Burkert 8045 User manual

Operating Instructions
Bedienungsanleitung
Manuel d‘utilisation
Type 8045
Insertion electromagnetic flowmeter
Magnetisch-induktives Durchfluss-Messgerät, Insertion
Débitmètre électromagnétique à insertion

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modification technique.
© Bürkert SAS, 2012 - 2019
Operating Instructions 1904/04_EU-ML 00559778 / Original FR

3
1 ABOUT THESE OPERATING INSTRUCTIONS .....................................................................................................................6
1.1 Symbols used ..........................................................................................................................................................................6
1.2 Definition of the word "device" .......................................................................................................................................6
2 INTENDED USE ....................................................................................................................................................................................7
3 BASIC SAFETY INFORMATION ....................................................................................................................................................7
4 GENERAL INFORMATION ................................................................................................................................................................9
4.1 Manufacturer's address and international contacts ............................................................................................9
4.2 Warranty conditions ..............................................................................................................................................................9
4.3 Information on the Internet ...............................................................................................................................................9
5 DESCRIPTION ....................................................................................................................................................................................10
5.1 Area of application .............................................................................................................................................................10
5.2 General description ...........................................................................................................................................................10
5.3 Description of the rating plate .....................................................................................................................................10
6 TECHNICAL DATA .............................................................................................................................................................................11
6.1 Conditions of use ................................................................................................................................................................11
6.2 Conformity to standards and directives .................................................................................................................11
6.3 Mechanical data ...................................................................................................................................................................12
6.4 Fluid data .................................................................................................................................................................................13
6.5 Electrical data .......................................................................................................................................................................13
6.6 Electrical connection .........................................................................................................................................................15
7 INSTALLATION AND COMMISSIONING ...............................................................................................................................16
7.1 Safety instructions .............................................................................................................................................................16
7.2 Fluid installation onto the pipe ....................................................................................................................................17
7.2.1 Recommandations for installing the 8045 on the pipe .............................................................18
7.2.2 Installation into the pipe of a 8045 with a G2'' nut .....................................................................20
7.2.3 Installation into the pipe of a 8045 with a clamp connection ..................................................21
7.3 Wiring .........................................................................................................................................................................................21
7.3.1 Equipotentiality of the installation ...................................................................................................22
7.3.2 Mounting the cable clamp ................................................................................................................24
7.3.3 Terminal assignment and use of the selectors ............................................................................24
English
Type 8045

4
7.3.4 Wiring the AO1 current output .......................................................................................................25
7.3.5 Wiring the DO1 transistor output ...................................................................................................26
7.3.6 Wiring the DI1 digital input ..............................................................................................................26
7.3.7 Wiring the DO2 and DO3 relay outputs .......................................................................................27
8 OPERATING AND FUNCTIONS .................................................................................................................................................28
8.1 Safety instructions .............................................................................................................................................................28
8.2 Operating levels of the device .....................................................................................................................................28
8.3 Description of the navigation keys and the status LEDs ..............................................................................30
8.4 Using the navigation keys ..............................................................................................................................................31
8.5 Details of the Process level ..........................................................................................................................................31
8.6 Details of the Parameters menu .................................................................................................................................32
8.6.1 Choosing the display language .......................................................................................................33
8.6.2 Choosing the flow rate units, the number of decimals and the units of the totalizers ........33
8.6.3 Entering the K-factor of the fitting used ........................................................................................35
8.6.4 Determining the fitting K-factor using a Teach-In procedure ...................................................35
8.6.5 Configuring the outputs (general diagram) ..................................................................................38
8.6.6 Configuring the AO1 current output ..............................................................................................39
8.6.7 Configuring the transistor output DO1 as a pulse output ........................................................40
8.6.8 Configuring the transistor output DO1 to switch a load depending on two
threshold values ..................................................................................................................................41
8.6.9 Configuring the transistor output DO1 to switch a load when the fluid direc-
tion changes ........................................................................................................................................43
8.6.10 Configuring the transistor output DO1 to switch a load when a warning
message is emitted by the device ..................................................................................................44
8.6.11 Configuring the DO2 and DO3 relay outputs .............................................................................44
8.6.12 Configuring the DI1 digital input .....................................................................................................47
8.6.13 Configuring the filter of the measured flow rate ..........................................................................51
8.6.14 Resetting both totalizers ...................................................................................................................52
8.6.15 Configuring the electric network frequency .................................................................................52
8.6.16 Parameterizing the cut-off flow rate ...............................................................................................53
8.6.17 Setting the brightness of the display and how long it stays ON, or deactivat-
ing the backlight .................................................................................................................................54
8.7 Details of the Test menu .................................................................................................................................................55
8.7.1 Adjusting the current output ............................................................................................................56
8.7.2 Calibrating the flow zero point ........................................................................................................57
8.7.3 Checking the outputs behaviour .....................................................................................................58
English
Type 8045

