Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 1 of 14
Table of Contents
1. MountingTips 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1. Connections and DIP switch settings 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2. Mounting the Fireray 50/100RV 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3. Mounting the prism reflector 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4. Connection 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Start-Up 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1. Setting up the detector 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2. Aligning the detector 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3. System test 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Tips on Maintenance and Service 9. . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Technical Data 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Additional Documentation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. Appendices 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1. Installation protocol 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2. Fault diagnosis 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.3. Notes 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 2 of 14
1. Mounting Tips
Usually, the detector and the reflector are installed at the same height and oriented
towards each other. The relatively broad angle of the IR beam eases adjustment
and guarantees reliable long-term stability.
The mounting surface for the detector must be firm and vibration-free. Metal
supports that can be influenced by heat or cold are not suitable for installation.
The detector must be installed such that sunlight and artificial light do not beam
directly into the detector’s lenses. Normal environmental light conditions have no
effect on the IR beam and the evaluation.
Mount the reflector on a solid surface at the permissible distance. Ensure that the
light beam meets the reflector on the vertical.
The reflectors must not be mounted on reflective surfaces such as glass or plain
sheet surfaces. Additional reflections lead to malfunctions.
For protection against radio interference, use a shielded cable. When you are
installing the cable, possible sources of disturbance must be circumvented and the
cable must be protected against mechanical damage.
A 6 DA mini distributor (product ID 2.798.400.302) is required for wiring.
There must be a free visual line between the detector and
reflector. The IR light beam must not be blocked by moved
objects!
Detector baseplate
Knurled screw for
vertical adjustment
Operating indicator
LEDs
Detector cover
210 mm
120 mm
Gimbal bearing
Operating mode switch
Knurled screw for
horizontal adjustment
(on right of detector)
Fig. 1.: Detector side view
Transmitter window
Receiver window

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 3 of 14
1.1. Connections and DIP switch settings
Plug connector
DIP switch
Operating
mode switch
2-pin output for
key switch (optional)
Mounting slots
Fig. 2.: Reverse side of detector with plug connector, operating mode switch and
DIP switch
on
off
DIP switch
The DIP switches can be accessed through the round recess in the detector base plate.
Table 1.: Functions of the DIP switch settings
*
Function
DIP switch settings
*
Function
1 2 3 4
50% threshold X X OFF OFF
35% threshold X X OFF ON
25% threshold X X ON OFF
12% threshold
(extremely sensitive, only for special applications!) X X ON ON
XAlarm relay saves the alarm OFF X X X
Automatic reset 5 s after the end of the alarm criterion ON X X X
Alarm relay after end of readjustment X OFF X X
XFault relay at end of readjustment, no alarm X ON X X
The factory presets are shaded in gray.
* The recommended settings for connection to a fire panel are marked with X.
Use DIP switches 3 and 4 to set the required alarm threshold. The factory setting
is moderate sensitivity (35%) for normal environmental conditions. Select a
threshold of 50% in very dirty environments.
Use DIP switch 1 to select the «Save alarm » or «Auto Reset» function
(recommended setting for connection to fire panel = «Save alarm »).

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 4 of 14
Plug connector
The plug connector can be accessed through the oval recess on the detector base plate.
Table 2.: Pin assignment of the 8-pin connector (from left to right)
PIN number Wire color Function
1Not assigned
2 blue Alarm relay, center contact (COM)
3 yellow Alarm relay, work contact (NO)
4 red Power supply +10 to +30 V DC
5 black Power supply -
6 green Fault relay, normally closed contact (NC)
7 white Fault relay, center contact (COM)
8Not assigned
1.2. Mounting the Fireray 50/100RV
To make mounting easier, you can remove the detector cover by gently raising the
upper and lower edges.
The mounting slots (see Fig. 2.), which are positioned at a90angle, enable vertical
or horizontal mounting of the detector.
Locate the four bore holes at the mounting location using the detector base plate.
Observe the planning notes and mounting tips!
Check the plug connector and the DIP switch settings (see Section 1.1.).
Secure the detector using four screws.
Refit the detector cover.
If a key switch is required, a two-wire cable should be routed from the detector to
the desired location during installation.
1.3. Mounting the prism reflector
Select the mounting location in line with the mounting tips (Section 1.).
A prism reflector must be used for the Fireray 50RV, and four prism reflectors
arranged in a square for the Fireray 100RV.
Fireray 50RV Fireray 100RV
ÌÌÌ
ÌÌÌ
ÌÌÌ
ÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
ÌÌÌÌ
Fig. 3.: Prism reflectors
Each reflector is secured using two mounting bores (Ğ3 mm). Arrange the four
reflectors for the Fireray 100RV such that there are no mounting holes in the center
(see Fig. 3.).

