Breville Juice Fountain BJE200 User manual

EN INSTRUCTION BOOK FR-CA MANUEL D'INSTRUCTIONS
the Juice Fountain™ Compact
Instruction Book - BJE200

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
• To protect against fire,
electrical shock and injury
to persons, do not immerse
the appliance, motor base,
cord or plug in water or
any other liquid.
• Unplug from outlet when
not in use, before putting
on or taking off parts,
and before cleaning or
attempting to move the
appliance.
• Avoid contact with
moving parts.
• Regularly inspect the
supply cord, plug and
actual appliance for any
damage. Do not operate
any appliance with a
damaged cord or plug
or after the appliance
malfunctions, or is
dropped or damaged in
any manner. Contact
2 Breville recommends safety first
8 Components
10 Assembly
11 Functions
13 Care & Cleaning
14 Tips
16 Fruit and Vegetable Facts
18 Troubleshooting
19 French
Contents

3
Breville consumer support
for assistance.
• The use of attachments
not recommended or sold
by Breville may cause fire,
electric shock or injury.
• This appliance is for
household use only.
Do not use this appliance
for anything other than
its intended use. Do not
use in moving vehicles or
boats. Do not use outdoors.
Misuse may cause injury.
• Do not let the power cord
hang over the edge of a
table or counter-top.
• Do not let the power
cord touch hot surfaces,
including stove, or become
knotted.
• Always make sure the
juicer cover is clamped
securely in place (with
safety locking arm) before
the motor is turned on.
Do not unfasten the
clamps (safety locking
arm) while the juicer is in
operation.
• Always ensure the juicer
is turned off after each
use. Make sure the filter
basket has stopped
rotating and the motor has
completely stopped before
disassembling.
• Do not push food into
the feed chute with your
fingers or other utensils.
Always use the food
pusher provided.Do not
place hand or fingers into
the food chute when it is
attached to the appliance.
If food becomes lodged in
feed chute, use food pusher
provided or another piece
of fruit or vegetable to
push it down. Turn motor
off and ensure that all
moving parts have stopped
before disassembling
juicer to remove the
remaining food.
• Do not use appliance if the
rotating sieve (filter basket)
is damaged.
• Do not modify the plug
in any way. If the unit
has a 2-pin plug it is it a

4
polarized plug. To reduce
the risk of electric shock,
this plug will fit in a
polarized outlet only one
way. If the plug does not fit
fully in the outlet, reverse
the plug. If it still does
not fit, contact a qualified
electrician.
ADDITIONAL
SAFEGUARDS
• Remove and safely discard
any packaging material or
promotional labels before
using the juicer for the first
time.
• To eliminate a choking
hazard for young children,
remove and safely discard
the protective cover fitted
to the power plug of this
appliance.
• Do not touch the small
cutting blades/teeth in the
base of the juicing disc.
• Do not touch the sharp
blade in the feed tube.
• Always make sure the
juicer is properly and
completely assembled
before connecting to
power outlet and operating.
• Ensure that the surface
where the appliance
operates is stable, level,
clean and dry.
• Vibration can occur during
normal operation.
• Any significant spillage
onto the surface under or
around the appliance, or
onto the appliance itself,
should be cleaned and
dried before continuing to
use the appliance.
• When using this appliance,
provide adequate air space
above and on all sides for
circulation.
• Do not operate juicer for
more than a minute at a
time when juicing rapid
rate or with firm pressure.
Allow the motor to rest for
1 (one) minute between
each use.
• This juicer is only
designed to juice fruits and
vegetables. Do not use any
frozen fruits or vegetables.