5
8.7.4 Setting the Kw coefficient of the flow sensor ..............................................................................59
8.7.5 Monitoring the flow rate in the pipe ...............................................................................................59
8.8 Details of the Information menu .................................................................................................................................61
9 MAINTENANCE AND TROUBLESHOOTING .......................................................................................................................62
9.1 Safety instructions .............................................................................................................................................................62
9.2 Cleaning the device ...........................................................................................................................................................62
9.3 Cleaning the flow sensor ................................................................................................................................................63
9.4 Replacing the seal on a 8045 with G2" nut ...........................................................................................................63
9.5 If you encounter problems ............................................................................................................................................64
9.5.1 Resolution of problems when the device status LED is OFF ..................................................64
9.5.2 Resolution of problems without message generation but device status LED ON ..............64
9.5.3 Resolution of problems without message generation and device status LED green .........66
9.5.4 Resolution of problems without message generation and device status LED red .............67
9.5.5 Resolution of problems without message generation and device status LED orange .......68
10 SPARE PARTS AND ACCESSORIES ......................................................................................................................................69
11 PACKAGING, TRANSPORT ..........................................................................................................................................................70
12 STORAGE ..............................................................................................................................................................................................70
13 DISPOSAL OF THE DEVICE ........................................................................................................................................................70
English
Type 8045

6
About these Operating Instructions
1 ABOUT THESE OPERATING INSTRUCTIONS
These Operating Instructions describes the entire life cycle of the device. Please keep these Operating Instruc-
tions in a safe place, accessible to all users and any new owners.
These Operating Instructions contains important safety information.
Failure to comply with these instructions can lead to hazardous situations. Pay attention in particular to the
chapters 3 Basic safety information and 2 Intended use.
▶Whatever the version of the device, these Operating Instructions must be read and understood.
▶When the symbol is marked inside or outside the device, carefully read the Operating Instructions.
1.1 Symbols used
Danger
Warns against an imminent danger.
▶Failure to observe this warning can result in death or in serious injury.
Warning
Warns against a potentially dangerous situation.
▶Failure to observe this warning can result in serious injury or even death.
Caution
Warns against a possible risk.
▶Failure to observe this warning can result in substantial or minor injuries.
notiCe
Warns against material damage.
Indicates additional information, advice or important recommendations.
Refers to information contained in these Operating Instructions or in other documents.
▶Indicates an instruction to be carried out to avoid a danger, a warning or a possible risk.
→Indicates a procedure to be carried out.
1.2 Definition of the word "device"
The word "device" used within these Operating Instructions refers to the insertion electromagnetic flowmeter
type 8045.
English
Type 8045