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 5 of 14
1.4. Connection
(if voltage drop <6V)
(if voltage drop >6V)
UEB UEA
SB SA
1
2
3
1
2
3
1
LSN
-U +U
-U +U
1Bridges Br1, Br2 in position 2-3
FAULT
ALARM
Power sup-
ply 10 - 30
V
Fireray 50/100 RV
rd
bl
RE
NSB 100 LSN
I3I4
NO
COM
NC
COM
NSB 100
EV 24 V - 24 V
I1 NLT1
I2 ⊥
I3 -U
Br 2
I4 +U
II1 NLT2
II2 ⊥
II3 -U
II4 +U
III1
III2
IV1 RR
IV2 R
V1 KR
V2 KA1
V3 KA2
Br 1
VII1VII2
VI1VI2
ye blkgn wh
2
2Contacts in open position
Configuration for LSN:
Parameterize the NSB in the control
panel to control output
KA1-KA2/KR-R-RR and “Control with
Fireray”.
Operating mode switches:
Prism Targeting
Alignment Mode
Operating Mode
DIP switch:
Functions, see table 1. (page 3)
Output
for key switch
(optional)
Operating mode
switch
3K3
Connection of a Fireray 50/100RV using a NSB100 LSN at the fire panel
6 DA mini
distributor
on
off
-+
DIP switch
(recommended set-
tings)
680Ω
Select the following DIP switch settings for connection to a fire panel (see table
1. on page 3):
- «Alarm relay saves the alarm»
- «Fault relay at end of readjustment, no alarm».

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 6 of 14
1Bridges Br1, Br2 on the NSB 100 in position 2-3 (see connection of one Fireray 50/100RV)
FAULT
ALARM
Power sup-
ply 10 - 30
V
Fireray 50/100 RV
rd
bl
NO
COM
NC
COM
ye blkgn wh
2
2Contacts in open position
Configurationfor LSN:
Parameterize the NSB in the control panel to control output
KA1-KA2/KR-R-RR and “Control with Fireray”.
Observe assignment to detector groups/detectors (see example).
Output
for key switch
(optional)
Operating mode
switch
DIP switch
(recommended
settings)
+
820
Connection of two Fireray 50/100RV to fire panel with cross zoning via an NBK
100 LSN and two NSB100 LSNs
V1
V2 Line 2
VI1
VI2 Line 1
V1
V2 Line 2
VI1
VI2 Line 1
NBK 100 LSN
NSB 100 LSN
V1 KR
V2 KA1
V3 KA2
NSB 100 LSN
V1 KR
V2 KA1
V3 KA2
3k92 FAULT
ALARM
Power sup-
ply 10 - 30
V
Fireray 50/100 RV
NO
COM
NC
COM
2
Operatingmode
switch
820
3k92
Parameterize, e.g. to 127/1
Parameterize, e.g. to
KA1-KA2-KR-150/2
Parameterize, e.g. to
KA1-KA2-KR-500/2
-
+
-
rd blk
bl ye gn wh
(if voltage drop <6V)
-U +U
-U +U
I3I4
NSB 100
EV 24 V - 24 V
150/1cross zoning with 500,
current trigger criterion
6 DA mini
distributor
6 DA mini
distributor
Output
for key switch
(optional)
Parameterize, e.g. to 127/2
Parameterize, e.g. to 127/3
500/1 cross zoning with 150,
current trigger criterion
1
1
DIP switch
(recommended
settings)

