1 For your information
Notice!
A language dependent inscription strip (ordering number F.01U.343.398) for insertion into
the main panel controller is attached to this operation guide.
This operation guide contains important information and notes on operating the FPA-5000/
FPA-1200.
Using the step-by-step directions, you can familiarize yourself with the individual functions:
–In overview, page 19 provides an overview of the operating and display elements and the
touch screen.
– In Operating principle, page 24, you will learn how to navigate through the individual
menus and which selection possibilities are available to you.
Each function is described in detail in an individual chapter.
Notice!
In standby mode, the standby screen is displayed. This contains different information
depending on the configuration.
If no longer operated, the panel controller switches to standby mode after 5 minutes and an
alarm event occurs after one hour. The touch screen backlighting switches off. To quit
standby mode, touch any part of the touch screen.
To call up the start menu or change the language display, see Operating principle, page 24.
You will find specific topics in the table of contents. If you are already practiced in the
handling of menus, you can use the overview of all menus in All functions at a glance, page 12.
See also
– In overview, page 19
– Operating principle, page 24
– All functions at a glance, page 12
– In overview, page 19
– Operating principle, page 24
– All functions at a glance, page 12
1.1 Open Source license agreement
Notice!
Bosch Sicherheitssysteme GmbH uses open source software within this product. The
declaration of the components and their respective licenses can be found on http://
www.boschsecurity.com/oss/.
1.2 Depiction of steps
The sequence of steps that you need to execute a function is depicted as follows:
1. In the start menu, select Bypass Block
2. Bypass
In more detailed form:
1. Call up the start menu.
2. Select Bypass Block.
3. Select Bypass.

Panel Controller For your information | en 9
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
1.3 Calling up the start menu
4Press the "home" key.
You can use this key to return from any submenu back to the start menu.
Notice!
The display changes from each menu element to the standby display if no entries are made
within one minute.
1.4 Changing language display
The panel language can be changed quickly with a shortcut; see the following instruction To
change the panel language using the menu, see Changing language display, page 31.
1. Select the "home" key.
2. Then press 1 on the alphanumeric keypad immediately after this.
3. Select OK to confirm the entry or Cancel to cancel the operation.
A list of the existing languages is displayed.
4. Select the language you require.
The displays are displayed in the selected language.
Notice!
After a system reboot following a power cut or battery failure, the default language set in the
FSP‑5000‑RPS is displayed again.
1.5 Warranty and liability
Warranty and liability claims for personal and property damage are excluded if these were
caused by one or several of the following causes:
– Use of the FPA-5000/FPA-1200 fire panel contrary to the regulations
– Improper set-up, installation, start-up, operation or maintenance
– Disregarding of the user manual
– Subsequent constructional changes
– Faulty repairs
– Catastrophes, influence of foreign bodies, and force majeure.
Without the permission of Bosch, no changes or additions to or rebuilding of the panel
including the panel controller may be undertaken.
Rebuilding requires written permission. In case of non-approved constructional changes, any
warranty claims against Bosch are voided.
1.6 Copyright
Bosch Sicherheitssysteme GmbH, Robert-Bosch-Ring 5, 85630 Grasbrunn, Germany retains
the complete copyright to the whole documentation. Without the express written permission
of Bosch, no part of these documents may be duplicated or transmitted in any form.
Bosch reserves the right to make changes to this manual without prior notice.

10 en | For your safety Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
2 For your safety
Before using the device, familiarize yourself with these instructions. If you do not read and
understand these explanations, you will not be able to operate the device faultlessly.
The operating instructions do not do away with the need for training by authorized personnel.
Notice!
The panel controller may only be operated by trained personnel. See skills required by
personnel.
This operation guide does not contain any general or special knowledge about safety issues.
Information on such issues is only given to the extent that it is needed for operation of the
device.
Ensure that you are familiar with all safety-related processes and regulations in your area. This
also includes how to behave in the event of an alarm and the initial steps to take if a fire
breaks out.
The operation guide should always be available on site. It is a statutory part of the system and
must be given to the new owner if the system is ever sold.
Notice!
The personal access code (consisting of user ID and password) must not be made known to
third parties.
2.1 Symbols and notes used
The various chapters only contain whatever safety information and notes are required for
operation of the system. Warning notes and operator guidance notes are displayed in the
appropriate parts of the panel controller display for your benefit.
The following search symbols are used:
!
Caution!
Text fields marked with this symbol contain warnings by which you must abide without fail —
for your own safety as well as that of the people around you
Notice!
Text fields marked with this symbol contain useful information to help you operate the
FPA-5000/FPA-1200 fire panel.
2.2 Operating the touch screen
Do not use any pointed or sharp objects when operating the touch-sensitive display. This
could damage the surface. Touch the touch screen with your finger (nail) or the stick attached
to the left-hand side of the panel controller.
2.3 Maintenance
Clean the touch screen and membrane keypad with a soft cloth only. If necessary, dampen the
cloth lightly with standard monitor cleaning agents. Do not use any aggressive cleaning agents
and ensure that no liquid enters the inside of the device.