5
• Hard fruits and vegetables
will put excess strain onto
the motor if a low speed is
selected.
• Remove rind from all citrus
fruit before juicing.
• Do not juice stone fruit
unless pits or seed stone
have been removed.
• This appliance is not
intended for use by
children or by persons with
reduced physical, sensory,
or mental capabilities, or
lack of experience and
knowledge.
• Close supervision is
necessary when any
appliance is used near
children.
• Children should be
supervised to ensure that
they do not play with the
appliance.
• Do not leave the appliance
unattended when in use.
• Keep hands, fingers, hair,
clothing as well as spatulas
and other utensils away
from the appliance during
operation.
• Keep the appliance clean.
Refer to care and cleaning
section.
• Turn the appliance OFF,
then unplug from the
outlet when not in use,
before assembling or
disassembling parts and
before cleaning.
• To unplug, grasp the plug
and pull from the outlet.
Never pull from the power
cord.
• Any maintenance other
than cleaning should
be performed by an
authorized Breville Service
Center. Do not attempt
to repair or service juicer,
Contact Breville Consumer
Support for assistance.
• If any of the contained
instructions or warnings
are not understood please
contact Breville Consumer
Support for assistance.

6
WARNING
Extra wide feed chute.
Do not place hands or
foreign objects down feed
chute. Always use the food
pusher provided.
SHORT CORD
INSTRUCTIONS
Your Breville appliance
is fitted with a short
power supply cord to
reduce personal injury or
property damage resulting
from pulling, tripping or
becoming entangled with a
longer cord.
If an extension cord is used,
(1) the marked electrical
rating of the cord set or
extension cord should
be at least as great as the
electrical rating of the
appliance, (2) the cord
should be arranged so
that it will not drape over
the countertop or table-
top where it can be pulled
on by children or tripped
over unintentionally and
(3) the extension cord
must include a 3-prong
grounding plug.

7
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
BREVILLE ASSIST®PLUG
Your Breville appliance
comes with a unique
Assist®Plug, conveniently
designed with a finger hole
to ease removal from the
power outlet. For safety
reasons it is recommended
you plug your Breville
appliance directly into its
own electrical outlet on a
dedicated circuit separate
from other appliances. If the
electric circuit is overloaded
with other appliances,
your appliance may not
function properly. It is not
recommended to use with a
power strip.

8
Components
B
I
H
C
A
D/E
J
F
G
K

9
A. Food Pusher
For pushing whole fruit and vegetables
down the patented wide feed chute.
(not dishwasher safe)
B. Unique Patented Centrally Located Feed
Chute
Ensures maximum juice extraction and fits
whole fruit and vegetables.
C. Nutri Disc™
Stainless steel micro mesh filter basket
designed for optimum juice and nutrient
extraction.
D. Juice Jug Lid
Allows juicer to operate with the lid on,
therefore eliminating any splatter during
operation. Place lid onto juice jug to store
juice in refrigerator (dishwasher safe top
shelf).
E. Built in Froth Separator in Lid
Ensures juice froth is separated from juice
when poured into a glass.
F. 800ml Dishwasher Safe Juice Jug
G. Safety Locking Arm
Juicer will not operate without juicer cover
in place and safely locking arm in place in
the vertical operating position.
H. Juicer Cover
(dishwasher safe top shelf)
I. Integrated Pulp Container
Will collect pulp for up to 1.5 liters of apple
juice.
J. High Performance 700 Watt Motor
K. Easy ON and OFF button
L. Not Shown
M. Cord Wrap
Cord wraps around a raised disc on the base
of the Juice Fountain™ Compact.
N. Spatula
Style end of brush is to assist in the removal
of pulp from the integrated pulp container
when juicing large quantities.
O. Nylon Bristle Brush
Included for easy cleaning of the micro
mesh filter basket.
NOTE
All Dishwasher Safe Parts are TOP SHELF
ONLY.

10
Assembly
1. Place the motor base on a flat, dry surface
such as a counter-top. Ensure that the
juice is turned OFF and the power cord is
unplugged.
2. Place the integrated pulp container on top
of the motor base. Locate the integrated
pulp container so that the spout fits through
the hole on the front of the motor base.
3. Align the arrows on the Nutri Disc™ with
the arrows on the motor drive coupling and
push down until it clicks into place. Ensure
the Nutri Disc™ is fitted securely inside
the integrated pulp container and onto the
motor base.
4. Place the juicer cover over the Nutri Disc™
and integrated pulp container. The ridges of
the rim of the juicer cover should align with
the small plastic wings on the integrated
pulp container. Lower into position.
NOTE
The juicing cover can be positioned in either
of the plastic wings on the integrated pulp
container.
5. Raise the safety locking arm up and lock
into the two grooves on either side of the
juicer cover. The safety locking arm should
now be in a vertical position and locked into
place on top of the juicer cover.
6. Slide the food pusher down the feed chute
by aligning one of the grooves in the food
pusher with the small bump on the inside of
the top of the feed chute. Continue to slide
the food pusher down the feed chute.

