PA30 Series Tychem® SL Hood User Manual
for Hospital Preparedness
It is anticipated that individuals contaminated as a result of
industrialaccidentsorterroristattacksmaybypassthetraditional
emergency medical services (EMS) and self-present at a health
care facility for treatment. These individuals present multiple
risks including: exposure of the healthcare workers that are
providing care and treatment to the patient, exposure of other
patients at the hospital, contamination of the healthcare facility
itself, spreading the contamination away from the point of origin,
and the financial risk in terms of the potential liability for the
healthcarefacility. Forthesereasons,itisimportantthattherebe
a practical and effective system in place to decontaminate
patients prior to treatment while protecting the healthcare
workers.
Healthcare workers performing this decontamination require,
among other things, proper and practical respiratory protective
equipment. The Bullard PA30 Series Powered Air-Purifying
Respirator (PAPR) can meet this requirement. The traditional
regulatory process of compliance with federally sanctioned
performance standards and certification testing to those
standards by NIOSH is not presently in place for the chemical
warfare agents that may be present in such an incident. The
respirator assembly in this manual, while it will provide this
protection, is not NIOSH approved, as again, these standards are
not yet in place.
Bullard PA30 Respiratory Systems provide filtered air through the
powered air-purifying blower and canister. The flow of air is
delivered to the respirator wearer through a patented air delivery
system. PA30 Series respirators offer protection from airborne
contaminants that are not immediately dangerous to life or health
(IDLH).
Bullard hoods will accommodate limited facial hair and eyewear
without compromising the level of protection.
The hood covers are held in place by snap-in replaceable
suspensions. Breathing air is supplied from a breathing tube
connected to the back of the hood.
PA3BU blower units are available with the PA3NBC canister
designed for protection against various toxic industrial chemicals
and chemical warfare agents. Refer to the PA3H Blower Assembly
User Manual for further information.
Fortechnicalassistance,contactBullardTechnicalSupport at 877-
BULLARD (285-5273) or 859-234-6616.
Component Concept - PA30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2, 4-5
Operations
Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PA30 Series Hood Assembly
Adjusting and Installing Headband
in Respirator Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting and Installing Hard Hat
in Respirator Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing BreathingTube Assembly in
Respirator Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PA30 Series Hood Use
Donning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Inspection, Cleaning and Storage
Hood and Headband . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Hard Hat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
BreathingTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Parts and Accessories for PA30 Series Respirators . . . . . . . . . . 11
Return Authorizations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table of Contents
Intended Application
WARNING
Read all instructions and warnings before using these respirators. Save this manual for future reference.
Failure to follow these instructions could result in death or serious injury.

TM
Wanring
2
WARNING
Failure to heed these warnings could result in death or serious injury.
1. Not for use in atmospheres immediately dangerous to life and health or where hazards have not been reasonably estimated and
anticipated.
2.This hood, as part of the complete respirator, provides respiratory protection against inhalation of radiological and nuclear dust
particles. Procedures for monitoring radiaton exposure and full radiation protection must be followed.
3. If during use an unexpected hazard is encountered such as a secondary CBRN device, pockets of entrapped hazard or any
unforeseen hazard, immediately leave the area for clean air.
4. Use in conjunction with personal protective ensembles that provide appropriate levels of protection against dermal hazard.
Failure to do so may result in personal injury even when the respirator is properly fitted, used, and maintained.
5. Some CBRN agents may not present immediate effects from exposure, but can result in delayed impairment, illness or death.
6. Direct contact with CBRN agents requires proper handling of the respirator after each use and between multiple entries during
the same use. Decontamination and disposal procedures must be followed. If contaminated with liquid chemical warfare agents,
dispose the respirator after decontamination.

➀Respirator Hood:
20SICV Tychem SL hood with taped and sealed seams
and press polished vinyl lens, with inner bib, long
outer bib, and headband suspension
20SICVH* Tychem SL hood with taped and sealed seams
and press polished vinyl lens, with inner bib and
long outer bib for use with head protection
*Requires one of the following Bullard hard hat models:
3000WHT, 3000RWHT, 5100WHT or 5100RWHT.
