Buyers Salt Dogg SHPE1000 Series User manual

1
9049 Tyler Blvd. • Mentor, Ohio 44060
Phone [phone] • Fax [phone]
Toll-Free Fax [phone] • saltdogg.com
Installation Instructions
—continued inside
SHPE1000 Series SaltDogg®
Electric Drive Poly Hopper
Spreader
1.0 cubic yard
U.S. PATENT 9,562,333
Table of Contents
General Information .....................................................................1
Safety Precautions .......................................................................1
Warranty Information ...................................................................2
Installation Instructions ............................................................ 2-4
Spreader Operation .....................................................................5
Spreader Maintenance.................................................................5
Repair Parts & Drawings .........................................................6 -10
General Information
Spreader models:
• SHPE1000- spreader with standard length chute
• SHPE1000X- spreader with extended length chute
Overall Length: 72 inches
Overall Width: 48 inches
Overall Height: (installed): 34 inches
Empty Weight:
343 lbs. (standard chute), 347 lbs. (extended chute)
Capacity Struck: 1.0 cu. yd.
Average Installation Time: 3 hrs.
Vehicle Requirements
• 1/2 or 3/4 ton pick-up truck.
• 135 AMP or higher alternator is recommended.
SHPE1000 SALTDOGG®SPREADER WARRANTY
INFORMATION
This warranty replaces all previous warranties and no
employee of this company is authorized to extend addi-
tional warranties, or agreements, or implications
not explicitly covered herein.
Buyers Products Company warrants all parts of the
product to be free from defects in material and workman-
ship for a period of two (2) years. Parts must be properly
installed and used under normal conditions. Normal wear
is excluded.
Any part, which has been altered, including modifica-
tions, misuse, accident, or lack of maintenance will not
be considered under this warranty.
The sole responsibility of Buyers Products Company
under this warranty is limited to repairing or replacing any
part(s), which are returned, prepaid, 30
days after such defect is discovered, and returned part(s)
are found to be defective by Buyers Products Company.
Authorization from Buyers Products Company must be
obtained before returning any part. The following infor-
mation must accompany defective parts returned
to Buyers Products Company: RMA #, spreader model,
serial number, date installed, and distributor from whom
purchased.
Buyers Products Company shall not be liable for damage
arising out of failure of any unit to operate properly, or
failure, or delay in work, or for any consequential dam-
ages. No charges for transportation or labor performed
on any part will be allowed under this warranty.
CAUTION
Do not overload vehicle beyond the vehicle’s GVWR or GAWR.
Check vehicle's load rating certification sticker for maximum
vehicle capacity.
Materials Recommended to Spread
Average Material Weights
Materials to use Weight (pounds per cubic yard)
Fine Salt-Dry 2,250
Coarse Salt-Dry 1,431
Sand/Salt up to 50/50 Mix-Dry 2,700
Note: To calculate the total spreader weight (including ice
control material), add the empty spreader weight plus the ice
control material and spreader accessories.

2
LOCK CHUTE
USING BOTH LATCHES
Safety Precautions
WARNING
Observe the following Safety Precautions before, during and
after operating this spreader. By following these precautions and
common sense, possible injury to persons and potential damage
to this machine may be avoided.
1. Read this entire Owners Manual before operating this
spreader.
2. Read all safety decals on the spreader before operating.
3. Check to make sure all safety guards are securely
mounted into place before operating this spreader.
4. Verify that all personnel are clear of the spreader
spray area before starting or operating this spreader.
5. Do not over-load your vehicle beyond payload limits.
If there are any questions, contact the vehicle manufacturer.
6. Do not adjust, clean, lubricate or unclog material
jambs without first turning off the spreader.
7. Do not climb on or in the spreader during operation.
Do not ride on the spreader while the vehicle is in motion.
8. Make sure the spreader is securely fastened to the vehicle in
accordance with this manual.
9. Do not operate a spreader that is in need of maintenance or
repairs.
10. Always disconnect the battery before removing or replacing
electrical components.
Installation Instructions
1. Mounting the Spreader onto the Vehicle:
A. Remove the tailgate from the vehicle.
B. Check truck’s bed for all kinds of sharp debris
or foreign objects. They can cut and seriously damage
poly hopper.