7
Intended use
2 INTENDED USE
Use of the device that does not comply with the instructions could present risks to people, nearby
installations and the environment.
The insertion electromagnetic flowmeter type 8045 is intended exclusively to measure flow rate in liquids.
▶This device must be used in compliance with the characteristics and commissioning and use conditions
specified in the contractual documents and in these Operating Instructions.
▶Never use this device for security applications.
▶This device must be protected against electromagnetic interference, ultraviolet rays and, when installed out-
doors, the effects of climatic conditions.
▶Only operate a device in perfect working order.
▶Requirements for the safe and proper operation of the device are proper transport, storage and installation, as
well as careful operation and maintenance.
▶Only use the device as intended.
3 BASIC SAFETY INFORMATION
This safety information does not take into account:
• any contingencies or occurrences that may arise during installation, use and maintenance of the devices.
• the local safety regulations for which the operating company is responsible including the staff in charge of
installation and maintenance.
Risk of injury due to high pressure in the installation.
▶Stop the circulation of fluid, cut off the pressure and drain the pipe before loosening the process connections.
Danger due to electrical voltage.
▶If a 18...36 V DC powered version is installed either in a wet environment or outdoors, all the electrical volt-
ages must be of max. 35 V DC.
▶Disconnect the electrical power for all the conductors and isolate it before carrying out work on the system.
▶Observe all applicable accident protection and safety regulations for electrical equipment.
Risk of injury due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Stop the circulation of fluid and drain the pipe before loosening the process connections.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and safety relating to the use of aggressive fluids.
English
Type 8045

8
Intended use
Various dangerous situations
To avoid injury take care:
▶not to use the device in explosive atmospheres.
▶not to use the device in an environment incompatible with the materials it is made of.
▶not to use fluid that is incompatible with the materials the device is made of.
▶not to subject the device to mechanical loads.
▶not to make any modifications to the device.
▶to prevent any unintentional power supply switch-on.
▶to carry out the installation and maintenance work by qualified and skilled staff with the appropriate tools.
▶to guarantee a defined or controlled restarting of the process, after a power supply interruption.
▶to observe the general technical rules when installing and using the device.
notiCe
The device may be damaged by the fluid in contact with.
▶Systematically check the chemical compatibility of the component materials of the device and the fluids likely
to come into contact with it (for example: alcohols, strong or concentrated acids, aldehydes, alkaline com-
pounds, esters, aliphatic compounds, ketones, halogenated aromatics or hydrocarbons, oxidants and chlorin-
ated agents).
notiCe
Elements / Components sensitive to electrostatic discharges
▶This device contains electronic components sensitive to electrostatic discharges. They may be damaged if
they are touched by an electrostatically charged person or object. In the worst case scenario, these compo-
nents are instantly destroyed or go out of order as soon as they are activated.
▶To minimise or even avoid all damage due to an electrostatic discharge, take all the precautions described in
the EN 61340-5-1 norm.
▶Also ensure that you do not touch any of the live electrical components.
English
Type 8045

9
General information
4 GENERAL INFORMATION
4.1 Manufacturer's address and international contacts
To contact the manufacturer of the device, use following address:
Bürkert SAS
Rue du Giessen
BP 21
F-67220 TRIEMBACH-AU-VAL
You may also contact your local Bürkert sales office.
The addresses of our international sales offices are available on the internet at: www.burkert.com
4.2 Warranty conditions
The condition governing the legal warranty is the conforming use of the device in observance of the operating
conditions specified in these Operating Instructions.
4.3 Information on the Internet
You can find the user manuals and technical data sheets regarding the type 8045 at: www.burkert.com
English
Type 8045

