Bosch ICP-CC488 User manual

EN
Quick Reference Guide
ICP-CC488
Control Panel
ICP-CC488

ICP-CC488 | Quick Reference Guide | Notices EN | 2
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
Copyright Notice
Unless otherwise indicated, this publication is the
copyright of Bosch Security Systems, Inc. (“Bosch”).
All rights are reserved.
You may download a single copy of this publication.
By downloading the publication you agree that you
will: (i) only use the publication for your own
reference; (ii) not commercially exploit or charge any
person for the use of the publication; and (iii) not
modify the publication in any way without the prior
written permission of Bosch.
Except as specified above or where authorized by the
Copyright Act 1968 (Cth), no part of this publication
may be reproduced, transmitted, modified or stored,
in any form or by any means, without the prior
written permission of Bosch.
Notice of Liability
This material is designed for use by tradespeople with
expertise in the installation of this product. Persons
without appropriate expertise should seek assistance
before attempting installation.
While care has been taken in the preparation of this
material, Bosch Security Systems, Inc. and its
representatives will not be responsible to any person
or entity for any loss or damage directly or indirectly
caused by information in, or any omission from, this
material.
Bosch Security Systems, Inc. reserves the right to
make changes to features and specifications of its
products at any time without prior notification.

ICP-CC488 | Quick Reference Guide | Contents EN | 3
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
Contents
1.0 Overview...........................................................6
1.1 Introduction ......................................................6
1.2 Programming ....................................................6
1.3 Programming Using A Codepad ....................6
1.4 Programming Option Bits ...............................7
1.5 Installer’s Programming Commands..............7
1.6 Arming/Disarming the System .......................8
1.7 Isolating Zones..................................................8
1.7.1 Standard Isolating.............................................8
1.7.2 Code to Isolate..................................................8
1.8 Add/Delete RF Devices (Wireless Zones) .....8
1.8.1 Add RF Device.................................................8
1.8.2 Delete RF Device .............................................8
1.9 Set First Test Report ........................................8
1.10 Event Memory Recall......................................8
1.11 Walk Test Mode...............................................8
1.12 Satellite Siren Service Mode ...........................8
1.13 Telephone Monitor Mode (Toggle On/Off) .9
1.14 Add/Delete User Code/RF Keyfob ...............9
1.14.1 Add A User Code ............................................9
1.14.2 Add RF Keyfob ................................................9
1.14.3 Delete a User Code/RF Keyfob .....................9
1.15 Change Domestic Telephone Numbers.........9
1.16 Turn Outputs On/Off......................................9
1.17 Setting Date and Time.....................................9
1.18 Day Alarm – Toggle On/Off ..........................9
1.19 STAY Mode 2 Zones – Program....................9
1.20 Fault Analysis..................................................10
1.21 Modem Call (Alarm Link).............................10
1.22 Latching Outputs (Reset)...............................10
1.23 Codepad ID/Buzzer Tone.............................10
1.24 Test Report .....................................................10
1.25 Speaker Test....................................................10
1.26 Bell Test...........................................................10
1.27 Strobe Test (Toggle On/Off).........................10
1.28 Telco Arm Sequence (Call Forward On).....10
1.29 Telco Disarm Sequence (Call Forward Off) 10
2.0 Programming Parameters ..............................11
2.1 Phone Programming ......................................11
2.1.1 Phone Number 1 - Receiver 1 ......................11
2.1.2 Phone Number 2 - Receiver 1 ......................11
2.1.3 Handshake Tone For Receiver 1..................11
2.1.4 Transmission Format For Receiver 1...........11
2.1.5 Subscriber ID Number For Receiver 1........11
2.1.6 Phone Number 1 - Receiver 2 ......................11
2.1.7 Phone Number 2 - Receiver 2 ......................11
2.1.8 Handshake Tone For Receiver 2..................11
2.1.9 Transmission Format For Receiver 2 ...........11
2.1.10 Subscriber ID Number For Receiver 2........11
2.1.11 Dialing Format................................................11
2.1.12 Reserved..........................................................12
2.1.13 Telco Arming Sequence (Call Forward On)12
2.1.14 Telco Disarm Sequence (Call Forward Off) 12
2.1.15 Call Back Telephone Number ......................12
2.1.16 Ring Count......................................................12
2.1.17 Telephone Line Fail Options ........................12
2.1.18 Dialer Options 1 .............................................12
2.1.19 Dialer Options 2 .............................................12
2.1.20 Dialer Options 3 .............................................12
2.1.21 Alarm Link Options .......................................12
2.2 Installer Code..................................................12
2.3 User Code Programming...............................12
2.3.1 User Codes......................................................12
2.3.2 Authority Levels .............................................13
2.4 Day Alarm Zones ...........................................13
2.5 EOL Resistor Value .......................................13
2.6 Zone Programming ........................................13
2.6.1 Zone Defaults..................................................13
2.6.2 Zone Types......................................................14
2.6.3 Zone Pulse Count ...........................................14
2.6.4 Zone Pulse Count Time.................................15
2.6.5 Zone Options 1...............................................15
2.6.6 Zone Options 2...............................................15
2.6.7 Zone Dialer Options ......................................15
2.6.8 Keyswitch Zone Options ...............................15
2.7 Swinger Programming ...................................15
2.7.1 Swinger Shutdown Count For Siren.............15
2.7.2 Swinger Shutdown Count For Dialer...........15
2.8 Zone Status Programming .............................15
2.8.1 Zone Status – Zone Tamper Report.............15
2.8.2 Zone Status – Walk Test Report...................15
2.8.3 Zone Status – Bypass Report.........................15
2.8.4 Zone Status – Trouble Report.......................15
2.8.5 Zone Status – Sensor Watch Report.............15
2.8.6 Zone Status – Alarm Restore Code..............15
2.8.7 Zone Status Reporting Options.....................15
2.9 RF Programming ............................................15
2.9.1 RF Supervision Time .....................................15
2.9.2 RF Low Battery Report..................................15
2.9.3 RF Receiver Trouble Report.........................16
2.9.4 RF Receiver Trouble Restore Report ..........16
2.9.5 RF Dialer Options ..........................................16
2.10 Report Programming .....................................16
2.10.1 Open/Close Reports ......................................16
2.10.2 Open/Close Reporting Options....................16
2.10.3 Codepad Duress Report ................................16
2.10.4 Codepad Panic Report...................................16