C. Lift spreader using tie downs (fig. 1), or using fork lift.
D. Lower spreader into the truck bed.
E. Center the spreader from side to side on the vehicle.
F. Attach the Chute Assembly to the spreader. First, hook the
Chute to the spreader by openings in the Chute’s handle.
Fig. 2
Then rotate the Chute into operating position and lock using two
spring latches.
G. Slide spreader towards front of the truck leaving adequate
space between chute and truck (2-3 inches). Measure the
distance from the front of the truck bed to front of the hopper’s
front legs. Fabricate spacer to fit between front of the spreader
and front of the bed per Fig. 4 and Fig. 5
Fig. 3
Fig. 1
USE ALL TIE-DOWNS
TO LIFT SPREADER

3
12"
6"
2" x 4"
2" x 6"
FIT TO BOX
FIT TO BOX
C. Apply dielectric grease or similar compound to
connectors before assembly. Connect the round
connector on the wire harness to the round connector on the
controller.
D. Lay out path for the power cable in the truck’s engine
compartment. Drill hole in the firewall or use an existing one to
pass the wire harness. Passing the power cable from inside of
the cab to the battery is recommended to protect the large high
amperage connector. Do not route the power cable close to
exhaust system!
E. Connect power cable connector to controller.
F. Connect the power cable ring terminals to the truck battery
(Fig. 7).
H. Secure spreader using four ratchet straps as shown in
Fig. 6. Tighten straps evenly to secure spreader in the middle of
the truck box.
Fig. 4
Fig. 5
Verify with the vehicle’s manufacturer that the factory
installed anchor points are designed for tie-down such load.
Inspect straps and hardware after each time spreader is
loaded. Tighten straps and hardware if necessary.
Fig. 6
2. Install Control Box & Vehicle Wiring Harness (Fig. 7).
NOTE: THIS IS A WIRE GROUND ELECTRICAL SYSTEM! NO
CONNECTIONS TO TRUCK'S FRAME OR BODY ALLOWED!
ALWAYS DISCONNECT BATTERY BEFORE ATTEMPTING
TO INSTALL ELECTRICAL COMPONENTS ON YOUR
VEHICLE.
To insure good performance of your spreader, check the
condition of truck’s electrical system. Using digital voltmeter,
check alternator and battery voltage. The voltage reading should
fall between 13.6 and 15.3 volts with engine running, head lights
and heater fan turned on. If voltage reading falls out of this range,
check and adjust your electric system.
A. Lay out a wiring path for the Vehicle Wiring Harness. Connect
the Wire Harness smaller terminal to the Chute’s harness, large
terminal to the Hopper’s harness. Drill all necessary holes or use
existing ones to pass the round connector into the trucks cab.
Secure harness to truck’s frame.
B. Mount the Controller in a convenient location in the truck cab.
Do not mount controller directly in front of the heat vents. Allow
ample air space around controller. Protect controller from water,
dirt and dust.
WARNING
Do not drill holes into fuel tanks, fuel lines, through electrical
wiring, etc that may be damaged by drilling.
CAUTION
Do Not Mount Controller In Way Of Air Bag Deployment. Do Not Drill Or Tap
Into Controller! Warranty Will Be Void!
WARNING
Use extreme caution when working around an operating vehicle
engine.
ATTENTION
Do not connect black (negative) wire to any part of vehicles
frame. Connect this terminal to battery’s negative terminal.

4
Fig. 7
full speed for 2 seconds, then slow down to dialed speed.
5. To activate the vibrator press the vibrator switch ON. Vibrator
switch will illuminate.
6. To stop the spreader, push ON-OFF switch to OFF position.
Controller Warnings
Check controller instruction sheet for latest controller updates
and troubleshooting codes. Controller instruction sheet is inside
controller shipping box.
IMPORTANT! INSTALLER, DO NOT DISCARD CONTROLLER
INSTRUCTION SHEET. STAPLE SHEET TO SPREADER
MANUAL AND GIVE TO END USER!
Note: To unclog auger manually, first remove the chute. Apply
1¼" open wrench on auger’s nut. Turn auger counterclockwise
several times.
Note: Do not run the vibrator longer than 30 minutes with 15
minutes between runs to avoid overheating.
Material Flow Adjustments
Always use screen during spreader operation! Various
materials have different moisture absorption rate, some
materials may not perform as desired. Therefore, the
substitution of the alternate material may be necessary for
optimum performance.