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 7 of 14
2. Start-Up
2.1. Setting up the detector
Start the «Prism Targeting»mode by moving the operating mode switch (see Fig.
2.) up (if the detector is mounted vertically) or to the right (if the detector is mounted
horizontally).
Connect the power supply.
The detector runs in initialization mode for approx. 5 s. The red LED flashes if the
detector is operational: 1 x for Fireray 50RV, 2 x for Fireray 100RV.
Now direct the detector at the prism, using the two knurled screws, until optimum
adjustment is confirmed by a steady yellow LED light. The following LED displays
support detector set-up:
Yellow LED display Detector status in «Prism Targeting» operating mode
off No signal at receiver
Flashes
-> Flashing frequency in-
creasing
Signal is received
-> The faster the flashing, the stronger the signal!
Steady light Optimum alignment achieved
The signal must only move from the reflector to the receiver,
under no circumstances must it move to other light sources or
reflective surfaces!
Cover the prism reflector with a non-reflective material to check. The LED must not be
lit. If the yellow LED does not go out, this indicates that a reflector is incorrectly aligned.
2.2. Calibrating the detector
Once the optimum detector set-up has been achieved, set the operating mode
switch to the center position without displacing the detector. The detector is now in
(«Alignment Mode»).
The detector runs through an automatic configuration procedure to optimize the
transmission power and the receiver sensitivity. The following detector statuses
may be displayed by the LEDs during this procedure:
LED displays Detector statuses in «Alignment Mode»
Flashing red Receiver input signal too strong, the transmission power will be
reduced. Wait until the LED goes out (max. 20 s).
Steady yellow light No signal is being received. Switch back to «Prism Targeting» mode
and repeat the detector set-up.
Flashing yellow The receiver is receiving a weak signal, the transmission power will
automatically be increased.
off Transmission power and receiver gain are optimum.
Flashing red and
yellow Automatic calibration in progress.

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 8 of 14
Follow the flow chart to perform the calibration process:
Switch center Alignment
Mode Yellow LED lights up
for approx. 5 s
Wait until both LEDs have
stopped flashing
Turn the knurled screws in
one direction and monitor
the LED status
No signal: back to
detector
set-up (Section 2.1.)
Which LED
lights up? Stop turning the knurled
screw and wait until the red
LED stops flashing
Turn the knurled screw
slowly in the same direction
Turn the knurled screw in
the other direction
Which LED
lights up?
Do not turn the knurled
screw any further
Repeat the
procedure for the other
detector axis with the
second knurled screw
Both axes ad-
justed?
Check optimum setting:
Yellow LED lights up:
1. With gentle pressure from top/bottom/left/right
on the detector housing.
2. Each time the knurled screws are moved.
Exit the
Alignment Mode
Switch at bottom:
Operating Mode
red
LED
yellow
LED
yellow
LED red LED
No LED
y
e
s
no
Steady
yellow LED

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 9 of 14
When the calibration procedure is complete, move the operating mode switch to the
bottom (if the detector is mounted vertically) or to the left (if the detector is mounted
horizontally). The detector is now in «Operating Mode».
The detector runs a calibration test for approx. 60 s. If the yellow LED lights up as
a steady light after the test, you must repeat the detector alignment and calibration
procedures (see Sections 2.1. and 2.2.).
If a detector alarm is reset in normal mode by a disruption of the power
supply, the detector automatically runs a calibration test. If the test is
failed, the detector remains in the alarm position. If the test is positive,
the yellow LED goes out, the fault relay is reset and the detector is
returned to normal mode.
In normal mode, the yellow LED flashes every 10 s.
2.3. System test
The «Alarm» and «Malfunction» functions must be checked before final start-up.
Alarm test
Hold the test filter in front of the receiver lens (upper or right-hand part of detector).
Select a volume of smoke slightly greater than the threshold set for the detector (see
Section 1.1.). Make sure that you do not also cover the transmitter -lens.
After approx.10 s, the red LED must light up and the alarm relay must close.
With the «Save alarm » detector setting (DIP switch 1 «off»), there must be a reset
at the control panel or the power supply must be disrupted for at least 5 s.
With the setting «Auto Reset» setting (DIP switch 1 «on»), the alarm is reset
automatically if the volume of smoke falls below the selected alarm threshold for at
least 5 s.
Fault test
Cover the reflector with a non-reflective material.
After approx. 10 s, the yellow LED must light up and the fault relay must open. As
soon as the obstruction is removed, the detector returns to normal mode
automatically after approx. 2 s.
3. Tips on Maintenance and Service
For maintenance and inspection work on danger detector systems, in Germany
the regulations of DIN VDE 0833 apply, which refer to the maintenance interval
according to the manufacturer’s instructions.
Bosch ST recommends a functional and visual inspection at least once a year.
Maintenance and inspection work should be carried out regularly and by trained
personnel.