NOTE
Optional accessories include 20RT ratchet headband,
20NC or ES42 chin strap.
➁Headband Suspension or Head Protection:
Hard hat models 3000, 3000R, 5100 or 5100R or
suspension models 20TG and 20RT.
➂Blower Assembly:
PA3H blower assembly includes:
PA3BU Blower Unit
PA1DB Vinyl Decon Belt Assembly
PA1AFI Air Flow Indicator
User Manual
NOTE
Breathing tube, PA3BP Battery packs, and chargers
sold separately.
➃Canisters:
See PA3H Blower Assembly User Manual for complete
information on the PA3NBC canister.
PA30 Series Tychem® SL Hood User Manual
for Hospital Preparedness
PA30 Component Concept
Component Concept
PA30 Powered Air-Purifying Respirators
Bullard PA30 Series powered air purifying respirators consist of four components (Figure 1).
Figure 1
➁Headband Suspension
or Hard Hat
3
➀Respirator Hood
PA1AFI
PA3HPBT
PA3NBC Canisters
PA3BU
➃
PA3DB
➂Blower Assembly

TM
Warning
4
Failure to heed these warnings could result in death or serious injury.
1. Improper respirator use could result in death or serious injury. Improper use may also cause certain life-threatening delayed lung
diseases such as silicosis, pneumoconiosis or asbestosis.
2. Thisrespirator,when properlyfittedand used,significantlyreduces,butdoesnotcompletelyeliminate,thebreathingofcontaminants
by therespirator wearer. Where excessiveairbornecontaminantlevelsarefound, youmayobtainbetterrespiratory protectionfrom
other types of respiratory protection equipment such as a valve-operated pressure-demand airline respirator or a pressure-demand
self-contained breathing apparatus respirator.
3. Regulations require that the employer provide training to the user on the proper use, maintenance and limitations of this equipment.
Each person using this respirator must first read and understand this entire instruction manual.The PA30 Series respirators should
only be used in accordance with these operating and maintenance instructions. If you have any questions concerning the use of this
respirator, ask your employer or call BullardTechnical Support at 877-BULLARD (285-5273).
4. Before using these respirators, be sure your employer has determined that ambient airborne contaminant concentrations do not
exceed those allowed by applicable OSHA, MSHA, EPA, NIOSH or ACGIH regulations and recommendations, or any other applicable
regulations. Before using the above respirator, Federal law requires that the employer shall identify and evaluate the respiratory
hazard(s) in the workplace, and that this evaluation shall include a reasonable estimate of employee exposures to respiratory
hazard(s), and an identification of the contaminant’s chemical state and physical form.
5. DO NOT wear this respirator if any of the following ambient conditions exist:
- Atmosphere is immediately dangerous to your life or health (IDLH).
-You CANNOT escape without the aid of the respirator.
- Atmosphere contains less than 19.5% oxygen.
-Work area is poorly ventilated.
- Unknown contaminants are present.
- Contaminant concentrations are in excess of regulations or recommendations (as described in item 4 above).
6. Thereareusers,environmentsandchemicalsfor which these respiratorsare not suitable.Itistheresponsibility of the user and the
employertodeterminethattheserespiratorsareappropriatefortheintendeduse.Theserespiratorsshouldnotbe usedaroundheat,
open flames, sparks or in any potentially flammable or explosive environment. CC20 materials will burn and will melt. DuPont
Tychem®spunbonded olefin apparel fabrics have “Class 1 - Normal Flammability” characteristics, as tested according to the
Flammable Fabrics Act. “Class 1” fabrics will burn and do not provide thermal protection if a fire or explosion should occur.
CC20 materials may create static electricity under low relative humidity. Surface resistance and charge dissipation are proportional
to the amount of antistatic agent on the fabric and the ambient relative humidity. Since the antistatic agent is water soluble, it can
be washed off with water. In addition, other clothing items that are not anti-static treated might be a potential source of static
formation and discharge. Contact your employer or DuPont at 1-800-44-TYVEK on this material.