SHPE1000 has one discharge opening covered with two
adjustable deflectors. To adjust amount of material going
through this opening loose two screws, slide deflectors to
increase or reduce opening exposure. It is recommended
Thoroughly clean battery terminals. Make sure battery
terminals have no tarnish or corrosion.
DO NOT CONNECT WIRE HARNESS TO DAMAGED
OR CORRODED TERMINALS! IT MAY RESULT IN
OVERHEATING, LOST POWER AND POTENTIAL
CONTROLLER DAMAGE!
G. Attach utility light (optional) to spreader hopper in desired
location. Connect as shown in Fig. 7. Use utility light kit part
number 3018009.
H. See controller instructions for latest updates and error
codes.
Spreader Operation
1. Different materials absorb moisture at different rates and
some materials may not perform as desired. Subsitution
of an alternative material may be necessary for optimum
performance.
2. When filling hopper use the supplied screen to prevent large
chunks of material and debris in the material to get into hopper
and cause damage.
3. Material must never be left in hopper for an extended
period of time. Material will absorb moisture, bind, harden
and could prevent spreader from proper operation or may
damage the spreader.
4. The SHPE1000 spreader is equipped with a dual independent
speed controller with warning indicators and a vibrator switch.
To start the spreader, press the ON-OFF switch. Switch will
illuminate. The auger will accelerate to full speed for 2 seconds,
then slow down to dialed speed. The spinner will accelerate to
3014199
3006724
3035933
CB120PB
3001379
BATTERY POSITIVE
BATTERY NEGATIVE

5
ATTACH HOOKS TO TARP RINGS
PASS STRAP TS15
BEHIND ROUND POST PASS STRAP TS20
BEHIND ROUND POST
LOOSE SCREWS
SLIDE DEFLECTORS TO OPEN/CLOSE DISCHARGE OPENING BELOW.
RETIGHTEN SCREWS AFTER ADJUSTMENT.
to expose more of rear (closer to truck's rear end) portion of
discharge opening to increase flow without overloading auger
gear motor. (Fig 8)
IMPORTANT! -Always turn off power before making any
spreader adjustments!
3. Lubricate bearing every 7-10 hours of operation using general
automotive grease.
4. Inspect terminals/connectors every time you disconnect
spreader from wire harness. Apply thin layer of dielectric grease
on terminals. If any tarnish/corrosion is found, clean terminals
and apply dielectric grease.
5. Use dielectric grease on all electrical connectors before an
electrical connection is made or after connector is disconnected
6. Empty the spreader of all ice control materials when not in
use. Wash out the spreader to prevent material builds up.
7. It is recommended to cover spreader with the tarp during
storage periods.
Fig. 8
Fig. 9
Spread Pattern Adjustment
Spread pattern can be adjusted by changing spinner disc speed
on controller by turning Spinner knob to desired speed level
from 1 (low) to 9 (high). Direction of material spread can also be
adjusted by rotating shield on chute assembly. To rotate shield
lose 2 wing nuts, rotate shield in desired direction, and retighten
wing nuts. See Fig.9. Make sure that after adjustment, bracket
stays inside shield groove located on top of shield. In addition,
chute assembly can be adjusted to lighter (drier) and heavier
(more moist) materials. Use different holes on bracket for lighter
or heavier materials to have material drop on spinner disc
center. See Fig.9.
WARNING
Never remove spreader with material in hopper.
End of Season Maintenance
1. Wash spreader. Make sure no material or residue is left in and
outside the hopper.
2. Lubricate bearing using general automotive grease.
3. Inspect wire harness, connectors for broken insulation, missing
components. Replace if necessary.
4. Apply dielectric grease on all electrical connectors.
5. Store hopper indoors, in a dry, cool place.
6. Remove controller from truck. Store controller indoors, in a dry,
cool place.
7. Inspect wire near connectors. Check for broken or missing
insulation. Check for tarnished or corroded wires. Trim corroded
wires and replace connectors if necessary.
Summer Storage
1. Apply dielectric grease or similar protective compound on all
electrical connectors & protect them with caps before storage.
2. Disconnect and remove speed controller from vehicle and
store it in dry and cool place. Protect controller from excessive
heat and moisture.
3. Clean hopper and trough from all kinds of debris.
4. Remove, thoroughly lubricate and reinstall trough bearing.
5. Protect hopper from excessive temperatures during
summer storage.