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 10 of 14
4. Technical Data
Operating voltage 10 V DC . . . 30 V DC
Current consumption:
- in standby mode
< 4 mA @ 24 V
- in standby mode
- in alarm/malfunction
< 4 mA @ 24 V
< 15 mA
Reset control by power disruption > 5 s
Alarm relay Normally open; dry
contact
(2 A @ 30 V DC)
Fault relay Normally close; dry
contact
(2 A @ 30 V DC)
Permissible distance between Fireray and the
reflector:
- Fireray 50RV
- Fireray 100RV
5 m to 50 m
50 m to 100m
Optical wavelength 880 nm
Adjustable alarm threshold values 2.50 dB (25%)
3.74 dB (35%)
6.02 dB (55%)
Axial deviation tolerance
(at 35% sensitivity) Detector $0.8 Prism reflector $5.0
Operating temperature -30C . . . +55C
Protection type IP 50
Dimensions (W x H x D) 126 x 210 x 120 mm
Weight 670 g
Housing:
- Color
- Material light gray/black ABS, non-flammable
VdS ID number G 203070
5. Additional Documentation
For those with access authorization, on the Bosch ST ExtraNet at
www.boschbest.de
the current information for each product, as well as the installation instructions
supplied with the device, are available for download as a PDF file.

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 11 of 14
6. Appendices
6.1. Installation protocol
Installation company:
Type of object:
Installation location:
Installation date:
Total number of all linear detectors:
Detector version:  Fireray 50RV
 Fireray 100RV
Detector – reflector distance: _________ m
Distance of the detector axes to one
another _________ m
Mounting height _________ m
Mounting surface (e.g. masonry/rein-
forced concrete/steel beams/wood/etc.)
Serial number(s)
Reflector size:  1 x (10 x 10 cm)
 4 x (20 x 20 cm)
Supply voltage: _________ V
Correct mechanical adjustment
of transmitter
(when gentle pressure is applied to the
detector housing from the left/right/top/
bottom, the yellow LED lights up initially):
 yes  no
Alarm triggered with absorption film
35% - 50% tested:  yes  no
Fault triggered by disruption of IR
beam tested:  yes  no
DIP switch settings:
on
off
1234
Comments (environmental conditions, e.g. dust, humidity, temperature etc.)
Installation tested on: ____________ by: __________________________

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 12 of 14
6.2. Fault diagnosis
Fault indicator Possible cause Action
Beam path blocked by an obstacle Check and/or ensure free visual line
in the area between the detector and
the reflector.
Reflector is contaminated/covered/
has fallen down. Check the status of the reflector and clean it if necessary.
Fault LED illumi-
nated permanently
Supply voltage too low. Measure supply voltage directly at
detector.
nated permanently
Mode sliding switch in upper position
(«Direct»)Set the switch to «Operation»and
wait until the 60 s activation routine is
complete.
Detector set-up changed on switch-
ing to «Operation».When operating the sliding switch fol-
lowing the correct adjustment, make
sure that the setting is not changed.
The limit of automatic gain control has
been reached Clean detector lens and reflector and correct mechanical adjustment!
Fault LED flashes «MODE Switch»sliding switch in up-
per position («Direct») and incom-
plete detector set-up
Align detector vertically and horizon-
tally until the fault LED is permanently
illuminated. Then continue using fine
adjustment (switch in center position)!
Alarm LED
illuminated
DIP switch 1 at OFF
(«Save alarm »),
the alarm display remains saved
Reset the detector by disrupting the
supply voltage for at least 5 s or
select «Reset»on the fire panel
illuminated
permanently Beam path (partially) blocked by an
obstacle Ensure a free visual line in the area between the detector and the
reflector!
No fault message
when IR beam is
disrupted
Detector receives partial IR signal,
e.g. via reflective surfaces near the
beam axis.
Cover reflector with a dark material to
test!
Check detector’s range of vision for
reflective objects!
Alarm triggered
when IR beam is
disrupted
An object placed in the beam path for
testing has acted as the reflector. For testing, use a non-reflective material, maintain a greater distance
to the detector, cover the reflector as
directly as possible.
Triggering of false
alarms Sensitivity to existing environmental
conditions set too high Select a less sensitive alarm thresh- old (DIP switches 3 and 4):
normal= 35%, less sensitive= 50%

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 13 of 14
6.3. Notes
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________

Bosch Security Systems
Robert-Koch-Str. 100
D-85521 Ottobrunn
Info-Service
Telephone: [phone] - 1039
Fax: [phone] - 1039
www.bosch-sicherheitssysteme.de
[email protected]