ICP-CC488 | Quick Reference Guide | Contents EN | 4
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.10.5 Codepad Fire Report .....................................16
2.10.6 Codepad Medical Report ..............................16
2.10.7 Codepad Reporting Options.........................16
2.11 System Status Programming..........................16
2.11.1 System Status – AUX Power Supply Fail
Report..............................................................16
2.11.2 System Status – AUX Power Supply Fail
Restore Report................................................16
2.11.3 System Status – AC Fail Report ...................16
2.11.4 System Status – AC Fail Restore Report .....16
2.11.5 System Status – Low Battery Report............16
2.11.6 System Status – Low Battery Restore Report16
2.11.7 System Status – Access Denied (Code Retry)16
2.11.8 System Status Reporting Options.................17
2.12 Test Report Programming.............................17
2.12.1 Test Report Time (Automatic)......................17
2.12.2 Test Reporting Dialer Options .....................17
2.13 Output Programming.....................................17
2.13.1 Outputs............................................................17
2.13.2 Event Codes....................................................18
2.13.3 Polarity (Modes) .............................................19
2.13.4 Time Base........................................................19
2.13.5 Time Base Multiplier .....................................19
2.13.6 One Shot Mode..............................................19
2.13.7 Pulsing Mode..................................................19
2.14 Time Programming........................................19
2.14.1 Entry Time 1...................................................19
2.14.2 Entry Time 2...................................................19
2.14.3 Exit Time (AWAY/STAY Modes)...............19
2.14.4 Entry Guard Time For STAY Mode............19
2.14.5 Delay Alarm Report Time ............................19
2.14.6 Sensor Watch Time........................................19
2.14.7 Codepad Lockout Time.................................19
2.14.8 Siren Run Time ..............................................19
2.14.9 Siren Sound Rate............................................19
2.14.10 Auto Arming Pre-Alert Time........................19
2.14.11 Auto Arming Time.........................................19
2.14.12 Auto Disarming Time ....................................20
2.14.13 Kiss-Off Wait Time ........................................20
2.14.14 Speaker Beep Volume ...................................20
2.15 Options Programming ...................................20
2.15.1 System Options 1 ...........................................20
2.15.2 System Options 2 ...........................................20
2.15.3 System Options 3 ...........................................20
2.15.4 System Options 4 ...........................................20
2.15.5 Consumer Options 1......................................20
2.15.6 Consumer Options 2......................................20
2.15.7 Consumer Options 3......................................20
2.15.8 Radio Input Options......................................20
2.15.9 Partitioning Options 1....................................20
2.15.10 Partitioning Options 2....................................20
2.16 Zone Allocations Programming ....................21
2.16.1 Zone Allocations Enabled for Area 1 and
Area 2 ..............................................................21
2.16.2 Zone Allocations for Area 1 and Area 2......21
2.17 User Code Area Assignment.........................21
2.18 Domestic Telephone Numbers .....................21
2.19 Reserved..........................................................21
2.20 RF Programming ............................................21
2.20.1 RF Options......................................................21
2.20.2 RF Device Mapping Option..........................22
2.20.3 Default RF Device Mapping for Devices 1 to
8........................................................................22
2.20.4 Default RF Device Mapping for Devices 9 to
16......................................................................22
2.20.5 RF Signal Strength for Devices 1 to 8..........22
2.20.6 RF Signal Strength for Devices 9 to 16........23
2.20.7 Reserved..........................................................23
2.21 System Option Programming........................23
2.21.1 Country Codes................................................23
2.21.2 Default Options ..............................................23
2.21.3 System Time ...................................................23
2.21.4 System Date ....................................................23
3.0 RF Receiver Interface ....................................24
4.0 RF Keyfob Operations...................................25
5.0 Connections for Split EOL Resistors............25
5.1 8 Burglary Zones ............................................25
5.2 8 Zone Operation Using N/O Contacts.......26
6.0 Wiring Diagrams ............................................26
7.0 Codepad Connections Partitioning...............29
8.0 Country Codes................................................30

ICP-CC488 | Quick Reference Guide | Contents EN | 5
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
Figures
Figure 1: RF Receiver (DSRF) Wiring Diagram ..24
Figure 2: RF3332: 2-Button Keyfob Transmitter .25
Figure 3: RF3334: 4-Button Keyfob Transmitter .25
Figure 4: Split EOL Wiring Diagram (Location
266 – 15)...................................................25
Figure 5: Split EOL Wiring Diagram with Tamper
(Location 266 – 14) .................................25
Figure 6: Split EOL Wiring Diagrams Using N/O
Contacts....................................................26
Figure 7: Wiring Diagram for Keyswitch Zone....26
Figure 8: ICP-CC488 Wiring Diagram .................27
Figure 9: ICP-CC488 Component Overlay..........28
Figure 10: Connections for CP-5 Master Partitioned
Codepad and CP-5 Area Addressable
Codepad...................................................29
Figure 11: Connections for Two CP-5 Area
Addressable Codepads ...........................29
Tables
Table 1: Quick Guide to Programming .................6
Table 2: Codepad Indicators...................................7
Table 3: Programming Option Bits ........................7
Table 4: Installer’s Programming Commands.......7
Table 5: Arming/Disarming the System ................8
Table 6: Telephone Monitor Mode........................9
Table 7: Fault Analysis Conditions.......................10
Table 8: Codepad ID/Buzzer Tone......................10
Table 9: Hexadecimal Values for Zone Nos. ......22

ICP-CC488 | Quick Reference Guide | 1.0 Overview EN | 6
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
1.0 Overview
1.1 Introduction
Thank you for choosing the ICP-CC488 Control
Panel for your installation. You will find this system
extremely flexible, reliable, and easy to use. This
Quick Reference Guide is supplied with the system
to provide users with enough basic information to
wire, configure, and program the system. Due to the
systems many programmable features and options,
we suggest that you obtain the ICP-CC488 Installation
Manual that provides detailed information on system
options, functions, and programming methods.
1.2 Programming
The programming options of the system are stored in
a non-volatile EPROM. This memory holds all
information during a total power loss and can be
changed as many times as required.
The entire programming sequence consists of
entering a location number and changing the data as
required.
Use the following methods to program the system:
•Codepad
•Alarm Link Software
1.3 Programming Using A Codepad
The system must be disarmed (with no active alarm)
to program the system. If there is an active alarm or
the system is armed, enter the code for User 1
(Default – 2580) followed by the [#] key. (User Code
1 is factory default as the Master Code.)
To enter Installer’s Programming Mode, enter the
installer code (Default – 1234) followed by the [#]
key. Two beeps are heard and both the STAY and
AWAY indicators flash simultaneously to indicate
that you entered programming mode. The codepad
indicators displays the current data programmed in
Location 000 (first location of the Primary Telephone
Number).
To move to another programming location, enter the
location number followed by the [#] key. The data in
the new location is displayed using the codepad
indicators. (For example, if you enter [3 4 #], the
system jumps to Location 034, the beginning of the
Subscriber ID Number For Receiver 1.)
To move to the next location, press the [#] key. This
steps you to the next location. The data in the next
location is displayed using the codepad indicators.
(For example, if you are currently positioned at
Location 034, pressing the [#] key takes you to
Location 035.)
To step back one location, press the [*] key. (For
example, if you are currently positioned at Location
35, pressing the [*] key returns to Location 34.)
To change data in the current location, enter the new
value (0 to 15) followed by the [*] key. This stores the
new data into the location. (For example, if you enter
the value [1 4 *], both the Zone 4 indicator and the
MAINS indicator display to represent the new data
value.)
To move to the next location, press the [#] key. The
data in the next location displays.
To exit from Installer’s Programming Mode, enter
[9 6 0 #]. Two beeps are heard and the STAY and
AWAY indicators no longer display. The system
returns to the disarmed state and is ready for use.
Table 1 displays a quick guide to programming:
Table 1: Quick Guide to Programming
Task Keystrokes
Enter Installer’s Programming
Mode
[1 2 3 4 #]
Exit from Installer’s
Programming Mode
[9 6 0 #]
Step to next Location [#]
Step back one Location [*]
Program new data into
Location
[Data][*] (Data – 0 to 15)
Jump to another Location [Location No.][#]