10
Description
5 DESCRIPTION
5.1 Area of application
The insertion electromagnetic flowmeter type 8045 is intended exclusively to measure flow rates in liquids.
The device makes it possible to switch a solenoid valve or activate an alarm thanks to a transistor output and,
for some versions, by means of two relay outputs, fully configurable and to establish a control loop thanks to a
4...20 mA current output.
The versions also equipped with a digital input make it possible to remotely activate a function.
5.2 General description
The device comprises both a flow sensor operating on Faraday's law and a transmitter with display.
The device is equipped with a 4...20 mA current output (analogue output, called AO1), a digital output (con-
figured as a pulse output by default, called DO1) and two totalizers.
Some versions are equipped with two relay outputs (called DO2 and DO3) and one digital input (called DI1).
The device operates on a 3 wire system and needs a 18...36 V DC power supply.
The electrical connection is made on the terminals blocks of the electronic board within the transmitter, through
two M20 x 1,5 cable glands.
5.3 Description of the rating plate
FLOW 8045 SST LONG SUPPLY: 18-36V– 300 mA
DO1: 5-36V– 100mA DO2/3: Rel 30V~ or 60V–
DI1: 18-36V– 10mA IP65 Fluid: PN16:-15/110°C
S/N 1000
00570481 W44MU
Made in France
12 5
69101213
3 4
1114 8 7
FLOW
15
1. Measured value and type of the device
2. Specification of the flow sensor
3. Specification of the DO1 digital output
4. Specification of the relay outputs DO2 and DO3
5. Electrical power supply and current
consumption
6. Manufacturing code
7. Conformity marking
8. Warning: Before using the device, take into
account the technical specifications described
in these Operating Instructions.
9. Certification
10. Fluid nominal pressure and fluid temperature
range
11. Protection class of the device
12. Specification of the DI1 digital input
13. Serial number
14. Article number
15. Shows the flow direction
Fig. 1 : Rating plate of the device (example)
English
Type 8045

11
Technical data
6 TECHNICAL DATA
6.1 Conditions of use
Ambient temperature –10...+60 °C
Air humidity < 85 %, non condensated
Height above see level max. 2000 m
Operating conditions Continuous
Equipment mobility Fixed
Use Indoor and outdoor
(Protect the device against electromagnetic interference, ultraviolet rays and,
when installed outdoors, against the effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
Protection class according to
IEC / EN 60529
IP65 1), if the device is wired and if the cable glands are tightened and the
cover lid is screwed tight.
1) not evaluated by UL
6.2 Conformity to standards and directives
The applied standards, which verify conformity with the EU Directives, can be found on the EU Type Examination
Certificate and/or the EU Declaration of Conformity (if applicable).
Conformity to the Pressure Equipment Directive
→Make sure the device materials are compatible with the fluid.
→Make sure the pipe DN is adapted for the device.
The device conforms to Article 4, Paragraph 1 of the Pressure Equipment Directive 2014/68/EU under the fol-
lowing conditions:
• Device used on a pipe (PS = maximum admissible pressure; DN = nominal diameter of the pipe)
Type of fluid Conditions
Fluid group 1, Article 4, Paragraph 1.c.i DN≤25
Fluid group 2, Article 4, Paragraph 1.c.i DN≤32
or PSxDN≤1000
Fluid group 1, Article 4, Paragraph 1.c.ii DN≤25
or PSxDN≤2000
Fluid group 2, Article 4, Paragraph 1.c.ii
DN≤200
or PS≤10
or PSxDN≤5000
UL certification
The devices with variable key PU01 or PU02 are UL-certified devices and comply also with the following standards:
• UL 61010-1
English
Type 8045

12
Technical data
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
6.3 Mechanical data
Part Material (8045 with flow sensor in
PVDF)
Material (8045 with flow sensor in
stainless steel)
Housing / seal PC / NBR Black PPA / NBR
Cover with lid / seal PC / silicone PSU / silicone
Front foil Polyester
M20x1,5 cable glands / seal PA / neoprene
Screws Stainless steel
Nut PC PPA
Flow sensor (exposed to the fluid) PVDF Stainless steel 316L (DIN 1.4404)
Seal FKM 8045 with a G2" nut: FKM
Earth ring of the flow sensor Stainless steel 316L (DIN 1.4404)
or Alloy C22
-
Electrodes holder - PEEK
Electrodes Stainless steel 316L (DIN 1.4404) or Alloy C22
Rating plate Polyester
8045 with flow sensor in PVDF 8045 with flow sensor in stainless steel
10
9
8
7
6
5
4
3
2
1
0
0 +20 +40 +60 +80
PVDF (PN10) /
PP (PN10)
P (bar)
PVC + PP
A
PVC (PN10)
T (°C)
Metal
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0-20 0 +20 +40 +60 +80 +100 +120
PVDF (PN10)
PVC (PN10)
PP (PN10)
T (°C)
P (bar)
PVC + PP
PVDF
A
DN100 for measuring
devices with a clamp con-
nection (PN10)
Metal
(PN16) 1)
1) Except DN100 for measuring devices with a clamp connection
A: range of use
Fig. 2 : Fluid pressure / fluid temperature dependency for a 8045 with PVDF flow sensor or stainless steel flow sensor and
a fitting S020 in metal, PVC, PVDF or PP
English
Type 8045

