busbi WASP User manual

WASP
USE OF ELECTRIC SCOOTERS
LEGAL WARNING:
•United Kingdom law –This e-scooter is not to be used on public roads, cycle paths or
pavements.
•Only to be used on private land and with the landowner’s permission.
IMPORTANT!
Read these instructions carefully and keep for future reference
Do not use the e-scooter when under the influence of medication or alcohol.
The user should check the limits of use in accordance with the local regulations (e.g. use in
pedestrian areas, on-road).
Watch for pedestrians and others in your vicinity when riding.
Always wear a helmet and suitable footwear when riding this e-scooter.
Ensure your battery is fully charged before use.
This product is not a toy, and is intended for riders aged 16+ years.
PLEV Class 2 - Designed to carry a single rider.
Do not use this e-scooter in rain, snow or icy conditions.
Read this manual and all warning labels on the product before using this product.

2
Additional Information
For more guidance and support videos to help you get started, please visit: busbistore.com/videos
or, simply open the camera app on your mobile phone, and point the camera at the QR code below:
Warnings
The following symbols and words are used in this user manual to signal and warn against
personal injury or damage to property. Warnings are intended to draw attention to potential
dangers.
Failure to follow a warning, may result in injury to yourself or other people , as well as causing
damage to property. Please read and follow all warnings.
DANGER
This warning identifies a hazard with a high degree of risk, that could result in
serious injury or death if not avoided.
WARNING
This warning identifies a hazard with a moderate degree of risk, that could
result in serious injury if not avoided.
CAUTION
This warning identifies a hazard with a low degree of risk, that could result in
minor or moderate injury if not avoided.
NOTE
This warning calls attention to potential property damage.

3
Table of Contents:
Section:
Page
Section:
Page
1. General Information.
4
6. General Maintenance.
119
1.1 Warranty.
4
6.1. Stem Locking Mechanism.
119
1.2 Conditions of Use.
4,5
6.2. Brake Adjustment and Maintenance.
119
2. Getting Started.
6
6.3. Adjusting the Mechanical Disc Brake.
119
2.1 Package Contents.
6
6.4. Brake discs.
220
3. Preparing for First Use.
8
6.5. Changing the Brake pads.
220
3.1 Assembly.
8,9
7. Cleaning and Storage.
220
3.2 Brake Cables –Fitment.
10
8. Further Guidance for safe use.
221
3.3 Folding and Unfolding the Busbi Wasp.
10,11
8.1. Weight limits.
222
3.4 Charging.
11
8.2. Maximum travel distance.
222
3.4.1 Connect the Charger.
11
9. Safety Features.
223
3.4.2 Charging Complete.
11
10. Busbi - Reducing Waste.
224
4. Riding your Busbi Wasp.
12,13
10.1 Disposal.
224
4.1 Braking.
14
4.2 Display Console.
15
Annex A
4.3 Lights –Operation.
15
Table 1 Inspection Schedule.
225
4.4 Speed modes.
15
Table 2 Wasp Specifications.
226
5. Battery Charging.
16
Table 3 Charger Specifications.
226
5.1. Battery Care and Safety.
16
Table 4 Wasp Dimensions.
226
5.2. Using the Battery Charger.
16
Table 5 Battery specifications.
227
5.3. Charging Procedure.
17
Declaration of Conformity.
228
5.4. Battery.
17
5.5. Battery Life.
17
Serial Number Identification.
229
5.6. General Precautions.
17,18
5.7. Battery service life.
18
5.8. Using the battery.
18

4
READ BEFORE USE
1. General Information:
This instruction manual will provide you with the information you need to use and maintain
your Busbi Wasp e-scooter.
Please read and retain these instructions for future use.
This manual contains important instructions for safety and care.
It is the responsibility of the user to read this manual and to follow these instructions before
using theproduct.
Failure to follow these instructions exposes the rider to the risk of injury or death.
Regular checks and maintenance are necessary to prevent premature wearor damage to
components which may result in an accident and or damage to your e-scooter.
1.1. Warranty.
Our Warranty does not cover normal wear and tear, damage caused by accidents, improper
use, excessive loads, improper assembly or maintenance, and damage caused by
modification.
1.2 Conditions of Use.
•At the time of manufacture, it is illegal to use an e-scooter on public roads, pavements,
cycle lanes or bridleways in the United Kingdom.
•Before use, read this manual carefully ensuring that you have understood all
information.
•This e-scooter is designated PLEV Class 2.
•This e-scooter is intended to be used by one rider at a time.
•This e-scooter is to be used by persons aged 16 years and above.
•You may use an e-scooter on private land, where the owner has given permission.
•This e-scooter is not intended for use on rough uneven ground, doing so may lead to a
fall and serious injury.
•This e-scooter must be properly maintained in accordance with these instructions.
•Periodically inspect your e-scooter confirming it is in safe working order.
•If you are in any doubt over the safe working order of your e-scooter, stop using it
immediately and consult a competent tradesman.
•Failure to comply with any warnings may result in injury to persons and property, and/or
cause premature and potentially irreversible damage to your electric scooter.
•This e-scooter incorporates an electric hub motor located in the front wheel.
•The hub motor is activated when the scooter is switched on and the throttle lever is
pressed.
•The hub motor drive disengages as soon as the brake lever is pulled.
•This e-scooter is electronically limited to a maximum speed of 25km/h.
• Do not ride the e-scooter in rain, snow or icy conditions.
• Do not use the scooter when under the influence of medication or alcohol.