ICP-CC488 | Quick Reference Guide | 1.0 Overview EN | 7
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
Table 2: Codepad Indicators
Data
Value
Zone 1
Indicator
Zone 2
Indicator
Zone 3
Indicator
Zone 4
Indicator
Zone 5
Indicator
Zone 6
Indicator
Zone 7
Indicator
Zone 8
Indicator
MAINS
Indicator
0
1X
2 X
3 X
4 X
5 X
6 X
7 X
8 X
9 X X
10 X
11 X X
12 X X
13 X X
14 X X
15 X X
1.4 Programming Option Bits
Use option bits to program any combination of the
four different options in one location by adding the
options together. Programming a zero disables all
four options.
Example
If at Location 177 you only want options 1, 2, and 4,
add the numbers together and the total is the number
to be programmed. The number to be programmed
is 7 (1 + 2 + 4 – 7).
Table 3: Programming Option Bits
Optio
n
Description
1 Dialer reporting functions allowed
2 Remote arming using telephone allowed
4 Answering machine bypass only when armed
8 Use bell 103 for FSK format
(Disabled – CCITT V21)
1.5 Installer’s Programming
Commands
Installer Programming Commands, displayed in
Table 4,can only be used when you enter Installer’s
Programming Mode. Enter the command followed
by the [#] key.
Table 4: Installer’s Programming Commands
Comman
d
Description
959 Test programming key.
960 Exit from Installer’s Programming Mode.
961 Default system back to factory settings.
962 Copy panel memory to programming key.
963 Copy programming key to panel memory.
964 Erase programming key.
965 Default system for domestic dialing format.
966 Enable/disable automatic stepping of locations
when programming.
999 Display software version (hand held
programmer required).

ICP-CC488 | Quick Reference Guide | 1.0 Overview EN | 8
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
1.6 Arming/Disarming the System
1.7 Isolating Zones
1.7.1 Standard Isolating
1. Press the [*] key twice.
2. Enter the zone number that you want isolated,
followed by the [*] key.
Repeat Step 2 if more than one zone is required
to be isolated.
3. Press the [#] key to exit when finished.
1.7.2 Code to Isolate
1. Press the [*] key once.
2. Enter your user code and press [*].
3. Enter the zone number that you want isolated,
followed by the [*] key.
Repeat Step 2 if more than one zone is required
to be isolated.
4. Press the [#] key to exit when finished.
1.8 Add/Delete RF Devices (Wireless
Zones)
1.8.1 Add RF Device
1. Enter the four character Installer Code, followed
by [0] and the [#] key (for example, [1 2 3 4 0
#]).
2. Enter the Device Number (1 to 16) you want to
add, followed by the [#] key.
3. Enter the 9-digit RF device ID number, followed
by the [#] key.
1.8.2 Delete RF Device
1. Enter the Installer Code followed by [0] and the
[#] key (for example, [1 2 3 4 0 #]).
2. Enter the Device Number (1 to 16) you want to
delete, followed by the [#] key.
3. Press the [*] key to delete the RF device.
1.9 Set First Test Report
1. Enter the four character Installer Code, followed
by [1] and the [#] key (for example, [1 2 3 4 1
#]).
2. Enter the Number Of Days (0 to 15) to wait until
the first test report, followed by the [#] key.
1.10 Event Memory Recall
Enter the four character Installer Code or Master
Code, followed by [8] and the [#] key (for example,
[1 2 3 4 8 #]).
The last 40 events (non-partitioned) or last ten events
(partitioned) are displayed in reverse order (for
example, most recent to least recent).
1.11 Walk Test Mode
1. Enter the four character Installer Code or Master
Code, followed by [7] and the [#] key (for
example, [1 2 3 4 7 #]).
2. Test each zone as required.
3. Press the [#] key to exit.
1.12 Satellite Siren Service Mode
Enter the four character Installer Code, followed by
[5] and the [#] key (for example, [1 2 3 4 5 #]).
Table 5: Arming/Disarming the System
AWAY Mode STAY Mode 1 STAY Mode 2
Arming
(On)
Press and hold the [#] key until two
beeps are heard.
Or
Enter your code followed by the [#]
key (for example, [2 5 8 0 #]).
Or
To arm all areas, enter your code
followed by [0] and then the [#] key
(for example, [2 5 8 0 0 #]).
Use a code to arm all areas
simultaneously that the code is
assigned to in AWAY Mode without
needing to arm each area individually.
Press and hold the [*] key until two
beeps are heard.
Or
Enter your code followed by the [*]
key (for example, [2 5 8 0 *]).
Press and hold the [0] key until
two beeps are heard.
Disarming
(Off)
Enter your code followed by the [#]
key (for example, [2 5 8 0 #]).
Or
To disarm all areas, enter your code
followed by [0] and then the [#] key
(for example, [2 5 8 0 0 #]).
Use a code to disarm all areas
simultaneously that the code is
assigned without needing to disarm
each area individually.
Press and hold the [*] key until two
beeps are heard (only if no alarm).
Or
Enter your code followed by the [#]
key (for example, [2 5 8 0 #]).
Press the [0] key until two
beeps are heard (only if no
alarm).
Or
Enter your code followed by the
[#] key (for example, [2 5 8 0
#]).

