Introduction
The CM746B 4G CAT 1 radio module allows you to inter-
face compatible security control panels to the CAT 1 cellu-
lar network providing a high reliability primary or backup
reporting path.
The CAT 1 network is widely supported by all carriers
however if the unit is being installed in a remote location,
you should insure the carrier you are using has sufficient
coverage (signal) for reliable performance. SIM’s must be
on a plan that includes a data allowance.
The unit is designed to plug onto the main control panel
PCB using the supplied plastic standoffs.
Module Compatibility
Panels Supported Minimum Firmware
Version Required
Solution 6000 Series 2.51.04
Table 1: Module Compatibility
Getting Started
There are four main steps required to configure the
CM746B for reporting to the control room. The instruc-
tions assume that you already have purchased a SIM card
and that the card has been charged with credit and acti-
vated on the network if necessary.
1. Install the SIM card into the lower card socket. (SIM1)
2. Install the CM746B hardware on the control panel.
3. Install the antenna.
4. Configure the module’s features and parameters.
5. Configure the control panel for reporting.
Step 1 - Installing the Radio Module
Ensure that the panel is powered off before proceeding.
Plug the 3 short plastic standoffs into the module and
then plug it onto the Expansion Port header pins on the
panel as shown in. Install the SIM card into the SIM 1 card
position.
Figure 1: CM746B Module Installed On Solution 6000
Step 2 - Installing the Antenna
Remove the knockout in the top of the cabinet and pass
the antenna lead through the hole ensuring the antenna
is on the outside of the cabinet. Screw the lead to the
socket on the radio module before powering the panel.
Step 3 - Configuring The Module
Once powered the radio will attempt to connect to the
network. This may take up to ten minutes to complete.
During this time the online indicator on the module will
be on solid. Once the radio has registered the online indi-
cator will begin to flash and the signal strength indicators
will show the current signal condition.
Experiment with the position of the antenna to find the
best signal strength before fixing it in place.
Step 4 - Configuring The Panel Reporting
Reporting configuration will vary depending on the
required options and whether or not the module is to be
used as the primary or secondary reporting route.
Configure the required reporting formats in MENU 5-4-0
and 5-4-1. The system can be configured to report to the
base station in Conettix IP, SIA IP, CSV or to selected phone
numbers via SMS.
All reporting scenarios are configured by varying the pro-
gramming of the reporting format and reporting routes
configurations options.
Module Indicators
The module includes 7 led indicators which are used to
show status and signal strength. See table below.
Module Indicators
Indicator Meaning
TX Module Transmitting Data
RX Module Receiving Data
Online ON Steady = Not Registered On Network
Pulsing = Registered On Network
Signal 1 Signal strength indicators show relative
signal level at the radio. Signal indicator 1
on indicates weak signal and all 4 indicators
on indicates stronger signal strength.
Signal 2
Signal 3
Signal 4
Table 2: GSM/GPRS Indicator Meanings

CM746B Installer Reference Guide
3
Bosch Security Systems 03/21 CM746BIRG FTR1.0
Supported Reporting Formats
Version 2.51.04 or higher of the Solution 6000 panel firm-
ware is required to support the CM746B.
The following reporting formats are currently supported
by the module.
SMS Format via GSM
CSV-IP Format via GPRS
Conettix Format via GPRS
SIA IP Format via GPRS
MyAlarm Format via GPRS
There is no support in the 4G module for Contact ID (CID)
over GSM.
CLI Trigger Output Control
The CLI trigger tables in MENU 6-5-5-0 and 6-5-6-1 can be
used to store a list of telephone numbers that can trigger
an output on the control panel. If you call the GSM unit
from a telephone number that matches a number in the
CLI list then the appropriate output will be operated.
An output needs to be programmed with an event type of
CLI Trigger and event assignment of 1 or 2 depending on
which table is to be checked.
Simply call the GSM unit from a telephone number that is
programmed in the CLI trigger list to activate the output.
Module Status
MENU 6-5-0 can be used to obtain various information on
the radio module. The following information is currently
available.
1) Connected Network
2) Signal Strength in dB
3) IMEI Number
4) Radio Firmware Revision
5) SIM Card Present
SMS Remote Control
The SMS control option in MENU 6-5-6 allows you to
program up to 10 telephone numbers that are allowed to
send SMS commands to the GSM unit.
Numerous commands can be sent to the panel using the
SMS control functions including arming/disarming areas,
controlling outputs and doors or checking system status.
The panel can also be requested to send a confirmation
SMS if required.
The control messages must be sent to the SIM phone
number.
The SMS Control phrase table shows the correct method
for constructing the SMS messages. Note there are no
spaces between the fields only commas as shown.
Smart Device Apps
Smart device apps are available to enhance alarm report-
ing and provide real time control of system areas, outputs
and doors etc. More information can be found in the app
stores or on the MyAlarm web site at www.myalarm.com.
au.
SMS Control Smartphone App
The MyAlarm SMS Control App for iOS and Android
devices is now available and can be used to simplify the
configuration and sending of SMS control messages.
You can search for the MyAlarm SMS Control app in the
app store or scan the QR codes below using your device’s
barcode reader for a direct link to the app.
Scan Here (iOS Version)
MyAlarm
SMS Control iFob Control