13
Technical data
6.4 Fluid data
Pipe diameter DN6 to DN400
Type of fitting S020
Fluid conductivity min. 20 µS/cm
Fluid viscosity < 1000 mPa.s
Fluid temperature
• 8045 with flow sensor in PVDF
• 8045 with flow sensor in stainless steel
The fluid temperature may be restricted by the fluid
pressure, the material the flow sensor is made of and
the material the S020 fitting used is made of. See Fig. 2.
• 0...+80 °C
• –15...+110 °C
Fluid pressure
• 8045 with flow sensor in PVDF
• 8045 with flow sensor in stainless steel
The fluid pressure may be restricted by the fluid
temperature, the material the flow sensor is made of,
the material the S020 fitting used is made of and the
DN of the S020 fitting. See Fig. 2.
• PN10 1)
• PN16 1)
Flow rate measurement
• Measurement range
• Measurement deviation ("measurement bias", as
defined in the standard JCGM 200:2012):
- with K-factor determined with a Teach-In
procedure
- with standard K-factor
• Linearity
• Repeatability
• 0.2...10 m/s
- ±0.5 % of the measured value 2) (at the value of
the Teach-In flow rate)
- ±3.5 % of the measured value 2)
• ±0.5 % of the full scale 2)
• ±0.25 % of the measured value
1) not evaluated by UL
2) Determined in the following reference conditions: fluid = water, water and ambiant temperatures = 20 °C, upstream and
downstream distances respected, appropriate pipe dimensions.
6.5 Electrical data
Operating voltage • 18...36 V DC,
• filtered and regulated
• oscillation rate: ±5 %
• Connection to main supply: permanent (through
external SELV and through LPS power supply)
Specifications of the power source (not supplied) of
the UL devices
• Limited power source according to UL / EN 60950-1
standards
• or limited energy circuit according to
UL / EN 61010-1, Paragraph 9.4
Current consumption 300 mA max. (at 18 V DC)
English
Type 8045

14
Technical data
Transistor output DO1
• type
• function
• frequency
• Electrical data
• duty cycle if f > 2 Hz
• min. pulse duration if f < 2 Hz
• protections
• NPN / PNP (wiring dependent), open collector
• pulse output (by default), user configurable
• 0...250 Hz
• 5...36 V DC, 100 mA max.
• 0.5
• 250 ms
• galvanically isolated, and protected against over-
voltages, polarity reversals and short-circuits
Relay outputs (DO2 and DO3)
• operating
• electrical data of the load
(non U-recognized devices)
• electrical data of the load
(U-recognized devices)
• max. breaking capacity
• life span
• hysteresis (by default), configurable, normally open
• 250 V AC / 3 A or 40 V DC / 3 A (resistive load)
• max. 30 V AC and 42 V peak / 3 A
or max. 60 V DC / 1 A
To use the relay outputs in a wet location, observe the
following DANGER safety instruction.
• 750 VA (resistive load)
• min. 100000 cycles
Current output AO1
• specification
• max. loop impedance
• 4...20 mA, sink or source (wiring dependent), 22 mA
to indicate a fault
• 1300W at 36 V DC,
1000W at 30 V DC,
700W at 24 V DC,
450W at 18 V DC
Digital input DI
• supply voltage
• input impedance
• min. pulse duration
• protections
• 18...36 V DC
• 15 kW
• 200 ms
• galvanically isolated, and protected against polarity
reversals and voltage spikes
Danger
Danger due to the operation of the relay outputs of a UL device in a wet location.
▶If a UL device is used in a wet location:
-energize the relay outputs with an alternating voltage of max. 16 Vrms and 22.6 Vpeak.
-or energize the relay outputs with a direct voltage of max. 35 V DC.
English
Type 8045