ICP-CC488 | Quick Reference Guide | 1.0 Overview EN | 9
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
1.13 Telephone Monitor Mode (Toggle
On/Off)
1. Enter the four character Installer Code, followed
by [6] and the [#] key (for example, [1 2 3 4 6
#]).
2. Press and hold the [9] key until two beeps are
heard to send a test report.
Table 6: Telephone Monitor Mode
Zone LED Dialing Event
1 Telephone Line Seized
2 Dialing Telephone Number
3 Handshake Received
4 Data Being Sent
5 Kiss-Off Received
None Released Telephone Line
You must exit from Telephone Monitor
Mode to resume normal operations.
1.14 Add/Delete User Code/RF Keyfob
1.14.1 Add A User Code
1. Enter the four character Master Code, followed
by [1] and the [#] key (for example, [2 5 8 0 1
#]).
2. Enter the User Number (1 to 16) you want to
add/change, followed by the [#] key.
3. Enter the new code, followed by the [#] key.
1.14.2 Add RF Keyfob
1. Enter the four character Master Code, followed
by [1] and the [#] key (for example, [2 5 8 0 1
#]).
2. Enter the User Number (9 to 16) you want to
add, followed by the [#] key.
3. Enter the 9-digit RF keyfob ID number, followed
by the [#] key.
1.14.3 Delete a User Code/RF Keyfob
1. Enter the four character Master Code, followed
by [1] and the [#] key (for example, [2 5 8 0 1
#]).
2. Enter the User Number (1 to 16) you want to
delete, followed by the [#] key.
3. Press the [*] key to delete the User Code.
1.15 Change Domestic Telephone
Numbers
1. Enter the four character Installer Code or Master
Code, followed by [2] and the [#] key (for
example, [1 2 3 4 2 #]).
2. Enter the digits for the telephone number.
3. If there is more than one telephone number,
press the [*] key, followed by the [4] key (inserts
break between phone numbers) and repeat Step
2, or press the [#] key to exit.
1.16 Turn Outputs On/Off
1. Enter the four character Master Code, followed
by [5] and the [#] key (for example, [2 5 8 0 5
#]).
2. Enter the Output Number (1 to 3) you want to
toggle on or off.
3. Press the [#] key to toggle on or the [*] key to
toggle off.
4. Press the [#] key to exit.
1.17 Setting Date and Time
1. Enter the four character Master Code, followed
by [6] and the [#] key (for example, [2 5 8 0 6
#]).
2. Enter the day (DD), month (MM), and year (YY)
followed by the hour (HH) and minute (MM).
3. Press the [#] key to exit.
1.18 Day Alarm – Toggle On/Off
Press and hold the [4] key until two beeps are heard.
Day alarm toggles on or off.
1.19 STAY Mode 2 Zones – Program
1. Enter the four character Installer Code or Master
Code, followed by [4] and the [#] key (for
example, [1 2 3 4 4 #]).
2. Enter the Zone Number you want the system to
automatically isolate, followed by the [*] key.
Repeat if more than one zone must be
automatically isolated when armed in STAY
Mode 2.
3. Press the [#] key to exit.

ICP-CC488 | Quick Reference Guide | 1.0 Overview EN | 10
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
1.20 Fault Analysis
1. Press and hold the [5] key until two beeps are
heard.
2. Zone Indicators display FAULT conditions (refer
to Table 7).
3. Press [#] key to exit.
Table 7: Fault Analysis Conditions
Zon
e
LED
Fault Condition Description
1 System Fault Press and hold button [1] to
determine fault.
1 – Battery Fail
2 – Date/Time
3 – RF Rx Jamming
RF Rx Tamper
RF Rx Comm’s Fail
4 – Horn Speaker Fail
5 – Telephone Line Fail
6 – EEPROM Fail
7 – AUX Power Supply Fail
8 – AC Fail
2 RF Low Battery Press and hold button [2] to
determine fault.
Displays zones (1 to 8) that
register RF Low Battery.
3 Zone Tamper Press and hold button [3] to
determine fault.
Displays zones (1 to 8) that
register Zone Tamper.
4 Sensor Watch Press and hold button [4] to
determine fault.
Displays zones (1 to 8) that
register Zone Sensor Watch
5 RF Sensor
Watch
Press and hold button [5] to
determine fault.
Displays zones (1 to 8) that
register Zone RF Sensor Watch
6 Communication
Fail
Press and hold button [6] to
determine fault.
1 – Receiver 1 Fail (Dialer)
2 – Receiver 2 Fail (Dialer)
1.21 Modem Call (Alarm Link)
Press and hold the [6] key until two beeps are heard.
1.22 Latching Outputs (Reset)
Press and hold the [7] key until two beeps are heard.
1.23 Codepad ID/Buzzer Tone
1. Press and hold the [8] key until the desired
buzzer tone is reached.
If the system is partitioned (CC488 only), the
codepad displays a number identifying which
area the codepad belongs (refer to Table 8).
2. Press the [#] key to exit.
Table 8: Codepad ID/Buzzer Tone
Zone LED Codepad Assignment
1 Area 1
2 Area 2
7 Master Partitioned Codepad
1.24 Test Report
Press and hold the [9] key until two beeps are heard.
1.25 Speaker Test
Press and hold the [1] key until two beeps are heard.
The speaker sounds for two sec.
1.26 Bell Test
Press and hold the [2] key until two beeps are heard.
The piezo sounds for two sec.
1.27 Strobe Test (Toggle On/Off)
Press and hold the [3] key until three beeps are heard
to turn the strobe on.
Or
Press and hold the [3] key until two beeps are heard
to turn the strobe off.
1.28 Telco Arm Sequence (Call Forward
On)
1. Enter your four character Installer Code or
Master Code followed by [3] and the [#] key (for
example, [1 2 3 4 3 #]).
2. Press [1] followed by the [#] key.
3. Enter the Call Forward On sequence.
4. Press the [#] key to exit.
1.29 Telco Disarm Sequence (Call
Forward Off)
1. Enter your four character Installer Code or
Master Code followed by [3] and the [#] key (for
example, [1 2 3 4 3 #]).
2. Press [2] followed by the [#] key.
3. Enter the Call Forward Off sequence.
4. Press the [#] key to exit.

