (0 - 15 Minutes)
7
Location 424 = (0 = Slowest Frequency / 15 = Fastest Frequency)
1
Location 425 = Increments of 5 Minutes (0 – 75 Minutes)
Location 426 = Hour Of The Day (Tens Digit)
Location 427 = Hour Of The Day (Units Digit)
Location 428 = Minute Of The Day (Tens Digit)
Location 429 = Minute Of The Day (Units Digit)
426 427 428 429
0 0 : 0 0
H H M M
Location 430 = Hour Of The Day (Tens Digit)
Location 431 = Hour Of The Day (Units Digit)
Location 432 = Minute Of The Day (Tens Digit)
Location 433 = Minute Of The Day (Units Digit)
430 431 432 433
0 0 : 0 0
H H M M
3
Location 434 = Increments Of 500 ms (500 ms - 8 Seconds)
13
Location 435 = (0 = No Beeps / 15 = Loudest Beeps)
1
1 = BOSCH Smart Lockout Allowed
2 = Horn Speaker Monitor
4 = Strobe Indication For Radio Arm/Disarm
8 = Assign Button 4 On Transmitter To Operate STAY Mode 1
0
1 = Codepad Panic To Be Silent
2 = Codepad Fire To Be Silent
4 = Codepad Medical To Be Silent
8 = Access Denied (Code Retries) To Be Silent
16 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Location 438
System Options 3
Location 439
System Options 4
Location 440
Consumer Options 1
Location 441
Consumer Options 2
Location 442
Consumer Options 3
Location 443
Radio Input Options
Location 478 - 525
Domestic Telephone Numbers
Location 526
Reserved
Location 527
RF Options
Location 528 - 535
RF Device Mapping
For Devices 1 – 8
Location 536 - 543
RF Device Mapping
For Devices 9 – 16
Location 748 - 749
Ring Burst Time (V1.07+)
8
1 = AC Fail After 1 Hour (Disabled = After 2 Minutes)
2 = Ignore AC Fail
4 = Pulse Count Handover Allowed
8 = Handover Delay To Be Sequential
0
1 = Panel To Power Up Disarmed (If Power Reset)
2 = Arm/Disarm Tracking On Power Up
4 = Internal Crystal To Keep Time
8 = Radio Keyswitch Interface, Night Arm Station Or RE005 Installed
0
1 = Test Reports Only When Armed
2 = Test Report After Siren Reset
4 = Auto Arm In STAY Mode 1
8 = STAY Indicator To Display Day Alarm Status
2
1 = Codepad Display Extinguish After 60 Seconds
2 = Single Button Arming Allowed (AWAY/STAY Mode 1 & 2)
4 = Single Button Disarming Allowed (STAY Mode 1 & 2)
8 = Alarm Memory Reset On Disarm
1 = Codepad Fault Beeps Allowed
2 = Use Digit 3 For Codepad Duress Alarm (Instead Of Digit 9)
4 = Alarms Activate Sirens and Strobe Outputs In STAY Mode 1 & 2
8 = Zone Tamper Alarms To Be Silent 5
0
1 = DS 304Mhz RF Receiver (RF3212)
2 = Latching Keyswitch Input
3 = Momentary Keyswitch Input
4 = Reserved
0
0
1 = Sound Siren On RF Receiver Fail
2 = Sound Siren On RF Receiver Tamper / Jamming
4 = Unseal Zone That Fails Supervision (If Supervision Enabled)
8 = RF Jamming Monitoring Allowed
Location 528 = Map RF Device 1 To Zone (1 To 8)
Location 529 = Map RF Device 2 To Zone (1 To 8)
Location 530 = Map RF Device 3 To Zone (1 To 8)
Location 531 = Map RF Device 4 To Zone (1 To 8)
Location 532 = Map RF Device 5 To Zone (1 To 8)
Location 533 = Map RF Device 6 To Zone (1 To 8)
Location 534 = Map RF Device 7 To Zone (1 To 8)
Location 535 = Map RF Device 8 To Zone (1 To 8)
528 529 530 531 532 533 534 535
1 2 3 4 5 6 7 8
D1 D2 D3 D4 D5 D6 D7 D8
Location 536 = Map RF Device 9 To Zone (1 To 8)
Location 537 = Map RF Device 10 To Zone (1 To 8)
Location 538 = Map RF Device 11 To Zone (1 To 8)
Location 539 = Map RF Device 12 To Zone (1 To 8)
Location 540 = Map RF Device 13 To Zone (1 To 8)
Location 541 = Map RF Device 14 To Zone (1 To 8)
Location 542 = Map RF Device 15 To Zone (1 To 8)
Location 543 = Map RF Device 16 To Zone (1 To 8)