7. Bullard recommends that you DO NOT wear these respirators until you have passed a complete physical exam (including a chest
x-ray), conducted by qualified medical personnel.
8. Donot modify or alter these respirators in any manner. Use only Bullard PA30replacementparts.FailuretouseBullardcomponents
andreplacementpartsfor use with this respirator invalidates all Bullard warranties, and could resultindeathor serious injury, lung
disease or exposure to other hazardous or life-threatening conditions.
9. Inspect all components of these respirator systems during cleaning and before and after each use for signs of wear, tear or damage
thatmight reduce the degree of protectionoriginally provided.Immediately replacewornordamagedcomponentswithBullardPA30
components, or remove the respirator from service. (See INSPECTION, CLEANING AND STORAGE section for instructions on proper
maintenance of PA30 Series respirators.)
10. DONOTusetheserespiratorsin poorlyventilatedareas,areas whereoxygenislessthan19.5%,or inconfinedspacessuchas tanks,
small rooms, tunnels or vessels unless the confined space is well-ventilated and contaminant concentrations are below the upper
limit recommended for this respirator. The procedures for confined space entry, operation and exit are defined in applicable
regulations and standards, including 29 CFR 1910.146.
11. DO NOT use these respirators for abrasive blasting or underwater diving.
12. DONOT reach your hand into the hood head cover in atmospheres containing air contaminants. Leave the contaminated area and
clean hands before reaching inside the hood.
WARNING

PA30 Series Tychem® SL Hood User Manual
for Hospital Preparedness
Warning/Operations
5
WARNING
Failure to heed these warnings could result in death or serious injury.
Use strictly in accordance with instructions, labels and limitations pertaining to the PA30 respirator.
1. The PA30 respirator does not supply oxygen.
2. Use only in adequately ventilated areas containing at least 19.5% oxygen.
3. Do not use when concentrations of contaminants are immediately dangerous to life or health.
4. Do not use these respirators for respiratory protection against abrasive blasting using silica sand as the abrasive.
5. Do not use in circumstances where the airborne concentration level of contaminant exceeds maximum use concentration for this
type of respirator as established by regulatory standards.
6. Leave area immediately if:
a. Breathing becomes difficult.
b. Dizziness or other distress occurs.
c. You taste or smell the contaminant.
d. Unit becomes damaged.
e. Low battery alarm sounds.
7. Use strictly in accordance with instructions, labels and limitations pertaining to the PA30 respirator in use.
8. Thisapparatusmustnotbeworn with the blowerunitswitchedoff. If switched off,a rapidbuild-upofcarbondioxideanddepletion
of oxygen may occur, which could result in death or serious injury.
9. Never alter or modify this respirator. Use only Bullard PA30 replacement parts for the PA30 respirator.
Operations
Protection
Respiratory
The PA30 respirator is not designed for use in any atmosphere
immediately dangerous to life or health (IDLH), or from which the
wearer cannot escape without the aid of the respirator.
Head
PA30 Series respirator hoods with the 20TG or 20RT headband
suspension DO NOT provide head protection. If head protection is
required, order the 20SICVH model.
The 20SICVHhood, when used with a Bullard model 5100 or 3000
hard hat, meets ANSI Standard Z89.1-1997 Type I, Classes E & G
requirements for protective headwear for industrial workers.These
hard hats are designed to provide limited head protection by
reducing the force of falling objects striking the top of the hard hat
shell.
Eyes
PA30 Series respirators DO NOT provide eye protection. Wear
approved safety glasses or goggles at all times.
Ears
PA30 Series respirators DO NOT provide hearing protection. Use
properly fitted earmuffs, earplugs or other protection when
exposed to high noise levels.

TM
PA30 Respirator Assembly
6
PA30 Respirator Assembly
Adjusting and Installing Headband
Suspension in Hood
(If using 20SICVH model, see page 7.)
1. Size the standard 20TG headband suspension by squeezing top
and bottom edges of rear buckle with your thumb and
forefinger. Decrease size of headband suspension by sliding
band through buckle.
