Bretford Basics BB44 User manual

BB44 BB48 BB54
WIDE BODY TV CARTS
Assembly Instructions
PARTS LIST
TOOLS REQUIRED
HARDWARE LIST
Ref Qty Part# Description
AA 24 030-0300 5/8" Square olt
24 030-0002 5/16-18 Hex Serrated Nuts
1 010-1106 Hex Wrench
Qty Part# Description
2 010-1891 Top & Middle Shelves
1 010-1892 ottom Shelf
2 022-1528 R/Front & L/Rear Legs ( 44)*
022-1564 R/Front & L/Rear Legs ( 48)*
022-1379 R/Front & L/Rear Legs ( 54)*
2 022-1529 L/Front & R/Rear Legs ( 44)**
022-1565 L/Front & R/Rear Legs ( 48)**
022-1380 L/Front & R/Rear Legs ( 54)**
2 015-0002 4" Casters w/o Lock
2 015-0003 4" Casters w/ Lock
OR
2 015-0017 5" Casters w/o rake
2 015-0018 5" Casters w/ rake
Hex Wrench (Provided)
Adjustable Wrench
Rubber Mallet
STEP 1
Position the front legs (stamped "O" & "X") with the brackets facing up and in as shown in Figure 1.
Slide each shelf onto the legs making sure the brackets are inside of the shelves (FIGURE. 2).
NOTE: The grommet holes should face up.
FIGURE 1 FIGURE 2
* These legs are marked with a "X"
** These legs are marked with an "O"
RETFORD ASICS


STEP 3
STEP 4
STEP 2
Slide the 2 remaining legs onto the shelves as shown.
Make sure the brackets are inside the shelves.
(Note the orientation of the "X" and "O" leg )
Secure each corner of the shelves with bolts (AA) and
nuts ( ) as shown.
Tap each caster into the bottom of each leg with a rubber mallet. Make sure
each caster is SECURELY in place and stand unit upright.
AA
Part #031-1067
Rev. 06.18.04 CH
Bretford Bretford Ltd.
11000 Seymour Avenue Technology House
Franklin Park, IL 60131 2 tongate, 110 Windsor Road
T L: 847.678.2545 Slough, Berkshire SL1 2JA ngland
800.521.9614 T L: 01753 53 99 55
FAX: [phone] FAX: [phone]
800.343.1779
www.bretford.com