11
7. Place the juice jug provided sideways under
the spout of the juicer. A graphic on the lid
shows where the juicer spout is to be placed.
NOTE
The jug is designed to clip in under the spout
to give it a positive location.
A glass could also be used to collect the juice,
but using the jug and lid is recommended to
avoid any splatter.
1. Wash your selection of fruit and vegetables
ready for juicing.
2. Ensure the juicer is correctly assembled.
Ensure the Nutri Disc™ is thoroughly
cleaned before each use (refer to care and
cleaning). Place the juice jug with lid fitted
(or glass) under spout before commencing
juicing.
3. Plug the power cord into a 110/120V power
outlet and push the ON/OFF button to ON.
4. With the motor running, place food into the
feed chute. Using the food pusher, gently
guide food down the feed chute. To extract
the maximum amount of juice, always push
the food pusher down slowly.
5. Juice will flow into the juice jug and the
separated pulp will accumulate in the
integrated pulp container.
NOTE
• Most fruit and vegetables such as small
apples, carrots and cucumbers will not need
to be cut to size as these will fit into the feed
chute whole.
• When juicing carrots place the tip of the
carrot into the feed chute last.
• When the integrated pulp container is full of
pulp, it must be emptied before continuing to
juice. (Refer to disassembling instructions).
• Reassemble machine to continue juicing.
WARNING
Never use fingers to push food down the feed
chute or to clear the feed chute. Always use the
food pusher provided.
Functions

12
DISASSEMBLING
1. Push the ON/OFF button on juicer to off
and unplug.
IMPORTANT
Wait for the filter basket to stop spinning
before continuing to step 2.
2. Pull the locking arm back over the grooves
on either side of the juicer cover.
3. Move the locking arm down.
4. Remove the integrated pulp container
(preferably with the juicer cover, Nutri
Disc™ and food pusher in place) by lifting
vertically from the motor base. Take it to the
sink for easy cleaning.
5. Remove the food pusher by lifting
it vertically.
6. Remove the juicer cover from the integrated
pulp container by lifting it vertically.
Remove any pulp from the cover by using
the flat end of the brush to gently scrape
down the sides.
7. Remove the Nutri Disc™ by lifting it
vertically from the pulp bowl surround.
8. Empty the pulp from the integrated pulp
container into a side bowl for composting
or into the bin.
9. Use the flat end of the brush to gently
scrape down inside the pulp container.
WARNING
The stainless steel filter basket contains
small sharp blades to cut and process fruits
and vegetables. Do not touch blades when
handling the filter basket.

13
Care & Cleaning
• Do not soak the Nutri Disc™ in bleach.
• Always treat the Nutri Disc™ with care as it
can be easily damaged.
• Discoloration of the plastic may occur
with brightly colored fruit and vegetables.
To help prevent this, wash parts immediately
after use.
• If discoloration does occur, the plastic parts
can be soaked in 10% lemon juice and water
or they can be cleaned with a non- abrasive
cleaner.
NOTE
To assist with cleaning soak the Nutri Disc™ in
hot soapy water for approximately 10 minutes
immediately after juicing is completed. If pulp
is left to dry on the filter it may clog the fine
pores of the filter mesh thereby lessening the
effectiveness of the juicer.
For your convenience a nylon cleaning brush
has been included with your juicer.
WARNING
Do not immerse the motor base in water or any
other liquid. Do not use water jet to clean the
motor base.
The center of the filter basket and feed chute
contain small sharp blades to process fruit and
vegetables during the juicing function. Do not
touch blades when handling the filter basket or
feed chute.
• Always ensure that the juicer is turned off
then remove the plug from the power outlet
before cleaning, dissembling and storing the
appliance.
• Follow these instructions to clean all surfaces
of parts that come into contact with food
during normal use.
• For easy cleaning – immediately after each
use always turn juicer off and then unplug.
• Then rinse removable parts under running
water (to remove wet pulp). Allow parts to
air dry.
• After disassembling the unit, all removable
parts may be washed in hot soapy water or
dishwasher safe parts may be placed in the
dishwasher.
• The juicer cover, integrated pulp container,
Nutri Disc™ and juice jug are dishwasher safe,
(top shelf only).
• Wipe the motor base with a damp cloth.
• For consistent juicing results always ensure
that the Nutri Disc™ is thoroughly cleaned
using the supplied nylon bristle brush.
Using the nylon washing brush, hold the
Nutri Disc™ under running water and brush
the inside of the basket, hold it up towards
a light to ensure the fine mesh holes are not
blocked. If the holes are blocked soak the
stainless steel filter basket in hot water with
10% lemon juice to loosen the blocked holes.
Alternatively wash the stainless steel filter
basket in the dishwasher.