536 537 538 539 540 541 542 543
0 0 0 0 0 0 0 0
D9 D10 D11 D12 D13 D14 D15 D16
Location 748 = Increments Of 5 ms (0 – 75 ms)
Location 749 = Increments Of 80 ms (0 – 1200 ms) 4 6
Solution Ultima 862 Quick Reference Guide 17
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Location 801 - 808
RF Signal Strength
For Devices 1 – 8
Location 809 - 816
RF Signal Strength
For Devices 9 - 16
Location 900
Default Options
Location 901 - 904
System Time
Location 905 - 910
System Date
Location 801 = Signal Strength For RF Device 1
Location 802 = Signal Strength For RF Device 2
Location 803 = Signal Strength For RF Device 3
Location 804 = Signal Strength For RF Device 4
Location 805 = Signal Strength For RF Device 5
Location 806 = Signal Strength For RF Device 6
Location 807 = Signal Strength For RF Device 7
Location 808 = Signal Strength For RF Device 8
801 802 803 804 805 806 807 808
0 0 0 0 0 0 0 0
D1 D2 D3 D4 D5 D6 D7 D8
Location 809 = Signal Strength For RF Device 9
Location 810 = Signal Strength For RF Device 10
Location 811 = Signal Strength For RF Device 11
Location 812 = Signal Strength For RF Device 12
Location 813 = Signal Strength For RF Device 13
Location 814 = Signal Strength For RF Device 14
Location 815 = Signal Strength For RF Device 15
Location 816 = Signal Strength For RF Device 16
809 810 811 812 813 814 815 816
0 0 0 0 0 0 0 0
D9 D10 D11 D12 D13 D14 D15 D16
0
0 = Defaulting System Allowed / 15 = Defaulting System Disabled
Location 901 = Hour Of The Day (Tens Digit)
Location 902 = Hour Of The Day (Units Digit)
Location 903 = Minute Of The Day (Tens Digit)
Location 904 = Minute Of The Day (Units Digit)
901 902 903 904
0 0 : 0 0
H H M M
Location 905 = Day Of The Month (Tens Digit)
Location 906 = Day Of The Month (Units Digit)
Location 907 = Month Of The Year (Tens Digit)
Location 908 = Month Of The Year (Units Digit)
Location 909 = Current Year (Tens Digit)
Location 910 = Current Year (Units Digit)
905 906 907 908 909 910
0 1 0 1 0 1
D D M M Y Y
18 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited

Solution Ultima RF Receiver Interface Connections
Figure 1: RF Receiver (RF3212) Wiring Diagram
Wiring and Power Up Operation
- Remove power from the control panel. The following describes the status of the module based on the LED
condition.
- Connect the RF Receiver to the control panel as shown
above using 0.8mm (22-gauge) or larger wire. Wire length
should not exceed 300 meters (1000 feet).
LED On – Module is functioning normally.
LED Off – Power failure has occurred or module is not wired
correctly.
- Apply power to the control panel. The red LED at the centre
of the module will turn on. LED Turns Off Momentarily – Module acknowledged receiving an RF signal from a remote RF device.
RF Keyfob Operations For Solution Ultima Series Control Panels
Figure 2: RF3332 - 2 Button RF Keyfob Figure 3: RF3332 - 2 Button RF Keyfob
Solution Ultima 862 Quick Reference Guide 19
Electronics Design and Manufacturing Pty LimitedSOL ULTIMA 862 QUICK REF GUIDE.D

Connections For Split EOL Resistors For Six Burglary Zones and Two 24 Hr Zones
Figure 4: Split EOL Wiring Diagram (Location 266 = 15) Figure 5: Split EOL Wiring Diagram With Tamper
(Location 266 = 14)
Connections For Split EOL Resistors Using N/O Contacts
Figure 6: Split EOL Wiring Diagrams Using N/O Contacts
Wiring Diagram For Keyswitch Zone
Figure 7: Wiring Diagram For Keyswitch Zone
20 Solution Ultima 862 Quick Reference Guide
SOL ULTIMA 862 QUICK REF GUIDE.DOCBosch Security Systems Pty Limited