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 11
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.0 Programming Parameters
Shaded rows indicate default values.
2.1 Phone Programming
2.1.1 Phone Number 1 - Receiver 1
Location 000 to 015
Default 0
0 – 10 and telephone termination – 0
Anywhere else 0 – 0
2.1.2 Phone Number 2 - Receiver 1
Location 016 to 031
Default 0
0 – 10 and telephone termination – 0
Anywhere else 0 – 0
2.1.3 Handshake Tone For Receiver 1
Location 032
1 HI-LO handshake (contact ID)
2 1400 Hz (Ademco TX @ 1900 Hz)
3 2300 Hz (Sescoa TX @ 1800 Hz)
4 No handshake
5 Pager
2.1.4 Transmission Format For Receiver 1
Location 033
1 Contact ID
2 4 + 2 express
3 FSK 300 Baud
4 Domestic
5 Basic Pager
6 Reserved
7 Reserved
8 Reserved
The Basic Pager option supports only
eight zones due to protocol limitations. If
you use more than eight zones, this
option is not recommended.
If you use the Zone 16, the 4 + 2 Express
and FSK 300 Baud formats are not
recommended because Zone 16 will be
assigned as "0" and some receivers will
not support this zone.
2.1.5 Subscriber ID Number For Receiver 1
Location 034 to 039
Default 0
Right justified
2.1.6 Phone Number 1 - Receiver 2
Location 040 to 055
Default 0
0 – 10 and telephone termination – 0
Anywhere else 0 – 0
2.1.7 Phone Number 2 - Receiver 2
Location 056 to 071
Default 0
0 – 10 and telephone termination – 0
Anywhere else 0 – 0
2.1.8 Handshake Tone For Receiver 2
Location 072
1 HI-LO handshake (contact ID)
2 1400 Hz (Ademco TX @ 1900 Hz)
3 2300 Hz (Sescoa TX @ 1800 Hz)
4 No handshake
5 Pager
2.1.9 Transmission Format For Receiver 2
Location 073
1 Contact ID
2 4 + 2 express
3 FSK 300 Baud
4 Domestic
5 Basic Pager
6 Reserved
7 Reserved
8 Reserved
The Basic Pager option supports only
eight zones due to protocol limitations. If
you use more than eight zones, this
option is not recommended.
If you use the Zone 16, the 4 + 2 Express
and FSK 300 Baud formats are not
recommended because Zone 16 will be
assigned as "0" and some receivers will
not support this zone.
2.1.10 Subscriber ID Number For Receiver 2
Location 074 to 079
Default 0
Right justified
2.1.11 Dialing Format
Location 080
1 Australian DTMF
2 Australian Decadic
3 Alternate DTMF and Decadic (Aust)
4 International DTMF
5 Reversed Decadic
6 Alternate DTMF and Reversed Decadic

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 12
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.1.12 Reserved
Location 081 to 112
2.1.13 Telco Arming Sequence (Call Forward
On)
Location 113 to 142
Default 0
2.1.14 Telco Disarm Sequence (Call Forward
Off)
Location 143 to 158
Default 0
2.1.15 Call Back Telephone Number
Location 159 to 174
Default 0
0 – 10 and telephone termination – 0
Anywhere else 0 – 0
2.1.16 Ring Count
Location 175
Default 8
0 Panel does not answer
1 to 13 No. of rings until panel answers
14 Answering machine bypass 2
15 Answering machine bypass 1
2.1.17 Telephone Line Fail Options
Location 176
Default 0
1 Display FAULT Indicator when telephone line fails
2 Sound alarm when system is armed
4 Sound alarm when system is disarmed
Options 2 and 4 must be used in conjunction with
Option 1 (for example, program 1, 3, 5, or 7)
2.1.18 Dialer Options 1
Location 177
1 Dialer reporting functions allowed
2 Remote arming by telephone allowed
4 Answering machine bypass only when armed
8 Use Bell 103 for FSK format (Disabled – CCITT V21)
2.1.19 Dialer Options 2
Location 178
Default 0
1 Open/Close Reports only if previous alarm
2 Open/Close Reports for STAY Mode 1 and STAY
Mode 2
4 Delay siren until transmission complete
8 Extend handshake wait time from 30 to 60 sec
2.1.20 Dialer Options 3
Location 179
Default 2
1 Set DTMF dialing pulses to 1 digit/sec
2 Lockout telephone line fail alarm
4 Change Decadic dialing to 60/40
8 Reserved
2.1.21 Alarm Link Options
Location 180
1 Upload/download allowed
2 Call back phone number required for upload/download
4 Exit from upload/download connection on alarm
8 Reserved
2.2 Installer Code
Location 181 to 184
Location Default
181 1
182 2
183 3
184 4
2.3 User Code Programming
2.3.1 User Codes
Location 185 to 264
Location Default
User #01 185 2
186 5
187 8
188 0
189 (Authority Level) 10
User #02 190 to 193 15
194 2
User #03 195 to 198 15
199 (Authority Level) 2
User #04 200 to 203 15
204 (Authority Level) 2
User #05 205 to 208 15
209 (Authority Level) 2
User #06 210 to 213 15
214 (Authority Level) 2
User #07 215 to 218 15
219 (Authority Level) 2
User #08 220 0
221 to 223 15
224 (Authority Level) 3
RF User #09 225 to 228 15
229 (Authority Level) 2
RF User #10 230 to 233 15
234 (Authority Level) 2
RF User #11 235 to 238 15
239 (Authority Level) 2
RF User #12 240 to 243 15
244 (Authority Level) 2
RF User #13 245 to 248 15
249 (Authority Level) 2
RF User #14 250 to 253 15
254 (Authority Level) 2
RF User #15 255 to 258 15
259 (Authority Level) 2
RF User #16 260 to 263 15
264 (Authority Level) 2

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 13
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.3.2 Authority Levels
Authority
Levels
Description
0 Arm/Disarm
1 Arm Only
2 Arm/Disarm and Open/Close Reports
3 Arm Only and Close Reports
4 Arm/Disarm and Code Required to Isolate
6 Arm/Disarm and Open/Close Reports and
Code Required to Isolate
8 Master Code and Arm/Disarm
10 Master Code and Arm/Disarm and
Open/Close Reports
12 Master Code and Arm/Disarm and Code
Required to Isolate
14 Master Code and Arm/Disarm and Code
Required to Isolate and Open/Close Reports
2.4 Day Alarm Zones
Locatio
n
265
Default 0
1 Zone 1
2 Zone 2
4 Zone 3
8 Zone 4
2.5 EOL Resistor Value
Location 266
0 No EOL
1 1k
2 1k5
3 2k2
4 3k3
5 3k9
6 4k7
7 5k6
8 6k8
9 10k
10 12k
11 22k
12 Reserved
13 Reserved
14 Split EOL (3k3/6k8 with tamper 1k)
15 Split EOL (3k3/6k8)
2.6 Zone Programming
2.6.1 Zone Defaults
Location 267 to 378
Location Default
Zone #01 (Default – Delay-1)
Zone Type 267 2
Zone Pulse Count 268 0
Zone Pulse Count Time 269 0
Zone Options 1 270 1
Zone Options 2 271 14
Report Code 272 1
Dialer Options 273 1
Zone #02 (Default – Handover)
Zone Type 274 1
Zone Pulse Count 275 0
Zone Pulse Count Time 276 0
Zone Options 1 277 1
Zone Options 2 278 14
Report Code 279 1
Dialer Options 280 1
Zone #03 (Default – Handover)
Zone Type 281 1
Zone Pulse Count 282 0
Zone Pulse Count Time 283 0
Zone Options 1 284 1
Zone Options 2 285 14
Report Code 286 1
Dialer Options 287 1
Zone #04 (Default – Handover)
Zone Type 288 1
Zone Pulse Count 289 0
Zone Pulse Count Time 290 0
Zone Options 1 291 1
Zone Options 2 292 14
Report Code 293 1
Dialer Options 294 1
Zone #05 (Default – Instant)
Zone Type 295 0
Zone Pulse Count 296 0
Zone Pulse Count Time 297 0
Zone Options 1 298 1
Zone Options 2 299 14
Report Code 300 1
Dialer Options 301 1
Zone #06 (Default – Instant)
Zone Type 302 0
Zone Pulse Count 303 0
Zone Pulse Count Time 304 0
Zone Options 1 305 1
Zone Options 2 306 14
Report Code 307 1
Dialer Options 308 1
Zone #07 (Default – Instant)
Zone Type 309 0
Zone Pulse Count 310 0
Zone Pulse Count Time 311 0
Zone Options 1 312 1
Zone Options 2 313 12
Report Code 314 1
Dialer Options 315 1