14
Tips
THE INSIDE INFORMATION
ON JUICING
Although juice drinks are usually developed
with flavor, texture and aroma at the forefront,
the health benefits certainly add to the
pleasurable taste experience.
Up to 70% of the nutrient content of fruit
and vegetables is found in the juice. Liquids
extracted from fresh fruit and vegetables form
an important part of a well balanced diet. Fresh
fruit and vegetable juices are an easy to make
source of vitamins and minerals.
Juices are rapidly absorbed into the blood
stream therefore being the quickest way in
which the body can digest nutrients.
When you make your own juices, you have
complete control over what you include in
them. You select the ingredients and decide if
you need to use sugar, salt or other flavoring
agents.
PURCHASING AND STORAGE OF
FRUIT AND VEGETABLES
• Always wash fruit and vegetables before
juicing.
• Always use fresh fruit and vegetables
for juicing.
• To save money and obtain fresher produce,
purchase fruit or vegetables that are in
season.
• Keep your fruit and vegetables ready for
juicing by washing them before storing.
• Most fruits and hardier type vegetables
can be stored at room temperature.
The more delicate and perishable items
such as tomatoes, berries, leafy greens, celery,
cucumbers and herbs should be stored in the
refrigerator until required.
PREPARATION OF FRUIT
AND VEGETABLES
• If using fruits with hard or inedible skins such
as mangoes, melons or pineapple, always peel
before juicing.
• Citrus fruit can be juiced in the juicer if
peeled first.
• All fruits with pits, hard seeds or stones such
as nectarines, peaches, mangoes, apricots,
plums and cherries must be pitted before
juicing.
• A small amount of lemon juice can be added
to apple juice to prohibit browning.
NOTE
Your juicer makes invigorating, frothy orange
juice. Simply peel the oranges and juice. (It is
best to refrigerate oranges before juicing).
THE RIGHT TECHNIQUE
When juicing a variety of ingredients with
varying textures start with the softer textured
ingredients then change to for harder texture
ingredients.
If you are juicing herbs, sprouts or leafy green
vegetables either wrap then together to form
a bundle or juice them in the middle of a
combination of ingredients to obtain the best
extraction.
NOTE
If juicing herbs or leafy green vegetables on
their own, the juice yield will be low due to the
nature of centrifugal juicing, it is advised to
juice them as with a combination of other fruit
and vegetables.

15
All fruit and vegetables produce different
amounts of liquids. This varies within the same
group i.e. one batch of tomatoes can produce
more juice than another batch. Since juice
recipes are not exact, the precise quantities
of any juice are not crucial to the success of a
particular mixture.
NOTE
To extract the maximum amount of juice
always push the food pusher down slowly.
GETTING THE RIGHT BLEND
It is easy to create great tasting juice. If you
have been making your own vegetable and
fruit juices, then you know how simple it is to
invent new combinations. Taste, color, texture
and ingredient preferences are a personal
thing. Just think of some of your favorite
flavors and foods – would they work well
together or would they clash. Some bold flavors
could over power the more subtle flavors of
others. It is however, a good rule of thumb is to
combine starchy, pulpy ingredients with those
high in moisture.
USING THE PULP
The remaining pulp left after juicing fruit or
vegetables is mostly fiber and cellulose which,
like the juice, contains vital nutrients necessary
for the daily diet and can be used in many
ways. However, like the juice, pulp should be
used that day to avoid loss of vitamins. Some of
the uses of pulp are to bulk out rissoles, thicken
casseroles or soups or in the case of fruit,
simply placed in a bowl topped with meringue
and bake for a simple dessert.
Apart from the consumption use, pulp is great
used in the garden for compost.
NOTE
When using the pulp, there may be some
pieces of fruit or vegetables remaining.
These should be removed before using the
pulp in any recipes.

