Breezesta AD-0106 User manual

REV00-1/19
FOLDING ADIRONDACK
AD-0106
1 AD-0106 Assembly
1-877-904-1234
www.Poly-Lumber-Furniture.com

A
B
C
D
F
E
a
b
c
d e
Suggested Tools:
Drill, Plastic Mallet
G
H
I
PARTS
PART DESCRIPTION PART NO. QTY
A LEFT FRONT LEG PRT-00026 1
B RIGHT FRONT LEG PRT-00038 1
C ANGLED SPREADER PRT-00295 2
D BASE ASSEMBLY SA-00009 1
E BACK SPREADER PRT-00027 1
F BACK ASSEMBLY SA-00012 1
G PIVOT ARM PRT-00037 2
H LEFT ARM ASSEMBLY SA-00010 1
I RIGHT ARM ASSEMBLY SA-00011 1
HARDWARE
PART DESCRIPTION PART NO. QTY
a 1/4"-10 X 3" LAG SCREW H-0000-S103 4
b 5/16" X 1-1/2" CHAIR BOLT H-0000-CB51615 6
c #8 X 1-1/2" TORX SCREW H-0000-S815 6
d LARGE WHITE NYLON WASHER H-0000-LWNW 6
e T20 & T25 TORX BIT H-0000-CTD 1
AD-0106 Assembly 2
1-877-904-1234
www.Poly-Lumber-Furniture.com

T20
c
x2
A
B
C
T25
D
b
x2
H
I
T20
c
x4
E
T25
d
x2
b
x2
1.
Begin by connecting Parts
A & B to C as shown; ensure all
parts are placed correctly
2.
Attach Part D between
Parts A & B with Hardware b
3.
Connect Part E using Hardware c;
ensure the part is correctly positioned
before attaching
4.
Attach Parts H & I as shown
Please read entire instructions
before beginning
Side View
3 AD-0106 Assembly
1-877-904-1234
www.Poly-Lumber-Furniture.com

F
T25
a
x2
T25
T25
G
x2
a
x2
b
x2
d
x4
5.
Place Part F on Part D &
connect it to Parts H & I as shown
6.
Attach Part G to the
Part F & D as shown