Panel Controller For your safety | en 11
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
2.4 Usage in accordance with regulations
The panel controller is designed for operating the FPA-5000/FPA-1200 fire panel. It can
perform the following tasks:
– Displaying and processing various message types such as alarm and trouble messages
– Bypassing, isolating and resetting elements
– Performing a walktest
– Display diagnostic information about every LSN element
– Configuration of detectors (short texts and detector sensitivity)
– Performing a drill
– Saving, displaying and printing out events
– Switching the system to day or night mode.
2.5 Skills required by personnel
Display of event messages on the panel controller must only be processed by trained
personnel.
The system walk test and detector configuration must only be performed by trained,
authorized personnel.

12 en | All functions at a glance Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
3 All functions at a glance
3.1 Calling up the start menu
Press the "home" key to return to the start menu from any submenu.
Notice!
The display changes from each menu element to the standby display if no entries are made
within one minute; see also Standby display.
3.2 Bypass/Isolate
3.2.1 Bypass
Bypass
Block
-> Bypass -> Show bypassed
devices
Select by
number
Bypass buzzer Printer
Block NAC Transmission
device
HVAC Doorholder
Detector Logical zone Extinguishing
system
Annunciator
Bypass group More... -> Control element Interface
module
Show bypassed devices
– Display of a list of all bypassed elements:
– Un-bypassing the bypassed elements.
Select by number
– Display of a list of all bypassed elements:
– Search for an element in a list by entering the number.
– Un-bypassing or bypassing an element.
3.2.2 Isolate
Bypass
Block
-> Bypass Show blocked devices Select by
number
Block Group Printer
Block -> Sounder Strobe HVAC Doorholder
Transmission device Detector Extinguishing
system
Annunciator
Logical zone More... -> Control
element
Interface
module
Show blocked devices
– Display a list of all isolated elements
– De-isolate isolated elements
Select by number
– Display a list of all elements that can be isolated
– Search for an element in a list by entering the number

Panel Controller All functions at a glance | en 13
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
– Isolate or de-isolate an element
3.3 Diagnostics
Diagnostics -> Element details Modules
Hardware Panel passport
LED test on modules History log
Network services VAS
Element details
–All info for one element: Display all diagnostic information about an element on a loop of
an LSN module.
–Info for element group: Select and display specific pieces of diagnostic information
about several elements in the selected LSN module.
–Info for all elements on the module: Select and display specific pieces of diagnostic
information about all LSN elements of the selected LSN module.
Modules
–Module passport: Display diagnostic information for each individual module: production
data, software version, CAN ID, compatibility.
–Module Compatibility: Display the software version of the selected module in
comparison with the control panel software version.
–Module status: Display hardware diagnostic data for the selected module.
Only for LSN modules:
–Module status and counters
–Reset counters: Reset the counters that record the frequency with which various events
occur.
Hardware
–Address cards: Additional display for each card slot of the serial number and number of
addresses per card.
–Display
–LED test: Test all LED displays on the panel controller. These remain lit for the
duration of approx. five seconds.
–Key test: Test the operativeness of the membrane keypad.
–Display test: Test the operativeness of the display.
–Display touch test: Test the operativeness of the touch-sensitive surface.
–Adjust touch screen: Adjust the location precision when touching the touchscreen.
–Serial interface: Display statistical data for the transmission.
–CAN bus: Display status of CAN interfaces.
Panel passport
Display diagnostic information such as manufacturing data or software version of the panel
controller.
LED test on modules
Test LED displays of individual modules and simultaneously test all LED displays.
History log
See Maintenance – History log
Network services
–Routing table