5
• Wear a helmet at all times when riding your e-scooter.
• Wear appropriate footwear when using this e-scooter.
• Your Busbi Wasp has a waterproof rating of IPX4, this means your Busbi Wasp is
protected against splashes of water.
• This e-scooter must be properly maintained according to these instructions.
• Carry out periodic checks as described in this manual to ensure your e-scooter is in
safe working order.
• Read this manual carefully and ensure that you have understood all the product
information before using it.
•The e-scooter is delivered with cruise control enabled.
You are advised to engage a professional tradesman to perform maintenance on your
e-scooter every six months, to ensure it is in good working order and safe to use.
It is the owner’s responsibility to ensure that all components are in safe working order
before use.
Choose a safe place, away from traffic, to familiarise yourself with your new electric
scooter. The hub motor may start in a sudden forceful manner, check that your
handlebars are straight and that the path is clear.
Take time to familiarise yourself with riding and controlling your e-scooter to avoid a
serious accident during the first few weeks.
Ensure you are in good health before riding your e-scooter.
In case of poor weather conditions, proceed with care and adjust your speed
and reactions accordingly.
The user must comply with the requirements of national regulations when using the
electric scooter on public roads (for example, lighting and signalling).
As with any mechanical component, a vehicle is subject to high stresses and wear.
The various materials and components may react differently to wear or fatigue.
If the expected service life for a component has been exceeded, it may break
suddenly, therefore risk causing injuries to the user. Cracks, scratches and discoloration
in the areas subject to high stresses indicate the component has exceeded its service
life and should be replaced.
IMPORTANT!
For your safety: Before each and every use, carry out the inspection schedule
described at Annex A, Table 1 , found at the end of this instruction manual.
CAUTION
WARNING

6
2. Getting started.
Attention: Please fully charge your Busbi Wasp before first use.
Your Busbi Wasp e-scooter is a two wheeled electric scooter, powered by a Lithium-ion
battery located inside the frame of the foot deck, and a hub motor incorporated in the
front wheel.
Your Busbi Wasp does not require connection with any external devices such as mobile
phones in order to operate.
Attention: Your Busbi Wasp is delivered with cruise control enabled.
Please familiarise yourself with this function before riding.
2.1. Package Contents.
Please check the contents as listed below and retain your packaging in case the
need to return your purchase.
User
Manual
Battery
Charger
Extension
Nozzle
Screws
Allen
Key
2 x
Busbi Wasp
Cable
lock.
Eco Friendly
Packaging

7
Display
Rear Brake Handle
(with bell)
RH Handle Bar Grip
Locking Buckle
(Used when folded)
Rear light
Front mud guard
Hub Motor
Rubber foot deck.
Kick stand
Brake Caliper
Side Reflector
Front wheel.
Rear Mud Guard
Locking Hook
(Used when folded)
LH Handle Bar Grip
Throttle
Handlebar
Stem
Disc Brake
plate
Side Reflector
Locking Hook
(Used when folded)
Power
Button
Charging
Port
Safety
Pin
Charging
Port
Locking
Lever

8
3. Preparing for first use:
Open the box and carefully take out all the parts, confirming the
contents.
Please retain the packaging, this will allow return of the product in
the event of any problems.
3.1 Assembly.
Place the e-scooter on the floor.
Push straight down on the rear mud guard
and hold, so as to release the locking hook
from the buckle.
Whilst holding down the rear mud guard, pull
the handlebar stem up and forward until you
hear the handlebar locking mechanism
engage with a ‘click’.
Place the scooter onto the kick stand.
Using the Allen key provided, unscrew and
remove the two bolts holding the locking hook
to the handlebar stem.
Remove the plastic stopper from top of the
handlebar stem. Retain the plastic stopper
with your packaging in case of return.

9
Please note, the following operation would
benefit from the assistance of a second
person holding the handlebars.
Identify the three cable connectors attached
to the handlebar assembly, and the
corresponding connectors in the handlebar
stem.
• Battery
• Rear Light
• Motor
Whilst supporting the handlebar assembly,
identify the correct orientation of each
matching connector pair.
Connect the three pairs of connectors,
ensuring each is fully pressed home.
Now gently introduce the handlebar
assembly into the stem tube whilst gently
pushing the cables and connectors inside
the handlebar stem.
Be careful not trap, pinch or damage the
electrical cables. If too much resistance is
felt, remove the handlebar assembly and
reposition the cables and connectors inside
the stem tube and repeat the above.
Align the two bolt holes of the handlebar
assembly neck with the holes in the stem.
Re-position the Locking Hook and secure
the two bolts through the three parts using
the Allen key provided.
Attention: Take care not to cross thread
the screws.

10
3.2 Brake Cable –Fitment
• Depress the brake lever and insert the head of the brake cable into the brake lever
bracket.
• Thread the cable through the slot in the brake lever until the sheath fits into the port
on the brake lever. Attention: You must pull on the sheath to perform this
operation.
• Check the brake operation by pulling the brake lever and confirm brake calliper
movement accompanied by inability to move the scooter through pushing.
• If necessary adjust the brake calliper see, Section 6.2
3.3 Folding and Unfolding the Busbi Wasp.
Please take time to view our helpful video by scanning the QR code found in the
introduction or by visiting: busbistore.com/videos
The Busbi Wasp is fitted with a unique locking mechanism, providing added safety.
The method of unfolding is as follows:
Unfolding the Busbi Wasp
• Push straight down on the rear mud
guard and hold, so as to release the
locking hook from the buckle.
• Whilst holding down the rear mud guard,
pull the handlebar stem up and forward
until you hear the handlebar locking
mechanism engage with a ‘click’.
• Place the scooter onto the kick stand.
Before riding the e-scooter, confirm the
Safety Pin is in the fully locked home
position.
(Red Stopper should be in contact with the
scooter frame).
WARNING