LOOSE WING NUTS
ROTATE SHIELD
HOLES FOR BRACKET
POSITION ADJUSTMENT
Spreader Maintenance
1. Wash spreader after every use. Make sure no material is left
under auger and/or inside trough.
2. Inspect and retighten fasteners after every 5-7 hours of
operation.

6
Bill of Materials Bill of Materials
ITEM PART NO. QT Y. DESCRIPTION
13007526 1 CHUTE POLY. EXT. LENGTH
23006833 1 GEAR MOTOR 12 VDC. SPINNER
33007824 1RETAINER GEARMOTOR, CHUTE
4FWL031058008SS 3 WASHER, 5/16 LOCK SST
5
FCS031018063SS 3 SCREW, HHC 5/16-18 X 5/8 SST
63012393 1SPINNER, 14" POLY CW
73027699 1HANDLE, CHUTE
83007564 1 BRACKET, SHIELD SST
93007004 1SHIELD, SPINNER, SHPE1500
10 3007413 1 COVER, GEAR MOTOR, CHUTE
11 FWF038100007SS 16 WASHER, FLAT 3/8 USS SST
12 FCS038016100SS 10 SCREW, HHC 3/8-16 X 1 304 SST
13 FNE038016044SS 10 NUT, NYLOCK 3/8-16 X 7/16 SST
14 3007522 6SCREW, SHEET MTL #12x1.0 HEX WASHER
HD SST
15 3007113 1 PIN, CLEVIS, 5/16 X 2-1/2, .141 HOLE ZN
16 FPC013000100 1 COTTER PIN, 1/8 X 1, ZINC
17 3002631 1LABEL, "NO STEP"
18 3007844 1 DECAL, DANGER STAY CLEAR
19 3025065 1BUSHING STRAIN RELIEF
Repair Parts - Standard Chute Assembly Repair Parts - Extended Chute Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
ITEM PART NO. QT Y. DESCRIPTION
13025063 1 CHUTE POLY, SHPE STD. LENGTH
23033665 1BRACKET WELDMENT, CHUTE
33006833 1 GEAR MOTOR 12 VDC. SPINNER
4
3027699 1HANDLE, CHUTE
5FWF038100007SS 10 WASHER, FLAT 3/8 USS SST
6FCS038016125SS 8 SCREW, HHC-3/8-16 X 1.25 SST
7FNE038016044SS 8 NUT, NYLOCK 3/8-16 X 7/16 SST
8FWF031075006SS 3 WASHER, 5/16 SAE SST
9FCS031018063SS 3 SCREW, HHC 5/16-18 X 5/8 SST
10 3012393 1SPINNER, 14" POLY CW
11 3025067 1ENCLOSURE, GEAR MOTOR
12 3025065 1BUSHING STRAIN RELIEF
13 3001537 3 SCREW, S0CBHCS #10 X 5/8 SST
14 FNE010024024SS 3 NUT, ELASTIC STOP 10-24 SS
15 3007113 1 PIN, CLEVIS, 5/16 X 2-1/2, .141 HOLE ZN
16 3017444 1SHIELD, CHUTE
17 3014960 2 BOLT, 3/8-16 X 1 CARRIAGE SHORT NECK SS
18 3017356 2 WASHER, EXTERNAL TOOTH LOCK 3/8 SS
19 3025064 2
NUT, 3/8-16 WING, SST
20 3014994 1 PIN,COTTER,1/8IN X 1IN SST

7
Bill of Materials
Repair Parts-Hopper Assembly
ITEM PART NO. QT Y. DESCRIPTION
13022973 1 HOPPER POLY 1 CU YA
23024289 1TROUGH ASSEMBLY, SHPE
33022230 2CROSS MEMBER
43022976 1BRACKET VIBRATOR, WELDMENT
5
3024288 2RETAINER VIBRATOR
6FWF038100007SS 6 WASHER, FLAT 3/8 USS SST
7FNE038016044SS 4 NUT, NYLOCK 3/8-16 X 7/16 SST
83007416 1 VIBRATOR 200 LBS 12 VDC
93017356 4 WASHER, EXTERNAL TOOTH LOCK 3/8 SS
10 FCS038016125SS 4 SCREW, HHC-3/8-16 X 1.25 SST
11 3007115 10 WASHER, FLAT 3/8 X 1.5 X.048 SST