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 14
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
Location 267 to 378 (Continued)
Zone #08 (Default – 24 hr Tamper)
Zone Type 316 9
Zone Pulse Count 317 0
Zone Pulse Count Time 318 0
Zone Options 1 319 1
Zone Options 2 320 12
Report Code 321 1
Dialer Options 322 1
Zone #09 (Default – Instant)
Zone Type 323 15
Zone Pulse Count 324 0
Zone Pulse Count Time 325 0
Zone Options 1 326 1
Zone Options 2 327 14
Report Code 328 1
Dialer Options 329 1
Zone #10 (Default – Instant)
Zone Type 330 15
Zone Pulse Count 331 0
Zone Pulse Count Time 332 0
Zone Options 1 333 1
Zone Options 2 334 14
Report Code 335 1
Dialer Options 336 1
Zone #11 (Default – Instant)
Zone Type 337 15
Zone Pulse Count 338 0
Zone Pulse Count Time 339 0
Zone Options 1 340 1
Zone Options 2 341 14
Report Code 342 1
Dialer Options 343 1
Zone #12 (Default – Instant)
Zone Type 344 15
Zone Pulse Count 345 0
Zone Pulse Count Time 346 0
Zone Options 1 347 1
Zone Options 2 348 14
Report Code 349 1
Dialer Options 350 1
Zone #13 (Default – Instant)
Zone Type 351 15
Zone Pulse Count 352 0
Zone Pulse Count Time 353 0
Zone Options 1 354 1
Zone Options 2 355 14
Report Code 356 1
Dialer Options 357 1
Location 267 to 378 (Continued)
Zone #14 (Default – Instant)
Zone Type 358 15
Zone Pulse Count 359 0
Zone Pulse Count Time 360 0
Zone Options 1 361 1
Zone Options 2 362 14
Report Code 363 1
Dialer Options 364 1
Zone #15 (Default – Instant)
Zone Type 365 15
Zone Pulse Count 366 0
Zone Pulse Count Time 367 0
Zone Options 1 368 1
Zone Options 2 369 14
Report Code 370 1
Dialer Options 371 1
Zone #16 (Default – Instant)
Zone Type 372 15
Zone Pulse Count 373 0
Zone Pulse Count Time 374 0
Zone Options 1 375 1
Zone Options 2 376 14
Report Code 377 1
Dialer Options 378 1
2.6.2 Zone Types
Zone Type Description
0 Instant
1 Handover
2 Delay-1
3 Delay-2
4 Reserved
5 Reserved
6 24 hr Medical
7 24 hr Panic
8 24 hr Hold-up
9 24 hr Tamper
10 Reserved
11 Keyswitch
12 24 hr Burglary
13 24 hr Fire
14 Chime
15 Not Used
2.6.3 Zone Pulse Count
Use the pulse count to program how many pulses (0
to 15) need to be registered within the pulse count
time to activate an alarm.

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 15
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.6.4 Zone Pulse Count Time
Option 20 ms Loop
Response Time
Option 150 ms Loop
Response Time
0 0.5 sec 8 20 sec
1 1 sec 9 30 sec
2 2 sec 10 40 sec
3 3 sec 11 50 sec
4 4 sec 12 60 sec
5 5 sec 13 90 sec
6 10 sec 14 120 sec
7 15 sec 15 200 sec
2.6.5 Zone Options 1
Option Description
1 Lockout siren/dialer
2 Delay Alarm report
4 Silent alarm
8 Sensor watch
2.6.6 Zone Options 2
Option Group
1 Isolated in STAY Mode 1
2 Zone isolation allowed
4 Forces arming allowed
8 Zone Restore Report allowed
2.6.7 Zone Dialer Options
Option Description
0 No zone reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.6.8 Keyswitch Zone Options
The keyswitch zone options replace Zone Options 1
only for the zones that were programmed to operate
as a keyswitch zone.
Option Description
0 Latching arm and disarm in AWAY Mode
1 Latching arm in AWAY Mode
2 Latching disarm from AWAY Mode or STAY
Mode
4 Latching arm and disarm in STAY Mode
5 Latching arm in STAY Mode
6 Latching disarm from STAY Mode
8 Momentary arm and disarm in AWAY Mode
9 Momentary arm in AWAY Mode
10 Momentary disarm from AWAY Mode or STAY
mode
12 Momentary arm and disarm in STAY Mode
13 Momentary arm in STAY Mode
14 Momentary disarm from STAY Mode
2.7 Swinger Programming
2.7.1 Swinger Shutdown Count For Siren
Location 379
Default 3
1 to 15 Number of times siren operates until lockout
2.7.2 Swinger Shutdown Count For Dialer
Location 380
Default 6
1 to 15 Number of times dialer operates until lockout
2.8 Zone Status Programming
2.8.1 Zone Status – Zone Tamper Report
Location 381 to 382
Location Default
Zone Tamper Report 381 0
Zone Tamper Restore Report 382 0
2.8.2 Zone Status – Walk Test Report
Location 383 to 384
Location Default
Walk Test Start Report 383 0
Walk Test End Report 384 0
2.8.3 Zone Status – Bypass Report
Location 385 to 386
Location Default
Zone Bypass Report 385 9
Zone Bypass Restore Report 386 8
2.8.4 Zone Status – Trouble Report
Location 387 to 388
Location Default
Zone Trouble Report 387 2
Zone Trouble Restore Report 388 3
2.8.5 Zone Status – Sensor Watch Report
Location 389 to 390
Location Default
Sensor Watch Report 389 4
Sensor Watch Restore Report 390 5
2.8.6 Zone Status – Alarm Restore Code
Location 391
Default 14
2.8.7 Zone Status Reporting Options
Location 392
0 No zone status reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.9 RF Programming
2.9.1 RF Supervision Time
Location 393
Default 0
Increments of 6 hrs. (0 to 90 hrs.)
2.9.2 RF Low Battery Report
Location 394 to 395
Location Default
RF Low Battery Report 395 6
RF Low Battery Restore Report 395 8