14 en | All functions at a glance Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
Information concerning the accessibility of all interfaces and nodes within the system
network.
–Ethernet ports
Information concerning various parameters and the status of the two Ethernet interfaces
available at the panel controller.
–Send ping command
Sending of a ping command to a specific IP address to check the availability of other
nodes in the network.
–Consistency check
The check performed determines whether the Ethernet configuration from FSP-5000-RPS
corresponds to the configuration entered at the panel controller. In the event of
discrepancies, a fault message is displayed.
–Ethernet redundancy
Information concerning the type of redundancy configuration (RSTP or dual-homing). In
the case of redundancy via RSTP, the RSTP parameters of the RSTP panel (local bridge)
and those of the root bridge are displayed.
–Remote services
Information concerning parameters and status of Remote Services. Connect the panel
manually to the Remote Portal server (the panel automatically tries to connect to the
server every 15 minutes).
VAS
Information on all connected electro-acoustic systems that are used for voice evacuation
systems.
3.4 Maintenance
Maintenance -> Walktest Change language
Activate outputs Activate transmission device
Remove detector History log
Change device at V.24
interface
Bypass buzzer
3.4.1 Walktest
Start / End walktest
Elements for the walktest are selected in this submenu. The following possibilities are offered
for selection:
–Select by number:
Display of a list of all elements:
Search for an element in a list by entering the number.
–Walktest group
–Loop
–Logical zone
–Elements
–Transmission device
–Control element
–More...
–DACT

Panel Controller All functions at a glance | en 15
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
–Key deposit
–Battery
–Mains power
When the walktest is complete, the following selection options are available:
– Adding the elements to be tested to a different walk test group (Assign tested elements
to walktest group).
– Continuing the walk test (No).
– Displaying tested or non-tested elements (Not tested, Tested).
Create / Change walktest group
– Deleting or adding individual elements to specified walktest groups.
– Delete all elements in a walktest group.
3.4.2 Change language
Change the language of the displays (Change language).
3.4.3 Activate Outputs
Activate outputs:
–Select by number:
Display of a list of all controllable elements.
Search for an element in a list by entering the number.
–Sounder
–Strobe
–HVAC
–More...
Start and terminate activation of the selected elements.
3.4.4 Activate the transmission device
Activate a selected transmission device (Activate transmission device).
3.4.5 Detector removal
Bypass all sounders and transmission devices for 15 minutes while a detector is being
removed (Remove detector).
3.4.6 History Log
– Filtering and displaying specific data
– Combining various filters
– Print out all filtered data or a specific part of the data
The following filters are available:
Filter Data, filtered by...
Without filter All data
Show all Delete filter Display all data with specification of event number, date,
time, element number and message type. Existing filters are
deleted.
Period Starting date, end date and time
Event types Message types, such as Fault
Device types Device types, such as Detectors
Address range Address range within a system

16 en | All functions at a glance Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
Filter Data, filtered by...
User commands Selected function fields, such as Acknowledge or Reset.
Walktest Elements switched to walktest mode
3.4.7 Change device on V.24 Interface
Assigning a different device to the V.24 interface (Change device at V.24 interface).
3.5 Configuration
Configuration -> Set input / output
groups
Set groups
Detector sensitivity Operator
Rename elements Overview
Network services About ...
Set input / output groups
–Input group or Output group
– Displaying the assigned elements.
– Add or delete elements.
– Rename group names.
Set groups
– Bypass group, isolate group or walktest group
– Displaying the assigned elements.
– Add or delete elements.
– Rename walktest, bypass and isolate groups.
Detector sensitivity
Change the sensitivity of individual detectors or zones. Two selection options are available: a
default sensitivity and an alternative sensitivity assigned in the FSP-5000-RPS programming
software.
Operator
If the same password is used per access level, the following options are offered:
–Change universal password
The same password can be configured for each access level in the FSP-5000-RPS
programming software. The password for access levels two to four can be changed.
If every user has a different password, the following options are offered:
–Change operator data
Change a user's password.
–Set default password
Reset an operator's password to his/her previous password.
Rename elements
Change the description of the elements.
Overview
Information on valid system configuration.
–Ethernet
Change and activate network settings (IP settings, Ethernet redundancy). Changes take
effect after restarting the panel.

