Bretford ec7000 User manual

EC7000
Computer Workstation
with CPU Holder
Assembly Instructions
PARTS LIST HARDWARE LIST
Qty Part# Description
1 010-3056 CPU Top Bracket
1 010-3057 CPU Bottom Bracket
1 010-3058 CPU Si e Bracket
1 010-3059 CPU Locking Sli e Bracket
4 017-0377 Front an Rear Leg
1 022-1993 Top Assembly
1 022-1991 Wire Tray Assembly
1 022-1992 H-Frame Assembly
2 015-0002 4" Casters w/o Lock
2 015-0003 4" Casters w/ Lock
Ref Qty Part# Description
AA 4 030-0200 1/4-20 x 1" Hex hea Screw
BB 4 030-0120 1/4-20 Square Nut
CC 8 030-0383 #10 x 1/2" Truss Hea Screw
DD 3 030-0147 1/4-20 x 1 1/4" Machine Screw
EE 6 030-0148 1/4-20 Acorn Nut
FF 2 030-0325 1/4-20 x 1/2" Combo Truss Screw
GG 1 030-0474BK 1/4-20 x 7/8" Flat H . Allen Screw
HH 1 SC1047BK 1/4-20 x 37.5mm Connector Bolt
II 2 030-0305 7/8" Washer
JJ 3 030-0207 1/4-20 Flange Hex Nut
KK 4 030-0272 1/4-20 x 1/2" Carriage Bolt
LL 4 030-0306 1" Washer
1 010-1106 Hex Wrench
1 HK1020 Stan ar Allen Wrench
TOOLS REQUIRED
Phillips Screw river
A justable Wrench
Rubber Mallet
Hex Wrench (provi e )
STEP 1
Lay the top shelf on a table so that the square brackets an
stiffener face up an the 4 corners hang over the table as shown.
NOTE: The logo label represents the front e ge of the top.
FRONT EDGE

EE
Sli e the H-frame between the legs as shown. The
shorter side faces the rear. Secure the frame to the legs
using screws (DD) an nuts (EE) as shown. NOTE: One
leg on the front si e DOES NOT GET HARDWARE, this is
left open for the CPU hol er. You eci e whether to leave
the right or left si e open.
DD
STEP 4
SHORTER SIDE
STEP 5
Insert each caster into the legs. If casters o not insert
easily, use a rubber mallet to tap each caster in place.
Make sure casters are SECURELY seate into the legs
before stan unit upright.
LEAVE OPEN FOR
CPU HOLDER (It can
be the right or left side
STEP 2 STEP 3
Position one leg into the square bracket so that the
cappe en is flush with the top of the shelf an the
holes face in as shown. LOOSELY attach with screws
(AA) an nuts (BB). Attach the remaining 3 legs in the
same manner.
BB
AA
Insert a self tapping screw (CC) approximately 3/4 of the
way into the first hole in each leg. Sli e each leg own so
that the square bracket rests on the shaft of the self
tapping screw, not the hea of the screw. T GHTEN ALL
SHELF HARDWARE.
CC

STEP 6
STEP 7
Sli e the locking bracket into the a justable bracket on the top shelf as shown. Align the
top bracket with both the a justable an locking bracket. Secure in place with screws
(FF). To a just top bracket, just loosen screws sli e bracket forwar or back war an
then tighten screws in place. NOTE: The locking an top bracket can be mounte to
either the right or left si e of the top shelf.
FF
TOP BRACKET
ADJUSTABLE BRACKET
BACK SIDE OF THE UNIT
Stan unit upright an position the wire tray between
the rear legs. Starting at the top, secure in place
using screws (CC) as shown.
LOCKING
BRACKET

Part #031-3240
Rev. 08.17.99 BW
Attach the si e bracket to the H-frame with screw (GG),
screws (HH), washers (II), nut (EE) an nut (JJ) as shown.
HH I I EE JJ
LL
KK
Attach the bottom bracket to the si e an top brackets with bolts (KK), washers (LL) an nuts (EE) an (JJ)
as shown. NOTE: To make any a justments to the height or wi th of the top or bottom brackets, just
loosen har ware, sli e bracket in esire irection an the retighten har ware in place.
SCREW (HH)
SCREW (GG)
NUT
(EE)
NUT
(JJ)
STEP 8
STEP 9
GG
EE JJ
LL EE
KK
JJ