16
Fruit & Vegetable Facts
FRUIT AND
VEGETABLES
BEST SEASON
TO BUY
STORAGE NUTRITIONAL VALUE CALORIE
COUNT
Apples Autumn/
Winter
Vented produce bags
in refrigerator
High in Dietary Fiber and
Vitamin C
166g Apple
=80 cals
Apricots Summer Unwrapped in crisper
of refrigerator
High in Dietary Fiber
Contains Potassium
55g Apricot
=19 cals
Bananas Autumn/
Spring
Room temperature Vitamins B6 & C,
Potassium, Dietary Fiber
100g Banana
=90 cals
Beets Winter Cut off tops, then
refrigerate unwrapped
Good source Folate and
Dietary Fiber Vitamin C
and Potassium
160g Beets
=79cals
Blueberries Summer Cover in the
refrigerator
Vitamin C 100g Blueberries
=52 cals
Broccoli Autumn/
Winter
Produce bag in
refrigerator
Vitamin C, Folate, B2, B5,
E, B6 and Dietary Fiber
100g Broccoli
=31 cals
Brussel
Sprouts
Autumn/
Winter
Unwrapped in crisper
of refrigerator
Vitamin C, B2, B6, E, Folate
and Dietary Fiber
100g Brussel
Sprouts =37 cals
Cabbage Winter Wrapped, trimmed in
the refrigerator
Vitamin C, Folate,
Potassium B6 and Dietary
Fiber
100g Cabbage
=22 cals
Carrots Winter Uncovered in
refrigerator
Vitamin A, C, B6 and
Dietary Fiber
100g Carrots
=33 cals
Cauliflower Autumn/
Winter
Remover outer leaves,
store in produce bag
in refrigerator
Vitamin C, B5, B6 Folate
Vitamin 5 and Potassium
100g
Cauliflower
=24.5 cals
Celery Autumn/
Winter
Refrigerate in
produce bag
Vitamin C and Potassium 100g stick
=15 cals
Cucumber Summer Crisper in refrigerator Vitamin C 100g Cucumber
=12 cals
Fennel Autumn to
Spring
Refrigerate Vitamin C, Dietary Fiber,
Folate
100g Fennel
=19 cals
Grapefruit All year round Room temperature Vitamin C, Bioflavornoids,
Lycopene, Dietary Fiber
100g Grapefruit
=33 cals

17
FRUIT AND
VEGETABLES
BEST SEASON
TO BUY
STORAGE NUTRITIONAL VALUE CALORIE
COUNT
Grapes
(Seedless)
Summer Produce bag in
refrigerator
Vitamin C, B6 and
Potassium
100g Grapes
=60-83 cals
Kiwi Fruit Winter/
Spring
Crisper in refrigerator Vitamin C and Potassium 100g Kiwi Fruit
=52 cals
Mangoes Summer Covered in
refrigerator
Vitamin A, C, B1, B6 and
Potassium
207g Mango
=113 cals
Melons
including
Watermelon
Summer/
Autumn
Crisper in refrigerator Vitamin C, Folate, Dietary
Fiber and Vitamin A
200g Melon
=50 cals
Nectarines Summer Crisper in refrigerator Vitamin C, B3, Potassium
and Dietary Fiber
151g Nectarines
=66 cals
Oranges Winter/
Autumn/
Spring
Cool, dry place for
1 week, transfer to
refrigerator to keep
longer
Vitamin C 131g Orange
=54 cals
Peaches Summer Ripen at room
temperature then
refrigerate
Vitamin C, Potassium,
Dietary Fiber, Beta
Carotene
100g Peaches
=42 cals
Pears Autumn/
Winter
Ripen at room
temperature then
refrigerate
Vitamin C & E Dietary
Fiber
161g Pear
=93 cals
Pineapple Spring/
Summer
Store in a cool place Vitamin C & E Dietary
Fiber
100g Pineapple
=43 cals
Spinach All year round Refrigerate Vitamin B6, C, E,
Beta carotene, Folate,
Magnesium, Potassium,
Dietary Fiber
100g Spinach
=15 cals
Sweet Potato All year round Store in cool place Vitamins C, E, Beta
Carotene, Dietary Fiber
100g Sweet
Potato =65 cals
Tomatoes Late Winter to
early Summer
Ripen at room
temperature
Lycopene, Vitamin C, E,
Folate, Dietary Fiber
100g Tomatoes
=15-17 cals