15
Technical data
6.6 Electrical connection
Type of connection Through two M20x1,5 cable glands
Cable specifications
• cable type
• Cross section
• Diameter of each cable:
- if only one cable is used per cable gland
- if two cables are used per cable gland
• shielded
• 0.5...1.5 mm2
- 6...12 mm
- 4 mm, with the supplied multi-way seal
English
Type 8045

16
Installation and commissioning
7 INSTALLATION AND COMMISSIONING
7.1 Safety instructions
Danger
Risk of injury due to high pressure in the installation.
▶Stop the circulation of fluid, cut off the pressure and drain the pipe before loosening the process connections.
Danger due to electrical voltage.
▶If a 18...36 V DC powered version is installed either in a wet environment or outdoors, all the electrical volt-
ages must be of max. 35 V DC.
▶Disconnect the electrical power for all the conductors and isolate it before carrying out work on the system.
▶Observe all applicable accident protection and safety regulations for electrical equipment.
Risk of injury due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Stop the circulation of fluid and drain the pipe before loosening the process connections.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and safety relating to the use of aggressive fluids.
Warning
Risk of injury due to non-conforming installation.
▶The electrical and fluid installation can only be carried out by qualified and skilled staff with the appropriate
tools.
▶Observe mounting instructions of the fitting or sensor-fitting.
▶Install appropriate safety devices (correctly rated fuse and/or circuit-breaker).
▶Install the circuit breaker or switch in a place which is easy to reach.
▶Identify the circuit breaker or switch as the electrical power cut-off system for the device.
▶It is imperative that devices be used that provide adequate protection against overloads.
▶Do not power a device, version 18...36 V DC, with an alternating voltage or with a direct voltage in excess of
36 V DC.
▶Respect standard NF C 15-100 / IEC 60364.
Risk of injury due to unintentional switch on of power supply or uncontrolled restarting of the
installation.
▶Take appropriate measures to avoid unintentional activation of the installation.
▶Guarantee a set or controlled restarting of the process subsequent to any intervention on the device.
English
Type 8045

17
Installation and commissioning
Warning
Risk of injury if the fluid pressure/fluid temperature dependency is not respected.
▶Take account of fluid pressure/fluid temperature dependency according to the nature of the materials the fit-
ting is made of (see the technical data and the Operating Instructions of the fitting used).
▶Comply with the Pressure Equipment Directive 2014/68/EU.
Warning
Danger due to non-conforming commissioning.
Non-conforming commissioning could lead to injuries and damage the device and its surroundings.
▶Before commissioning, make sure that the staff in charge have read and fully understood the contents of the
manual.
▶In particular, observe the safety recommendations and intended use.
▶The device / the installation must only be commissioned by suitably trained staff.
Protect this device against electromagnetic interference, ultraviolet rays and, when installed outdoors, the
effects of the climatic conditions.
7.2 Fluid installation onto the pipe
Danger
Risk of injury due to high pressure in the installation.
▶Stop the circulation of fluid, cut off the pressure and drain the pipe before loosening the process connections.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and safety relating to the use of aggressive fluids.
The insertion electromagnetic flowmeter type 8045 has to be inserted into an S020 fitting mounted on a pipe.
English
Type 8045

