Bradley 594 User manual

594
Combination Unit
Washroom Accessories
Document No. 8620
© 2012 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 800.BRADLEY (800.272.3539) Fax: 262.253.4161
bradleycorp.com
Page 1 of 2
This information is subject to change without notice. 5/3/2012
Model 594 — Partition-Mounted
Serves Two Compartments
Dual Roll Tissue Dispenser/Waste Receptacle
Product Materials
CABINET: 22 gauge stainless steel with exposed surfaces in architectural
satin finish. Welded construction with burr-free edges.
FLANGE: 22 gauge stainless steel with exposed surfaces in architectural
satin finish. One-piece seamless construction, 1" wide with ¼" return.
DOOR: 18 gauge stainless steel with full-length piano hinge and tumbler
lock keyed like other Bradley units.
PUSH FLAP DOOR: 22 gauge stainless steel with exposed surfaces in
architectural satin finish. Self-closing, with heavy-duty stainless steel piano
hinge.
WASTE RECEPTACLE: leakproof molded plastic. 1.0 gal. capacity.
SPINDLE: polyethylene, non-removable by user.
Capacity
Toilet Tissue Dispensers-Four standard core toilet tissue rolls through 5¼"
in diameter. Box of 500 waxed paper liners are available by ordering part
number P11-022.
Operation
Hinged access door permits servicing of components from one side.
Installation
Verify all rough-in dimensions prior to installation. Requires partition
opening 153⁄8"W x 18¼"H. Location of hole and dimensions should be noted
in partition specifications. Flanges adjustable for partitions from 3⁄8" to 2¾"
thick. Remove one flange and install cabinet in partition opening flush against
partition. Position flanges on both sides of cabinet and secure with mounting
screws (included) at holes provided.
Guide Specification
Partition-mounted combination unit shall include toilet tissue dispenser and
napkin disposal, and be fabricated of stainless steel with seamless exposed
surfaces in satin finish. Door and back panel shall be 18 gauge. Door shall
have piano hinge and tumbler lock.
Overall dimensions: 171⁄8"W x 20"H x 4½"D.
5900 Series Combination Units are to be installed so that
doors open 90° to fill product maintain waste container.
ADA Compliant
Consult local and national accessibility codes for proper
installation guidelines.
Conformity and compliance to local and national codes is
the responsibility of the installer.
Hinged Side
594
Combination Unit
Washroom Accessories
Document No. 8620
© 2012 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 800.BRADLEY (800.272.3539) Fax: 262.253.4161
bradleycorp.com
Page 2 of 2
This information is subject to change without notice. 5/3/2012
Dim. "A" Key Surface:
For Dim. "A" Top of Rough Wall
Opening
Bottom of Rough Wall
Opening
For Bottom Toilet Paper
Opening Lower Lip @ Dim. "A"
Top of 1½" grab bar (installed with
1½" clearance) to finished floor
Not Applicable 37" (940mm) 18¾" (476mm) 19" (483mm)
36" (914mm) 33" (838mm) 14¾" (375mm) 15" (381mm)
Rough wall opening:
Partition-Mount: 15³⁄₈" (391mm) Wide x 18¼" (464mm) High x Partition Thickness
Dimensions
17¹⁄₈"
(435mm)
16¹⁄₈"
(410mm)
5"
(127mm)
½"
(13mm)
18"
(457mm)
6"
(152mm)
15¹⁄₈"
(384mm)
Push Flap
Door
Removable
Waste
Receptacle
Adjustable Flange Fixed
Flange
Toilet Tissue
Spindle (qty. 4)
Mounting
Holes
1" (25mm)
Ty p.
³⁄₈" to 2¾"
(10mm to 70mm)
Partition Thickness
4½"
(114mm)
1¼"
(32mm)
9"
(229mm)
20"
(508mm)
7¹⁵⁄₁₆"
(202mm)
1½"
(38mm)
Dim. "A"
to finished
floor
Grab bars must be ordered separately. To learn more about Bradley's
wide variety of grab bar configurations, visit bradleycorp.com.
4¼"
(108mm)
