Broyhill SANDPOINTE A222021602 User manual

ASSEMBLY INSTRUCTIONS
ITEM#: A222021602
SKU#:810553660
SANDPOINTE 2PC DINING
CHAIRS L,*+T COLOR
Need help? We are here for you! 1(866)578-6569 24/7 • Toll Free
SANDPOINTE

• Please read and understand this entire manual before attempting to assemble or install the product.
• Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
• Do not place the product on a damp or conductive subsurface.
• Standing on or misuse of this chair may result in damage and injury. Read and follow mfg. assembly and use
instructions. Not intended for commercial use.
• Keep all children and pets away from assembly area.
• Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to keep them secure!
• Weight limit: 250 LBS
• Before using, clean the chair completely with a soft dry towel.
• Do not use harsh abrasives or cleaners.
• When not in use, store in a cool, dry area and for best results always cover the chair with an outdoor cover.
WHAT IS COVERED?
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 12 months
2/10
*(1(5$/%(6735$&7,&(6)25$66(0%/<
:$51,1*6
:$55$17<
0$,17(1$1&(

3/10
(;3/2'(''5$:,1*

AA H010030032 Bolt M6*20 6 1
BB H010030023 Bolt M6*35 4 1
CC H050020017 Spring
Washer M6 10 1
DD H050010025
Flat was her
M6 10 1
EE H090030002 Wrench M6 1 0
A 1 Chair Back 1
B1 1 Left Arm 1
B2 1 Right Arm 1
C 1 Seat 1
D 1
Foot pad
Pre-assembled 4
4/10
3$576 /,67
+$5':$5(/,67
Label Part Number Description Qty Part Image
Add
Label Part Number Description Qty Part Image

•Separating parts before starting
3URYLGHGLQKDUGZDUHSDFN
How many people are needed for installation?
5/10
+(/3)8/+,176

Assembled View:
1x
1x
2x
2x
4x
4x
6/10
Attached Seat(C) to Chair Back(A)
with Bolts(AA/BB), Spring Washer
(CC) and Flat washer(DD), tighten
the Bolts(AA/BB) to 80% depth with
Wrench(EE).
67(3

Assembled View:
1x
1x
1x
2x 2x
7/10
Attached the Left Arm (B1) to
Seat(C) with Bolts(AA/BB), Spring
Washer(CC) and Flat washer(DD),
tighten the Bolts(AA/BB) to 80%
depth with Wrench(EE).
67(3

Assembled View:
1x 1x 1x
8/10
Attached the Left Arm(B1) to Chair
Back(A) with Bolt(AA), Spring
Washer(CC) and Flat washer(DD),
tighten the Bolts(AA/BB) to 80%
depth with Wrench(EE).
67(3

Assembled View:
1x
2
1x
2x x 1x
9/10
Attached the Right Arm(B2) to
Seat(C) with Bolts(AA/BB), Spring
Washer(CC) and Flat Washer(DD),
tighten the Bolts(AA/BB) to 80%
depth with Wrench(EE).
67(3

Assembled View:
1x 1x 1x
10/10
Attached the Right Arm(B2) to Chair
Back(A) with Bolt(AA), Spring
Washer(CC) and Flat washer(DD),
tighten all the Bolt to 100% depth
with Wrench(EE) at last.
67(3