2. Squeeze the buckle to disengage sizing mechanism, and place
headband suspension on your head. Continue squeezing buckle
while pulling headband suspension down over your head.
Headband suspension automatically adjusts to your size and
locks when you release your grip (see Figure 3). Headband
suspension should feel comfortable and snug.
NOTE
If using the optional 20RT ratchet headband
suspension, refer to the instruction sheet provided
with the 20RT.
Sizing 20RT Ratchet Headband Suspension
Working from inside hood, turn ratchet knob until headband
suspension is at its largest size. Place hood on your head and
adjust ratchet knob from outside the hood to a comfortable fit. An
optional chin strap is available for additional comfort and stability.
3.With clear lens facing you, insert headband suspension into
hood with headband suspension snaps facing front.
4. Engage four headband suspension snaps into corresponding snap
studs mounted in plastic lens (see Figure 4).
Adjusting Crown Straps for Vertical Fit
To improve the comfort of 20TG and 20RT headband suspensions,
adjust the crown straps vertically by repositioning the headband
suspension keys in the crown straps. Vertical adjustment makes
headband suspension ride higher or lower on the wearer's head.
To adjust the crown strap:
1. Remove headband suspension from respirator hood.
2. Rotate crown strap 90° until key dislodges from keyhole (see
Figure 5).
3. Move key to desired vertical position.
4. Rotate crown strap 90° to secure key in keyhole (see Figure 6).
5. Repeat steps 2-4 for other crown strap keys.
6. Reinstall headband suspension into respirator hood, following
directions above.
If Using Optional 20NC Chin Strap:
Formostwearers,theheadbandsuspensionholdsthehood inplace
without a chin strap. If the hood rises off your head during use, a
chin strap is recommended (not available on loose-fitting facepiece
hoods). Refer to the list of replacement parts and accessories. To
install the chin strap:
1. Remove headband suspension from hood.
2. Snap chin strap stud buttons into the holes on each side of the
headband suspension, inserting from the inside.
3. Align holes on chin strap to stud buttons and pull downward to
lock in place (see Figure 7).
4. Place headband suspension on your head. Adjust chin strap
length with the plastic slide.
5.Remove headband suspension from your head. Install
headband suspension into respirator hood.
Figure 4
Figure 6
Figure 7
Figure 5
Crown Strap
Headband
Suspension
Key Hole
Headband
Suspension
Key
Brow Pad
Ratchet
Knob Headband
Figure 3

Installing Hard Hat
7
Adjusting and Installing Hard Hat
in Respirator Hood*
1. Assemble and adjust the standard Bullard hard hat suspensionsTG600 or ES-
ULTRA or the optional ratchet suspensionsTGRT600 or ESRTSL by following the
directions on instruction sheet attached to headband on hard hat. Read all hard
hat warning labels and instructions.The following Bullard hard hat models are
available for use with PA30 Series respirator hoods: 3000, 3000R, 5100 and
5100R.
2. If desired, install and adjust optional ES42 hard hat chin strap.
3. Before inserting hard hat into hood, remove the two adhesive-backed Velcro®
strips attached to the Velcro piece that is sewn into the hood (see Figure 9 &
10).
4. Peel the backing off the longer Velcro tab and apply it to the inside center rear of
the hard hat, about 1/4" up from the edge. Apply shorter Velcro tab to the
underside of the brim of the hard hat (see Figure 10).
5. Insert hard hat into respirator hood with cap visor facing front of hood (see
Figure 8).
6.Tuck cap brim on top of front elastic Velcro band sewn into hood (see Figure 9).
7. Loop the Velcro strip sewn inside the hood around the back of the cap and affix it
to the corresponding Velcro tab previously installed inside the hard hat in step 4
(see Figure 10).
* 20SICVH model respirator hoods require a hard hat.
Figure 10
Velcro strip
Window
Front elastic
band
Velcro Strip
Figure 9
Figure 8
Velcro tabs
PA30 Series Tychem® SL Hood User Manual
for Hospital Preparedness

TM
Breathing Tube Assembly/Donning/Doffing
8
Installing Breathing Tube Assembly
in PA30 Respirator Hoods
1. Remove nylon clamp from plastic anchor plate on hood (see
Figure 11).