CM746B Installer Reference Guide
4Bosch Security Systems 03 /21 CM746BIRG FTR1.0
Scan Here (Android Version)
SIM Balance Recharge Reminder Function
In Solution 6000 version 2.20 firmware, a new SIM ex-
pire parameter can be added to the to the SIMBAL setup
command when using the GSM module with a pre-paid
SIM card. When configured the control panel will send a
reminder to the designated SIM owner prompting them
to recharge the SIM before it expires.
The SIM Balance string would include the following pa-
rameters including the new optional reminder in weeks
(01 to 52 weeks).
The MyAlarm SMS Control smart device app has been
updated to include support for this new feature. For more
information refer to the example below.
User Code
This field is used to enter your PIN (eg. 2580).
Command Header
The command header field is fixed - SIMBAL.
Access Number
Enter the communication provider’s access number for
SIM card balance enquiries.
• Optus = 9999
• Vodafone = 1555 / 1512
• Telstra = #100#
• Virgin = 225
Text
Enter the text required by the communication providers
to obtain your SIM card balance (Max = 16 characters). In
Australia, examples may change and include:
• Optus = Balance
• Vodafone = Blank Message
• Telstra = Voice Call
• Virgin = Bal
Preamble
Enter text to search for the credit remaining on your SIM
card (eg. if Vodafone Australia displays‘U’ve Remaining:
365 day: $35.53 Exp: 09/11/2015’ enter ‘Day:’ as the pream-
ble).
Minimum Amount
Enter the minimum balance to filter GSM module SIM card
balance enquiries. This allows the GSM module to only
forward an SMS balance alert message to your mobile
telephone when the SIM card balance falls below the
minimum amount set here.
Days
This parameter sets how often the GSM module will
automatically request a SIM card balance. This can be set
between 001 and 255 days / 000 = disabled.
Mobile
This parameter allows you to program which mobile
telephone number the GSM module will forward the SIM
card balance enquiry of the GSM module to.
Expire Reminder
Enter the number of weeks for the GSM module to remind
you to recharge your GSM SIM card (01 to 99 weeks / 00 =
disabled).
Example
The example below is requesting a SIM Balance of the SIM
card connected to the Vodafone network (Australia) with a
reminder that the credit available on the SIM card requires
a recharge in 25 weeks using a 180 day prepaid SIM card.
The SIMBAL requests a balance enquiry every two days
when the balance falls below $20.00.
SIMBAL,2580,1555,Day,$20.00,002,0414123456,25
After 25 weeks, the GSM module will send the following
SMS, ‘SIM is about to expire please recharge immediately’.
Information in this example is correct at time of print-
ing. Check with your telco carrier as these options may
change.

CM746B Installer Reference Guide
5
Bosch Security Systems 03/21 CM746BIRG FTR1.0
Description SMS String
Arming / Disarming Areas
Turning Area 1 On <User Code>,AREA,1,ON
Turning Area 1 On With Confirmation <User Code>,AREA,1,ON,CONFIRM
Turning Area 1 Part 1 On <User Code>,AREA,1,PART 1
Turning Area 1 Part 1 On With Confirmation <User Code>,AREA,1,PART 1,CONFIRM
Turning Area 1 Part 2 On <User Code>,AREA,1,PART 2
Turning Area 1 Part 2 On With Confirmation <User Code>,AREA,1,PART 2,CONFIRM
Turn Multiple Areas On <User Code>,AREA,1,2,3,4,ON
Turn All Areas On That the User Belongs To <User Code>,AREA,ON
Turning Area 1 OFF <User Code>,AREA,1,OFF
Turning Area 1 OFF With Confirmation <User Code>,AREA,1,OFF,CONFIRM
Check Area Status <User Code>,AREA,1,STATUS
Check Status Of Multiple Areas <User Code>,AREA,1,2,3,STATUS
Turning Outputs On/Off
Turn Output 1 On <User Code>,OUTPUT,1,ON
Turn Output 1 On With Confirmation <User Code>,OUTPUT,1,ON,CONFIRM
Turn Multiple Outputs On <User Code>,OUTPUT,1,2,3,4,ON
Turn Multiple Outputs On With Confirmation <User Code>,OUTPUT,1,2,3,4,ON,CONFIRM
Turning Output 1 OFF <User Code>,OUTPUT,1,OFF
Turning Output 1 OFF With Confirmation <User Code>,OUTPUT,1,OFF,CONFIRM
Turning Multiple Outputs OFF <User Code>,OUTPUT,1,2,3,4,OFF
Turning Multiple Outputs OFF With Confirmation <User Code>,OUTPUT,1,2,3,4,OFF,CONFIRM
Check Output Status <User Code>,OUTPUT,1,STATUS
Check Status Of Multiple Outputs <User Code>,OUTPUT,1,2,3,4,STATUS
Locking and Unlocking Doors
Unlock Door 1 <User Code>,DOOR,1,UNLOCK
Unlock Door 1 With Confirmation <User Code>,DOOR,1,UNLOCK,CONFIRM
Unlock Multiple Doors <User Code>,DOOR,1,2,3,UNLOCK
Unlock Multiple Doors With Confirmation <User Code>,DOOR,1,2,3,UNLOCK,CONFIRM
Lock Door 1 <User Code>,DOOR,1,LOCK
Lock Door 1 With Confirmation <User Code>,DOOR,1,LOCK,CONFIRM
Lock Multiple Doors <User Code>,DOOR,1,2,3,LOCK
Lock Multiple Doors With Confirmation <User Code>,DOOR,1,2,3,LOCK,CONFIRM
Check Status Of A Door <User Code>,DOOR,1,STATUS
Check Status Of Multiple Doors <User Code>,DOOR,1,2,3,STATUS
Check System Status <User Code>,SYSTEM,STATUS
SIM Balance Check - Must have been configured under site settings
Check Current SIM Balance <User Code>,SIMBAL,<Access Number>,<Text.,
<Preamble>,<Min Amount>,<Days>,<Mobile>,<Expire
Reminder>
Table 3: GSM SMS String Commands