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 16
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.9.3 RF Receiver Trouble Report
Location 396 to 397
Location Default
RF Receiver Trouble Report
(tens digit)
396 7
RF Receiver Trouble Report
(units digit)
397 9
2.9.4 RF Receiver Trouble Restore Report
Location 398 to 399
Location Default
RF Receiver Trouble Restore
Report (tens digit)
398 7
RF Receiver Trouble Restore
Report (units digit)
399 11
2.9.5 RF Dialer Options
Location 400
0 No Zone Status Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.10 Report Programming
2.10.1 Open/Close Reports
Location 401 to 402
Location Default
Open Report 401 11
Close Report 402 12
2.10.2 Open/Close Reporting Options
Location 403
0 No Open/Close Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.10.3 Codepad Duress Report
Location 404
Default 6
2.10.4 Codepad Panic Report
Location 405 to 406
Location Default
Tens digit 405 7
Units digit 406 15
2.10.5 Codepad Fire Report
Location 407 to 408
Location Default
Tens digit 407 7
Units digit 408 14
2.10.6 Codepad Medical Report
Location 409 to 410
Location Default
Tens digit 409 7
Units digit 410 13
2.10.7 Codepad Reporting Options
Location 411
0 No Codepad Alarm Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.11 System Status Programming
2.11.1 System Status – AUX Power Supply
Fail Report
Location 412 to 413
Location Default
Tens digit 412 10
Units digit 413 3
2.11.2 System Status – AUX Power Supply
Fail Restore Report
Location 414 to 415
Location Default
Tens digit 414 10
Units digit 415 8
2.11.3 System Status – AC Fail Report
Location 416 to 417
Location Default
Tens digit 416 10
Units digit 417 2
2.11.4 System Status – AC Fail Restore Report
Location 418 to 419
Location Default
Tens digit 418 10
Units digit 419 7
2.11.5 System Status – Low Battery Report
Location 420 to 421
Location Default
Tens digit 420 10
Units digit 421 1
2.11.6 System Status – Low Battery Restore
Report
Location 422 to 423
Location Default
Tens digit 422 10
Units digit 423 6
2.11.7 System Status – Access Denied (Code
Retry)
Location 424 to 426
Location Default
Code retry limit (0 – unlimited) 424 6
Tens digit 425 7
Units digit 426 12

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 17
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.11.8 System Status Reporting Options
Location 427
0 No Codepad Alarm Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.12 Test Report Programming
2.12.1 Test Report Time (Automatic)
Location 428 to 434
Location Default
Hour of day (tens digit) 428 0
Hour of day (units digit) 429 0
Minute of day (tens digit) 430 0
Minute of day (units digit) 431 0
Test report (tens digit) 432 7
Test report (units digit) 433 1
Repeat interval in days 434 0
2.12.2 Test Reporting Dialer Options
Location 435
0 No Codepad Alarm Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
2.13 Output Programming
2.13.1 Outputs
Location 436 to 465
Location Default
Output 1 (Default – Horn
Speaker)
Event Code 436 1
Event Code 437 14
Polarity 438 0
Time Base 439 0
Time Base Multiplier 440 0
Time Base Multiplier 441 0
Output 2 (Default – Fire Alarm With Verification)
Event Code 442 2
Event Code 443 7
Polarity 444 10
Time Base 445 2
Time Base Multiplier 446 1
Time Base Multiplier 447 5
Strobe Output (Default – Strobe – Reset After 8
hrs.)
Event Code 448 2
Event Code 449 0
Polarity 450 6
Time Base 451 4
Time Base Multiplier 452 0
Time Base Multiplier 453 8
Relay Output (Default – Sirens Running)
Event Code 454 1
Event Code 455 15
Polarity 456 1
Time Base 457 0
Time Base Multiplier 458 0
Time Base Multiplier 459 0
Codepad Buzzer (Default – Entry/Exit Warning and Day
Alarm)
Event Code 460 0
Event Code 461 13
Polarity 462 2
Time Base 463 1
Time Base Multiplier 464 0
Time Base Multiplier 465 1

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 18
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.13.2 Event Codes
Event
Code
Description
0 0 EDMSAT – satellite siren (output 1 only)
0 1 System armed
0 2 System disarmed
0 3 Armed in STAY mode
0 4 Armed in AWAY mode
0 5 Pre-arming alert
0 6 Exit Warning (all zones sealed) and entry warning
0 7 Exit Warning
0 8 Exit Warning finished
0 9 Kiss-off after end of Exit Time
0 10 Reserved
0 11 Entry warning
0 12 Entry warning and day alarm resetting
0 13 Exit Warning and entry warning and day alarm
resetting
0 14 Day alarm resetting
0 15 Day alarm latching
1 0 Day alarm enabled
1 1 Telephone line fail
1 2 Kiss-off received
1 3 AUX Power Supply fail
1 4 AC fail
1 5 Low battery
1 6 Horn speaker fail
1 7 Sensor watch alarm
1 8 Codepad medical alarm
1 9 Codepad fire alarm
1 10 Codepad panic alarm
1 11 Codepad duress alarm
1 12 Access denied (code retries)
1 13 Reserved
1 14 Horn speaker (output 1 only)
1 15 Sirens running
2 0 Strobe
2 1 Silent alarm
2 2 Alarm in STAY Mode
2 3 Alarm in AWAY Mode
2 4 System fault
2 5 Fire alarm (resetting)
2 6 Fire alarm (latching)
2 7 Fire alarm (verification)
2 8 Remote control 1
2 9 Remote control 2
2 10 Remote control 3
2 11 Radio control output 1
2 12 Radio control output 2
2 13 Radio control output 1 - not in AWAY Mode
2 14 Radio control output 2 - not in AWAY Mode
2 15 Communications fail after 3 attempts
2.13.2 Event Codes (continued)
Event
Code
Description
3 0 Communications fail
3 1 Dialer disabled
3 2 Dialer active (on-line)
3 3 Ring detect
3 4 Codepad panic (multi-break)
3 5 Mimic zone 1
3 6 Mimic zone 2
3 7 Mimic zone 3
3 8 Mimic zone 4
3 9 Mimic zone 5
3 10 Mimic zone 6
3 11 Mimic zone 7
3 12 Mimic zone 8
3 13 Reserved
3 14 Reserved
3 15 Reserved
4 0 Reserved
4 1 Reserved
4 2 Reserved
4 3 Reserved
4 4 Reserved
4 5 Chime
4 6 Zone not sealed
4 7 Zone not sealed after Exit Time
4 8 Reserved
4 9 AC MAINS cycle (60 Hz or 50 Hz)
4 10 Area 1 – zone unsealed
4 11 Area 2 – zone unsealed
4 12 Reserved
4 13 Reserved
4 14 Reserved
4 15 Reserved
5 0 Reserved
5 1 Reserved
5 2 Area 1 in alarm
5 3 Area 2 in alarm
5 4 Reserved
5 5 Reserved
5 6 Area 1 armed
5 7 Area 2 armed
5 8 Reserved
5 9 Reserved
5 10 Area 1 disarmed
5 11 Area 2 disarmed
5 12 Reserved
5 13 Reserved
5 14 Any areas armed
5 15 Any areas disarmed
6 0 Area 1 codepad data terminal
6 1 Area 2 codepad data terminal