18
Installation and commissioning
7.2.1 Recommandations for installing the 8045 on the pipe
→Choose an S020 fitting appropriate to the velocity of the fluid inside the pipe: refer to the graphs below:
0.10.3 0.51 35 10
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
20
50
100
200
m3/h
0.2
0.5
1
2
5
10
20
50
100
200
500
1000
2000
3000
l/min
0.30.5 1351030
m/s
fps
US gpm
0.05
0.1
0.2
0.5
1
2
5
10
20
50
100
200
500
1000
DN 65 (DN80)*
DN 50 (DN65)*
DN 40 (DN50)*
DN 32 (DN40)*
DN 25 (DN32)*
DN 20 (DN25)*
DN 15 (DN15 / DN20)
*
500
1000
2000
2000
5000
10000
5000
20000
5000
10000
20000
30000
50000
100000
DN 400
DN 350
DN 300
DN 250
DN 200
DN 150
DN 125
DN 100
DN 80 (DN100)*
DN 6
DN 8
Example
Flow rate
Fluid velocity
Example:
• Specification: if the nominal flow rate is
10 m3/h, the ideal flow velocity is between 2
and 3 m/s.
• Solution: intersection between flow rate and
flow velocity in the graph gives the appro-
priate pipe diameter, DN40 (or DN50 for the
asterisked fittings).
* For the fittings:
• with external thread connections acc. to
SMS 1145
• with welding end connections acc. to
SMS 3008,
DIN 11866 Rg C / BS 4825-1 / ASME BPE
or
DIN 11850 Rg 2 / DIN 11866 Rg A /
EN 10357 Rg A
• with Clamp connections acc. to SMS 3017,
BS 4825-3 / ASME BPE
or
DIN 32676 Rg A
→Install the device on the pipe in such a way that the upstream and downstream distances are respected
according to the design of the pipes, refer to standard EN ISO 5167-1 and Fig. 3:
English
Type 8045

19
Installation and commissioning
flow direction
50 x DN 5 x DN 40 x DN 5 x DN
25 x DN 5 x DN 20 x DN
5 x DN
18 x DN 5 x DN 15 x DN 5 x DN
With control valve Pipe with 2 elbows at 90° in 3
dimensions
Pipe with 2 elbows at 90° Pipe with 1 elbow at 90° or 1
T-piece
With pipe expansion With pipe reduction
Fig. 3 : Upstream and downstream distances depending on the design of the pipes.
→Respect the following additional mounting conditions to ensure that the measuring device operates correctly:
- Preferably install the device at a 45° angle to the horizontal centre of the pipe to avoid having deposits on the
electrodes and false measurements due to air bubbles (see Fig. 4);
45°
45°
Fig. 4 : Mounting angle on the pipe
- Ensure that the pipe is always filled in the section around the device (see Fig. 5).
- When mounting vertically ensure that the flow direction is in an upward direction (see Fig. 5).
Horizontal mounting
Correct Incorrect
Vertical mounting
Correct Incorrect
flow direction
Fig. 5 : Filling of the pipe
English
Type 8045

20
Installation and commissioning
- Prevent the formation of air bubbles in the pipe in the section around the device (see Fig. 6).
- Always mount the device upstream a possible injection point in the pipe of a high-conductivity fluid (for
example: acid, base, saline,...).
Correct flow direction Incorrect
Correct Incorrect
Fig. 6 : Air bubbles within the pipe
→If necessary, use a flow conditioner to improve measurement precision.
7.2.2 Installation into the pipe of a 8045 with a G2'' nut
In order to ensure a high accuracy of the measurements and good stability of the „flow zero“ point, install
the device into the processed medium at least 24 hours before calibration.
1
2
3
5
4
6
FLOW
flow direction
Electrodes
→Install the fitting (see mark 4, Fig. 7) into the
pipe taking into account the recommendations in
chap. 7.2.1.
→Check that there is a seal 6 on the device 1.
→Insert the nut 3 on the fitting 4.
→Insert the snap ring 2 into the groove 5.
→Position the device 1 in order the arrow on the
side of the housing indicates the direction of the
flow. The totalizers will increment.
→Insert the device 1 into the fitting 4.
→Tighten the nut 3 by hand on the device 1.
Fig. 7 : Installation into the pipe of a 8045 with a G2'' nut
English
Type 8045