CM746B Installer Reference Guide
6Bosch Security Systems 03 /21 CM746BIRG FTR1.0
GPRS Using The CM746B 4G Radio
The APN Server Name, APN User Name and APN Password
menu’s need to be configured before the 4G radio can
establish a GPRS data connection with the telco provider.
Applications such as the MyAlarm iFob control app or
reporting back to base over the GPRS connection require
a data connection.
Devices > GSM/GPRS Module >
APN Server Name MENU 6-5-7
APN (Access Point Name)
Enter the appropriate name of your 3G/4G GPRS mobile
network provider to connect to the public Internet. For
example Telstra APN=telstra.wap, Optus APN=yesinternet,
Vodafone APN=live.vodafone.com
APN Server Name Gi1
Press  OK to SAVE
Devices > GSM/GPRS Module >
APN Username MENU 6-5-8
This can be used to identify you on a network however is
mostly left BLANK.
APN Username Gi1
Press  OK to SAVE
Devices > GSM/GPRS Module >
APN Password MENU 6-5-9
A secret word or phrase that must be used to gain admis-
sion to the network however mostly left BLANK.
APN Password Gi1
Press  OK to SAVE
i
Note
No SIM card is supplied with this module. A SIM card
is required for operation. It is the customers responsi-
bility to make sure that SIM credit is charged and that
sufficient data is available at all times. The SIM card
should be installed in the lower SIM socket (SIM 1).
Optional AN110 High Gain Outdoor Antenna
For installations where adequate signal strength is not
available using the supplied indoor antenna, an optional
outdoor antenna can be used.
The AN110 antenna offers up to 10dBi peak gain (4G) and
is supplied with a mounting bracket, mast U clamp and a
15m RG58 cable with N-male to SMA - male connectors.
AN110 Specifications
Frequency Range 698~960Mhz/1710~2700Mhz
Impedance 50 Ohms
VSWR <1.5
Gain 10dBi Peak
Poloariztion Vertical
Radiation Omni Directional
Colour White
Operating Temp -40 ~ +60 Celcius
Size 246mm x 75mm x 82mm
Table 4: AN110 Specifications
Figure 2: AN110 Outdoor Antenna And Cable

CM746B Installer Reference Guide
7
Bosch Security Systems 03/21 CM746BIRG FTR1.0
CM746B Specifications
Part Number: CM746B - 4G GSM/GPRS/SMS Radio Module
Reporting Formats:
SMS via GSM , CSV-IP via GPRS and Conettix Format via GPRS are supported.
MyAlarm iFob Control and MyAlarm SMS Control apps and SolutionLink RAS are supported.
The CM746B does NOT support Contact ID (CID) over GSM.
Operating Voltage: Supplied by Panel - Derate the maximum available 12V accessory power from the panel by
100ma when the module is fitted.
Compatible With: Solution 6000 Control Panel (Firmware V2.51.04 or higher)
SIM Card Type: Standard size SIM cards
The SIM card should be installed in SIM 1 socket.
Radio: 4G Quectel EG91 - CAT-1 Network (3G Fallback)
Antenna: Quad Band Omni Directional Magnetic Base Antenna with integrated lead and SMA Con-
nector. 3dbi gain - 50 ohm. Optional high gain outdoor antenna is available. (P/N AN110)
Module Connection:
The CM746B is mounted directly to the expansion port on the control panel PCB. Three
plastic standoffs are supplied to support the module and these should be connected to the
control panel before installing the CM746B.
Operating
Environment: 0˚ to 55˚C RH 5 to 85% at 30˚C non-condensing.
Warranty: 3 years from date of manufacture (return to base)
In the interest of ongoing product development this document is subject to change without notice.

Bosch Security Systems
Level 2, 21 Solent Circuit
Baulkham Hills, NSW 2153
Australia
Phone: [phone]
www.boschsecurity.com.au
© 2021 Bosch Security Systems
BLCM746BIRG
Issue FTR1.0