2. Insert the open end of the breathing tube approximately five
inches into hood’s air entry sleeve (see Figure 12).
3. Install nylon clamp over air entry sleeve and breathing tube,
inserting clamp locks through two holes in plastic anchorplate
thatis sewnintohood.Locksshould face awayfromuser’sneck
(see Figure 13).
4. Engage clamp locks and squeeze together until tight.
5. Attach other end of PA3HPBT breathing tube to the blower unit
by screwing the adapters together.
PA30 Series Hood Use
1. Position headband suspension or hard hat for a comfortable
fit. (See instructions on page 13 for proper sizing).
2. If using an optional chin strap, pull elastic strap under your
chin. Adjust for a secure and comfortable fit.
3. Tuck inner bib of hood into shirt or protective clothing for
additional splash and overspray protection (see Figure 14).
4. Pull respirator outer bib over collar of shirt or protective
clothing. Pull the long outer bib down on the outside of
clothing and tie at the sides.
5. With air flowing into your respirator, you are now ready to
enter work area.
Donning and Removing the
PA30 Respirator
Refer to the Pre-Operational Inspection and Donning
Instructions in the Bullard PA3H Blower Assembly User
Manual.
To don the hood after donning blower (see PA3H Blower
Assembly User Manual
Figure 12
Figure 13
Figure 11
To tighten
To remove
To tighten
WARNING
Do not put on or remove these respirators in a hazardous
atmosphere except for emergency escape purposes. Failure to
heed these warnings could result in death or serious injury.
Figure 14

PA30 Series Tychem® SL Hood User Manual
for Hospital Preparedness
Inspection, Cleaning, and Storage
9
Inspection, Cleaning and Storage
Bullard PA30 Series respirators have a limited service life.
Therefore,a regular inspection and replacement program mustbe
conducted.
The Bullard PA30 Series respirators and all component parts and
assemblies should be inspected for damage or excessive wear
before and after each use to ensure proper functioning.
Immediatelyremovetherespirator fromserviceandreplace parts
or assemblies that show any sign of failure or excessive wear that
might reduce the degree of protection originally provided.
Use only Bullard PA30 replacement parts.
Since respirator use and the quality of maintenance performed vary
with each job site, it is impossible to provide a specific time frame for
respirator replacement.
Inspect all components of this respirator system during cleaning and
beforeandaftereachuse forsignsof wear,tearordamagethatmight
reduce the degree of protection originally provided. Respirators used
by more than one person must be cleaned, inspected and sanitized
after each use. If not cleaned, contamination may cause illness or
disease.
Hood and Headband Suspension
Inspection
Inspect the hood material for rips, tears, or damage from
excessive wear that might reduce the degree of protection
originally provided. Inspect the inner neck cuff for elasticity. The
respirator’s plastic lens should be inspected for cracks, scratches
or any other signs of damage.
Disassemble the breathing tube from the hood by removing the
nylon hose clamp. To remove the hose clamp, slide the locks
sideways in opposite directions.
Remove the headband suspension and optional chin strap from
the hood. Inspect headband suspension for cracks, frayed or cut
crown straps, torn headband or size adjustment slots, loss of
pliability,orothersignsof excessivewear.Check thechinstrapfor
loss of elasticity, cuts, and cracked hanger clips.
If damage is detected, replace immediately with Bullard
replacement part(s) or remove the respirator from service.
Cleaning
Bullard does not recommend laundering the hood.When the hood
becomes dirty, it should be discarded and replaced. The
respirator’s plastic lens, headband suspension, and optional chin
strap should be hand-sponged with warm water and mild
detergent, rinsed, and air-dried. After cleaning and before
reassembling, once again carefully inspect parts for signs of
damage.
WARNING
The air you breathe will not be clean unless the respirator you
wearisclean.Failuretoheedthiswarningcouldresultindeath
or serious injury.
