Caddytek CaddyCruiser ONE V3 User manual

One-click folding 4-wheel golf push cart
Model: CaddyCruiser ONE V3
User Manual

CaddyTek Inc.
20153 Paseo Del Prado
Walnut, CA91789, USA
Tel: [phone]
www.caddytek.com
Service/Technical support: 800-630-0968

WARNING:
FOR YOUR OWN SAFETY, PLEASE REVIEW THESE WARNINGS AND
KEEP THIS USER GUIDE FOR FUTURE REFERENCE.
●Before using this golf cart, please read and
understand the important
instructions and warnings in this user guide.
●AVOID INJURY by always following the instructions carefully.
●AVOID INJURY by keeping clear of moving parts while adjusting, folding
or unfolding this cart.
●ALWAYS make sure the cart is fully extended and locked before use.
●ALWAYS make sure the cart is folded and locked properly before lifting or
transporting.
●ALWAYS use the brake when parking the cart.
●DO NOT run while using this cart.
●DO NOT use accessories other than those designed specifically for this
cart.
●Keep hands and fingers away from moving parts or sliding sections of the
cart

Package contents:
1. The main frame of the cart
2. Two front wheels 26.6 cm (10.5 in.) and 2 rear wheels 29.2 cm (11.5 in.)
3. Umbrella holder
4. Basket (pre-installed on the cart)
5. Drink holder
6. This user manual
7. Hangtags on the handle
8. Tools for adjustment
In case any of the above items are missing or damaged, please call 909-895-6478 or email
serv[email protected]m to report.
Parts identification:
A: PVC handle grip
B: Scorecard holder assembly
C. Handle frame
D: Upper bag holder bracket assembly
E: Adjustable handle mechanism
F: Main connecting rod
G: Main frame
H: Leg bracket
I: 2 holes right leg frame
J: 4 holes leg frame
K: 2 holes left leg frame
L: Left stabilization bar
L1: Right stabilization bar
M: Footbrake assembly
N: Left rear wheel holder
N1: Right rear wheel holder
O: Holding slot for folded cart frame
P: Supporting cable
Q: Sub-connecting rods
R: Front wheel fork assembly
S: Rear wheel assembly
T: Lower bag holder bracket assembly
U: Front wheel lock mechanism
V: Front wheel assembly
W: Umbrella holder base
X: Umbrella holder
Y: Basket with cooler
Y1: Handle mesh net
Z: Drink holder
Z1: Umbrella holder storage rack
M
N1
P
L1
I
Y1
O
L
K
N
Z1
A
WC
Z
D
E
F
G
SQJ
R
V
U
T
X
B
H
Y

Extending the cart
Lift the upper bag bracket
as shown in Fig. 1.
Simply pull the handle and upper bag bracket
as shown in Fig. 2 to extend the cart. (Shake
the cart slightly to release the main frame
from the holding slot if necessary.)
Press the red bottom on the leg
frame and insert the wheels as
shown in Fig. 3 to install the
rear wheels.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Press the red bottom on the
front wheel axel and insert the
wheels as shown in Fig. 4 to
install the front wheels.
Unfolding motion
Install wheels

Folding the cart
Fig. 10
Turn the red knob as shown in
Fig. 5 to release and tighten
the handle.
Fig. 5
Fig. 7
Fig. 9
To achieve the optimal folded size, adjust the
handle to the 2nd highest location marked by the
small label near red knob as shown in Fig. 6.
Cart folding red
button
Press the red folding button and push the handle downward as
shown in Fig. 7 and Fig. 8 to fold the cart till the main frame clicks
into the holding slot as in FIG. O.
Push the upper bag bracket downward as
shown in Fig. 9. Fig. 10 shows the cart is folded.
Fig. 8
Fig. O
Fig. 6

Install umbrella holder
Use the brake Install drink holder
To put in use:
Simply attach the umbrella holder
onto the cart as in Fig. 11 & 12.
To store:
Attach the umbrella holder to the storage
rack on the right leg frame as in Fig. 13.
Press the brake pedal to
brake and push again to
release as Fig. 14.
Fig. 11
Fig. 12
Fig. 13
Fig. 14
When installing the drink holder,
align the smallest part of the slot on
the holder with the fixed blocks.
Then pull
horizontally to fit the
holder on the base.
Fig. 15
Fixed block on base notch
Slot on holder

Front wheel alignment
Bag holder strap adjustment
Refer to Figs. 19 and 20:
1. Pull the elastic strap out of the strap buckle as in Fig. 19.
2. Adjust the strap to desired length.
3. Push the elastic strap back to the strap buckle as in Fig. 20.
Fig. 16
Left Right
A
B
Fig.
17
Fig. 18
Hex wrench
Alignment adjusting screws A/B
If the cart veers to the left, please use the hex wrench to turn screwA counterclockwise and
Screw B clockwise to adjust the alignment.
If the cart veers to the right, please use the hex wrench to turn screw A clockwise and
screw B counterclockwise to adjust the alignment.
Fig. 19 Fig. 20