12 FWL038069009SS 12 WASHER, LOCK RHS-3/8 SST
13 FCS038016075SS 12 SCREW, HHC-3/8-16 X 3/4 SST
14 3007236 1COVER GEARMOTOR
15 3007821 1STRAIN RELIEF BUSHING
ITEM PART NO. QT Y. DESCRIPTION
16 FWL025050006SS 6 WASHER, 1/4 IN. SPRING LOCK SST
17 FCS025020075SS 6 SCREW, CAP 1/4-20 X 3/4 SST
18 3007522 6
SCREW, SHEET MTL #12x1.0 HEX WASHER
HD SST
19 4375 4 CLAMP, HOSE .4375, 9/32 HOLE
20 3022220 4
TIE-DOWN WELDMENT
21 FWF050106010 12 WASHER, FLAT 1/2” SAE ZINC
22 3005140 12 SCREW, HH1/2-13 x 3.5, GR 5 ZN
23 FNE050013053 12 NUT, NYLOCK 1/2-13 ZINC
24 3022977 2 DEFLECTOR
25 9240132 1 DECAL #2, DANGER BEFORE SVCE
26 3012898 1 DECAL, CHECK STRAPS
27 3022955_ 1 HOSEGREASE, 1/8 NPT, 36 IN LONG
28 3020713 1 CONNECTOR, MALE, FEMALE
29 H3309X2 1 CONNECTOR, FEM NPT TO FEM NPT 1/8 X 1/8
30 800 1 GREASE FITTING, 1/4 STD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1516 17
18
19
20
21
22
23
24
25
26
27
28 29 30

8
9049 Tyler Blvd. • Mentor, Ohio 44060
Phone [phone] • Fax [phone]
Toll-Free Fax [phone] • saltdogg.com
3027465_D
Bill of Materials
Repair Parts- SpreaderRepair Parts- Trough
Bill of Materials
1
2
3
4
5
6
7
8 9
1011
12
ITEM PART NO. QT Y. DESCRIPTION
13024290 1TROUGH WELDMENT SHPE1500
23007000 1 GASKET, FELT BEARING
33018919 1BEARING, 2-HOLE FLANGED 1" SST
4FNE038016044SS 2 NUT, NYLOCK 3/8-16 X 7/16 SST
5
3018007 1AUGER SHPE SST
63007824 1RETAINER GEARMOTOR, CHUTE
73009995 1GEAR MOTOR, AUGER SHPE
8FWL031058008SS 3 WASHER, 5/16 LOCK SST
9FCS031018063SS 3 SCREW, HHC 5/16-18 X 5/8 SST
10 FPY031000150 1 PIN, CLEVIS, 5/16 X 1-1/2, W/ 5/32 PH, ZN
11 3014994 1PIN,COTTER,1/8IN X 1IN SST
12 3006844 1WIRE HARNESS
ITEM PART NO. QT Y. DESCRIPTION
13022974 1 HOPPER ASS'Y 1 CU YA
23022978 1SCREEN SHPE1000
366050 4 SNAPPER PIN, 1/4 X 2, YLW ZINC
43022980 1LABEL SERIAL NUMBER SHPE1000
5
3025070 1 CUTE ASSEMBLY. STD LENGTH
63007527 1 CHUTE POLY EXT. ASSEMBLY
73027463 1HARDWARE KIT SHPE1000
83014199 1CONTROLLER, SHPE, SALT DOGG
93006724 1WIRE HARNESS, MAIN
10 3035933 1 POWER CABLE, CONTROL BOX
11 1496505 1 HOLD DOWN KIT, SPREADER (4 STRAPS)
12 3022979 1TARP SHPE1000
13 TS20 2 STRAP, RUBBER TARP 20" (27" MAX)
14 TS15 2 STRAP, RUBBER TARP 15" (22" MAX)
15 9225 8 S-HOOK, 2.5" ZN, TARP STRAP
3001379 1 BATTERY CABLE
CB120PB 1 CIRCUIT BREAKER
7
8
9
10
11 12 13 14 15 16
1
2
3
4 5
6
Service Parts and Accessories
PART NO. DESCRIPTION
3012431 Replacement Motor for 3006833, 3027293
3021617 Replacement Coupler for 3006833, 3027293
3021616 Rocker Switch for Controller 3014199
3020624 Remote Grease Kit
LS6 Wetting System, 30 Gal.
LS6H Wetting System, Hydraulic, 30 Gal.