18
Troubleshooting
PROBLEM EASY SOLUTION
Machine will not work
when turned ON • The safety locking arm may not be correctly engaged in the vertical operating position with the locking arm located into the two grooves on
either side of the juicer cover.
Motor appears to
stall when juicing • Wet pulp can build up under the cover if the juicing action is too
vigorous. Try slower juicing action by pushing the food pusher down
slower. Clean the integrated pulp container, the Nutri Disc™ and the
juicer cover.
Excess pulp building
up in the Nutri Disc™ • Stop the juicing process. Remove the juicer cover, scrape off pulp.
Re-assemble and begin juicing again. Try alternating (soft and hard)
vegetable and fruit varieties.
Pulp too wet and reduced
extracted juice • Try a slower juicing action by pushing the food pusher down slower.
Remove Nutri Disc™ and thoroughly clean mesh walls with the nylon
brush. Rinse the Nutri Disc™ under hot water. If the fine mesh holes are
blocked, soak the Nutri Disc™ in a solution of hot water with 10% lemon
juice to unblock the holes or wash in the dishwasher. This will remove
excess fiber build up (from fruit or vegetables) which could be inhibiting
the juice flow.
Juice leaks between the rim
of the juicer and the cover of
the filter
• Try a slower juicing action by pushing the food pusher down slower.
Bowl container juice
sprays out from spout • Try a slower juicing action by pushing the food pusher down slower.
Juicer makes loud noise
when turned on • Nutri Disc™ is not properly locked into position. Turn the ON/OFF
button to OFF and unplug.
• Disassemble the juicer (refer to disassembling).
• Re-assemble (refer to assembly).
No juice coming out
while juicing • Check that the spout is not blocked with pulp.
• Refer to care and cleaning.

FR-CA MANUEL D'INSTRUCTIONS
the Juice Fountain™ Compact
Manuel d'instructions - BJE200

20
BREVILLE VOUS
RECOMMANDE
LA SÉCURITÉ
AVANT TOUT
Chez Breville, la sécurité
occupe une place de choix.
Nous concevons et fabriquons
des produits de consommation
sans jamais perdre de vue la
sécurité de notre précieuse
clientèle. De plus, nous
vous demandons d'être très
vigilant lorsque vous utilisez
un appareil électrique et de
respecter les mesures de
sécurité décrites ci-dessous.
IMPORTANTES
MESURES DE
SÉCURITÉ
LISEZ TOUTES LES
INSTRUCTIONS AVANT
USAGE ET CONSERVEZ-
LES À TITRE DE
RÉFÉRENCE.
• Pour vous protéger contre
le feu, les décharges
électriques ou les
blessures, n’immergez pas
l’appareil, le socle motorisé,
le cordon ou la fiche dans
l’eau ou tout autre liquide.
• Une étroite surveillance
est nécessaire lorsque
l’appareil est utilisé par ou
à proximité des enfants.
• Débranchez l’appareil
lorsqu’il n’est pas en usage,
avant d’assembler ou de
retirer les pièces, et avant
de le nettoyer ou de tenter
de le déplacer.
• Évitez tout contact avec les
pièces mobiles.
20 Breville vous recommande
la sécurité avant tout
26 Composants
28 Assemblage
29 Fonctions
31 Entretien & Nettoyage
32 Trucs
34 Information Sur Les
Fruits & Légumes
36 Guide de dépannage
Table des
matières