CAUTION
Do not use volatile solvents for cleaning this respirator or any
parts and assemblies. Strong cleaning and disinfecting agents,
and many solvents, can damage the plastic parts and reduce
the protective properties of the respirator. Failure to heed
these instructions may result in minor or moderate injury
and/or equipment damage.
WARNING
Failure to heed these instructions could result in death or
serious injury.
LEAVEWORK AREA IMMEDIATELY IF:
- Any respirator component becomes damaged
- Airflow into respirator hood stops or slows down
- PA30 Respirator low battery alarm sounds
- Breathing becomes difficult
-You become dizzy, nauseous, too hot, too cold, or ill
-You taste, smell, or see contaminants inside
respirator hood
-Your vision becomes impaired
WARNING
Donotstorerespirator in yourworkareaorleave it unattended
in a contaminated environment. Respirable contaminants can
remain suspended in the air for more than one hour after work
activity ceases, even though you may not see them. Proper
work practice requires you to wear the respirator until you are
outside the contaminated area. If you place or store the
respirator in a contaminated environment, contaminants, dirt,
and dust could get into the respirator. When you put the
respirator back on, you could breathe in contaminants upon
reuse. Failure to heed these instructions could result in death
or serious injury.

TM
Inspection, Cleaning, and Storage
10
Hard Hat
Inspection
Inspect the hard hat shell for nicks, gouges, cracks, and any damage
due to impact, rough treatment, or wear.
Remove the headband suspension and optional chin strap from the
hard hat. Inspect the headband suspension for cracks, frayed or cut
crown straps, torn headband and size adjustment slots, loss of
pliability or other signs of excessive wear. Check the chin strap for
loss of elasticity, cuts, and cracked hanger clips.
If damage is detected, replace part(s) immediately with Bullard
replacement parts or remove the hard hat from service.
Cleaning
The hard hat shell, headband suspension, and optional chin strap
should be hand cleaned with warm water and mild detergent,
rinsedandair-dried.Aftercleaning andbeforereassembling,once
again carefully inspect parts for signs of damage.
Breathing Tube
Inspection
Inspect the breathing tube for tears, cracks, holes, or excessive
wear that might reduce the degree of protection originally
provided. If any signs of excessive wear are present, replace the
breathingtubeimmediately orremovetherespiratorfromservice.
Cleaning
To clean the breathing tube, hand-sponge with warm water and
mild detergent, being careful not to get water inside. Rinse and
air-dry. After cleaning, once again carefully inspect breathing tube
for signs of damage.
Storage
After reusable respirator components have been cleaned and
inspected, place them in a plastic bag or an airtight container.
Store the respirator and parts where they will be protected from
contamination, distortion and damage from elements such as
dust, direct sunlight, heat, extreme cold, excessive moisture and
harmful chemicals.
Refer to the or PA3H Blower Assembly User Manual for
additional Inspection, Cleaning and Storage
Instructions.

ESRTSL
Ordering Information
11
Parts and Accessories for PA30 Series
Powered Air-Purifying Respirators
PA30 respirators consist of four components – respirator hood, headband suspension or head protection (hard hat), blower assembly,
and canister. The PA3H blower assembly is sold with the belt and air flow indicator. Breathing tube, battery and charger are sold
separately.
Respirator Hoods
Hood with inner bib, for use with Bullard hard hat
20SICVH Tychem SL, with taped and sealed seams, pressed
polished vinyl lens,hard hat not included
Hood with inner bib and long outer bib, for use with
headband suspension
20SICV Tychem SL, with taped and sealed seams, pressed
polished vinyl lens, and 20TG headband suspension
20SICVN Tychem SL, with taped and sealed seams, pressed
polished vinyl lens, no headband suspension
Headband Suspensions and Hard Hats
20TG Standard headband suspension
20RT Sure-Lock®ratchet headband suspension
3000 Hard hat with standard suspension, white
3000R Hard hat with ratchet suspension, white
5100 Hard hat with standard suspension, white
5100R Hard hat with ratchet suspension, white
Accessories for Headbands Suspension and Hard Hats
ESULTRA Standard replacement suspension for 3000 hard hat
ESRTSL Replacement ratchet suspension for 3000R hard hat
TG600 Standard replacement suspension for 5100 hard hat
TGRT600 Replacement ratchet suspension for 5100R hard hat
20NC Chin strap for 20TG and 20RT headband suspension
ES42 Chin strap for 3000 and 5100 hard hats
PA30 Respirator System
PA30PREP Hospital preparedness PAPR system. Includes
PA3H Blower Assembly, PA3HPBT BreathingTube,
20SICVNTychem SL hood, 20RT Ratchet
Suspension, PA3SMC Charger, and set of 3 PA3NBC
Canisters
Blower Assembly
PA3H Blower with internal voltage alarm. Includes vinyl
decon belt and air flow indicator. Breathing tube,
battery and charger sold separately.