Panel Controller All functions at a glance | en 17
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
Notice!
Changes may only be made by trained specialist personnel. Competent knowledge of
networking and protocols is essential!
–Change date / time
If starting the panel for the first time enter the current time and date. The setting of the
correct date is a prerequisite for connecting the panel to the Remote Portal server.
–Remote ID:
Enter the Remote ID: required for all Remote Services, e.g. Remote Connect and change
the System ID: if necessary.
3.6 Switching to day or night mode
– Switch to day or night mode
– In day mode: Set the reset time to night mode for the current day.
3.7 Further functions
Further functions -> Change date / time Master password
Remote access Change password
Drill Alarm counters
Change date / time
Change the time and date
Master password
Depending on how the panel is configured, one of these two options will be offered:
– Entering a master password that is valid indefinitely.
This password cannot be changed and is available from the relevant Bosch branch on
request
– Entering a master password that is valid for a specified period of time. This password is
only valid for 24 hours and must first be requested; see Master password, page 89.
After the password has been entered, various options are offered depending on the
configuration; see Operator, page 86.
Drill
Start and terminate a fire drill. During the drill, fire alarms, trouble messages and home
automation alarms are displayed.
Remote Services
– Enable a remote access connection via telephone.
– Block Remote Maintenance until next panel reboot.
– Block Remote Alert until next panel reboot.
Change password
Depending on how the panel is configured, the option of changing the password for every user
is offered.
Alarm counters
– Display the number of internal and external alarm messages and the number of service
alarms that were reported during the lifetime of the panel.
– Reset the alarm counter for each alarm type

18 en | All functions at a glance Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
3.8 Search Function/Element
Search function /
element
-> Search function
Go to element
Search function
– Display a list of all functions and device descriptions in alphabetical order.
– Select a function or device description from the list.
Go to element
Display of a list of all elements that are connected to the system and select an element from
this list in order to display more detailed information.
–by logical address: Search for an element in a list by entering the logical address
allocation.
–by physical address: Search for an element in a list by entering the physical address
allocation.
–By description: Search for an element in a list by entering the description.
3.9 Reset
Reset -> Event type Scope
Logical zone Detector
This panel

Panel Controller In overview | en 19
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
4 In overview
This chapter contains information about the following elements of the panel controller:
–Operating elements, page 19
–Display elements, page 20
–Touch screen, page 21
–Display support information, page 23
1
2
0
A l a r m
Test
Transmission Device
activated
Bypassed
Transmission Device
bypassed
Signals bypassed
Power
Fault
Fault Transmission
Device
Fault System
Fault Signals
0
Bypass
Isolate
Maintenance
Switch to day mode
Search Function/
Element
Diagnostics
Configuration
Further functions
Reset
0 0 0
Fire Control Fault Bypass Status
1
1
2
1
3
4
1 Function keys 3 Key switch
2 Alphanumeric keypad 4 LED display
4.1 Operating elements
The operating elements include points 1 - 3.
Function keys
To select a function, press the appropriate membrane key.
The following functions can be executed with the function keys:
Display a list of the networked panels and establish a remote
connection with a networked panel (only valid for FPA-5000) or a
remote keypad.
Display the address for technical support, if saved.

20 en | In overview Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
"Home" key. Call up the start menu.
Return to the previous selection.
"Key" key. Log in and out: Enter user ID and password.
Temporarily switch off the internal buzzer.
"Left arrow" key. Move the cursor one place to the left on the search
screen.
"Right arrow" key. Move the cursor one place to the right on the search
screen.
"Double arrow" key. Switch between status bars if two or more are
available. Call up the status bar to scroll rapidly through lists.
"Enter" key. Confirm an alphanumeric entry. Confirm an entry that is
not confirmed by selecting the OK field on the touch screen.
Alphanumeric keypad
Entry of letters, special characters, and numbers.
Key switch
The key switch has two programmable key positions. Depending on the configuration, it is
possible to switch between day and night operation, for example.
Notice!
Only give the key to people who have been trained to operate the panel controller and who
have knowledge in the area of fire protection. Otherwise, operation may be incorrect and
people may be injured. To prevent possible misuse, remove the key after operation and store
it in a secure location.
4.2 Display elements
LED display
Display Color Light signal Meaning
Steady Flashes
Alarm Red x Panel is in alarm state Also
continuously on in event of Fire PAS
Walktest Yellow x System is being tested