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 19
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.13.3 Polarity (Modes)
Option Description
0 Output not used
1 Normally open, going low
2 Normally open, pulsing low
3 Normally open, one shot low
4 Normally open, one shot low (reactivate)
5 Normally open, one shot low (can reset)
6 Normally open, one shot low (alarm)
7 Normally open, latching low
8 Normally low, going open
9 Normally low, pulsing open
10 Normally low, one shot open
11 Normally low, one shot open (reactivate)
12 Normally low, one shot open (can reset)
13 Normally low, one-shot open (alarm)
14 Normally low, latching open
2.13.4 Time Base
Option Description
1 200 ms
2 1 sec
3 1 min
4 1 hr
2.13.5 Time Base Multiplier
Enter a value between 01 and 99.
2.13.6 One Shot Mode
When you program the output polarity as one shot,
the time base is multiplied by the time base
multiplier. (For example, if the time base – 2 and the
multiplier – 05, the output operates for 10 sec)
2.13.7 Pulsing Mode
When you program the output polarity as pulsing,
the time base becomes the ON time and the
multiplier becomes the OFF time. The OFF time is
the time base x the multiplier. (For example, if you
want the output to pulse 1 sec ON and 5 sec OFF,
you would program time base as one and the
multiplier as five.)
2.14 Time Programming
2.14.1 Entry Time 1
Location 466 to 467
Location Default
Increments of 1 sec (0 to 15 sec) 466 4
Increments of 16 sec (0 to 240 sec) 467 1
2.14.2 Entry Time 2
Location 468 to 469
Location Default
Increments of 1 sec (0 to 15 sec) 468 8
Increments of 16 sec (0 to 240 sec) 469 2
2.14.3 Exit Time (AWAY/STAY Modes)
Location 470 to 471
Location Default
Increments of 1 sec (0 to 15 sec) 470 12
Increments of 16 sec (0 to 240
sec)
471 3
2.14.4 Entry Guard Time For STAY Mode
Location 472 to 473
Location Default
Increments of 1 sec (0 to 15 sec) 472 0
Increments of 16 sec (0 to 240
sec)
473 0
2.14.5 Delay Alarm Report Time
Location 474 to 475
Location Default
Increments of 1 sec (0 to 15 sec) 474 0
Increments of 16 sec (0 to 240
sec)
475 0
2.14.6 Sensor Watch Time
Location 476 to 477
Location Default
Increments of days (tens digit) 476 0
Increments of days (units digit) 477 0
2.14.7 Codepad Lockout Time
Location 478
Default 0
Increments of 10 sec (0 sec to 150 sec)
2.14.8 Siren Run Time
Location
479
Default 5
Increments of 1 min (0 min to 15 min)
2.14.9 Siren Sound Rate
Location 480
Default 7
0 – Slowest frequency
15 – Fastest frequency
2.14.10 Auto Arming Pre-Alert Time
Location 481
Default 1
Increments of 5 min (0 min to 75 min)
2.14.11 Auto Arming Time
Location 482 to 485
Location Default
Hour of the day (tens digit) 482 0
Hour of the day (units digit) 483 0
Minute of the day (tens digit) 484 0
Minute of the day (units digit) 485 0

ICP-CC488 | Quick Reference Guide | 2.0 Programming Parameters EN | 20
Bosch Security Systems, Inc. | 12/08 | F01U089458-02
2.14.12 Auto Disarming Time
Location 486 to 489
Location Default
Hour of the day (tens digit) 486 0
Hour of the day (units digit) 487 0
Minute of the day (tens digit) 488 0
Minute of the day (units digit) 489 0
2.14.13 Kiss-Off Wait Time
Location 490
Default 3
Increments of 500 ms (500 ms – 8 sec)
2.14.14 Speaker Beep Volume
Location 491
Default 13
0
15
No Beeps
Loudest Beeps
2.15 Options Programming
2.15.1 System Options 1
Location 492
1 Bosch Security Systems smart lockout allowed
2 Horn speaker monitor
4 Strobe indication for radio arm/disarm
8 Assign button 4 on transmitter to operate STAY
Mode 1
2.15.2 System Options 2
Location 493
Default 0
1 Codepad panic to be silent
2 Codepad fire to be silent
4 Codepad medical to be silent
8 Access denied (code retries) to be silent
2.15.3 System Options 3
Location 494
1 AC fail after 1 hr (Disabled – after 2 min)
2 Ignore AC fail
4 Pulse count handover allowed
8 Handover delay to be sequential
2.15.4 System Options 4
Location 495
Default 0
1 Panel to power up disarmed (if power reset)
2 Arm/disarm tracking on power up
4 Internal crystal to keep time
8 Night arm station or RE005 installed
2.15.5 Consumer Options 1
Location 496
Default 0
1 Test reports only when armed
2 Test report after siren reset
4 Auto arm in STAY Mode 1
8 STAY indicator to display day alarm status
2.15.6 Consumer Options 2
Location 497
1 Codepad displays extinguish after 60 sec
2 Single button arming allowed (AWAY/STAY Modes 1
and 2)
4 Single button disarming allowed (STAY Modes 1 and
2)
8 Alarm memory reset on disarm
2.15.7 Consumer Options 3
Location 498
1 Codepad fault beeps allowed
2 Use digit 3 for codepad duress alarm (instead of
digit 9)
4 Alarms activate sirens and strobe outputs in STAY
Modes 1 and 2
8 Zone tamper alarms to be silent
2.15.8 Radio Input Options
Location 499
Default 0
1 DSRF Receiver
2 Latching keyswitch input
3 Momentary keyswitch input
4 Reserved
2.15.9 Partitioning Options 1
Location 500
Default 0
1 First to Open/Last to Close reporting armed
2 Area 1 codepad connected to data terminal
4 Reset sirens from any area allowed
8 Master codepad to display AUX indicator when online
2.15.10 Partitioning Options 2
Location 501
Default 0
1 Lock area 1 to Receiver 1 and lock area 2 to Receiver 2
2 User codes allowed to arm/disarm both areas at same
time (Code [0][#])
4 Reserved
8 Reserved