Battery Chargers for PA3 Blower Assembly
PA3SMC Quick charger for PA3/PA5 (2 ports)
PA3GC Tabletop Gang Charger for PA3BP (6 ports)
PA30 Accessories/Replacement Parts
PA1DB Decon belt/lumbar
PA1DEB Extension decon belt kit
PA1AFI Air Flow Indicator
PA3HPBT Breathing tube assembly (tube/clamp) withTychem
SL cover
PA1BTS BreathingTube seal
PA3BU PA3 Blower housing unit, motor, and impeller
PA3BP Battery Pack (4 hr. Capacity)
PA3BPC Battery Port Cover
20SLBTC Tychem SL BreathingTube Cover
20SICVH 20SICV
20SICVN
20RT
20TG
20NC
3000
5100
ESULTRA
TG600
TGRT600
ES42
CATALOG CATALOG
NUMBER DESCRIPTION NUMBER DESCRIPTION
PA30 Series Tychem® SL Hood User Manual
for Hospital Preparedness
PA1AFI
PA3HPBT
PA3BU
PA3DB
PA3NBC Canisters

TM
Respiratory
Protection Fire and Rescue Safety
Head
Protection Thermal
Imaging
6081506399(0703)
Bullard
1898 Safety Way
Cynthiana, KY 41031-9303
Toll free: 877-BULLARD (285-5273)
Tel: [phone]
Fax: [phone]
www.bullard.com
Bullard GmbH
Hochkreuzallee 36
53175 Bonn-Bad Godesberg
Germany
Tel: [phone]
Fax: [phone]
©2003 Bullard. All rights reserved.
“It’sYour Life andYou’reWorth It” is a trademark of Bullard.
Tychem is a registered trademark of E.I. DuPont de Nemours & Company.
Velcro is a registered trademark of Velcro USA.
ISO 9001
certified
Return Authorization
The following steps must be completed before Bullard will accept any returned goods. Please read carefully.
Follow the steps outlined below to return goods to Bullard for repair or replacement under warranty or for paid repairs:
1. Contact BullardTechnical Support by telephone or in writing at:
Bullard
1898 SafetyWay
Cynthiana, KY 41031-9303
Toll-free: 877-BULLARD (285-5273)
Phone: [phone]
In your correspondence or conversation withTechnical Support, describe the problem as completely as possible. For
your convenience, your technical support specialist will try to help you correct the problem over the phone.
2. Verify with your technical support specialist that the product should be returned to Bullard.Technical Support will
provide you with written permission and a return authorization number as well as the labels you will need to return
the product.
3. Before returning the product, decontaminate and clean it to remove any hazardous materials which may have settled
on the product during use. Laws and/or regulations prohibit the shipment of hazardous or contaminated materials.
Products suspected to be contaminated will be professionally discarded at the customer’s expense.
4. Ship returned products, including those under warranty, with all transportation charges pre-paid. Bullard cannot
accept returned goods on a freight collect basis.
5. Returned products will be inspected upon return to the Bullard facility. BullardTechnical Support will telephone you
with a quote for required repair work which is not covered by warranty. If the cost of repairs exceeds stated quote by
more than 20%, your technical support specialist will call you for authorization to complete repairs. After repairs are
completed and the goods have been returned to you, Bullard will invoice you for actual work performed.
